Captuvo™ SL22/42 HomeBase
Quick Start Guide
CAPTUVO22-42-HB-QS Rev A
6/14

Overview
The HomeBase is a single charging cradle that can power one
Apple®iPod touch®/Apple iPhone®sled and charge its battery in four
hours for non-healthcare sleds and six hours for healthcare sleds. If
the iPod touch/iPhone is inserted into the sled, it will be charged
along with the sled.
We recommend use of Honeywell peripherals, power cables,
and power adapters. Use of any non-Honeywell peripherals,
cables, or power adapters may cause damage not covered by
the warranty.
Unpacking the HomeBase
Open the shipping box and inspect the package to see that the fol-
lowing standard items are included:
• One HomeBase (Models: SL-HB-C or SL-HB-C-H)
• One wall adapter
• Quick Start Guide
These items are needed to operate the HomeBase. If any items are
missing or anything appears to be damaged, contact your Customer
Account Representative. Keep the original packaging in case you
need to return the HomeBase for service or to store the HomeBase
while not in use.
Convenient Storage
Since charging terminates when the battery has a full charge, the
HomeBase is a safe and convenient storage receptacle for your
Captuvo sled.
!

Front Panel
Back Panel
Power Supply Connector

Power
The terminal requires 5 Volts DC input for battery charging; the
power adapter on the power cable converts the voltage from the
power source to 5 volts DC. Use only a UL Listed power supply,
which has been qualified by Honeywell with output rated at 5VDC
and 3A amps with the device.
Honeywell recommends that you leave the HomeBase connected to
its power source at all times, so that it is always ready to use.

Connecting Power to the HomeBase
1. Plug the wall adapter cable into the power connector on the back
panel of the HomeBase.
2. Plug the A/C power cord into a standard wall outlet.
The HomeBase is ready to begin charging the sled/iPod touch/
iPhone.

Charging the Battery
1. Install the main battery pack in the sled.
2. Verify the HomeBase has power.
3. Slide the sled into the well. Charging begins immediately if
required by the sled or the iPod touch/iPhone. If the iPod touch/
iPhone is installed in the sled, the battery icon at the top of the
screen indicates that it is charging. The sled and the iPod touch/
iPhone charge simultaneously and completely depleted batteries
will be charged in four hours for non-healthcare sleds and six
hours for healthcare sleds.
.
Ensure all components are dry prior to mating sleds/bat-
teries with peripheral devices. Mating wet components
may cause damage not covered by the warranty
!

Agency Information
USA
FCC Part 15 Subpart B Class B
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or televi-
sion reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio or television
technician for help.
If necessary, the user should consult the dealer or an experienced
radio/television technician for additional suggestions. The user may
find the following booklet helpful: “Something About Interference.”

This is available at FCC local regional offices. Honeywell is not
responsible for any radio or television interference caused by unau-
thorized modifications of this equipment or the substitution or attach-
ment of connecting cables and equipment other than those specified
by Honeywell. The correction is the responsibility of the user.
Use only shielded data cables with this system. This unit has been
tested with cables less than 3 meters. Cables greater than 3 meters
may not meet class B performance.
Caution: Any changes or modifications made to this equipment not
expressly approved by Honeywell may void the FCC authorization to
operate this equipment.
Canada
Industry Canada ICES-003
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Conformité à la règlementation canadienne
Cet appareil numérique de la Classe B est conforme à la norme
NMB-003 du Canada. Son fonctionnement est assujetti aux condi-
tions suivantes :
1. Cet appareil ne doit pas causer de brouillage préjudiciable.
2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris
le brouillage pouvant causer un fonctionnement indésirable.

