1-1
SECTION 1
General Information

System Overview
Introduction
Congratulations on your purchase of Honeywell's IGSMHS combination Internet and GSM
communication module (henceforth referred to as IGSMHS). It represents the latest and
most innovative communication technology for the security industry and uses the most
sophisticated encryption to ensure the highest level of security for your customer.
The IGSMHS module requires an AlarmNet–i account. For new installations, please
obtain the account information from the central station prior to programming this module.
For replacement installations, the AlarmNet-i account is created automatically when the
module is registered.
In addition to alarm reporting, the IGSMHS provides upload/downloading capability of
Honeywell's control panel data over the Internet (via the AlarmNet-G network), using GSM
(Global System for Mobile) technology.
General Information
Honeywell's IGSMHS Internet communication module communicates via the Internet (when
service is available) and switches to GSM service when the Internet is not available.
In normal operation (with Internet connectivity), the IGSMHS communicates from your
customer's network connection to the Honeywell Network Operations Center, (NOC) via the
AlarmNet-i network. The NOC receives data and routes the information to the Central
Station of your choice, based on the account number you assign to the module. Note that your
Central Station needs to give you the account number. The same account number is used for
both Internet and GSM transmissions. If your current Central Station is capable of receiving
signals from the Honeywell NOC, they are capable of receiving signals from the IGSMHS
module.
If, for some reason, Internet connectivity is not available, (for example, your customer's ISP
is off line or disconnected), the IGSMHS will transmit signals via the AlarmNet-G (GSM)
cellular network, which uses the GPRS (General Packet Radio Service) to complete these
transmissions. These transmissions are sent to the Honeywell NOC and then forwarded to
your Central Station exactly the same way as if they were received via the Internet.
If the Internet and GPRS (part of the GSM cellular network) are both unavailable (fail), the
message will not be sent via this communication module.
For maximum reliability, it is recommended the device be operated in dual path
mode with Internet and GSM both enabled and connected.

IGSMHS Installation and Setup Guide
1-2
System Features
Basic features include:
Supports dynamic or static IP addressing, and installs behind firewalls without
compromising network security.
Quick connection to compatible Honeywell series control panels
Simple programming using a 7720P programming tool
Reports fire (Fire has not been evaluated by UL), burg, and status messages via the
Internet
Reports messages via AlarmNet-G as backup to Internet reporting
Allows uploading and downloading of control panel data over the Internet.
About AlarmNet-i Internet Application
AlarmNet-i is a fully encrypted, secure method of delivering alarm messages from a
protected premise to an AlarmNet equipped central station. An Internet Communicator
Module transmits status, supervisory, and alarm messages to the AlarmNet Control Center
using a broadband Internet connection.
The AlarmNet Control Center identifies, validates, and forwards the messages to the
appropriate AlarmNet central station. AlarmNet-i has an unlimited account capacity.
Encryption
The IGSMHS supports private key encryption. Private Key encryption means that both the
sender and the receiver know the KEY used to encrypt the data. Each communication
module produced by Honeywell is loaded with a globally unique identifier called a MAC
number, and a large random number or KEY. This KEY and MAC number are also stored in
the AlarmNet servers. When a communication module contacts AlarmNet, it sends the MAC
number in the clear followed by the message that is encrypted using the KEY data. The
server looks up its copy of the KEY based on the MAC number and uses that KEY to decrypt
the message.
The IGSMHS uses 256 bit AES (Rijndael) encryption (which is required for certain
government installations). The AlarmNet-i AES Encryption Software Module Version 1.0
contained in the Honeywell products has NIST approval. Listings for this approval can be
found at http://csrc.nist.gov/cryptval/aes/aesval.html Certification number 127.
ULThe IP and GSM signaling paths are suitable for encrypted line security when programmed
for 1 minute IP/GSM Fault Times. The system configurations are not suitable as a Dual Line
Signal transmission system.
Modes of Operation
The IGSMHS provides four modes of operation so it can be used with various types of control
panels, as summarized below.
UL Only ECP Mode and Zone Trigger modes have been approved for UL installations.
ECP Mode
This mode is for use with Honeywell control panels that support ECP communication
The module connects to the control panel’s keypad terminals and provides 2-way
communication with the control panel using ECP messaging
The control panel treats the IGSMHS as a communications module (LRR), so program the
control panel accordingly, including setting the module’s proper LRR device address
Reports are sent in Contact ID format
The module also supports two hardwire zone trigger inputs (zones 6 and 7)
Options include; V+, V–, EOL, inverted, and non-inverted.

