Honeywell DCS19W User manual

MS2420
Bar Code Scanner / Avery Scale
Installation and User’s Guide

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information
contained in this document without prior notice, and the reader should in all cases consult HII to determine
whether any such changes have been made. The information in this publication does not represent a
commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein: nor for incidental or
consequential damages resulting from the furnishing, performance, or use of this manual.
This document contains propriety information that is protected by copyright. All rights reserved. No part of this
document may be photocopied, reproduced, or translated into another language without the prior written
consent of HII.
© 2009 - 2012 Honeywell International Inc. All rights reserved.
Web Address:
Trademarks
www.honeywellaidc.com
Stratos, MetroSet, and MetroSelect are a trademarks or registered trademarks of Metrologic Instruments, Inc.
in the United States and/or other countries.
Microsoft, Windows, and Windows 95 are trademarks or registered trademarks of Microsoft Corporation.
IBM is a trademark of International Business Machines Corporation.
Other product names mentioned in this manual may be trademarks or registered trademarks of their respective
companies and are the property of their respective owners.
Patents
For patent information, please refer to www.honeywellaidc.com/Patents.

iii
Table of Contents
Introduction
Manual Scope.............................................................................................................................................. 1
Product Overview ........................................................................................................................................ 1
Base Kit Components .................................................................................................................................. 2
Optional Accessories ................................................................................................................................... 2
Replacement Parts ...................................................................................................................................... 4
General Precautions .................................................................................................................................... 5
MS2420 Scanner/Avery Scale Design Specifications
Operational ..................................................................................................................................................7
Mechanical ..................................................................................................................................................7
Scale Capacities.......................................................................................................................................... 8
Electrical......................................................................................................................................................8
Environmental.............................................................................................................................................. 8
Base Model Characteristics
Components ................................................................................................................................................ 9
Dimensions................................................................................................................................................ 11
Connector Panel........................................................................................................................................ 11
Caution and Serial Number Labels ............................................................................................................ 12
Installation
Quick Installation Outline ........................................................................................................................... 13
Site Requirements ..................................................................................................................................... 13
Vertical Clearance................................................................................................................................ 13
Ventilation and Spacing ....................................................................................................................... 13
Service Access .................................................................................................................................... 14
Power Installation................................................................................................................................. 14
Checkout Counter Layout Consideration.............................................................................................. 14
Unpacking the Unit .................................................................................................................................... 15
MS2420 Package Warning ........................................................................................................................ 16
Installing the Unit in the Counter ................................................................................................................ 16
MS2420 Mounting Diagram ....................................................................................................................... 17
Cable Installation (Interface Specific)......................................................................................................... 18
RS232.................................................................................................................................................. 18
Full Speed USB ................................................................................................................................... 20
IBM OEM ....................................................................................................................................... 21
Serial Emulation Mode ................................................................................................................... 21
Keyboard Emulation Mode ............................................................................................................. 21
RS485.................................................................................................................................................. 23
Cable Installation (Secondary Scanner)..................................................................................................... 25
EAS Deactivation....................................................................................................................................... 27
Scanner Operation
Scan Zone ................................................................................................................................................. 29
Wake Activation Area (Photocell LED Output) ........................................................................................... 31
Changing the Wake Area Sensitivity Level................................................................................................. 32
Audible Indicators ...................................................................................................................................... 33
Visual Indicators ........................................................................................................................................ 34
Failure Modes............................................................................................................................................ 35
Diagnostic Indicator Display; Error Codes.................................................................................................. 36
Power Save Modes.................................................................................................................................... 39
Beeper Options and Button Functions ....................................................................................................... 40
Beeper Tone and Volume Control........................................................................................................ 40
The Multi-Function Button .................................................................................................................... 41