Europe
The CE marking indicates compliance to 2004/108/EC EMC Direc-
tive with Standards EN55022 CLASS B, EN55024, EN61000-3-2,
EN61000-3-3. 2011/65/EU ROHS (Recast). In addition, complies to
2006/95/EC Low Voltage Directive, when shipped with recom-
mended power supply.
For further information please contact:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell International Inc. shall not be liable for use of our product with
equipment (i.e., power supplies, personal computers, etc.) that is not CE
marked and does not comply with the Low Voltage Directive.
La marquage CE indique que cet appareil est conforme à la Direc-
tive CEM 2004/108/CE et avec les normes EN55022 CLASSE B,
EN55024, EN61000-3-2, EN61000-3-3. 2011/65/EU ROHS
(Recast). De plus, il est conforme à la Directive sur les basses ten-
sions 2006/95/EC, lorsqu’il est fourni avec le bloc d’alimentation
recommandé.
Pour plus de renseignements, communiquez avec :
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell ne sera pas tenu responsable de l’utilisation de ses produit avec
de l’équipement (c’est-à-dire, blocs d’alimentation, ordinateurs personnels,
etc.) qui ne porte pas la marque CE et n’est pas conforme à la Directive sur
les basses tensions.
La marquage CE apposée sur ce dispositif atteste qu’il est con-
forme à la Directive CEM 2004/108/CE et aux normes EN55022
CLASSE B, EN55024, EN61000-3-2, EN61000-3-3. 2011/65/EU
ROHS (Recast). En outre, s’il est fourni avec l’alimentation recom-
mandée, ce dispositif est conforme à la Directive « basse tension »
2006/95/CE. Pour plus d’informations, veuillez contacter :

Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Pays-Bas
Honeywell ne peut pas être tenu responsable des éventuelles conséquences
de l'utilisation de ses produits avec des équipements (modules d'alimenta-
tion, ordinateurs personnels, etc.) ne comportant pas la marque CE et non
conformes à la Directive sur les basses tensions.
La marcatura CE indica conformità ai sensi della direttiva EMC
2004/108/EC con gli standard N55022 Classe B, EN55024,
EN61000-3-2, EN61000-3-3. 2011/65/EU ROHS (Recast). È con-
forme inoltre ai sensi della Direttiva bassa tensione 2006/95/EC se
spedito con l’alimentatore consigliato. Per ulteriori informazioni rivolgersi a:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Paesi Bassi
Honeywell declina ogni responsabilità per l'utilizzo del prodotto con disposi-
tivi (ad esempio alimentatori, personal computer ecc.) non contrassegnati
dal marchio CE e non conformi alla Direttiva Bassa Tensione.
Die CE-Kennzeichnung wird die Einhaltung der EMV-Richtlinie
2004/108/EG mit den Normen EN55022 Klasse B, EN55024,
EN61000-3-2, EN61000-3-3 angezeigt. 2011/65/EU ROHS
(Recast). Ferner entspricht dieses Gerät der Niederspannungsricht-
linie 2006/95/EG, wenn es mit dem empfohlenen Netzteil geliefert wird. Weit-
ere Informationen sind unter folgender Adresse erhältlich:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Niederlande
Honeywell haftet nicht für die Verwendung seiner Produkte mit Komponenten
(z. B. Stromversorgungen, PCs usw.), die nicht mit dem CE-Zeichen gekenn-
zeichnet sind und die nicht den Vorschriften der Niederspannungsrichtlinie
entsprechen.
El marcado CE indica que cumple con la Directiva 2004/108/EC
EMC y los estándares EN55022 Clase B, EN55024, EN61000-3-2,
EN61000-3-3. 2011/65/EU ROHS (Recast). Además, cumple con la

Directiva 2006/95/EC sobre el material eléctrico destinado a utilizarse con
determinados límites de tensión, cuando se envía con una fuente de ali-
mentación recomendada. Para obtener información adicional, póngase en
contacto con:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Países Bajos
Honeywell no será responsable del uso de sus productos con equipos (p. ej.,
fuentes de alimentación, ordenadores personales, etc.) que no presenten la
marca CE y no cumplan con la Directiva sobre el material eléctrico destinado
a utilizarse con determinados límites de tensión.
El marcado CE indica que cumple con la Directiva 2004/108/EC
EMC con los Estándares EN55022 CLASE B, EN55024, EN61000-
3-2 y EN61000-3-3. 2011/65/EU ROHS (Recast). Además, cumple
con la Directiva 2006/95/EC sobre baja tensión cuando se envía
con la fuente de alimentación recomendada. Si desea obtener más infor-
mación, póngase en contacto con:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Países Bajos
Honeywell no asumirá responsabilidad por el uso de sus productos con equi-
pos (p. ej., fuentes de alimentación, computadoras personales, etc.) que no
presenten la marca CE y no cumplan con la Directiva sobre baja tensión.
A marcação CE indica conformidade com a Diretiva EMC 2004/108/
EC, com os Padrões EN55022 CLASSE B, EN55024, EN61000-3-2
e EN61000-3-3. Além disso, indica conformidade com a Diretiva
para baixa tensão 2006/95/EC, quando o dispositivo é enviado com
a fonte de alimentação recomendada. Para obter mais informações, entre
em contato com:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
Holanda

