Honeywell SmartLine RMA800 User manual

Honeywell Process Solutions
Foundation Fieldbus
RMA803 Remote Indicator
User's Guide
34-ST-25-51
Revision 4
March 2020

Page ii Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Copyrights, Notices and Trademarks
© Copyright 2020 by Honeywell, Inc.
Revision 4, March 2020
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as
may be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information
and specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International
Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1250 W Sam Houston Pkwy S
Houston, TX 77042

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page iii
About This Document
This guide provides the details of programming Honeywell RMA803 Remote Indicator for applications
involving FOUNDATION Fieldbus protocol. For installation, wiring, and maintenance information, refer to
the RMA803 Remote Indicator User Manual.
The configuration of your Remote Indicator depends on the mode of operation and the options selected for it
with respect to operating controls, displays and mechanical installation.
An RMA803 Remote Indicator can be digitally integrated with:
•Experion PKS, you need to supplement the information in this document with the data and procedures in
the Experion PDF Collection.
Release Information
Document Name
Foundation Fieldbus RMA803 Remote Indicator
User's Guide
Document ID
34-ST-25-51 Release
Number Publication Date
1st Release 1 June 2014
Ferrite core info added 2 September 2014
FM Approvals updated. Certs updated to include 801 3 February 2019
SAEx approval added 4 March 2020
References
The following list identifies all documents that may be sources of reference for material discussed in this
publication.
Quick Start Installation Guide, # 34-ST-25-52
HART/DE Option User Manual, Document # 34-ST-25-40

Page iv Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Patent Notice
The Honeywell Remote Indicator family is covered by one or more of the following U. S. Patents: 5,485,753;
5,811,690; 6,041,659; 6,055,633; 7,786,878; 8,073,098; and other patents pending.
Support and Contact Information
For Europe, Asia Pacific, North and South America contact details, see back page or refer to the appropriate
Honeywell Solution Support web site:
Honeywell Corporate www.honeywellprocess.com
Honeywell Process Solutions https://www.honeywellprocess.com/remote-meter-assemblies
Training Classes www.honeywellprocess.com/en-US/training
Telephone and Email Contacts
Area Organization Phone Number
United States
and Canada Honeywell Inc. 1-800-343-0228 Customer Service
1-800-423-9883 Global Technical Support
Global Email
Support Honeywell Process Solutions [e-mail]
Field Product
Sales Honeywell Process Solutions [e-mail]

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page v
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special
consideration.
TIP: Identifies advice or hints for the user, often in terms of
performing a task.
REFERENCE -EXTERNAL: Identifies an additional source of
information outside of the bookset.
REFERENCE - INTERNAL: Identifies an additional source of
information within the bookset.
CAUTION
Indicates a situation which, if not avoided, may result in equipment
or work (data) on the system being damaged or lost, or may result in
the inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used
to alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING: Indicates a potentially hazardous situation, which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or
60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which
equipment may be sensitive. Observe precautions for handling
electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the
protective earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as
noise immunity improvement. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance
with national local electrical code requirements.

Page vi Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Symbol Definition
Earth Ground:Functional earth connection. NOTE: This
connection shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.
Chassis Ground: Identifies a connection to the chassis or frame of
the equipment shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page vii
Terms and Acronyms
Term Definition
Alarm The detection of a block leaving a particular state and when
it returns back to that state.
Analog Input (function
block) One of the standard function blocks define by the Foundation Fieldbus
AP Absolute Pressure
Application A software program that interacts with blocks, events and
objects. One application may interface with other
applications or contain more than one application.
AWG American Wire Gauge
Block A logical software unit that makes up one named copy of a
block and the associated parameters its block type specifies.
It can be a resource block, transducer block or a function
block.
Configuration (of a
system or device)
A step in system design: selecting functional units, assigning
their locations and identifiers, and defining their
interconnections.
Device A physical entity capable of performing one or more specific
functions. Examples include Remote Indicators, actuators,
controllers, operator interfaces.
DCS (Distributed Control System)
DD Device Description
Device Description Description of FBAPs within a device. Files that describe the
software objects in a device, such as function blocks and
parameters. The DD binary are created by passing DD
source files through a standard tool called a tokenizer.
Device Description
Language A standardized programming language (similar to C) used to write device description source files.
Device Tag The Physical Device Tag of the device as specified in the
Foundation Fieldbus specifications.
DP Differential Pressure
DTM Device Type Manager
EDD Electronic Device Description
EDDL
Electronic Device Description Language
EEPROM Electrically Erasable Programmable Read Only Memory
EMI Electromagnetic Interference
Event An instantaneous occurrence that is significant to scheduling
block execution and to the operational (event) view of the
application.
Field Device A fieldbus-compatible device that contains and executes
function blocks.