iv
Startup....................................................................................................................................................... 42
Power-Up Test Mode................................................................................................................................. 42
Configuration Mode ................................................................................................................................... 42
Scale Operation
Scale Zeroing ............................................................................................................................................ 43
Calibration ................................................................................................................................................. 44
Tools Required..................................................................................................................................... 44
Scale Calibration Methods ................................................................................................................... 44
Priming the Scale for Calibration (lbs. & kg) ......................................................................................... 45
Scale Calibration Procedure (lbs. & kg) with Remote Display............................................................... 46
Bar Code Calibration Procedure without Remote Display .................................................................... 50
Calibration Verification............................................................................................................................... 54
U.S. Pounds (lbs.)................................................................................................................................ 54
Kilograms (kg)...................................................................................................................................... 55
Security Seal Installation............................................................................................................................ 56
Pressure Sensitive Security Seal ......................................................................................................... 56
Wire Security Seal (Conversion Kit 46-00239) ..................................................................................... 57
Maintenance
Horizontal Scan Window Replacement ...................................................................................................... 59
Daily Maintenance ..................................................................................................................................... 60
Troubleshooting
Troubleshooting Symptom / Solution Chart................................................................................................ 61
Scanner and Cable Terminations
Scanner Pinout Connections...................................................................................................................... 65
Scanner Scale Pinout Connections............................................................................................................ 66
Cable Connector Configurations ................................................................................................................ 67
Regulatory Compliance
Safety ........................................................................................................................................................ 69
EMC .......................................................................................................................................................... 70
Weights & Measures.................................................................................................................................. 71
Limited Warranty ........................................................................................................................................... 73
Index............................................................................................................................................................... 75
Customer Support ......................................................................................................................................... 77
Technical Assistance ................................................................................................................................. 77
Product Service and Repair ....................................................................................................................... 77

1
Introduction
Manual Scope
This guide provides an overview of the MS2420 bar code scanner/Avery scale operation with detailed
information about setup and installation. Adobe®Acrobat®
Product Overview
versions of the user's manuals are also available for
download from www.honeywellaidc.com.
Honeywell’s MS2420 scanner/Avery scale is designed to meet the demanding needs of high volume
supermarket and point-of-sale applications. With advanced features like 5-sided, 360° scanning, 5400 scans
per second, a complex scan zone and advanced decoding software, this high performance series of in-counter
scanner/scale products guarantees fast customer checkouts with minimal operator fatigue and stress. The
MS2420 scanner/Avery scale is equipped with a multitude of standard features including:
StratosSCAN – 5-sided, 360° scanning that minimizes product orientation
StratosSPHERE – Decoding software that reads poor quality and damaged bar codes
StratosSYNC – Horizontal and vertical scanning zones operate independently from one another
GS1 DataBar Decoding – Decodes GS1 DataBar, GS1 DataBar Limited and GS1 DataBar Expanded
symbologies
Flash ROM – Upgrade latest software enhancements on site.
Powered Aux Port – Connect hand-held scanner for large or bulky items
Integrated Scale – Factory integrated field upgradeable Avery scale
Loud Speaker – 3 volume/7 tone settings can be heard in all environments
Easy Configuration – Windows®
Fully Automatic – “No touch” photo-sensor wake up from power save modes
based utility or simple bar code setup
EAS Deactivation – Electronic Article Surveillance (EAS) included
Field Replaceable Vertical Window – Quickly remove vertical window for cleaning or replacement
StratosSCOPE – Visual diagnostic indicator for easy-to read feedback on scanner condition
StratosSWAP – Modular optics engine technology – small, pre-aligned, field replaceable modules
StratosSCHOOL – Operator training software

