Honeywell MN10CCS User manual

Model:
MN10CCS / MN10CHCS
MN12CCS / MN12CHCS
MN14CCS / MN14CHCS
Series
Customer Support:
Web: www.jmatek.com
USA: 1-800-474-2147 | [email protected]
CANADA^: 1-888-209-0999 | [email protected]
^ Canada Customer Support service available for models sold in Canada only.
Portable Air Conditioner
User Manual
Read and save these instructions before use

EN
•
•
•
•
•
•
•
•
•
•
•
•
•
•
DO NOT operate the unit with a damaged plug or loose wall
outlet. If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
DO NOT cover the air intake and exhaust when in use.
DO NOT place objects on or sit on the unit.
Always turn off and unplug the unit when cleaning or
servicing.
DO NOT use the appliance if it is damaged.
If service is needed contact an authorized service agent.
Unplug the unit when stored or not in use.
DO NOT pull or carry the appliance by the power cord.
DO NOT pinch the power cord in the door and DO NOT pull
it along edges or sharp corners.
DO NOT run the power cord under carpeting and rugs.
Use caution to prevent tripping on cord.
DO NOT use the device in the following cases:
- Near a fire source
- In areas where gasoline, paint or other flammable
goods are stored
- In an area where the water can be projected
DO NOT touch the plug or the device with wet hands.
Basic safety precautions should always be followed when
using electrical appliances.
SAFETY
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS. READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE. IN CASE THERE IS ANY
INCONSISTENCY OR CONFLICT BETWEEN THE ENGLISH
VERSION AND ANY OTHER LANGUAGE VERSION OF THE
CONTENT OF THIS MATERIAL, THE ENGLISH VERSION
SHALL PREVAIL.
WARNING:

EN
SAFETY (CONTINUED)
This appliance has been manufactured for use in domestic
environments and should not be used for other purposes.
Only use the installation kit provided to install this unit.
DO NOT attempt to extend the Exhaust Hose or install
this unit using other methods other than that shown in
this manual. Improper installation will void any existing
warranties.
DO NOT use an extension cord with this unit.
This appliance can be used by children aged from 8 years
and above, and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
Never insert your fingers or rods into the air outlet. Take
special care to warn children of these dangers.
The manufacturer is not liable for injury caused to
persons or property damage due to non-compliance
with maintenance instructions and improper use of the
appliance.
The appliance shall be installed in accordance with national
wiring regulations.
The appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction.
Children should be supervised to ensure that they do not
play with the appliance.
•
•
•
•
•
•
•
•
•

1
THANK YOU
USER TIPS
Congratulations on your purchase of this Honeywell Portable Air Conditioner.
Regarding the information pertaining to the installation, handling, servicing, cleaning and disposal
of the appliance, please refer to the below paragraph of the manual.
Portable Air Conditioners are ideal for spot cooling. The compressor, condenser and evaporator are
housed in a compact unit. The air is dehumidified and cooled while a flexible Exhaust Hose sends
heat outside. The air conditioner includes a window venting kit.
No permanent installation is needed. The unit is easy to move from room to room and offers a truly
flexible air conditioning solution.
Auto Evaporation System - The unit automatically evaporates the condensate through the Exhaust
Hose. There is no need to empty the drainage tank except in humid conditions. Read and follow the
instructions carefully.
To ensure optimal efficiency of the product, keep doors and windows closed when it is used as an air
conditioner or dehumidifier. If the product is being used with the fan function only, an open window
could improve air circulation.
EN
Important:
Before installing the unit, place it UPRIGHT for 1 hour before use to allow the refrigerant to stabilize.
Manually adjust the air vent located at the top of the unit to adjust the direction of air flow.
Follow installation instructions to set up the unit.
Plug the unit into a properly grounded circuit. DO NOT plug into an extension cord.
•
•
Cooling, Heating* and Dehumidifying
Operation Fan Operation
*Applicable for models with Heating feature only.