Page viii Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Term Definition
FDT
Flash Download Tool
FF Foundation Fieldbus
Foundation Fieldbus Communications protocol for a digital, serial, two-way
system which interconnects industrial field equipment such
as sensors, actuators and controllers.
FTA Field Termination Assembly
Function Block An executable software object that performs a specific task,
such as measurement or control, with inputs and outputs
that connect to other function blocks in a standard way.
Function Block
Application Process The part of the device software that executes the blocks (function, transducer, or resource blocks).
Hz Hertz
IDE Integrated Development Environment
inH2O Inches of Water
LGP In-Line Gauge Pressure
Link Active Scheduler A device which is responsible for keeping a link operational.
The LAS executes the link schedule, circulates tokens,
distributes time messages and probes for new devices.
LRL Lower Range Limit
LRV Lower Range Value
Macrocycle The least common multiple of all the loop times on a given
link.
mAdc Milliamperes Direct Current
Manufacturer's Signal
Processing A term used to describe signal processing in a device that is not defined by FF specifications.
MAO Multiple Analog Output
mmHg Millimeters of Mercury
mV Millivolts
Network Management A part of the software and configuration data in a Foundation
Fieldbus device that handles the management of the
network.
Network Management
Agent Part of the device software that operates on network management objects.
Network Management
Information Base A collection of objects and parameters comprising configuration, performance and fault-related information for
the communication system of a device.
Nm Newton. Meters
NPT National Pipe Thread
NVM Non-Volatile Memory

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page ix
Term Definition
Object Dictionary Definitions and descriptions of network visible objects of a
device. There are various object dictionaries within a device.
The dictionaries contain objects and their associated
parameters which support the application in which they are
contained.
Objects Entities within the FBAP, such as blocks, alert objects, trend
objects, parameters, display lists, etc.
OOS Out Of Service
P Pressure
Pa Measured static pressure in PV4 algorithm
Parameters A value or variable which resides in block objects
Pdp Measured differential pressure in Pascals in PV4 algorithm
PM Process Manager
Proportional Integral
Derivative control A standard control algorithm. Also refers to a PID function block.
PSI Pounds per Square Inch
PSIA Pounds per Square Inch Absolute
Pu Static pressure at upstream point
PV Process Variable
PWA Printed Wiring Assembly
RFI Radio Frequency Interference
RMA Remote Meter Assembly
RTD Resistance Temperature Detector
Stack The software component that implement the Foundation
Fieldbus communications protocol specifications, including
FMS, FAS, DLL, SM and NM.
Status A coded value that qualifies dynamic variables (parameters)
in function blocks. This value is usually passed along with
the value from block to block. Status is fully defined in the FF
FBAP specifications.
System Management Provides services that coordinate the operation of various
devices in a distributed fieldbus system.
System Management
Agent Part of the device software that operates on system management objects.
System Management
Information Base A collection of objects and parameters comprising configuration and operational information used for control of
system management operations.
TAC Technical Assistance Center
Trim Point A selected reference point at which a measurement is
calibrated.
URL Upper Range Limit

Page x Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Term Definition
URV Upper Range Value
US Universal Station
Vac Volts Alternating Current
Vdc Volts Direct Current
Virtual
Communication
Reference
A defined communication endpoint. Fieldbus
communications can primarily only take place along an
active communications "path" that consists of two VCR
endpoints.
Virtual Field Device A logical grouping of "user layer" functions. Function blocks
are grouped into a VFD, and system and network
management are grouped into a VFD.
For example, to establish communications between a
transducer block and a function block, a VCR must be
defined at the transducer block and a VCR must be defined
at the function block.