2
Base Kit Components
Part #
Description
MS2420-105Az MS2420 Scanner/Avery Scale
z D Diamonex Horizontal Window
S Sapphire Horizontal Window
00-02407 MetroSelect™
00-02034
Configuration Guide
MS2xxx Stratos™
00-05312
Series Configuration Addendum
MS2420 Scanner/Avery Scale Installation and User’s Guide
Guides also available for download at www.honeywellaidc.com.
Other items may be ordered for the specific protocol being used. To order additional items, contact the
dealer, distributor or Customer Service Department.
Optional Accessories
Part # Description
57-57210x-N-3 RS232 Interface Cable, Straight Cord with Short Strain Relief
57-57212x-N-3 RS485
57-57201x-N-3
Port 9 Cable, Straight Cord
USB Full Speed Communication Cable, Straight Cord, Type A (Non-Locking)
Connector
57-57227x-N-3 USB Full Speed Communication Cable, Straight Cord,
Locking 12V Plus-Power™ Type A
57-57000x-N-3 Dual Interface Cable, Straight Cord with Short Strain Relief
57-57008x-N-3 Aux Program Cable, Straight Cord with Short Strain Relief
57-57099x-3 LSO RS232 PowerLink AUX Cable with built in Power Jack,
Straight Cord with Short Strain Relief
57-57099x-3-12 RS232 AUX, Straight Cord, 3.7 m (12') (for 95xx, 5145 and 7580 scanners)
CBL-420-300-C00 RS232 AUX, Coiled Cord (for 1200, 1300 and 1900 Series scanners)
52-52511x EAS cable, 24"
52-52556x EAS cable, 6'
AC to DC Power Transformer - Regulated
Output: +5.2V @ 4A, +12V @ 1.5A
70-74868 120V United States and Canada
70-74882 220V – 240V Continental European
70-74880 220V – 240V United Kingdom
70-74884 220V – 240V China
70-74886 220V – 240V Australia
70-74888 220V – 240V India
46-00239 Wire Seal Conversion Kit
Applicable for IBM®Host applications.

3
Optional Accessories
Part # Description
Optional Remote Scale Display
46-00248 Remote Scale Display (lb.)
46-00249 Remote Scale Display (kg)
Figure 1. Optional Remote Scale Display Dimensions
Figure 2. Optional Remote Scale Display Controls (46-00248 lb, 46-00249 kg)
Specifications are subject to change without notice.

4
Replacement Parts
Part # Description
Caution
Window types (Diamonex and Sapphire) are not interchangeable due to laser safety and/or
scanner performance differences.
To change window type, the scanner must be returned to the manufacturer for reconfiguration.
46-00232 Vertical Window
46-00233 Diamonex Platter - Full Size
46-00296 Diamonex Platter - Full Size, with Product Weight Roll Bar / Platter Lift Handle
46-00235 Sapphire Platter - Full Size
46-00297 Sapphire Platter - Full Size, with Product Weight Roll Bar / Platter Lift Handle
Other items may be ordered for the specific protocol being used. To order additional items, contact the
dealer, distributor or Customer Service Department.

5
General Precautions
The following are some general precautions to remember when handling the MS2420 scanner/Avery scale.
Do Not Turn the unit upside down with the platter in place.
Do Not Press on the window in the replacement
platter or the vertical window frame.
Platter Removal
No hardware or tools are required to remove
the platter (see Figure 5). Refer to the
Maintenance section of this manual for
additional information on platter replacement.
Note: See caution statement on page 4.
Finger Recesses
Rest both thumbs against the vertical window
frame for added stability when lifting the unit by
the finger recesses.
Figure 6.
Figure 4.
Figure 3.
Figure 5.

6

7
MS2420 Scanner/Avery Scale Design Specifications
Operational
Light Source: VLD 650 nm
Peak Laser Power: <1.5 mW
Embedded Laser: Max Optical Power: 10 mW
Wavelength: 650 nm
Horizontal Depth of
Field:
0 mm - 100 mm (0"- 4") for 0.33 mm (13 mil) Bar Code
Vertical Depth of
Field:
0 mm - 216 mm (0"- 8.5") for 0.33 mm (13 mil) Bar Code
Scan Speed: 5400 Scan Lines per Second
No. of Scan Lines: 56 (40 Horizontal / 16 Vertical)
Motor Speed: 6000 / 6000 RPM (Horizontal / Vertical )
Min Bar Width: 0.114 mm (4.5 mil)
Scan Zone: 360°
Decode Capability: All Standard 1-D Bar Codes, GS1 DataBar, GS1 DataBar Expanded, and
GS1 DataBar Limited Bar Codes
System Interfaces: RS232, Aux RS232, RS48, and USB
Print Contrast: 35% Minimum Reflectance Difference
No. Characters Read: Up to 80 data characters. Maximum number will vary based on symbology and
density.
Beeper Operation: 7 Tones or No Beep; 3 Volume Settings
Indicators (LED)
Blue Laser ON, Ready to Scan
Blue Flash Good Read, Decoding
Amber Scale at Zero
Mechanical
MS2420 L x W x H: 399 mm (15.7") [L] 292 mm (11.5") [W] 130 mm (5.12") [Tower Height]
Depth (Below
Counter):
100 mm (3.9")
Weight (with Platter): 9.97 kg (22 lbs.)
Specifications are subject to change without notice.