2
PARTS DESCRIPTION
EN
6
13
12
11
8
910
1
3
2
4
5
7
1) Control Panel
(Incl. Signal Receptor)
8) Power Supply Cord
2) Air Outlet 9) Remote Control
3) Handle 10) Lower Drain Plug with Plastic Cap
(Air Conditioning Mode)
4) Casters 11) Upper Drain Plug
(De-humidifier Mode)
5) Upper Dust Filter 12) Lower Dust Filter
6) Upper Grill 13) Lower Grill
7) Exhaust Hose Connector

3EN
INSTALLATION
It is important that the installation instructions below are followed for successful installation of this
Portable Air Conditioner. Please call Customer Support if you have any difficulties or queries
regarding these installation procedures.
Installation Kit:
Installation Steps:
Exhaust Hose Connector, Exhaust Hose and window bracket panel adapter are pre-assembled
inside the package.
1.
1. Window Bracket Kit (1 Set) 4. Hole Cover (1 Piece)
2. Window Bracket Panel Adapter (1 Piece) 5. Exhaust Hose (1 Piece)
3. Exhaust Hose Connector (1 Piece)
5
1 3
x1
x1
x1 x1
2
4
x1
Hose:
Length: 12" to 47" (30 cm to 120 cm)

4
INSTALLATION (CONTINUED)
2. The Window Brackets allow you to install to windows and balcony doors of different heights or
width.
Adjustable Knobs
3. Connect the Exhaust Hose to the rear exhaust outlet on the back of the unit. Rotate clockwise to
ensure the knob mechanism is locked in place. Anticlockwise to unlock the knob mechanism.
Note: After setting the window bracket to the size of your window, please remove it from the window
and follow the instructions below.
To install the window bracket to the window frame, you need to adjust the height or width of the
window bracket by extending the length according to the height or width of the window. When the
length is set, tighten the Adjustable Knobs (preinstalled on the window bracket) to ensure the window
bracket is secured in the desired position. Use one or all three pieces of window bracket as needed.
EN
19.7" (50 cm)
1 part
19.7" (50 cm) to
38.2" (97 cm)
2 parts
47.2" (1.2 m)
3 parts

5EN
INSTALLATION (CONTINUED)
4. Connect the window bracket to the window bracket panel adapter. Slide-in the window bracket
panel adapter then rotate clockwise until it is locked in place.
5. Connect the window bracket to the window.
6. The Portable Air Conditioner is now ready to use.

6
INSTALLATION (CONTINUED)
IMPORTANT: Do not replace or lengthen the Exhaust Hose as this could cause the unit to
malfunction.
The supplied Exhaust Hose has a diameter of 5" (12.7 cm) and can be extended from
12" to 47" (30 cm to 120 cm).
Do not bend (to the extent shown below) the Exhaust Hose. A bent hose will block exhaust air and
cause the unit to malfunction or shut-off.
Make sure the back of the unit is at least 20" (50 cm) away from the wall. Do not place the unit in
front of curtains or drapes as this could obstruct the airflow.
•
•
•
WARNING: Any warranties included with this product will be voided if an extra extension hose is
added to the originally provided installation kit or if the installation is performed differently than the
manufacturer's instructions, without proper consultation. Please contact Customer Support for help
with installation procedures if needed.
NOT RECOMMENDED RECOMMENDED
20" (50 cm)
MAX. 14" (36 cm)
EN
MAX. 40" (102 cm)
MIN 35.6 cm

7
USE & OPERATION
CONTROL PANEL
FUNCTION BUTTONS
1) Power Control / Standby Mode 4) Timer / Temperature Set Controls
2) Warning Light (when flashing) 5) Fan Speed Control
3) Mode Control
EN
(6) (5) (4) (4) (3) (1),(2)
The Power Control turns the unit on and off. When the unit is plugged in, this button lights up indicating it
is in a Standby Mode ready to be switched on anytime.
POWER CONTROL
Settings: Air Conditioning, Heating*, Dehumidifying, Fan.
The corresponding indicator light will illuminate to indicate the current mode setting.
MODE CONTROL
Air Conditioning Mode
Adjust fan speed and air temperature to suit your desired comfort level.
Temperature setting range is 16°C - 32°C (61°F - 89°F).
•
*Applicable for models with Heating feature only.
STOP
Condensation may accumulate in the unit.
If the internal tank becomes full, the Power Control light will flash and the unit will not operate until
the unit has been drained (refer to Water Condensation Drainage).
After switching the air conditioner off, you must wait 3 minutes before switching it back on again.
WARNING LIGHT