Section 1: General Information
1-3
UL – For the IGSMHS, only the V+ inverted, V– non-inverted, and EOL options have been
evaluated.
ULOpening and Closing ring back is fully supported.
Zone Trigger Mode
This mode is for use with control panels that do not support ECP communication nor
4204 Relay Modules
The module provides six input zones and each zone can be configured for +V, -V, or
EOLR triggering.
UL – For the IGSMHS, only the V+ inverted, V– non-inverted, and EOL options have
been evaluated.
Each zone can be programmed for inverted operation, delayed reporting, and restoral
reporting
Zone 1 input can distinguish between pulsed and steady signals and report fire or
burglary alarms respectively
Zone 1 can be programmed to report a LYNX panic (if used with LYNX control panel)
UL – This feature has not been evaluated by UL.
Reports are sent in ADEMCO High-Speed format
ULOpening and Closing ring back is supported by the control panel’s digital dialer.
4204 Mode and Two-4204 Mode
This mode is for use with Honeywell control panels that do not support ECP commu-
nication, but do support 4204 Relay Modules
The module connects to the control panel’s keypad terminals
The control panel treats the module as 4204 Relay Module(s), so program the control
panel accordingly, including setting the module’s proper 4204 device address
4204 mode provides up to four zone inputs, plus two optional trigger zones,
depending on options programmed
Two-4204 mode provides up to eight zone inputs, depending on options programmed
Each 4204 zone can be programmed for delayed reporting and restoral reporting
Reports are sent in ADEMCO High-Speed format
UL4204 Mode and Two-4204 Mode has not been evaluated.
Module Supervision Features
The IGSMHS provides the following types of supervision and module fault detection:
Network communication failure: In the event the AlarmNet network does not hear a
supervisory message from the module within a specified time AlarmNet notifies the
central station of a communication failure.
Communication path failure: In the event the module detects a communication path
failure, the control panel can be notified of a trouble condition with the module after
a specified time has elapsed.
Fault output: Terminal 11 can serve as a fail-safe trigger for module fault conditions.
If used, the fault relay will trip when the following conditions occur: tamper*, power
loss*, low battery*, battery charger fault*, loss of network connectivity*, the
communication module is not registered and the communication module is remotely
disabled by AlarmNet.
*Alarm reporting for the noted conditions must be enabled for it to trigger the fault
relay.