8
Scale Capacities
Capacity: kg unit 15 kg lb. unit 30.0 lb.
Minimum Increment: kg unit 0.005 kg lb. unit 0.01 lb.
Maximum Static
Weight:
kg unit 75 kg lb. unit 150 lb.
Adjustments
required:
Calibration is required for scaled units.
Electrical
Voltage Supply: 4A @ +5V / 0.8A @ +12V
Operating Power: 11.2 Watts
Standby Power: 4.0 Watts
Operating Current: 1.7A @ 5.2V / 0.2A @ 12V
Standby Current: 0.6 A @ 5.2V / 0.07A @ 12V
DC Transformers: Class I; 5.2VDC @ 4A; 12VDC @ 1.5A
For Regulatory Compliance Information, refer to pages 69 - 71.
Environmental
Operating
Temperature:
0°C to 40°C (32°F to 104°F)
IP Rating: IP 55
Light Levels: 4842 Lux (450 footcandles)
Storage
Temperature:
-40°C to 60°C (-40°F to 140°F)
Humidity: 5% to 95% Relative Humidity, Non-Condensing
Contaminants: Sealed to resist airborne particulate contaminants.
Ventilation: None Required
Specifications are subject to change without notice.

9
Base Model Characteristics
Components
Figure 7. MS2420 Components

10
Components
Item
No. Description of Item in Figure 7
1 Scale Zero Button (see page 43)
2 Amber LED, Scale Zero Indicator (see page 43)
3 Volume/Tone Multi-Function Button (see page 41)
4 Blue LED Indicators (see page 34)
5 Photocell Window
6 Speaker
7 High Impact Window Frame/Vertical Window (Laser Aperture)
8 Finger Recesses for Lifting (Located Under Platter)
9 Replaceable Stainless Steel Platter with Diamonex or Sapphire Horizontal Window
(Laser Aperture)
10 Flow Direction Indicator
11
Sealed Calibration Switch/Button Cover (Located Under Platter)
On a fully installed unit, the calibration switch cover should be sealed with a lead wire or paper
seal. This seal indicates the appropriate Federal, State and Local Weights and Measures
authorities have calibrated the scale. See the Scale Operation: Calibration section of this guide for
further information.
12 Product Weight Roll Bar / Platter Lift Handle
13 Leveling Bubble for Scale Arms (Located Under Platter)
14 Diagnostic Indicator Display (see page 36 for Error Codes)
15 Power and Scale Connectors (see page 11)
16 Leveling Feet
17 Interface, Aux Scanner and EAS Connectors (see page 11)
Note: Scanner/Scale label information can be found on page 12.

11
Dimensions
Figure 8. MS2420 Dimensions
Connector Panel
Figure 9. MS2420 Connector Panel
Specifications are subject to change without notice.

12
Caution and Serial Number Labels
Figure 10. MS2420 Label Locations (Top) and Examples (Bottom)
Caution: To maintain compliance with applicable standards, all circuits connected to the imager must
meet the requirements for SELV (Safety Extra Low Voltage) according to EN/IEC 60950-1.
To maintain compliance with standard CSA C22.2 No. 60950-1/UL 60950-1 and norm
EN/IEC 60950-1, the power source should meet applicable performance requirements for a
limited power source.