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page xi
Contents
1. INTRODUCTION ........................................................................... 1
1.1 About the RMA803 Remote Indicator............................................................ 1
1.2 Features and Options..................................................................................... 3
1.3 RMA803 major assembly and electronic housing components.................4
1.4 Features of a Remote Indicator..................................................................... 5
1.5 RMA803 Remote Indicator Nameplate .......................................................... 6
1.6 Safety Certification Information .................................................................... 6
1.7 Display Options............................................................................................... 6
1.8 Optional 3-Button Assembly.......................................................................... 6
2. GETTING STARTED..................................................................... 7
2.1 Verifying the installation ................................................................................ 7
Verifying Remote Indicator installation tasks..........................................................................7
2.2 Verifying communication with the Remote Indicator.................................. 8
Identify the Remote Indicator.................................................................................................8
2.3 Establishing communication with host systems......................................... 9
Device Description (DD).........................................................................................................9
Enhanced Device Description (EDD).....................................................................................9
Device Type Manager (DTM).................................................................................................9
3. INSTALLATION AND STARTUP................................................ 11
3.1 Installation Site Evaluation ..........................................................................11
3.2 Display Installation Precautions.................................................................. 11
3.3 Mounting Remote Indicator..........................................................................11
Summary..............................................................................................................................11
Mounting Dimensions...........................................................................................................12
Bracket Mounting Procedure................................................................................................12
3.4 Wiring a Remote Indicator............................................................................ 13
Overview..............................................................................................................................13
Wiring Procedure.................................................................................................................13
Fieldbus Network Wiring......................................................................................................14
Lightning Protection.............................................................................................................14
Supply Voltage Limiting Requirements................................................................................14
Explosion-Proof Conduit Seal..............................................................................................14
4. OPERATION................................................................................ 15
4.1 Overview ........................................................................................................15
4.2 Three-Button Operation................................................................................15
4.3 Menu Navigation ...........................................................................................16
4.4 Data Entry ......................................................................................................16

Page xii Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
4.5 Editing a Numeric Value............................................................................... 17
Selecting a new setting from a list of choices ......................................................................17
The Advanced Display Menus.............................................................................................18
4.6 Advanced Displays....................................................................................... 25
Button operation during monitoring......................................................................................27
5. RMA803 FF REMOTE INDICATOR CONFIGURATION ............. 28
5.1 Importing the RMA803 FF Device Description (DD) files.......................... 28
Importing the DD to Experion PKS.......................................................................................28
5.2 Configuring the function block application process................................. 32
About the Function Block Application Process (FBAP)........................................................32
Block Alarms........................................................................................................................32
Process Alarms....................................................................................................................34
5.3 Resource block ............................................................................................. 35
Configuring the Resource block...........................................................................................35
RESTART............................................................................................................................35
Execution.............................................................................................................................36
CYCLE TYPE ......................................................................................................................36
MEMORY.............................................................................................................................36
MAX NOTIFY.......................................................................................................................36
FEATURES..........................................................................................................................36
Reports................................................................................................................................36
SOFT W LOCK and HARD W LOCK...................................................................................37
Field Diagnostics..................................................................................................................38
Parameter List .....................................................................................................................41
5.4 Diagnostic Transducer block....................................................................... 45
Execution.............................................................................................................................45
Parameter List .....................................................................................................................46
5.5 LCD Transducer block.................................................................................. 48
Execution.............................................................................................................................48
Advanced Display................................................................................................................48
Parameters List....................................................................................................................51
5.6 Proportional Integral Derivative (PID) block with auto tune..................... 54
Execution.............................................................................................................................55
Auto tuning...........................................................................................................................58
Auto tuning procedure..........................................................................................................58
Parameter list.......................................................................................................................59
Attributes..............................................................................................................................63
5.7 Input Selector block...................................................................................... 64
Execution.............................................................................................................................64
Parameters List....................................................................................................................66
Attributes..............................................................................................................................68
5.8 Integrator block............................................................................................. 69
Execution.............................................................................................................................69
Parameters List....................................................................................................................75
Attributes..............................................................................................................................77
5.9 Arithmetic block............................................................................................ 78
Execution.............................................................................................................................78
Parameter List .....................................................................................................................81
Attributes..............................................................................................................................82
5.10 Signal Characterizer block....................................................................... 83
Execution.............................................................................................................................83
Parameter list.......................................................................................................................85
Attributes..............................................................................................................................86

