Honeywell CO48PM User manual

Portable Evaporative Air Cooler
for Outdoor, Indoor & Commercial Use
OWNER’S MANUAL
Read and save these instructions before use
Model: CO48PM
Power rating: 140 Watts
Voltage rating: 120 Volt AC, 60Hz
For product inquiries or support, visit www.honeywellaircoolers.com
Made in P.R.C.Customer Support : 1-800-474-2147
OFF
COOL
ON
OFF
ON
0
3
2
1
SPEED SWING
MAX
MIN

SECTION PAGE
1. THANK YOU .........................................................................................................
2. USER TIPS ...........................................................................................................
3. SAFETY ................................................................................................................
4. PARTS DESCRIPTION .........................................................................................
5. USE & OPERATION .............................................................................................
Control Panel ....................................................................................................
Control Knobs ....................................................................................................
6. CLEANING & MAINTENANCE .............................................................................
7. TROUBLESHOOTING GUIDE .............................................................................
8. TECHNICAL SPECIFICATIONS ...........................................................................
9. ELECTRICAL WIRING DIAGRAM ........................................................................
2
3
5
8
9
9
10
Fill Water .......................................................................................................... 11
13
15
16
17
10. SERVICE AND WARRANTY ................................................................................ 18
Read all instructions carefully before setting up and operating the cooler, and
please keep this instruction manual for future reference. This manual is designed to
provide you with important information needed to setup, operate, maintain, and
troubleshoot your cooler. Failure to follow these instructions may damage and/or
impair its operation and void the warranty.
1
INDEX

2
THANK YOU
Congratulations on your purchase of this versatile Honeywell Evaporative Air Cooler. For
optimum cooling from your cooler, fill the water tank to maximum level and load ice inside
the ice compartment before you turn on your air cooler.
Cooler Location (Important - Please Read!)
Place the cooler in front of an open door or window. Ensure that there is adequate cross -
ventilation in the room by leaving a door or window open opposite the cooler.
Following these guideline will ensure your cooler will work as effectively as possible.
Not an Air Conditioner (Important - Please Read!)
The evaporative air cooler is not an air conditioner as it does not use a compressor or refrig-
erant gas. It should not be expected to cool as efficiently as a refrigerated air conditioner.

Pump
Water
Honeycomb Cooling Media
Evaporative Air Cooling Mechanism
Warm and
dry air
Cool and
humid air
Energy Efficient, No Compressor
3
USER TIPS
Honeywell Evaporative Air Coolers are built to maximize energy efficiency and keep costs low.
Warm air is drawn into the cooler and enters the Honeycomb Cooling Media. Water pumped
from the tank pours over the honeycomb media. As the warm air passes through the media,
the water absorbs the heat, naturally cooling and humidifying the air. A fan propels the cooled
air out into the room. This no-compressor system cools naturally, efficiently and inexpensively.

4
USER TIPS
NOTE (Important - Please Read!)
When the product is used for the first time the Honeycomb Cooling Media will have an odor
which will dissipate in a few hours or so of initial use.
The recommended maximum relative humidity level is 60% or
less, which allows a noticeable temperature decrease. The
temperature decrease will be greater in drier climates
because higher evaporation occurs when the humidity is low.
The evaporative air cooler should not be used in enclosed
spaces. It must be kept level and there must be water in the
water tank. The room should have doors and windows
opened to allow free air flow. The evaporative air cooler works
best when placed near an open window, so that outside air is
drawn into the evaporative air cooler, the air circulates in the
room, then exits via the door. The maximum cooling effect is
felt when a person is in the flow of air coming out of the
evaporative air cooler.
The evaporative air cooler can also be used to humidify dry
air during cool weather. To be used for humidification the
windows and doors should be closed to allow the humidified
air to accumulate.
Indoor Use
Room with open windows & door
(RECOMMENDED)
Room with closed windows & door
(NOT-RECOMMENDED)

OFF
COOL
ON
OFF
ON
0
3
2
1
SPEED SWING
MAX
MIN
120V - 60 Hz
Shock Hazard
Water Level Indicator
Your cooler runs on 120 Volt AC, 60 Hz current. Check the
household voltage to ensure it matches the appliance's rate
specification.
Before operating the product remove it from its packaging
and check that it is in good condition.
DO NOT operate any product with a damaged cord or plug.
DO NOT run power cord under carpeting, or cover it with
rugs or runners. Keep the cord away from areas where it may
be tripped over.
Always unplug the product before refilling the water tank.
Always unplug the appliance from the power source before
cleaning, servicing or relocating the unit.
Remove the power cord from the electrical receptacle by
grasping and pulling on the power cord plug-end only, never
pull the cord.
DO NOT use the product in areas where gasoline, paint or
other flammable goods and objects are stored.
When using the ''COOL'' setting, check the water tank to
ensure that it is full. Operation of this cooler on the ''COOL''
setting with an empty tank may result in damage to the water
pump.
Read And Save These Instructions:
When using electrical appliances, basic safety precautions should always be followed:
•
•
•
•
•
•
•
•
•
5
SAFETY