8
USE & OPERATION (CONTINUED)
FUNCTION BUTTONS (CONTINUED)
EN
Fan Mode
For air circulation without air conditioner cooling.
•
Heating Mode*
This unit uses HeatPump technology which reverses the air conditioning cooling cycle by
transferring heat from the outside into the room – this is more energy efficient than traditional
electric heaters that generate heat instead of transferring heat into the room. These properties
make this heater ideal for use in autumn or spring when outdoor temperatures are not severely
cold, or as supplemental heating in colder rooms of your home.
•
*Applicable for models with Heating feature only.
Dehumidifying Mode
Air is dehumidified as it passes through the unit, without being in full cooling mode.
If room temperature is higher than 25°C (77°F) fan speed can be adjusted; otherwise fan speed is
preset to LOW.
Note: If the unit will be used mainly as a dehumidifier, do not connect the Exhaust Hose.
Continuous drainage is then necessary (refer to Continuous Draining for Dehumidifier Mode).
•
When heating mode is selected the indicator light will shine. Heating is activated only when
the ambient temperature is below 25°C (77°F). In this mode, the desired temperature can be
set between 16°C 25°C (61°F - 77°F).
Note: The Exhaust Hoses must vent outside the room when using heating mode.
IMPORTANT: The Heat pump draws moisture from the air which then condenses into the
internal water tank. The unit will pause operation when the tank is full and will restart when
the tank has been emptied. It is recommended to use the heating mode in a room with 50%
humidity or lower. Avoid operating moisture-producing products or appliances such as a
humidifier or a kettle when using the unit in heating mode.
See the “Draining Water Condensation in Heat Mode” section for more information on draining
the water tank.
IMPORTANT: The Dehumidifier mode is used to support moisture reduction but should not
be expected to dehumidify to the same degree as a standard dehumidifier-only appliance. The
built-in dehumidifier automatically adjusts dehumidification based on ambient room temperatures.
It is not possible to adjust to a desired humidity percentage. The front display only shows the
current AND desired temperatures. It does not show humidity levels.

9
USE & OPERATION (CONTINUED)
EN
FUNCTION BUTTONS (CONTINUED)
TEMPERATURE / TIMER SET CONTROLS
Used for adjusting the timer and thermostat.
The default display is setting temperature.
In cooling mode, when ▼or ▲ button is pressed, the set temperature is displayed and may be
adjusted. After 10 seconds the display will revert back to room temperature. Temperature is only
adjustable in cool mode. The time is adjustable between 1 - 24 hours.
Note: By pressing both ▼or ▲ buttons at the same time, the display will toggle between
Celsius(°C) and Fahrenheit(°F).
•
•
•
While the unit is turned on, press the timer button then press the ▼or ▲ to select the number of
hours you would like the unit to continue to run. The unit will turn off automatically.
AUTO TURN OFF:
While unit is running, press the ▼or ▲ button to select the number of hours you want the unit to run
in air conditioning mode.
AUTO TURN ON:
When unit is in a standby mode (plugged in with power light on), then press the ▼ or ▲ button to
select the number of hours until you want the unit to automatically start running.
TIMER CONTROL
3 Settings: High, Medium and Low.
FAN SPEED CONTROL

10EN
USE & OPERATION (CONTINUED)
REMOTE CONTROL
The functions work the same as the Portable Air Conditioner's Control Panel.
All key functions can be accessed from the remote control.
Note:
Battery Installation: Remove the cover on the back of the remote control and insert two AAA
batteries with + and - pointing in the proper direction according to the polarity markings.
•
Use only two AAA or IEC R03 1.5V batteries.
Remove the batteries if the remote control is not in use for a month or longer.
All batteries should be replaced at the same time, do not mix with old batteries.
Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium) batteries.
Properly dispose of used batteries.
•
•
•
•
•
Caution:
Power Control
ON / OFF
Temperature / Timer Set
Used for adjusting the timer and
temperature.
When the ▼or ▲ key is pressed, the
set temperature is displayed and
may be adjusted
Timer setting is available from 1 - 24 hours
by pressing the key ▼or ▲.
•
•
•
Mode Control
Timer Control
In running mode: Auto switch off
In stand-by mode: Auto switch on
Press ▼or ▲button to adjust the
time setting for 1 hour intervals.
Air Conditioning Dehumidifying
Heating*Fan
Press this button to change the operation
mode in the order of:
Fan Speed Control
• HIGH • MID • LOW
*Applicable for models with Heating feature only.
This device complies with part 15 of the FCC Rules. Operation is subject to following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment dose cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment info an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.

