Honeywell NOTIFIER INSPIRE E10 User manual

INSPIRE E10/E15
Fire Alarm Control panels
Operating Instructions

2
CONTENTS
Conventions 3
Abbreviations 3
Introduction 4
Display and controls 4
Touch screen display 4
Panel Buzzer 4
LED indicators and PUSH Button Controls 5
Touch Screen buttons, icons and symbols 6
License not found 11
If your INSPIRE panel displays a
message then get in
touch with your servicing organisation. A panel without
a license runs a risk of fire alarm system functionality
being compromised. 11
Normal SAFE Condition 12
Password entry to Controls 15
Change Access Level 2 Password 16
Fire Condition 17
What Do I need to do? 17
Evacuate Button 18
Viewing Multiple Fire Events 18
Enable / Disable Zones 20
Enable / Disable Devices by Detection Zone 21
Enable / Disable Devices on a Loop 22
Fault Warnings condition 23
Disablement condition 24
Technical Alarms 25
Test System 26
Viewing the Event Logs 28
Time and date settings 29
Language And Country Settings 30
Day/Night MODE Settings 31
System Information 32
Log In and Out 34
Update 35
Buzzer Settings 35
Enable Commissioning Mode 35

3
INSPIRE E10/E15 Control Panels - Operating instructions
CONVENTIONS
Where appropriate, in this manual there are advisory
notes, warnings and cautions to remind you to consider
safety at all times.
This symbol precedes a note that
highlight important information that is
normally hidden in the main text.
This symbol precedes information
that warns of danger that may result
in serious injury or death, also used
as a caution to prevent damage to
the equipment.
This symbol precedes information
about compliance with standard(s).
ABBREVIATIONS
CIE Control and Indicating Equipment
CPU Central Processing Unit
E10 Smaller size Notifier panel
E15 Larger size Notifier panel
FARE Fire Alarm Routing Equipment
FRE Fault Routing Equipment
FPE Fire Protection Equipment
HMI HumanMachine Interface
LED Light emitting diode (light)
MCP Manual call point

4
INTRODUCTION
The purpose of this manual is to explain how to use the
INSPIRE E10/E15 Fire Alarm Control panel’s - Control
and Indicating Equipment CIE (hereafter also referred
to as the ‘panel’ or ‘control panel’). It documents how
to use the built-in touch screen and push button
controls to access various functions and/or carry out
regular mandatory procedures required by the local
fire industry regulations. Helpful descriptions and tips
are also provided to assist the user in understanding
the status information provided by the Control Panel’s
touch screen and light indicators. The INSPIRE
E10/E15 Control Panels are designed to meet the
requirements of EN 542 and EN 544.
DISPLAY AND CONTROLS
The control panel's touch screen display and LED
indications allow the user to review the system status
and with appropriate user PIN access perform tasks
in accordance with the requirements of the local fire
regulations.
TOUCH SCREEN DISPLAY
The panel’s user interface is a large 10” colour touch
screen display (1280 × 800 pixels) for primary system
status, indication and control.
PANEL BUZZER
This internal panel buzzer provides an audible alert to
the authorised user to take immediate action whenever
the system detects any condition, such as a fire or fault
event. It provides a continuous or intermittent sound
depending on the type of event.
The SILENCE BUZZER control button is used to silence
(mute) the internal buzzer after it starts sounding
following a Fire/Fault event. This control is available at
all access levels without a need for user password.

5
INSPIRE E10/E15 Control Panels - Operating instructions
LED INDICATORS AND PUSH BUTTON CONTROLS
There are 7 status LED indicators provided on the panel fascia and there are 3 push buttons for event conditions.
Condition /
Control
LED
Colour
Description FIRE
FAULTFAULT
SYSTEM FAULT
DISABLE
DELAY ACTIVE
POWER
SILENCE-RESOUND
MUTE BUZZER
RESET
TEST
FIRE Red A fire condition has been detected.
FAULT Yellow There is a fault in the system.
SYSTEM FAULT Yellow The system software or parts of it has failed
and/or the site specific data is corrupt.
DISABLE Yellow One or more device / zone are disabled.
TEST Yellow A system test is in progress.
DELAY ACTIVE Yellow One or more sounder / output delay is
configured in the Cause & Effect matrix.
POWER Green The system is switched On and the power is
supplied via the mains voltage.
The essential controls are the push buttons and touch screen buttons, when lit
they are active for selection by the authorised users having password access to the
controls The buttons are made active during event conditions, such as after fire
detection or when a fault has occurred in the system.
SILENCE/
RESOUND
White Silence or Resound the alarms sounders and
outputs in the system.
MUTE BUZZER White Silence the panel buzzer.
RESET White Reset the panel after a fire condition.