Water / Ice Compartment
Floor Level
•
•
•
•
•
•
•
•
•
•
•
•
•
DO NOT attempt to repair or adjust any electrical or mechan-
ical functions of the cooler, as this may void the warranty.
DO NOT cover the air inlet or outlet on the appliance as this
may cause motor damage.
DO NOT insert or allow objects to enter any ventilation or
exhaust opening as this may damage the product and could
cause an electrical shock or fire.
DO NOT operate with the Honeycomb media removed as this
will overload and damage the motor.
DO NOT leave the operating appliance unattended for any
extended period of time.
DO NOT let children play with this appliance, packaging or
plastic bags.
If the unit is damaged or if it malfunctions, do not continue to
use it. Refer to the Troubleshooting Guide (page 15) and
contact the service center.
Place the unit on a level floor.
This product is not intended for use in wet or damp locations.
DO NOT use in bathrooms. Never locate the product where
it may fall into a bathtub or other water container.
Store in a dry area when not in use.
This appliance is not intended for use by persons (including
children or elderly) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Always grip the side handles to move the cooler.
6
SAFETY

SAFETY
7
Don't use indoor extension cords outside. Look for extension cords specifically marked for
outdoor use. Look for extension cords that have a GFCI (Ground Fault Circuit Interrupter)
built in.
Make sure the amperage rating for the extension cord is higher than the amperage rating
for the appliance. Check labels and owner's manuals on the appliance and the extension
cord for amperage ratings.
Power cords have to be contained. If they must run along the ground, make sure every inch
of them is secured so they will not be tripped over.
The wiring and connections must be waterproof. Be sure the connections (to the air cooler)
never get wet. Your unit is waterproof, but everything attached to it must be waterproof, too.
Set up your unit so it cannot be tripped over or wobble loose. It must rest on a solid
support.
•
•
•
•
•

OFF
COOL
ON
OFF
ON
0
3
2
1
SPEED SWING
MAX
MIN
8
PARTS DESCRIPTION
10
1 Water Inlet and Ice
Loading Compartment
2 Handle
3 Left Honeycomb Panel
4 Lever for Horizontal Louvers
5 Water Tank
6 Casters
7 Horizontal Louvers
8 Water Level Indicator
9 Control Panel
10 Right Honeycomb Panel
11 Continuous Water Supply Connection
12 Drain Plug
13 Backside Honeycomb Panel
14 Power Cord & Plug
15 Rear Grill Removal Screws
16 Water Fill Door
1
2
9
8
3
4
5
6
7
11
16
15
12
13
14

9
Control Panel
COOL SPEED SWING
OFF ON OFF ON
03
2
1
NOTE:
Speed control may be marked as High / Med / Low in certain units.
USE & OPERATION

10
Control Knobs
Speed / On - Off
COOL
OFF ON
SWING
OFF ON
SPEED
03
2
1
Connect to the power supply and turn the Speed knob. The fan
will start. Change the speed from 1 for Low to 2 for Medium to
3 High. To switch OFF the unit turn the Speed know to "0".
Cool
To begin cooling the desired area turn the "COOL" switch ON.
The water pump will operate. You can feel the cooler air after
the Honeycomb cooling media is completely wet.
Swing
Turn the "SWING" switch ON. The louvers will begin to move
from right to left automatically. Manually adjust the horizontal
louvers to change vertical airflow.
Horizontal Louvers
Manually adjust the horizontal louvers to change vertical
airflow.
USE & OPERATION

Filling With Water
Water Inlet (Manually)
Unplug from power when refilling.
CAUTION
• To refill the water tank, pull out the Water Fill Door located
on the top of the unit (#16 on Page 8) and fill water to the
Max, as indicated on the Water Level Indicator (#8 on Page 8).
• Do not fill water above the Max water level mark.
• For maximum cooling performance, put ice cubes inside the
Ice Loading Compartment located on the top of the Air Cooler
(#1 on Page 8).
Water can be filled into the air cooler by:
Continuous water supply (Auto Refill)
Connect a garden hose to the continuous water supply inlet.
Water Inlet (Manually)
Water / Ice can be put into the tank through the top opening.
There is a hole for water to flow into the tank.
Water Inlet
Water Fill Door
Ice Loading
Compartment
USE & OPERATION
11

N
Filling With Water (Continuous Water Supply Connection)
CAUTION
Unplug from power source before filling
This automated process eliminates the need to manually refill the water tank.
Securely connect the continuous water supply connector (located on the lower left
side panel #11 on Page 8) to the water supply.
Turn on the water.
The water tank will refill automatically.
The water float valve will detect the water level and will automatically start
or stop the water flow.
Plug the unit into the power supply and turn the unit on.
Installing Hose Adapter And Float Valve
•
•
•
•
•
Connect the garden hose to the water supply connector (# 11 on Page 8)
Verify that connections are secure and turn on the water.
•
•
Hose Connectora
12
USE & OPERATION