IGSMHS Installation and Setup Guide
1-4
Primary power loss and low battery conditions.
Cover tamper condition.
Antenna
The IGSMHS comes equipped with an internal antenna. This feature provides additional
security to the installation by making the module tamper resistant.
ULExternal antenna options have not been evaluated by UL.
AMPS antennas, such as the 7825-OC antenna, cannot be used with this product.
Specifications
Mechanical
Dimensions: 8.4" x 8.0" x 1.5"
Weight: 2.4 lbs., with battery
Electrical
Input Power: 16.5VAC, 40VA transformer, Honeywell Model No. 1361
Current Drain: 65mA average standby, 500mA peak transmit
Or
12VDC from control panel.
Current Drain: 80mA average standby, 650mA peak transmit
UL: Powering the IGSMHS from a control panel has not been evaluated by UL.
Backup Battery: 6V, 3.1AH, Honeywell part number K14139, (included)
Expected Battery Life: 5 Years (approx.)
Fault Relay Output: Open collector, 12VDC, .25W max.
Positive Trigger Level: 6V or greater = positive trigger. (4V or less = restore.)
Negative Trigger Level: 4V or less = negative trigger. (6V or greater = restore.)
RF
Transceiver Type: Quad-Band GSM/GPRS Class 10
Modulation: GMSK
Antenna: Internal GSM quad-band antenna 1.3 dBi gain
Band
Transmission
Frequency
(MHz)
Transmit
Power
(dBm)
Receive
Frequency
(MHz)
Receive
Sensitivity
(dBm)
Number
of
Channels
Channel
Spacing
(MHz)
Duplex
Separation
(kHz)
GSM 850 824-849 33 869-894 -107 124 200 45
GSM 900 890-915 33 935-960 -107 124 200 45
GSM 1800 1710-1785 30 1805-1880 -106 374 200 95
GSM 1900 1850-1910 30 1930-1990 -105.5 299 200 80
Ethernet
Network Standard: IEEE 802.3u compliant
Data Rate: 10Base-T / 100Base-T with auto detect
Ethernet Cable: Cat. 5 (min), MDI /MDI-X auto crossover

Section 1: General Information
1-5
Environmental
Operating temperature: –20º to +55ºC (UL evaluated range: 0º to +49ºC)
Storage temperature: –40º to +70ºC
Humidity: 0 to 85% relative humidity, non-condensing
Altitude: to 10,000 ft. operating, to 40,000 ft. storage
Compatibility
For a list of control panels that are compatible with various features of this communication
module, go to:
http://www.security.honeywell.com/hsc/resources/MyWebTech.
After logging on, select the applicable communication product, and then select “Compatibility
Chart” under Essential Docs.
For UL installations, compatible control panels are:
Vista-128BP
Vista-250BP
For UL installations, compatible receivers are:
MX8000 (UL – can be used for supplemental reporting in ECP mode when
connected to model 7810iR-ENT; must be used for opening/closing ring
back in Zone Trigger mode when connected to control unit’s DACT.)
7810iR-ENT (UL – must be the primary alarm receiver.)
Ademco 685 (UL – Ademco 685 has not been evaluated by UL.)
UL The Automation System must be UL1981 listed.
The IGSMHS has been evaluated for connection to police station receivers.

IGSMHS Installation and Setup Guide
1-6

2-1
SECTION 2
Mounting and Wiring

Determine the Signal Strength and Select a Location
The IGSMHS must be mounted indoors within the protected premises. When choosing a
suitable mounting location, understand that signal strength is very important for proper
operation. For most installations using the supplied antenna, mounting the unit as high as
practical, and avoiding large metal components provides adequate signal strength for proper
operation.
You will use the communications module to determine signal strength in order to find a
suitable mounting location.
NOTE: If the SIM is already activated, the RSSI signal strength indicators will indicate
signal strength.
If the SIM has not been activated, the firmware in the communications module enables it
to communicate with the cellular network towers (without the SIM being activated) so
that signal strength measurements can be determined. In this case, you can display the
signal strength by simultaneously pressing the MODE and TAMPER switches.
RF Exposure
Warning – The antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be collocated or
operating in conjunction with any other antenna or transmitter.
NOTE: The IGSMHS must be installed in accordance with the National Fire Alarm Code,
ANSI/NFPA 70.
Unshielded, 22 AWG cable is recommended for IGSMHS power/data wires.
1. Unpack the IGSMHS and detach the case back by pushing up into the two tabs located at
the bottom of the IGSMHS with the blade of a screwdriver while pulling the case back
and case front apart.
2. Temporarily connect the IGSMHS to the AC transformer, supplied.
3. Choose the installation site with the best signal strength by observing the signal
strength (RSSI) bar graph (refer to Appendix A for information about signal strength and
status indications). Signal strength should be within 3-5 bars. The best signal strength
is usually found at the highest point in the building, near a window. Unplug the
transformer.
3 BARS MIN.
GYGGRY
7845i-GSM-025-V0
4. Mark the location for the IGSMHS.