6
TOUCH SCREEN BUTTONS, ICONS AND SYMBOLS
Essentil nd Emergenc Controls Description
or
Reset
Pressing the ‘RESET’ touch screen button or the push
button it will reset the panel to return it to normal
condition after an event.
or
Silence/Resound
Pressing the ‘Silence/Resound’ touch screen or the
panel push button will silence all Alarm sounders.
or
Silence/Resound
Pressing the ‘Silence/Resound’ touch screen or the
panel push button will resound, activate, previously
silenced Alarm sounders.
or
Mute Buzzer
Pressing the ‘Mute Buzzer’ touch screen button or the
panels push button will silence the active panel buzzer.
UK
The touch screen 'Evacuate' button is not
VdS approved. Normally hidden, this button
is configured to appear on the panel to meet
site needs where required, such as in the UK.
Pressing the touch screen 'Evacuate’ button it will start
all the Alarm Sounders in the system.
Pressing the 'Silence Alarms' button it will silence all
the Alarm Sounders in the system.

7
INSPIRE E10/E15 Control Panels - Operating instructions
Event Smbols Description
This indication shows there are a few active Fire events. In this example the number
signifies there are 4 active Zone Fires. By selecting this icon you can view active Zones in
fire.
This indication shows there are active Fault events. In this example the number signifies
there are 12 active Faults. By selecting this icon you can view active Faults.
This symbol show there are active Disablement events. In this example the number
signifies there are 51 active Disablements. By selecting this icon you can view active
Disablements.
This symbol shows there are currently no active Zone in Test in the system.
When there are Zones in Test then a number is displayed. In this example there are no
zones in test. By selecting this icon and if there were active Zones in Test then you could
view those zones in test mode.

8
Alarm Devices
status
Description
This ‘Activated’ indication is given when Alarm Devices in the system are activated.
This ‘Fault’ indication is given when Alarm Devices in the system are faulty.
This ‘Disabled’ indication is given when Alarm devices in the system are disabled.
This is a delayed status indication that appears with delayed operation of Alarm Devices.
This 'Normal' indication is given here during non fire condition or after alarms are
silenced and the system is reset for normal operation.
Fire Brigade
status
Description
This 'FD Called' indication is given as a feedback that the Fire Brigade action was
successfully deployed.
The ‘Activated' indication is given when the Fire Brigade link is activated automatically.
This 'Fault' indication is given when the Fire Brigade link or the Routing Equipment is
faulty.
This ‘Disabled’ indication is given when Fire Brigade link is disabled.
This is a delayed status indication which appears with delayed operation of Fire Brigade
link.
This 'Normal' indication is given when the Fire brigade link is not activated and fault free
for normal operation..

9
INSPIRE E10/E15 Control Panels - Operating instructions
Fire Protection
equipment status Description
This ‘Activated' indication is given when the Fire protection equipment activation has
happened.
This 'Actuated' indication is given as a feedback that the Fire Protection activation
action was successfully deployed.
This 'Fault' indication is given when Fire protection equipment or the transmission
path is faulty.
This 'Disabled' indication is given when Fire protection equipment is disabled.
This is a delayed status indication which appears with delayed operation of Fire
Protection equipment.
This 'Normal' indication is given when the Fire protection equipment is not activated
and fault free for normal operation.
Fault Routing
equipment status Description
This 'Activated' indication is given when Fault Routing equipment has activated.
This 'Fault' indication is given when Fault Routing equipment or the transmission
path is faulty.
This 'Disabled' indication is given when Fault Routing equipment is disabled.
This is a delayed status indication which appears with delayed operation of Fire
Routing equipment.
This 'Normal' indication is given when the Fire routing equipment is not activated
and fault free for normal operation.

10
Event
Smbols
Description
This is a fire symbol that accompanies active and historic fire events.
This is a fault symbol that accompanies active and historic fault events.
This is a disablement symbol that accompanies active and historic disablement events.
This is a test symbol that accompanies active and historic test events.
This four square icon with a blue dot on the top right indicates there is an active
technical alarm.
Selections Description
Selecting this menu icon will open various settings or view options for selection.
Selecting this button expands information normally hidden.
Selecting this button compresses and hides the displayed information.
Selecting this button provides more information on the subject.

11
INSPIRE E10/E15 Control Panels - Operating instructions
Selecting this button takes you to the previous screen.
Selecting this button exits the menu.
Selecting this icon will return the display to a home page, which may be a default SAFE
(Normal) page or an event page such as Fire, Fault, Disablement or Test condition.
or
or
By clicking on a box or radio button it will toggle between selected and deselected. This
is used to filter events.
Notification button when active provides further information and action required. The
notifications can also be viewed by selecting 'Menu' followed by 'Notification' button.
LICENSE NOT FOUND
If your INSPIRE panel displays a message then get in touch with your servicing
organisation. A panel without a license runs a risk of fire alarm system functionality being compromised.