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page xiii
5.11 MAO Block ................................................................................................. 87
Execution.............................................................................................................................87
Parameter list.......................................................................................................................88
Attributes..............................................................................................................................89
5.12 Configuring the Remote Indicator using Field Device Manager (FDM) system 89
6. RMA803 FF REMOTE INDICATOR OPERATION...................... 90
6.1 Operational considerations..........................................................................90
LAS Capability .....................................................................................................................90
Special Non-volatile parameters and NVM Wear-out...........................................................90
Mode Restricted Writes to Parameters................................................................................90
6.2 Configuration of the RMA803 Remote Indicator using Handheld (HH)... 90
6.3 Performing block instantiation.................................................................... 91
About block instantiation......................................................................................................91
Block instantiation using Experion PKS...............................................................................91
7. RMA803 FF REMOTE INDICATOR MAINTENANCE................. 92
7.1 Overview ........................................................................................................92
7.2 Preventive Maintenance Practices and Schedules ...................................92
7.3 Replacing the Local Display and Communication Electronic Assembly 92
7.4 Downloading the firmware........................................................................... 94
About firmware download feature ........................................................................................94
Class 3.................................................................................................................................94
Recommendations...............................................................................................................94
Downloading the File............................................................................................................95
7.5 Licensing for Function Blocks ....................................................................96
8. RMA803 FF REMOTE INDICATOR TROUBLESHOOTING....... 97
8.1 Troubleshooting overview ...........................................................................97
Device status and faults.......................................................................................................97
8.2 Troubleshooting the Remote Indicator.......................................................98
Device not visible on the network.........................................................................................98
Incorrect or non-compatible tools.........................................................................................99
8.3 Troubleshooting blocks .............................................................................100
Non-functioning blocks.......................................................................................................100
Troubleshooting block configuration errors........................................................................100
Troubleshooting the Resource block..................................................................................100
Troubleshooting the Diagnostics Transducer block ...........................................................101
Troubleshooting the LCD Transducer block.......................................................................102
Troubleshooting the Proportional Integral Derivative (PID) block.......................................103
Troubleshooting the Input Selector block...........................................................................104
Troubleshooting the Integrator block..................................................................................106
Troubleshooting the Arithmetic block.................................................................................107
Troubleshooting the Signal Characterizer block.................................................................108
Resolving the block configuration errors............................................................................109
8.4 Device Diagnostics ..................................................................................... 110
RMA803 FF Remote Indicator memory..............................................................................110
Performing diagnostics in the background.........................................................................110
BLOCK_ERR parameter....................................................................................................110
Background Diagnostics Execution, BLOCK_TEST parameter.........................................110

Page xiv Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
8.5 Restoring the Remote Indicator to default settings................................ 111
Remote Indicator Diagnostics............................................................................................111
Function Block Faults.........................................................................................................111
8.6 Understanding simulation mode............................................................... 112
About simulation mode jumper ..........................................................................................112
Setting simulation jumper...................................................................................................112
Enabling simulation mode..................................................................................................113
Simulation mode truth table...............................................................................................113
8.7 Understanding write protection................................................................. 114
8.8 Critical Diagnostics Screens ..................................................................... 114
Fault Conditions and Recommended Corrective Actions...................................................114
9. PARTS LIST.............................................................................. 115
9.1 Overview ...................................................................................................... 115
APPENDIX A. PRODUCT CERTIFICATIONS ................................... 118
10. INDEX........................................................................................ 126