IGSMHS Installation and Setup Guide
2-2
Mounting the IGSMHS
The communications module can be mounted in two ways depending on the installation
requirements.
ULThe cover must be secured with the supplied screw.
Standard Mounting Procedure
1. Locate the case back over selected mounting position such that the opening in the case
back is aligned with the wire/cable opening on the mounting surface.
2. Pass the wire /cable through the opening in the case back, or route through the
removable knockouts located on the back cover.
3. Secure the case back to the mounting surface using four screws (supplied).
4. When all wiring is completed, attach the case front. Position the top first, then press the
bottom section until it snaps in place. Secure bottom using the supplied cover screw.
(This is required for UL installations.)
7845i-GSM-028-V0
MOUNTING
SCREW (4)
(TYP)
WALL OR
MOUNTING
SURFACE
INTERNAL
ANTENNA
TAB
COVER SECURING SCREW
OPTIONAL WIRING
KNOCKOUT
OPTIONAL WIRING
KNOCKOUTS
TAB
CASE
FRONT
CASE
BACK
FOR EXTERNAL ANTENNA
50 OHM, MMCX ONLY
7720P PROGRAMMER PORT
NOT FOR TELEPHONE SERVICE USE!
PRIMARY POWER:9-1 .5VAC
BATTERY: V. 3.1 AHr FOR 24 Hr BACKUP
FCC ID: GIPMC5 IC: Y2 7W - MC5
GSM
GPPS
WEB
MODE 2
MODE 1
RSSI
Honeywell
RX
TX
MAC LABEL HERE
TRANSMIT LED
Figure 2-1. Standard Mounting

Section 2: Mounting and Wiring
2-3
Wiring the IGSMHS
UL Installation must be in accordance with; the National Electrical Code, UL681 Installation and
Classification for Burglary and Hold-Up Alarm Systems, and UL827 for Central-Station Alarm
Services.
IGSMHS must be connected to a UL Listed dry contact or voltage trigger outputs of a UL Listed
compatible control panel.
All interconnecting wires between the UL Listed control panel and the IGSMHS must be less than 3
feet in length contained in the same room. All interconnecting wiring must be installed in rigid or EMT
(where exposed on interior walls) or in flexible metal tubing if run in the walls or ceiling.
A UL listed control panel must monitor the radio fault output of the IGSMHS. Premises openings and
closings should be sent via the UL listed control panel.
Only ECP mode has been evaluated by UL.
4204 Mode and Two-4204 Mode has not been evaluated.
Wiring a Telco Line Fault Monitor for Zone Mode
When using an Ademco No. 659EN Line Fault Monitor, follow the diagram below for wiring
information. (For detailed information, refer to the Ademco No. 659EN Installation
Instructions P3516-1V2.)
High Security
Communicator
CONTROL PANEL
IGSMHS-002-V0
ZONE 7
OR
RED
AUX
POWER
9
4
10
TB1
ZONE 6
GND
RED
No. 659EN Line Fault Monitor
86753421
6-14VDC
STAND BY: 5mA
ACTIVE: 35mA
BLK
BLK
TO TELCO LINE
(Disregard Polarity)
The Telco line fault monitor should utilize either zone 6 or zone 7 on the IGSMHS. When
programming the IGSMHS ensure the following programming is accomplished. The example
below is for Zone 6.
Programming Prompt Setting
Enable Zn6 [Y]
Zn6 Trigger Type [V+]
Invert Zn6 [Y]
Restore Zn6 [Y]
Delay Zn6 [00]
Rpt Zn6 ONLY if Armed [N]