Honeywell não se responsabiliza pelo uso de nossos produtos com equipa-
mentos (fontes de alimentação, computadores pessoais, etc.) que não este-
jam marcados com CE e em conformidade com a Diretriz de Baixa
Voltagem.
CE 㸼⼎䆒໛ヺড় 2004/108/EC EMC ᣛҸ EN55022 B ㉏ǃ
EN55024ǃEN61000-3-2ǃEN61000-3-3 2011/65/EU ROHS
(Recast). ⱘ󰵼ޚ㽕∖DŽℸ໪ˈ೼䱣䰘ᓎ䆂ⱘ⬉⑤ᯊˈ䆒໛䖬ヺড়
2006/95/EC Ԣ⬉ᣛҸⱘ㽕∖DŽ᳝݇݊Ҫֵᙃˈ䇋㘨㋏˖
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
བᵰ䗮䖛≵᳝ CE 󰵼䆄Ϩϡヺড়Ԣ⬉ᣛҸⱘ䆒໛ ˄བˈ⬉⑤ǃϾҎ䅵ㅫᴎ
ㄝ˅Փ⫼៥Ӏⱘѻકˈ Honeywell ϡ䋳ӏԩ䋷ӏDŽ
CE!㧁娴ẋ堐㛔墅伖䫎⎰!2004/108/EC EMC!㊯Ẍ炻思⽒㧁㸾!EN55022 CLASS
BˣEN55024ˣEN61000-3-2!␴
!EN61000-3-3ˤ2011/65/EU ROHS
(Recast).. 劍㛔㨇䳬旬ⷞ⺢嬘ἧ䓐䘬暣㸸墅伖炻⎴㗪ḇ䫎⎰!2006/95/EC!Ỷ暣!!
⡻㊯Ẍˤ!⤪暨忚ᶨ㬍屯妲炻婳倗䴉烉
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
劍惵⎰㛒㧁䣢 CE ⍲ᶵ䫎⎰Ỷ暣⡻㊯Ẍ䘬姕⁁ ( ⌛暣㸸ὃㅱ☐ˣᾳṢ暣儎䫱䫱 ) ἧ䓐ㆹᾹ
䘬䓊⑩炻Honeywell 㤪ᶵ屈屔ˤ
CE 䮥䯃䭴䮺䭷ߪޔᧄⵝ⟎߇ 2004/108/EC EMC Directive ߩⷙᩰ EN55022
CLASS BޔEN55024ޔEN61000-3-2ޔEN61000-3-3. 2011/65/EU ROHS
(Recast). ߦḰ᜚ߒߡ޿ࠆߎߣࠍ␜ߒ߹ߔޕ߹ߚޔផᅑ㔚Ḯઃ߈ߢ಴⩄ߐࠇ
ߡ޿ࠆ႐วߪޔ2006/95/EC Low Voltage Directiveߦ߽Ḱ᜚ߒߡ޿߹ߔޕ⹦⚦
ߦߟ޿ߡߪޔ⸥ߦ߅໧޿วࠊߖߊߛߐ޿ޕ
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands

CE 䮥䯃䭴䮺䭷䈏䈭䈒 䇮 Low Voltage Directive㩷䈮ㆡว䈚 䈭 䈇ᯏེ㩷㩿 㔚Ḯⵝ⟎䇮 䊌䊷䉸 䊅
䊦㩷䉮 䊮䊏 䊠 䊷䉺 䈭䈬 㪀㩷䈫 䈫 䉅 䈮ᒰ␠䈱⵾ຠ䉕 ૶↪䈚 䈢႐ว䇮 Honeywell 䈲৻ಾ䈱⽿છ
䉕⽶䈇䉁䈞䉖䇯
CEG䖐㐐⏈ 2004/108/EC EMC Directive㢌G䖐㨴GEN55022 CLASS B, EN55024,
EN61000-3-2, EN61000-3-3. 2011/65/EU ROHS (Recast). 㡸G㨴㍌䚜㡸G㢌GGGGGGG
⴬䚝⏼␘ UG❄䚐 SGỀ㣙╌⏈G㤸㠄GḩἽ㣙㾌㝴G䚜󰾭G㥐ḩ╌⏈G󰶒㟤㜄⏈G2006/95/
EC Low Voltage Directive ⪰G㨴㍌䚜㡸G㢌⴬䚝⏼␘ UG㣄㉬䚐G⇨㟝㡴G␘㢀㡰⦐GⱬGGGGGGGG
㢌䚌㐐ὤGⵈ⣁⏼␘ U
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell ⏈Low Voltage Directive 㢌 㦤䚡㡸 㨴㍌䚌㫴 㙾Ḕ CE ὤ䝬⪰ 䟁☑䚌㫴 㙾㡴
㣙⽸ (㜼:㤸㠄 ḩἽ 㣙㾌 ,PC☥)㝴 䚜󰾭 ␭㇠ 㥐䖼㡸 ㇠㟝䚜㡰⦐㒜 ⵐ㈑䚌⏈ 㛨⛔䚐
ⱬ㥐㜄⓸ 㵹㢸㡸 㫴㫴 㙾㏩⏼␘ .
Маркировка СЕ означает соответствие Директиве по
электромагнитной совместимости 2004/108/EC со стандартами
EN55022 CLASS B, EN55024, EN61000-3-2, EN61000-3-3. 2011/
65/EU ROHS (Recast).Кроме того,соответствие Директиве по
низкому напряжению 2006/95/EC при отправке с рекомендуемым
источником питания.Для получения более подробной информации
обращайтесь по адресу:
Hand Held Products Europe B.V.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Компания Honeywell не несет ответственность за использование нашего
товара с оборудованием (например,источниками питания,
персональными компьютерами)без маркировки СЕ,которое не
соответствует Директиве по низкому напряжению.

Honeywell Scanning & Mobility Product
Environmental Information
Refer to www.honeywellaidc.com/environmental for the RoHS /
REACH / WEEE information.
Technical Assistance
Contact information for technical support, product service, and
repair can be found at www.honeywellaidc.com.
User Documentation
To download the CAPTUVO SL22/42 sled documentation, go to
www.honeywellaidc.com.
Limited Warranty
Refer to www.honeywellaidc.com/warranty_information for your
product’s warranty information.
Patents
For patent information, refer to www.hsmpats.com.

㦘㹡㦘⹂䓸德⚜䱿♙⚺摞䤓㪖幕㫋㆞
(Names and Content of Hazardous Substances or Elements)
捷ↅ⚜䱿Parts Name) 㦘㹡㦘⹂䓸德㒥⏒侯
(Toxic and Hazardous Substances or Elements)
杔
(Pb)
㻭
(Hg)
柘
(Cd)
⏼ↆ杻
(Cr6+)
⮩䅃勣啾
(PBB)
⮩䅃ℛ啾
搩(PBDE)
◿Ⓠ䟄恾㨎3&% oooo o o
䜡䞡ഫ:HLJKW xooo o o
⏔䟄⣷$GDSWHU xooo o o
⮥⮂Housing) oooo o o
⬉⑤㒓Power Cord) xooo o o
o: 嫷䯉年㦘㹡㦘⹂䓸德⦷年捷ↅ㓏㦘⧖德㧟㠨₼䤓⚺摞⧖⦷ 6-7 㪖⑕屓⸩䤓棟摞尐㻑ⅴₚ (Indicates that
this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in
China’s SJ/T11363-2006.)
x: 嫷䯉年㦘㹡㦘⹂䓸德咂⺠⦷年捷ↅ䤓㩟₏⧖德㧟㠨₼䤓⚺摞怔⒉ 6-7 㪖⑕屓⸩䤓棟摞尐㻑 (Indicates
that this toxic or hazardous substance contained in at least one of the homogeneous materials for this part is
above the limit requirement in China’s SJ/T11363-2006. )

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make
changes in specifications and other information contained in this
document without prior notice, and the reader should in all cases
consult HII to determine whether any such changes have been
made. The information in this publication does not represent a com-
mitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages
resulting from the furnishing, performance, or use of this material.
HII disclaims all responsibility for the selection and use of software
and/or hardware to achieve intended results.
This document contains proprietary information that is protected by
copyright. All rights are reserved. No part of this document may be
photocopied, reproduced, or translated into another language with-
out the prior written consent of HII.
2014 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Apple, iPod touch, and iPhone are trademarks of Apple Inc., regis-
tered in the U.S. and other countries. App Store is a service mark of
Apple Inc.