11
CLEANING & MAINTENANCE
Appliance Maintenance:
Turn off the appliance before disconnecting the power supply.
Only clean the appliance with a soft dry cloth.
1.
2.
End of Season Storage & Maintenance:
If the appliance will not be used for a long time, follow these steps:
Be sure to drain the left-over water condensation. Remove the lower drain plug and use a
shallow pan to collect the water (make sure to replace the drain plug when finished).
To dry excess moisture, run the unit in Fan only mode for 30 minutes before storing.
Turn off and unplug the air conditioner from the power supply.
Remove the dust filter and clean with water. Dry the dust filter and then reinstall.
1.
2.
3.
4.
EN
WARNING: DO NOT power or operate the Air Conditioner when cleaning or when the Dust Filter is
removed from the unit, or if there is a loose-fitting Dust Filter. DO NOT attempt to handle or touch
any of the parts or wiring inside the Rear Grill after the Dust Filter has been removed from the unit.
Doing so can cause serious injury or electrical shock.
Switch off and unplug the air conditioner from
the electrical outlet.
Remove the Upper Dust Filter and the Lower Dust Filter.
Gently wash using water and/ or diluted liquid dishwashing
detergent.
Rinse thoroughly and gently shake excess water from
the filters. Make sure the filters are dry before reinstalling.
Note: You may use a vacuum cleaner to remove dust.
Replace the Upper Grill and the Lower Grill onto the unit.
1.
2.
3.
4.
Dust Filter Maintenance:
The dust filter is to be cleaned every two weeks to maintain
air cooling efficiency. Please follow the below instructions for
cleaning the dust filter:
Rear Grill
Upper
Dust Filter

12
Cover the air conditioner with a cloth/ plastic bag before storage, to protect from dust and
scratches collecting on the surface of the unit.
It is recommended to coil the power cord before storing to ensure the cord is protected from
bents and creases.
Store the air conditioner in a cool, dry place, away from direct sunlight.
6.
7.
8.
Remove the Exhaust Hose from the unit by rotating anti-clockwise to unlock the knob
mechanism then sliding out.
Remove the window bracket panel adapter from the window bracket by rotating anti-clockwise
then pulling away.
It is recommended to store the Window Kit parts in a bag together with the Remote Control
and placing them together with the air conditioner unit.
If needed, you can clean the Window Kit with a damp cloth and water before storing.
Make sure all parts of the Window Kit are dry before storage.
•
•
•
•
CLEANING & MAINTENANCE (CONTINUED)
Disconnecting the Window Installation Kit:5.
EN

13EN
*Applicable for models with Heating feature only.
WATER CONDENSATION DRAINAGE
Plastic Cap
and Lower
Drain Plug
Shallow Pan
(Not included)
Unplug the unit from power source.
Place a shallow pan under the lower rubber drain plug.
See diagram.
Remove the lower rubber drain plug.
Water will drain out and collect in the shallow pan.
After the water is drained, replace the lower rubber
drain plug firmly.
You can now turn on the unit.
1.
2.
3.
4.
5.
6.
Manual Draining in Cooling, Dehumidifying and Heating* Modes
Water may need to be drained in high humidity areas.
If you find that there is a high volume of condensation and a shallow pan is not enough for your use,
you can use a large pan to drain. Follow the below instructions carefully:
WARNING: For safety reasons, the Portable Air Conditioner must NOT be positioned on a base that is
higher than 1" from the floor. This is only recommended if you have a stable, flat base to position the
Portable Air Conditioner on safely.
Find a flat, stable board that is up to 1" thick. The base
could be a wooden board purchased from your local
hardware store, with a minimum base dimension of 20"
(length) x 17" (width) x 1" (thick).
The base should be large and sturdy enough to fit the
Portable Air Conditioner on top. The air conditioner must
be stable and not rock or move when positioned on this
base and not easy to topple over.
Drain the water from the lower drain plug as needed,
into a larger pan or through a drain tube. If using a drain
tube, you can purchase vinyl tubing which has an outside
diameter of 5/8" and an inside diameter of ½".
Remember the drain tube must be positioned lower than
the drain plug so the water condensation does not
flow backwards back into the air conditioner.
1.
2.
3.
Wooden Board
Height: up to 1"
Large Pan
(Not included)
Plastic Cap
and Lower
Drain Plug
When there is excess water condensation inside the unit, the air conditioner stops running and
shows a warning light (the Power Control button flashes with a red light). This warning light indicates
that the water condensation needs to be drained using the following procedures:

14EN
WATER CONDENSATION DRAINAGE (CONTINUED)
EN
*Applicable for models with Heating feature only.
Unplug the unit from power source.
Remove the upper rubber drain plug.
Some residual water may spill so please have a pan to
collect the water. See diagram.
Connect the drain connector to a ¾" hose or standard
garden hose (not included).
The water can be continuously drained through the
drain tube into a floor drain or bucket.
Replace the drain plug.
You can now turn on the unit.
1.
2.
3.
4.
5.
6.
Continuous Draining for Dehumidifier Mode
Drain Tube
Upper Rubber
Drain Plug
While using the unit in dehumidifier mode, continuous
drainage is recommended.
IMPORTANT: The water cannot be drained using the continuous drain option in heating* mode.
In Heating mode, the internal water tank collects condensation faster and may require more
frequent emptying of the tank in more humid rooms. It is recommended to use the heating mode in a
room with 50 % humidity or lower. Avoid operating moisture-creating products or appliances such as
a humidifier or a kettle when using the unit in heating mode.
IMPORTANT: It is NOT recommended to connect the drain hose for continuous drainage while the
unit is switched ON in air conditioning cooling mode. Doing so can reduce the cooling efficiency
of the Portable Air Conditioner. Only drain the water condensation when the unit is switched off.
Continuous drainage is only suitable when the unit is set up in Dehumidifier mode.

15
The following troubleshooting guide addresses the most common problems. If problems persist, call
customer support. Unplug and disconnect the appliance from the power source before attempting
to troubleshoot.
TROUBLESHOOTING GUIDE
EN
PROBLEM POSSIBLE CAUSE SOLUTION
The air
conditioning
unit does not
start
No electricity. Check for power.
Batteries in the remote
control need to be
replaced.
Change remote control batteries.
The power cord is not
properly plugged in. Remove and reconnect the power cord.
The safety LCDI plug has
tripped (USA / Canada /
Mexico only).
Reset the safety LCDI plug, if problem
persists contact our customer support
(USA / Canada / Mexico only).
Runs a short
while only
The thermostat
temperature setting
is too close to room
temperature.
Lower the set temperature.
Air outlet is blocked. Make sure the Exhaust Hose is properly connected.
There are tight bends in
the air Exhaust Hose. Connect Exhaust Hose as per instructions on page 3.
In Heating
Mode*,the unit
keeps switching
off frequently
The room is too humid.
Water Tank needs to be
emptied.
In heating mode, the heat pump condenses moisture
from the air into the internal water tank. In more
humid rooms, it will collect faster and need to be
emptied out more frequently. It is recommended to
use the heating mode in 50% humidity or less.
Switch off any appliances such as a humidifier or
kettle to avoid extra moisture build up in the room
when operating in heating mode.
*Applicable for models with Heating feature only.

16
TROUBLESHOOTING GUIDE (CONTINUED)
PROBLEM POSSIBLE CAUSE SOLUTION
Runs but not
cooling
A door or window is open. Make sure the window or door is closed.
The dust filter is dirty. Clean the dust filter.
The Exhaust Hose is
detached.
Reinstall Exhaust Hose properly
(refer to Installation section).
Temperature setting is
too high. Reduce temperature setting on control panel.
Air outlet or intake is
blocked. Remove blockage.
Room exceeds
recommended size. Move unit to smaller room.
Large size or number of
windows are decreasing
cooling effectiveness.
Cover windows with curtains or blinds.
Will not run and
Power button
is blinking
(water full
indicator)
Excess water
condensation inside
the tank.
Drain the water (refer to Water Condensation
Drainage).
EN

17EN
TROUBLESHOOTING GUIDE (CONTINUED)
PROBLEM POSSIBLE CAUSE SOLUTION
Heater* is not
switching ON.
Heating function not
activated yet.
The ambient temperature
is too high.
Check that the Heating function has been activated.
will be illuminated when the
Heater is switched ON.
Heating is activated
only when the ambient
temperature is below
25°C (77°F).
Switch on the Heating function when the ambient
temperature reaches below 25°C (77°F).
EN
*Applicable for models with Heating feature only.