IGSMHS Installation and Setup Guide
2-4
Wiring for ECP, 4204 and Two-4204 Modes
Most Honeywell control panels support ECP data communication. Check the Installation
and Setup Guide for the control panel you are using to see if it supports ECP communication.
Connect the IGSMHS to a compatible Honeywell VISTA control panel's ECP terminals, in
parallel with keypads and other peripheral devices such as RF receiver, VIP module, etc.
Wire length /gauge limitations are the same for the module as they are for keypads and other
peripheral devices. To wire the module for ECP or 4204 modes, see Figure 2-2 and make the
following connections:
COMMUNICATIONS
MODULE
VISTA CONTROL PANEL
iGSMBR-005-V0
GND GND
ECP DATA IN
2
1
4
5
TB1
TRANSFORMER
AC INPUT 2
AC INPUT 1
J1 BATTERY
+12V AUX ECP (+) VOLTAGE INPUT
3
D ATA I N ECP DATA OUT
6
DATA OUT
BLK
YEL
RED
GRN
Figure 2-2. Wiring a VISTA for ECP Mode or 4204 Modes
Wiring for Zone Trigger Mode
To trip a zone using a positive trigger, the voltage level must be:
6V or greater = positive trigger. (Levels above +14V may cause damage to the unit.)
4V or less = restore.
To trip a zone using a negative trigger, the voltage level must be:
4V or less = negative trigger.
6V or greater = restore. (Levels above +14V may cause damage to the unit.)
NOTE: Remember to program the communications module zone for the desired trigger type.
Connect a wire from the triggering source (bell output, voltage trigger, etc.) of the control
panel to the zone input of the module, and connect a common ground between the module
and control panel. Examples of zone connections follow:
COMMUNICATIONS
MODULE
TRIGGERING DEVICE
GSMV-005-V0
GND GND
ZONE INPUT Z1/Z2
2
1
4
5
TB1
TRANSFORMER
AC INPUT 2
AC INPUT 1
+ TRIGGER
(VOLTAGE: 6 to 13V)
J1
BATTERY
Figure 2-3. Wiring Zone 1 Input for a Positive (+) Trigger

Section 2: Mounting and Wiring
2-5
TRIGGERING DEVICE
GSMV-006-V0
GND GND
ZONE INPUT Z1/Z2
2
1
4
5
TB1
TRANSFORMER
AC INPUT 2
AC INPUT 1
- TRIGGER
(VOLTAGE 4 to 0V)
COMMUNICATIONS
MODULE
J1
BATTERY
Figure 2-4. Wiring Zone 1 Input for a Ground (-V) Trigger
iGSMBR-010-V0
GND
ZONE INPUT Z1/Z2
2
1
4
5
TB1
TRANSFORMER
AC
AC
2K EOL
RESISTOR
N.C.
N.O.
COMMUNICATIONS
MODULE
J1
BATTERY
Figure 2-5. Wiring Zone 1 Input for EOL Supervised N.O. /N.C. Triggers
Wiring for Module Fault Relay
You may wire and program the module's fault output trigger for fail-safe mode (see the
prompt "FLT REL ON Y/N").
To sense a module fault at the control panel, make connections as shown in Figure 2-6,
including the proper EOL resistor required by the control panel.
UL For Commercial Burglary, a 24 hour zone (supervisory) must be assigned on the
control panel, with the communication module's fault relay wired to that zone.
iGSMBR-011-V0
12V AUX
GND
ZONE IN (+)
2K EOL
RESISTOR
CONTROL PANEL
GND
ECP (+) VOLTAGE INPUT
2
1
4
3
TB1
TRANSFORMER
AC INPUT 2
AC INPUT 1
RAD FLT
11
COMMUNICATIONS
MODULE
J1
BATTERY
Figure 2-6. Wiring the Fault Relay to a Control Panel Zone for Normally Closed Fault
ULZones should use EOL resistors, and be pro-
grammed as V+ Inverted or V– Inverted
operation such that a cut line results in an
alarm.
EOL resistors must be UL Listed.
Do not use zones 1 and 2 for UL
installations.