12
NORMAL SAFE CONDITION
FIRE
FAULTFAULT
SYSTEM FAULT
DISABLE
DELAY ACTIVE
POWER
SILENCE/ RESOUND
MUTE BUZZER
RESET PANEL
Normal healthy screen





ToggleNight Mode is Active
Normal Normal Normal Normal
Alarm Devices Fire Brigade Fire Protection Fault Routing
SILENCE-RESOUND
TEST
MUTE BUZZER RESET Evacuate
A N Other Co Ltd
Main Office building
Date & Time
Panel and Access Level
LED indication of panel / system status.
Physical Push buttons - Essential controls.
System Condition
Toggle between Day Mode and Night Mode
Status of Alarm Device, Fire Brigade, Fire
Protection and Fault Routing
Touch Screen Essential Controls
Panel Buzzer which is normally silenced and
is made active with an event.
The panel touch screen is the primary status indicator.
This allows all the event information required to be
displayed to meet the requirements of EN 542 for any
system condition or detected event and in a clear and
concise way.
When the panel is in the status Normal condition the
display shows a healthy status, denoted as SAFE.
The time, panel name, site photo or the authorised
servicing company name/logo and along with contact
details may be displayed, which may also include
mobile contact numbers.

13
INSPIRE E10/E15 Control Panels - Operating instructions
Condition and Function Status
If you navigate away from an Event page then the Condition and Function Status will remain. For example this
may be the case if the menu icon is accessed to view historic events or enter the Enable/Disable controls.
Condition /
Function symbol
Description 

This icon appears at the top of
the page as a reminder there
is at least one active fire event
present.
This icon appears at the top
of the page as a reminder
there is at least one active
disablement event present.
Here the System Function of
Alarm devices is Activated.

14
Day or Night Mode operation
This is a Toggle function, if configured for your system, will allow a change between Day Mode and Night Mode.
The Day Mode is made active on preselected days of the week over preselected time period. Outside the Day
Mode the Night mode is automatically made active.
When the Day mode is active the ‘Delay Active’ LED is lit and the LED is Off during Night Mode
The switch between Day mode and Night mode is possible using the Toggle button during Normal
'SAFE' condition. During event condition such as with an active Fault or Disablement event, then this
toggle functionality is accessible using the menu, see "Day/Night Mode Settings" on page 29..
Day mode
During the Day Mode and upon detection of a Fire the activation of alarm output is delayed to allow the incidence
to be investigated. When the Verification Delay button is pressed then the initial investigation delay ends and
verification delay starts.
Any active delay can be stopped by selecting the button.
Night Mode
In the Night Mode the sensors operate normally and upon detection of fire the alarm outputs are activated
without delay.
At any time to toggle between Day Mode and Night Mode see page 30.
VdS default configuration
The Day mode may need to be enabled manually. A VdS approved default configuration will cause auto
delay to be deactivated on entry into Night mode, so manual intervention is required to activate Day
mode.

15
INSPIRE E10/E15 Control Panels - Operating instructions
PASSWORD ENTRY TO CONTROLS
Many of the touch screen control buttons and physical push buttons control require password entry. Each
on-site authorised user will have a unique PIN configured by the service organisation to access controls at the
Control panel. This allows authorised users to control the fire alarm system during normal, fault, disablement, test
and fire conditions.
Once User Level 2 PIN is entered and subsequently if the controls are not used for 5 minutes’ duration, then the
panel will log out of Access level 2 and returns to Access Level 1. The duration is configurable and can be changed
during commissioning to site specific needs.
When you operate a control then you are likely to be prompted to enter a password:
01 Select a Role from the drop down, choose Level 2 .
02 Using the keypad enter password number and then select the Enter . Use the factory set password
‘22222222’ or a unique password if it was changed.



On completion the Access level 2 controls are accessible, see also section headed LOG IN and OUT.
We recommend that the factory set Access level 2 password is changed to a unique
minimum 6-digit and up to a maximum 8-digit password.

16
Panel Buzzer
CHANGE ACCESS LEVEL 2 PASSWORD
It is recommended the persons responsible for the system should change
the Access Level 2 factory set password to a unique password, between 6
and 8 digits
 



01 Select the Menu icon and
log in with your Access level 2
password.
02 Select the ‘Password change’
button.
03 Determine a suitable numeric
password. Ensure the is kept
safe and is known by you the
responsible person.
04 Enter a new password 
and confirm by entering it
the second time . Select
the Tick button to accept
change of password.

