Honeywell AD1200-CT User manual

AD1200-CT
Three Phase DIN-RAIL Meter
Product Manual

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
Contents
1. Overview...............................................................................................................................................2
2．Introduction ......................................................................................................................................2
2.1 Device description ........................................................................................................................2
2.2 Standards and References........................................................................................................2
2.3 Characteristics...............................................................................................................................2
3. Basic Parameters .............................................................................................................................3
4. Mechanical Construction ..............................................................................................................4
4.1 Outline Dimensions .....................................................................................................................4
4.2 Connection Diagram.....................................................................................................................4
5. Meter functions ................................................................................................................................4
5.1 Communication............................................................................................................................4
5.2 Button................................................................................................................................................4
5.3 Backlight ..........................................................................................................................................5
5.4 Pulse output....................................................................................................................................5
5.5 LCD display content ....................................................................................................................5
5.5.1 Parameters show on the LCD screen.............................................................................5
5.6 System parameters address.....................................................................................................8
6. Installation Instruction ............................................................................................................11
6.1 Installation instructions..........................................................................................................11
6.2 Installation instruction details .............................................................................................12
7. Safety Instructions ....................................................................................................................13

1. Overview
A Din Rail CT three-phase four wire meter electronic meter. This meter complies with
the standards of IEC62052-11 and IEC62053-21. It has the capability of measuring
the consumption of active as well as reactive energy. It has many advantages, such as
good reliability, small volume, light weight and easy installation.
2．Introduction
2.1 Device description
Type
Connec
tion
Un
Ib (Imax)
fn
Imp/
kWh
Accuracy Class
AD1200
CT
Connec
t
3*230/400V
5(6) A
CT Connect
50/6
0Hz
1200
0
Activ
e
Cl. 1
2.2 Standards and References
The AD1200 meets and operates in accordance with the following Standards:
IEC 62052-11-
2003
Electricity metering equipment (a.c.) –General
requirements, tests, and test conditions –Part 11: Metering
equipment
IEC 62053-21-
2003
Electricity metering equipment (a.c.) –Particular
requirements –Part 21: Static meters for active energy
(classes 1 and 2)
2.3 Characteristics
➢Three phase active/reactive energy
➢Positive and negative measurement
➢Four tariffs.
➢It can be set to five measurement modes according to the synthesis code.
➢CT setting: 5:5—7500:5 CT ratio.
➢Maximum demand calculation.
➢A button can reset the energy.

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
3. Basic Parameters
Description
Values
Meter Type
Three phase, Four-Wire, CT Connected
Accuracy
Active Class 1.0 (IEC 62053-21)
Nominal Voltage Un
3*230 /400V
Current Range
5 (6)A
Nominal Frequency fn
50Hz
Starting Current
0.2% In
Meter Constant
12000 imp/kWh
Start-up Time
≤ 5s
Power Consumption
Voltage circuit: ≦1W ,8VA
Current circuit at Ib: ≦4VA
Operating Voltage Range
Nominal Operating Voltage: 0.9Un～1.1 Un
Extended Operating Voltage: 0.8Un～1.15 Un
Specified operating temperature range
-20℃～+70℃
Limit operating temperature range
-25℃～+70℃
Limit Storage and transportation
temperature range
-40℃～+70℃
Relative Humidity
≦85%
Insulation
AC voltage test subjected to 4kV
Impulse voltage test subjected to 6kV

4. Mechanical Construction
4.1 Outline Dimensions
Height 100mm
Width 76mm
Depth 65mm
4.2 Connection Diagram
5. Meter functions
5.1 Communication
The meter supports both IR (near infrared) and RS485 communication. IR complies with
EN62056(IEC1107) protocol, and RS485 communication use the MODBUS protocol.
5.2 Button
The meter has two buttons, which can be display all the contents by pressing the buttons.
The CT ratio, LCD scroll display time, reset the energy and backlight mode can be set by the
buttons on the screen.