IGSMHS Installation and Setup Guide
2-6
Ethernet Connections
UL
For UL installations, the Cat. 5 Ethernet connection between the IGSMHS and the router
cannot exceed 12 feet with both the IGSMHS and the router located within the same room.
Use a Listed cable /DSL router suited for the application.
Connect one end of the Ethernet cable (Category 5) to the IGSMHS’s RJ45 Ethernet
connector and the other end to the cable/DSL router as shown in the figure below.
TO ROUTER
RJ45
(FOR INTERNET
CONNECTION)
7720P
PROGRAM
CONNECTOR
J1
BATTERY
CONNECTOR
RSSI
M0
M1
GPRS
IBS
iGSMBR-012-V0
Figure 2-7. Ethernet Connections
Power Connections and Options
Powering the Communication Module
For a standard installation, primary power is provided by the AC plug-in transformer. For
ECP communication, you must also connect the +12VDC AUX voltage output of the control
panel (9.6V-13.8V typical) (see Figure 2-8).
In all installations, TB1-4 GND must be connected to ground (GND) on the control panel.
iGSMBR-013-V0
12V AUX
GND
COMMUNICATIONS
MODULE
CONTROL PANEL
GND
ECP (+) VOLTAGE INPUT
2
1
4
3
TB1
TRANSFORMER
AC INPUT 2
AC INPUT 1
J1
BATTERY
Figure 2-8. Powering the Communications Module
NOTE: When calculating the total load on the auxiliary power output of the control panel, budget 10mA
for the IGSMHS when using ECP mode.
Standard
Installation

Section 2: Mounting and Wiring
2-7
Backup Battery Connection
The included battery (K14139) is used for backup in the event of power loss to the
communications module. It does not provide power to the control panel.
The battery can provide over 24 hours of system life in the event of a power failure.
A programmable power loss message can alert the AlarmNet Control Center when system
power is lost (power loss messages are reported within 1-3 hours of actual loss).
The module transmits a low-battery message (programmable) when the battery reaches
5.7V ±5%, indicating subsequent messages may not be transmitted.
The system shuts down when the battery falls below 5.1V, and radio transmissions are no
longer possible.
If system power is restored before the module shuts down, a power restore message is sent
within 1-3 hours after power is restored, and the battery is recharged using the IGSMHS’s
built-in battery charger. If system power is restored after the IGSMHS has shut down, a
power-on reset condition exists, the module initializes itself and the battery will recharge.
Install the battery as follows, and refer to the Summary of Connections diagram at the end of
this document.
1. Place the battery inside the case back.
2. Snap the right side of the battery clip onto the inside of the case back and secure the left
side with the screw provided.
NOTE: Do not plug the battery in until after you have powered-up the IGSMHS.
Initial Power-Up Sequence
Before connecting power, check that the following have been completed:
If using ECP, 4204 or 2-4204 Mode, terminal block TB1 V+ and GND terminals are
connected to the control panel’s auxiliary power output: 12VDC nominal.
Plug in the transformer.
Connect the red and black battery cables to the battery terminals. Connect battery cable
to connector J1.
Power up the control panel.
Initially, all IGSMHS programming options are set to the factory default settings.