13
Installation
Quick Installation Outline
The following is a quick preview of the steps required for first time installations. Each item is discussed in
detail later in this section.
Determine clearance, ventilation and service access requirements.
Determine checkout counter layout taking into account package flow, cable routing and power
requirements.
Choose the mounting option which provides the best cable/power access and unit stability.
Unpack the unit.
Make the appropriate countertop cutouts and install all support brackets.
Place the unit in the counter.
Install the platter.
Follow the steps under the correct interface to connect the cables and power supply.
Configure the unit for the correct interface.
Calibrate the scale.
Site Requirements
Before installing the MS2420 scanner/Avery scale, please consider the following items.
Vertical Clearance
A minimum clearance height of 5.25" from the checkout counter surface is needed for the vertical 'hood' on all
of the scanner models.
Ventilation and Spacing
All MS2420 models have a die-cast housing to dissipate heat allowing the unit to operate without a ventilation
fan. The temperature surrounding the unit is recommended not exceed 40°C (104°F). There should be
adequate convection and minimal heat producing equipment in close proximity of the unit. A cooling fan with a
filter is recommended if there will be a conveyor motor or other heat producing equipment close to the unit that
will create a high temperature environment.
Adequate spacing between the unit and the checkout counter opening is required for proper operation of the
scale. When the scanner/scale model is mounted properly, the scale platter should be able to move up and
down freely without hitting the edges of the checkout counter cutout. Refer to Installing the Unit in the Counter
for detailed cutout dimensions and mounting instructions.

14
Service Access
When routing and installing the cable(s) and power supply, make sure to leave access that these components
may be swapped easily without the need to remove the unit from the checkout counter.
When changing the StratosSWAP optics engine modules, removing the unit completely from the checkout
counter is recommended.
When calibrating or zeroing the scale, do not remove the unit from the checkout counter. Refer to the Scale
Operation Section of this guide for detailed instructions on zeroing and calibration.
Power Installation
The Power Supply (AC/DC) should be connected to an AC outlet that is free of electrical noise (clean). A
qualified electrician can determine the amount of electrical noise on the AC line. See additional information on
power installation and restrictions under the Installation: Interface section of this manual.
Note: Using a switched AC outlet is recommended. The switch should be located on the operator’s side of
the checkout counter in close proximity to the MS2420 scanner to facilitate calibration and service of
the unit.
Checkout Counter Layout Considerations
When placing a scanner in a checkout counter, the following factors should be considered.
Items should flow at a distance to the operator that maximizes comfort. The operator should not need
to stretch or strain to reach for and scan packages.
The MS2420 can scan a bar code on five sides of a package. The packages should flow into the scan
area that provides the maximum reading performance. No lifting or orientation of the items is
necessary. A properly placed item diverter can maximize the flow of packages.
In what direction are the packages flowing? Most checkout counters are designed for left-handed
takeaway. If the operator is facing the vertical window of the scanner, packages flow from the
operator's right to left. The packages are in queue on the conveyor to the right and the bagging is to
the left.

15
Unpacking the Unit
1. Make sure the shipping box is topside up before opening.
2. Remove the accessories box and check the box’s content
for the following items.
Product Manuals
Power Supply
Communication Cables
Remote Scale Display (Optional)
3. Carefully remove the platter and store it in a safe location
until the unit is properly installed into the checkout counter.
4. Lift the MS2420 scanner out of the box by carefully
grasping both sides near the center of the unit and lifting
directly up. Refer to Figure 12 for hand placement.
Important! Do not remove the MS2420 scanner from the
box by grabbing the shipping foam. This can
result in the unit falling!
5. Carefully remove the shipping foam from around the
MS2420 scanner.
Figure 11
Figure 12
Figure 13

16
MS2420 Package Warning
All hardware securing the scale arms during shipping must be removed or the scale will not function!
Figure 14.
* Do not discard instructions and shipping hardware!
These items must be reinstalled if the unit is going to be shipped.
Installing the Unit in the Counter
Before starting to mount the MS2420 determine:
the scanner's orientation in reference to the operator and the direction of package flow,
the mounting method that provides the most stability for the scanner and
if any additional materials or tools are required for installation.