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
：
unused
5.3 Backlight
Through the button setting, it can be divided into three modes: it is on when the button has
been pressed, always on and always off.
5.4 Pulse output
Set 12000/1200/120/12, total four pulse output modes by communication.
5.5 LCD display content
5.5.1 Parameters show on the LCD screen
：reverse indicate(if shows the reverse power, then display the REV)
：total kWh indicate(if shows the total kWh and total tariff kWh, then display this sign)
：content indicate, it can be shown T1 and T2, L1 and L2
：power factor display
：frequency display
：kWh unit display, it can show kW, kWh, kvarh, V, A and kVA
Press the page button, and it will shift to another main page.
LCD Display Content
Page Content Unit LCD sign

1 Current direction
2 Combinatorial active total energy kWh Σ 0
3 Combinatorial active energy of tariff1 kWh Σ T1
4 Combinatorial active energy of tariff2 kWh Σ T2
5 Combinatorial active energy of tariff3 kWh Σ T3
6 Combinatorial active energy of tariff4 kWh Σ T4
7 Forward active total energy kWh Σ 1
8 Forward active energy of tariff1 kWh T1
9 Forward active energy of tariff2 kWh T2
10 Forward active energy of tariff3 kWh T3
11 Forward active energy of tariff4 kWh T4
12 Reverse active total energy kWh REV Σ 2
13 Reverse active energy of tariff1 kWh REV T1
14 Reverse active energy of tariff2 kWh REV T2
15 Reverse active energy of tariff3 kWh REV T3
16 Reverse active energy of tariff4 kWh REV T4
17 L1 total active energy kWh Σ L1
18 L1 forward active energy kWh L1
19 L1 reverse active energy kWh REV L1
20 L2 total active energy kWh Σ L2
21 L2 forward active energy kWh L2
22 L2 reverse active energy kWh REV L2
23 L3 total active energy kWh Σ L3
24 L3 forward active energy kWh L3
25 L3 reverse active energy kVarh REV L3
26 Combinatorial reactive total energy kVarh Σ 0
27 Combinatorial reactive energy of tariff1 kVarh Σ T1
28 Combinatorial reactive energy of tariff2 kVarh Σ T2
29 Combinatorial reactive energy of tariff3 kVarh Σ T3
30 Combinatorial reactive energy of tariff4 kVarh Σ T4
31 Forward reactive total energy kVarh Σ 1
32 Forward reactive energy of tariff1 kVarh T1
33 Forward reactive energy of tariff2 kVarh T2
34 Forward reactive energy of tariff3 kVarh T3
35 Forward reactive energy of tariff4 kVarh T4
36 Reverse reactive total energy kVarh REV Σ 2
37 Reverse reactive energy of tariff1 kVarh REV T1
38 Reverse reactive energy of tariff2 kVarh REV T2
39 Reverse reactive energy of tariff3 kVarh REV T3
40 Reverse reactive energy of tariff4 kVarh REV T4
41 L1 total reactive energy kVarh Σ L1
42 L1 forward reactive energy kVarh L1
43 L1 reverse reactive energy kVarh REV L1
44 L2 total reactive energy kVarh Σ L2

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
45 L2 forward reactive energy kVarh L2
46 L2 reverse reactive energy kVarh REV L2