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page xv
Tables
Table 1: Feature and Options..........................................................................................3
Table 2: Available Display Characteristics ...................................................................... 6
Table 3: Remote Indicator installation verification tasks .................................................7
Table 4: Remote Indicator parameters............................................................................ 8
Table 5: Three-Button Option Functions .......................................................................16
Table 6: Three-Button Data Entry..................................................................................17
Table 7: Advanced Display Main Menu Structure.........................................................18
Table 8: Diagnostics Menu............................................................................................18
Table 9: Display Setup Menus.......................................................................................19
Table 10: Information Menus.........................................................................................22
Table 11: Advanced Displays with PV Format Display Indications...............................26
Table 12: Bit mapping of the BLOCK_ERR...................................................................32
Table 13: Priority for Alarms..........................................................................................34
Table 14: Diagnostic Definitions....................................................................................38
Table 15: Resource block parameters ..........................................................................41
Table 16: Diagnostic Transducer block parameters......................................................46
Table 17: LCD parameters............................................................................................ 49
Table 18: LCD Transducer block parameters ...............................................................51
Table 19: PID Tuning parameters .................................................................................57
Table 20: PID block parameters....................................................................................59
Table 21: Input Selector block parameters....................................................................66
Table 22: Integrator block parameters ..........................................................................75
Table 23: Arithmetic block parameters..........................................................................81
Table 24: Signal Characterizer block parameters.........................................................85
Table 25: MAO block parameters..................................................................................88
Table 26: Resource block............................................................................................ 100
Table 27: Diagnostics Transducer block .....................................................................101
Table 28: LCD Transducer block.................................................................................102
Table 29: PID block .....................................................................................................103
Table 30: Input Selector block.....................................................................................104
Table 31: Integrator block............................................................................................106
Table 32: Arithmetic block ...........................................................................................107
Table 33: Signal Characterizer block...........................................................................108
Table 34: Resolving block configuration errors...........................................................109
Table 35: Diagnostics.................................................................................................. 110
Table 36: Setting the Simulation Jumper ....................................................................113
Table 37: Simulation Mode Truth Table ......................................................................113
Table 38: Write lock.....................................................................................................114
Table 39: Fault Conditions and Recommended Corrective Actions............................114
Table 40: Summary List of Recommended Spare Parts.............................................115
Table 41: Pipe and Wall Bracket Parts (Refer to Figure 25).......................................115
Table 42: Remote Indicator Major Assemblies............................................................117

Page xvi Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Figures
Figure 1: RMA803 Major assemblies .............................................................................. 4
Figure 2: Electronic Housing components....................................................................... 4
Figure 3: Typical Bracket Mounted Installations............................................................ 11
Figure 4: Pipe Mounting Bracket Secured to a Horizontal or Vertical Pipe...................12
Figure 5: Two Position FF Terminal Block .................................................................... 13
Figure 6: Three-Button Option....................................................................................... 15
Figure 7: Locating Simulation and Write Protect Jumpers............................................ 23
Figure 8: Advanced Display Formats with the Process Variable ..................................25
Figure 9: LCD Transducer block ................................................................................... 48
Figure 10: PID block...................................................................................................... 54
Figure 11: PID block schematic diagram....................................................................... 54
Figure 12: Input Selector block...................................................................................... 64
Figure 13 : Input Selector schematic diagram............................................................... 65
Figure 14: Integrator Block............................................................................................ 69
Figure 15: Two Rate Inputs........................................................................................... 70
Figure 16: Arithmetic block............................................................................................ 78
Figure 17: Arithmetic schematic diagram...................................................................... 79
Figure 18: Signal Characterizer Block........................................................................... 83
Figure 19: Signal characterizer curve............................................................................ 84
Figure 20: Multiple Analog Output block ....................................................................... 87
Figure 21: Connecting the Remote Indicator to the handheld....................................... 91
Figure 22: PWA Replacement....................................................................................... 92
Figure 23: Simulation Write Lock Jumper Location on Comms Module assembly..... 112
Figure 24: Local Display Fault Diagnostic Conditions................................................. 114
Figure 25: Pipe and Wall Bracket Parts ...................................................................... 115
Figure 26: Electronic Housing, Display End................................................................ 116
Figure 27: Electronic Housing, Terminal Block End.................................................... 117