WARNING
•
•
•
•
Before cleaning, turn the unit off and disconnect from the power source.
Use a damp cloth to remove dirt and dust from the outside of the unit.
Never use abrasive cleaners.
When the unit is not in use, store it in a dry place, out of direct sunlight.
Important - Please Read!
•
•
•
•
The cooler is supplied with Honeycomb Cooling Media.
The cleaning frequency for the Honeycomb media depends on local air and water
conditions. In areas where the mineral content of water is high, mineral deposits may build up
on the Honeycomb Cooling Media and restrict air flow. Draining the water reservoir and
refilling with fresh water at least once a week will help reduce mineral deposits. If mineral
deposits remain on the Honeycomb media, the media should be removed and washed under
fresh water. The media should be cleaned every two months or sooner, depending on your
needs.
Do not run the unit in COOL mode with stale water in the tank. Empty the tank and refill it
with fresh water if the water has been standing in the tank for an extended period of time.
For best results, allow the Honeycomb Cooling Media to dry after each use by turning off the
cool function 15 minutes before turning the unit off.
13
CLEANING & MAINTENANCE

14
CLEANING & MAINTENANCE
Water Drain
Plug
Open Screws
Cleaning The Honeycomb Cooling Media
Draning and Cleaning The Water Tank
•
•
•
•
•
•
•
•
•
•
•
•
The air cooler is now ready to be used. This cleaning process should be repeated monthly to
maintain the integrity of the unit and to remove particles filtered from the air.
Turn the power “off” and disconnect the air cooler from the power supply.
Move the unit to a location where it can be drained.
Remove the drain plug and allow the tank to empty(#12 on Page 8).
Refill the water tank up to the maximum level with clean water and drain
it completely.
Fill water tank and rinse at least 2-3 times before use.
After cleaning ensure that the drain plug is back in place.
•Plug into the power supply and turn on unit.
Turn off the unit, and unplug the power cord from wall
outlet.
Rotate the unit facing the back panel, and locate the Rear
Grill Removal Screws (#15 on Page 8). Remove the 4
screws with a screw driver.
Pull the rear grill panel, until it is completely
•This cooler has Honeycomb cooling media on the right and
left panels. The cleaning and removal procedure is the same
as rear panel.
removed.
Plug into the power supply and turn on unit.
The Honeycomb cooling media can now be seen. Clean
honeycomb with clean cloth to remove all the dust &
dirt particles.
Once cleaning is finished, reassemble the unit.

15
Customer Support: 1-800-474-2147
TROUBLESHOOTING GUIDE
No discharge of air Cord is not plugged in. Make sure power cord is
plugged in and the supply
switch is on.
Power is not on. Turn the unit ON by pressing
button on the control panel.
Not Cooling / Unit is
making noise
Pump is not turned ON. On Control Panel, turn COOL
FUNCTION to “ON”.
Low or no water in tank,
when COOL is selected.
Refill water tank.
Odors When the Cooler is new. When the unit is used for the
first time, the Honeycomb
Cooling Media will have an
odor, which will dissipate
within a few hours of initial use.
If the Cooler has been used. There may be an algae issue.
Replace the Honeycomb Cooling
Media.
Damaged Pump or Calcium
deposits on blower.
Contact service center.
PROBLEM POSSIBLE CAUSE SOLUTION

MODEL NO. CO48PM
120 V
60 Hz
140 Watts
12.6 Gallon
Honeycomb
24.40(L) X 14.76(W) X 34.17(H)
29.3 lbs
Voltage
Frequency
Wattage
Water Tank Capacity
1.83A
Ampere
Cooling Media
Product Dimension (inches)
Net Weight
16
TECHNICAL SPECIFICATIONS

17
ELECTRICAL WIRING DIAGRAM

18
SERVICE AND WARRANTY
1-YEAR LIMITED WARRANTY
Read all the instructions before attempting to use this product.
This 1 year limited warranty applies to repair or replacement product found to be defective in
material or workmanship.
At its option, JMA NORTH AMERICA LLC will repair or replace this product if it is found to be
detective in material or workmanship.
This warranty does not cover damage resulting from any unauthorized attempts to repair or
from any use not in accordance with the instruction manual.
This warranty does not apply to any damage resulting from commercial, abusive, unreasonable
use or supplemental damage. Defects that are the result of normal wear and tear will not be
considered manufacturing defects under this warranty.
JMA NORTH AMERICA LLC IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY NATURE. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION
TO THE DURATION OF THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential
damages or limitations on how long an applied warranty lasts, so the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and you
also may have other rights which vary from jurisdiction to jurisdiction. This warranty
applies only to the original purchaser of this product from the original date of purchase.
A.
B.
C.