5.6 System parameters address

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
Meter ID
(default)
Function
Code
Register
Address(Hex)
Register
Address(Dec)
Contents
Register No.
Read/Write
length
data
mode
01
03
0000
0
Serial number
1
Read
4
01
03
0002
2
Meter ID
2
Read
2
01
03
0003
3
Baud Rate
3
Read
2
01
03
0004
4
Software Version
4
Read
4
float
01
03
0006
6
Hardware Version
5
Read
4
float
01
03
0008
8
CT Rate
6
Read
2
01
03
0009
9
S0 output rate
7
Read
4
float
01
03
000B
11
Combined Code
8
Read
2
01
03
000C
12
HOLIDAY-WEEKEND T
9
Read
2
01
03
000D
13
Cycle time
10
Read
2
01
03
000E
14
L1 Voltage
11
Read
4
float
01
03
0010
16
L2 Voltage
12
Read
4
float
01
03
0012
18
L3 Voltage
13
Read
4
float
01
03
0014
20
Grid Frequency
14
Read
4
float
01
03
0016
22
L1 Current
15
Read
4
float
01
03
0018
24
L2 Current
16
Read
4
float
01
03
001A
26
L3 Current
17
Read
4
float
01
03
001C
28
Total Active Power
18
Read
4
float
01
03
001E
30
L1 Active Power
19
Read
4
float
01
03
0020
32
L2 Active Power
20
Read
4
float
01
03
0022
34
L3 Active Power
21
Read
4
float
01
03
0024
36
Total reactive power
22
Read
4
float
01
03
0026
38
L1 reactive power
23
Read
4
float
01
03
0028
40
L2 reactive power
24
Read
4
float
01
03
002A
42
L3 reactive power
25
Read
4
float
01
03
002C
44
Total Apparent Power
26
Read
4
float
01
03
002E
46
L1 Apparent Power
27
Read
4
float
01
03
0030
48
L2 Apparent Power
28
Read
4
float
01
03
0032
50
L3 Apparent Power
29
Read
4
float
01
03
0034
52
Total Power Factor
30
Read
4
float
01
03
0036
54
Power Factor
31
Read
4
float
01
03
0038
56
Power Factor
32
Read
4
float
01
03
003A
58
Power Factor
33
Read
4
float
01
03
003C
60
Time
34
Read
8
01
03
0040
64
Time switch
35
Read
2
01
03
0041
65
CRC CODE
36
Read
2
01
03
0100
256
Total Active Energy
35
Read
4
float
01
03
0102
258
L1 Total Active Energy
36
Read
4
float
01
03
0104
260
L2 Total Active Energy
37
Read
4
float
01
03
0106
262
L3 Total Active Energy
38
Read
4
float
01
03
0108
264
Forward Active Energy
39
Read
4
float
01
03
010A
266
L1 Forward Active Energy
40
Read
4
float
01
03
010C
268
L2 Forward Active Energy
41
Read
4
float
01
03
010E
270
L3 Forward Active Energy
42
Read
4
float
01
03
0110
272
Reverse Active Energy
43
Read
4
float
01
03
0112
274
L1 Reverse Active
Energy
44
Read
4
float
01
03
0114
276
L2 Reverse Active
Energy
45
Read
4
float
01
03
0116
278
L3 Reverse Active
Energy
46
Read
4
float
01
03
0118
280
Total Reactive Energy
47
Read
4
float
01
03
011A
282
L1 Reactive Energy
48
Read
4
float
01
03
011C
284
L2 Reactive Energy
49
Read
4
float

01
03
011E
286
L3 Reactive Energy
50
Read
4
float
01
03
0120
288
Forward Reactive Energy
51
Read
4
float
01
03
0122
290
L1 Forward Reactive
Energy
52
Read
4
float
01
03
0124
292
L2 Forward Reactive
Energy
53
Read
4
float
01
03
0126
294
L3 Forward Reactive
Energy
54
Read
4
float
01
03
0128
296
Reverse Reactive Energy
55
Read
4
float
01
03
012A
298
L1 Reverse Reactive
Energy
56
Read
4
float
01
03
012C
300
L2 Reverse Reactive
Energy
57
Read
4
float
01
03
012E
302
L3 Reverse Reactive
Energy
58
Read
4
float
01
03
0130
304
T1 Total Active Energy
59
Read
4
float
01
03
0132
306
T1 Forward Active
Energy
60
Read
4
float
01
03
0134
308
T1 Reverse Active
Energy
61
Read
4
float
01
03
0136
310
T1 Total Reactive Energy
62
Read
4
float
01
03
0138
312
T1 Forward Reactive
Energy
63
Read
4
float
01
03
013A
314
T1 Reverse Reactive
Energy
64
Read
4
float
01
03
013C
316
T2 Total Active Energy
65
Read
4
float
01
03
013E
318
T2 Forward Active
Energy
66
Read
4
float
01
03
0140
320
T2 Reverse Active
Energy
67
Read
4
float
01
03
0142
322
T2 Total Reactive Energy
68
Read
4
float
01
03
0144
324
T2 Forward Reactive
Energy
69
Read
4
float
01
03
0146
326
T2 Reverse Reactive
Energy
70
Read
4
float
01
03
0148
328
T3 Total Active Energy
71
Read
4
float
01
03
014A
330
T3 Forward Active
Energy
72
Read
4
float
01
03
014C
332
T3 Reverse Active
Energy
73
Read
4
float
01
03
014E
334
T3 Total Reactive Energy
74
Read
4
float
01
03
0150
336
T3 Forward Reactive
Energy
75
Read
4
float
01
03
0152
338
T3 Reverse Reactive
Energy
76
Read
4
float
01
03
0154
340
T4 Total Active Energy
77
Read
4
float
01
03
0156
342
T4 Forward Active
Energy
78
Read
4
float
01
03
0158
344
T4 Reverse Active
Energy
79
Read
4
float
01
03
015A
346
T4 Total Reactive Energy
80
Read
4
float
01
03
015C
348
T4 Forward Reactive
Energy
81
Read
4
float
01
03
015E
350
T4 Reverse Reactive
Energy
82
Read
4
float
01
03
0300
768
TIME interval 1
83
Read
24
01
03
030C
780
TIME interval 2
84
Read
24
01
03
0318
792
TIME interval 3
85
Read
24
01
03
0324
804
TIME interval 4
86
Read
24