3-1
SECTION 3
Programming the IGSMHS

General Information
The IGSMHS is designed to deliver alarms via the Internet to an AlarmNet central station or
via the AlarmNet-G network, using GSM (Global System for Mobile) technology when the
Internet is not available.
The IGSMHS uses 256 bit AES (Rijndael) encryption which is required for certain
government installations.
The IGSMHS module requires an AlarmNet–I account. For new installations, please obtain
the account information from the central station prior to programming this module. For
replacement installations, the AlarmNet-i account is created automatically when the module is
registered.
You can program a IGSMHS by one of the following methods:
Through the AlarmNet Direct website
Through use of a 7720P Programming Tool
Through a programming mode in the control panel, on panels that support this option
UL Only ECP and Zone Trigger modes have been evaluated by UL.
Programming the Control Panel to work with the IGSMHS
For Residential and Commercial control panels, there are certain programming field settings
that must be adhered to for using the IGSMHS. (For programming information, please refer
to the appropriate control panel guides.) Ensure the following programming fields are set:
RESIDENTIAL / COMMERCIAL Control Panels (Such as the VISTA-10P, 15P, and 20P series.)
UL: These control panels have not been evaluated by UL.
Programming Field Setting
29 Menu Mode for IP/GSM Enable 1 (Enable LRR.)
54 Dynamic Signaling Delay 0 (Dialer and LRR reports go out at the same time.)
55 Dynamic Signaling Priority 0 (Primary dialer reports first.)
COMMERCIAL Control Panels (Such as the VISTA-128 /250 series.)
Programming Field Setting
32 Primary Subscriber's Acct No. nnnn (Required for the communicator to report.)
56 Dynamic Signaling Delay 00 (Dialer and LRR reports go out at the same time.)
57 Dynamic Signaling Priority 1 (Communicator, as first reporting.)
58 Comm Central Station #1
Category Enable
111111 (All events will be reported to the primary Central
Station.)
59 Comm Central Station #2
Category Enable
000000 (If Central Station #2 is not used.)
111111 (If Central Station #2 is used.)
#93 Menu Mode Zone programming – set Zone 803 for Type 05.
Device programming – set Address 03 for Type 06 (LRR).

IGSMHS Installation and Setup Guide
3-2
Using the AlarmNet Direct Website
To program the module via the website (if you are already signed up for this service), go to:
https://services.alarmnet.com/AlarmNetDirect/userlogin.aspx
If you are not signed up for this service, click on “Dealer Sign-Up.
Log in and follow the on-screen prompts.
Please have the following information available when programming the module:
1. Primary City ID (two-digit number)
2. Primary Central Station ID (two-digit hexadecimal number)
3. Primary Subscriber ID (four-digit number)
4. MAC ID and MAC CRC number (located on the outside of box and on label inside module)
of the communication module you are installing
After programming is complete, you must transfer the data to the module and the module
must be registered. Refer to Section 4: Registration, for further instructions.
Using a 7720P Programming Tool
Connect the 7720P Programming Tool as shown below. The IGSMHS powers the 7720P
Programming Tool via the programming jack, and automatically senses the presence of the
7720P when it is plugged in.
7720P
PROGRAM
CONNECTOR
ABC
DE
F
STX
123
45
6
98
7
#0
Xmit
Shift
Space Enter
Shift
N /Y
BS / ESC
/
7720 PROGRAMMING TOOL
RSSI
M0
M1
GPRS
IBS
iGSMBR-015-V0
Figure 3-1. Cable Connections
Each key of the 7720P has two possible functions: a normal function and a Shift function.
To perform a normal key function, simply press the desired key.
To perform a Shift function, press the [shift] key, and then press the appropriate key.
The prompts in this document reflect use of the 7720P Programming Tool. The table below
lists each normal and shift key function.
Table 3-1. 7720P Normal and Shift Key (shift LED lit) Functions
KEY NORMAL KEY FUNCTION SHIFT KEY FUNCTION
BS /ESC [BS]: Press to delete entry [ESC]: Press to quit program mode; also can reset
programming defaults*
/[]: Scroll down programming []: Scroll up programming
N/Y [N]: Press for "NO" answer [Y]: Press SHIFT-Y for "YES" answer
SHIFT Press before pressing a SHIFT key function. Will light SHIFT LED. LED goes out once a key
is pressed. Press again for each SHIFT function desired.
1/A [1]: For entering the number 1 [A]: For entering letter A
2/B [2]: For entering the number 2 [B]: For entering letter B
3/C [3]: For entering the number 3 [C]: For entering letter C
4/D [4]: For entering the number 4 [D]: For entering letter D
5/E [5]: For entering the number 5 [E]: For entering letter E