17
INSPIRE E10/E15 Control Panels - Operating instructions
FIRE CONDITION
When one or more fire events occur, the screen turns red, the
first zone in alarm and the time the zone went into the fire
condition is displayed . A flashing indication is given of the
first Zone in Fire . Also, the total number of active zones in
fire is shown . For fire events, the information on the display
is supported by lit general FIRE LED .
The panel buzzer provides an audible sound and the MUTE
BUZZER key is lit to prompt an action.
WHAT DO I NEED TO DO?
Use the information provided by the Display and the LEDs to
understand quickly the situation and what action needs to
be taken. To assist this process, the panel’s display indicates
the zone location(s) of the fire event(s). Use the information
provided to identify the geographic source of the fire. Follow
site procedures on what to do in the event of a fire.
01 To silence panel buzzer select MUTE BUZZER on the
Touch Screen or press the push button on the panel.
02 Log in with your Access level 2 password.
03 If configured, the Alarms delay will be activated
and will be replaced by the Verification Delay if the
Verification delay button is pressed.Note the DELAY
ACTIVE LED will be lit and the count-down time will now
show the Verification delay. The Delay can be forced to
end by selecting the End Delay button.
04 With the emergency over and when it is safe to do so
select SILENCERESOUND button to
silence Alarms .
05 When the devices responsible for the
alarm is cleared for normal operation
then select RESET touch screen or
push button on the panel.




Accident and Emergency Ground Floor - West




DELAY ACTIVE
FIRE

VdS

SILENCE-RESOUND MUTE BUZZER RESET
Verication delay

18
Evacuate Button
EVACUATE BUTTON
This touch screen 'Evacuate' button
is not VdS approved. Normally hidden,
this button is configured during
commissioning to appear on the
panel screen to meet site needs where
required, such as in the UK.
01 Log in with your Access level 2 password.
02 Press touch screen ‘Evacuate’ button (see on
the previous page) and acknowledge to start all
the Alarm Sounders in the system.
03 Pressing the 'SILENCERESOUND' button will
silence all the Alarm Sounders.
VIEWING MULTIPLE FIRE EVENTS
If the panel enters the alarm state with more than one
zone in a Fire condition then these visual and audible
indications are given:
The display shows information about fire events, such
as the first zone and latest zone in fire condition.
Also:
- The general FIRE LED (red) is lit
- Zones in Fire are indicated on the display
- and the First Zone in fire is a flashing indication.
- The panel buzzer operates and you can mute the
sound by pressing the 'MUTE BUZZER' button .
Any outputs are programmed to operate immediately
including sounder devices are automatically activated.
Select Show All button to view details of all active
Zone fire events.
Log Book Entry
Enter information about this fire event(s) in the log
book. Ensure the log entry contains the date of the
event(s) and also the keyholder’s name / signature.
Information about the alarm event is also stored in the
fire control panel’s event log and can be accessed by
the service engineer.
Accident and Emergency Ground Floor - West wing
Accident and Emergency Ground Floor - East wing


FIRE





VdS

MUTE BUZZER

19
INSPIRE E10/E15 Control Panels - Operating instructions
FIRE LIST VIEW
Select ‘Show All’ in the active Fire screen and then List view tab. The list shows further information of Zones
in fire. Each Zone can be expanded further by selecting the down arrow icon to show details of device that has
detected the fire event.
List View 
Accident and Emergency Ground Floor - West wing
Accident and Emergency Ground Floor - Examination room
Accident and Emergency Ground Floor - Reception


P01 - Panel 1
L01 - Loop 1
D001 - Device 1
Assessment Room 2
Smoke Sensor
P01 L01 D001
02
03
Show All

20
Enable / Disable Zones
ENABLE / DISABLE ZONES
You can selectively disable or enable Zone(s) using the
‘Group by: Zones’ view. Also you can enable or disable
System Functions from this view.
Enable/Disable
Enable / disable Devices, Zones
etc








If disabled, the
Display shows:
DISABLE
LED indication
given:
1 Point
Points
20 Points
5 Points
16 Points
Points
Points
7 Points
15 Points
17 Points
27 Points
Control Outputs
How to Enable / Disable Zone(s)
01 Select the Menu icon and log in with your
Access level 2 password.
02 Select the ‘Enable/Disable’ button and
ensure ‘Group By: Zone’ is selected from
drop down options.
03 Momentarily select the required Zone check
box(s) ensure the required boxes are
checked ..
04 Select either ‘Permanently Disable’ or
‘Enable’ button. Note the selected Zone(s)
are either disabled or enabled.
How to Enable/Disable System Functions
05 Carry out steps as for How to Enable /
Disable Zone(s), steps 01 to 02. Expand the
'System Functions' view .
06 If installed and configured you can now
select either ‘Disable’ or ‘Enable’ the
required 'System Function':
- Alarm Devices
- Fire Alarm Routing Equipment
- Fire Protection Equipment
- Fault Routing Equipment
- Control Outputs.
An indication is given if disabled.
