Honeywell C7110C1040 User manual

® U.S. Registered Trademark MU1B-0658GE51 R0619B
Copyright © 2019 Honeywell Inc.  All Rights Reserved
D Montageanweisung
C7110C1040 and C7110C1080
Wall Modules
DK Installationsvejledning
ES Instrucciones de montaje
F Instructions d'installation
I Istruzioni di montaggio
N Installationsinstruktioner
NL Installatievoorschrift
P Instruções de montagem
S Installation instruktioner
FI Asennusohje
PL Instrukcja montażu
MOUNTING INSTRUCTIONS
A. CAUTION B. WIRING
WARNING
Risk of electric shock or equipment damage!
► Do not touch any live parts.
► Disconnect power supply before making connections.
► Do not reconnect power until installation is complete.
► Observe precautions for handling electrostatic sensitive
devices.
CONTROLLER
MAX. 305 m (1000 ft)
6 mm (1/4 in.)
1.5 ... 0.34 mm
2
(16 ... 22 AWG)
MAX. 0.5 Nm (4.4 lb-in.)
MIN. 150 mm (6 in.)
C. REMOVING COVER, INSERTING SCREWS D. INSTALLATION POSITION
1234567
2X
3.5x25 CROSS-RECESSED
PAN HEAD TAPPING SCREW
DEBUG CAL0 2000 3000 CAL400
2
1
LIFT
PRESS
~1.3 m
X X
X
X

C7110C1040 AND C7110C1080 WALL MODULES - MOUNTING INSTRUCTIONS

Manufactured for and on behalf of the Connected Building Division of Honeywell Products and Solutions SARL, Z.A. La Pièce, 16, 1180 Rolle, Switzerland by its Authorized Representative:
Home and Building Technologies
Honeywell GmbH
Böblinger Strasse 17
71101 Schönaich, Germany
Phone [phone]
Fax [phone]
http://ecc.emea.honeywell.com
MU1B-0658GE51 R0619B Subject to change without notice
E. WIRING TERMINALS OF C7110C1080
1234567#
#
#
#
#
#
#
#
C7110C1040 / 1080 CONTROLLER
COM COM TEMPERATURE INPUT CO2 INPUT 0...10 V PT1000 / NTC 20kOhm
! !
24 VAC 24 VAC CO2 OUTPUT 0...10 V 24 VAC/DC
LINE
V
OLTAGE LINE
V
OLTAGE
F. CONFIGURATION JUMPER G. T7460-LONJACK (OPTIONAL)
FACTORY TEST: DO NOT USE!
BACKGROUND CALIBRATION
ZERO CALIBRATION
FACTORY DEFAULT = 0...2000 ppm
0...3000 ppm
C7110C1040 / 1080
WALL MODULE
PRODUCT DATA
(EN0B-0775GE51)
1234567
CONNECTION
TERMINALS
PC
CONNECTION
DEBUG CAL0 2000 3000 CAL400