Revision 3 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page 1
1. Introduction
1.1 About the RMA803 Remote Indicator
The Honeywell RMA803 is a Foundation Fieldbus Remote Indicator that provides the following
benefits to the user:
Connectivity
The RMA803 can be used with any Foundation Fieldbus device. The values from these Fieldbus
devices can be connected to the RMA803 via the MAO function block (for example) and then sent
to the LCD display via the LCD Transducer block. The RMA803 can display up to eight (8) values
from the devices on the H1 segment.
Mounting
The RMA803 can be connected anywhere along the H1 segment, providing easy access to data from
devices that are mounted in inaccessible locations. The LCD module can be rotated in 90 degree
increments, allowing the RMA803 to be mounted in any orientation.
Capacity
The RMA803 can display up to eight (8) function block values. The RMA803 will automatically
rotate through these values at a user-configurable rate. The user can also step through the values on-
demand using the local pushbuttons.
LCD Display formats
The RMA803 provides three user-friendly formats, including bar graph and trend. The scale limits
of the bar graph and trend are configured by the user to allow optimum visibility of the process
value. The trend format will plot the trend of the selected function block value. The duration of the
trend is configured by the user, providing up to 24 hours of history for the selected value.
Custom labeling
The user can enter a custom tag for each screen to provide clear identification of the displayed value.
The user can also enter custom units for each screen, or select the units from a predefined list. The
length of the custom tag is 14 characters; the length of the custom units label is 8 characters.
Additional calculation and control
The RMA803 provides a robust set of function blocks that can be used to provide additional
calculation and control capability.
Backup Link Active Scheduler (LAS)
The RMA803 can also be configured as backup LAS, allowing the Fieldbus devices on the H1
segment to continue operating if the primary LAS fails.

Page 2 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
Additional Function Blocks
The RMA803 consists of two Application Software options, which are:
•Standard Operating Software – Consists of Resource block, AI block, LCD Transducer block,
Diagnostic Transducer block, and MAO (Multiple Analog Output) function block
•Additional Function Blocks – Consists of PID block, Signal Characterizer block, Arithmetic
block, Input Selector block and Integrator block. Refer to Section 7.5 for more details.
Note: Additional Function blocks are available post liscensing.

Revision 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Page 3
1.2 Features and Options
The RMA803 Foundation Fieldbus Remote Indicator has the following features:
Table 1: Feature and Options
Feature/Option Standard/Available Options
Communication Protocols Fieldbus and only Advanced Display
Human-Machine Interface (HMI)
Options (Advanced Display) Advanced Digital Display:
0, 90, 180, & 270 degree viewing position adjustments
Standard and custom measurement units available.
Up to eight display screens with 3 formats are possible (Large
PV or PV with Bar Graph or PV with Trend Graph)
Configurable screen rotation timing (4 to 30 sec)
Ability to enable/disable screen rotation
Three-button programming (optional)
Advanced display languages:
East Asian: EN, CH, JP
Western: EN, GE, FR, IT, SP, RU, TU
Approvals (See Appendix C for details.) ATEX, CSA, FM, IECx, NEPSI
Mounting Brackets Pipe mounting and wall mounting brackets in carbon steel and
316 stainless steel.
# of Devices/ Segments Entity IS model: 6 devices/segment
Schedule Entries 46 (max)
# of VCRs50 (max), 50-link objects
Compliance Testing Tested according to ITK 6.1.1
Software Download Class-3 of the Common Software Download procedure as per
FF-883.

Page 4 Foundation Fieldbus RMA803 Remote Indicator User's Guide Revision 4
1.3 RMA803 major assembly and electronic housing
components
The following illustrations depict the major assembly and electronic housing components.
Figure 1: RMA803 Major assemblies
Figure 2: Electronic Housing components
