Honeywell Dolphin CT40 User manual

User Guide
Dolphin™ CT40 Display Dock
Model CT40-DB

Disclaimer
Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in
this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes
have been made. The information in this publication does not represent a commitment on the part of HII.
HII shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential
damages resulting from the furnishing, performance, or use of this material. HII disclaims all responsibility for the selec-
tion and use of software and/or hardware to achieve intended results.
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this doc-
ument may be photocopied, reproduced, or translated into another language without the prior written consent of HII.
Copyright 2018-2019 Honeywell International Inc. All rights reserved.
Web Address: www.honeywellaidc.com
Trademarks
Android is a trademark of Google LLC.
DisplayLink is a registered trademark of DisplayLink (UK) Limited.
Other product names or marks mentioned in this document may be trademarks or registered trademarks of other compa-
nies and are the property of their respective owners.
Patents
For patent information, refer to www.hsmpats.com.

Dolphin CT40 Display Dock i
TABLE OF CONTENTS
Customer Support ........................................................................................................................ iii
Technical Assistance ............................................................................................................. iii
Product Service and Repair ................................................................................................ iii
Limited Warranty .................................................................................................................... iii
Chapter 1 - About the Display Dock .............................................................. 1
About the Dolphin CT40 Display Dock .................................................................................. 1
Out of the Box............................................................................................................................ 1
Features of the Dock............................................................................................................... 1
About the Dock Status LED ................................................................................................. 2
About the Dock Connectors .......................................................................................................2
Connect to Power..................................................................................................................... 2
Connect to Monitor................................................................................................................. 2
Connect to an Ethernet Network ....................................................................................... 3
Connect to an USB Device ................................................................................................... 3
Chapter 2 - Use the Display Dock...................................................................5
Check Software on Computer ................................................................................................... 5
Install DisplayLink Software...................................................................................................... 5
Download the APK................................................................................................................... 5
Install the Software ................................................................................................................. 6
Insert CT40 Computer into the Dock ..................................................................................... 6
Chapter 3 - Configure the Display App.........................................................9
How to Configure the Display Dock Settings...................................................................... 9

ii Dolphin CT40 Display Dock
Start the Display Dock Settings App.................................................................................9
Set Display Dock Settings.....................................................................................................9
Set Screen Settings...........................................................................................................9
Set Peripheral Settings.................................................................................................10
Appendix A - Specifications.......................................................................... 11
Label Locations............................................................................................................................11
Connected Devices and Specifications ..............................................................................11
Monitor Connections...........................................................................................................11
Supported Devices .........................................................................................................11
Non-Supported Devices...............................................................................................11
USB Devices ............................................................................................................................12
Supported Devices .........................................................................................................12
Non-Supported Devices...............................................................................................12
Power Supply Specifications...................................................................................................12
Clean the Dock..............................................................................................................................12
Mount the Display Dock............................................................................................................12

Dolphin CT40 Display Dock iii
Customer Support
Technical Assistance
To search our knowledge base for a solution or to log in to the Technical Support
portal and report a problem, go to www.hsmcontactsupport.com.
For our latest contact information, see www.honeywellaidc.com/locations.
Product Service and Repair
Honeywell International Inc. provides service for all of its products through service
centers throughout the world. To obtain warranty or non-warranty service, return
your product to Honeywell (postage paid) with a copy of the dated purchase
record. To learn more, go to www.honeywellaidc.com and select Service & Repair at
the bottom of the page.
Limited Warranty
For warranty information, go to www.honeywellaidc.com and click Get Resources >
Product Warranty.

iv Dolphin CT40 Display Dock

CHAPTER
1
Dolphin CT40 Display Dock 1
ABOUT THE DISPLAY DOCK
This chapter introduces the Dolphin™ CT40 Display Dock. Use this chapter to learn
about the basic dock features and how to connect to the dock.
Note: For more information on the Dolphin CT40 Mobile Computer, go to
www.honeywellaidc.com.
About the Dolphin CT40 Display Dock
The Display Dock allows the CT40 to become a personal computer. A monitor, key-
board, mouse, and audio can be connected through the dock via the USB ports.
The dock also provides an Ethernet connection.
Out of the Box
Make sure that your shipping box contains these items:
• CT40 Display Dock (CT40-DB)
•Poweradapter
•Powercord
• Regulatory Sheet
If any of these items are missing or appear damaged, contact Customer Support.
Keep the original packaging in the event that you need to return the Display Dock
for service or if you want to store the charger when not in use.
Features of the Dock
Caution: We recommend the use of Honeywell accessories and power
adapters. Use of any non-Honeywell accessories or power
adapters may cause damage not covered by the warranty.

2Dolphin CT40 Display Dock
Note: The dock supports USB direct connections only. The dock does not support USB hub
connections, including keyboards with USB port(s).
About the Dock Status LED
About the Dock Connectors
Connect to Power
1. Plug the power cord into the power supply.
2. Plug the power supply cable into the power jack on the back of the dock.
3. Plug the power cord into a standard wall outlet.
Connect to Monitor
Note: See Monitor Connections for a list of approved connections.
1. Plug the HDMI cable into the dock.
2. Plug the other end of the HDMI cable into the monitor.
HDMI LED USB Ports
(See Note)
USB Port
(See Note)
DC
Power
Jack
Ethernet
Port
HDMI
Port
Status Description
Constant Green The dock is connected through HDMI.
Off The dock is not connected or lost connection through HDMI.
Warning: Ensure all components are dry prior to mating terminals/
batteries with peripheral devices. Mating wet components may
cause damage not covered by the warranty.

Dolphin CT40 Display Dock 3
Connect to an Ethernet Network
1. Plug the Ethernet cable into the dock.
2. Place the CT40 computer in the dock.
Note: For advanced Ethernet settings, go to www.honeywellaidc.com for the Dolphin CT40
User Guide.
Connect to an USB Device
Note: See USB Devices for a list of approved USB devices.
Note: The dock supports USB direct connections only. The dock does not support USB hub
connections, including keyboards with USB port(s).
Plug the USB type A cable into a USB port on the dock.

4Dolphin CT40 Display Dock