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
6. Installation Instruction
6.1 Installation instructions
Installation staff should be experienced electrician or specialized person, and should ensure that they
have read this user guide.
During installation, if it comes across severe strike or falling, which causes obvious damage trace, don’t
install it or turn it on. Please contact us in time.
Before leaving our factory, all the meters have been checked out and lead sealed, they can be installed
directly.
Meters should be installed indoors or outdoors in a cabinet. The wall which is installed should be firm
and fireproof, besides, no corrosive gas in the air.
Meters should be installed according to the wiring diagram on terminal box. When inserting, using
copper wire or copper connector will be better.
01
03
0330
816
TIME interval 5
87
Read
24
01
03
033C
828
TIME interval 6
88
Read
24
01
03
0348
840
TIME interval 7
89
Read
24
01
03
0354
852
TIME interval 8
90
Read
24
01
03
0360
864
TIME zone
91
Read
24
01
06
0002
2
Meter ID
1
Write
2
01
06
0003
3
Baud Rate
2
Write
2
01
06
0008
8
CT Rate
3
Write
2
01
10
0009
9
SO OUTPUT
4
Write
4
float
01
06
000B
11
Combined Code
5
Write
2
01
06
000C
12
HOLIDAY-WEEKEND T
6
Write
2
01
06
000D
13
Cycle time
7
Write
2
01
10
003C
60
Time
8
Write
8
01
10
0300
768
TIME interval 1
9
Write
24
01
10
030C
780
TIME interval 2
10
Write
24
01
10
0318
792
TIME interval 3
11
Write
24
01
10
0324
804
TIME interval 4
12
Write
24
01
10
0330
816
TIME interval 5
13
Write
24
01
10
033C
828
TIME interval 6
14
Write
24
01
10
0348
840
TIME interval 7
15
Write
24
01
10
0354
852
TIME interval 8
16
Write
24
01
10
0360
864
TIME zone
17
Write
24

6.2 Installation instruction details
*Choose 35mm standard Din-Rail ( the length is confirmed by yourself ), fixed them in the location
which are waiting for installation;
*Push down the clip under the bottom of the meter for a gear, see fig. 1 and fig.2;
Fig.1 Fig.2
*Put the meter into the Din-rail as per Fig. 3, then push up the clip for a gear, install meter to the Din-
rail, see Fig. 4;
Fig. 3 Fig. 4
*Making the connection according to the wiring diagram;
*After connection, use lead sealing to seal terminal cover.
After
push
down
the
clip

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
Recommended wire（For your reference）：
Safe carrying capacity of rubber or plastic insulated wire(1)
specification（mm）
nominal cross
section
（mm2）
Safe carrying capacity（A）
BX
BLX
BV
BLV
1*1.13
1
20
18
1*1.37
1.5
25
22
1*1.76
2.5
33
25
30
23
1*2.24
4
42
33
40
30
1*2.73
6
55
42
50
40
7*1.33
10
80
55
75
55
7*1.76
16
105
80
100
75
7*2.12
25
140
105
130
100
7*2.50
35
170
140
160
125
19*1.83
50
225
170
205
150
19*2.14
75
280
225
255
185
19*2.50
95
340
280
320
240
Note ：BX(BLX ）copper （aluminum ）core rubber insulated wire or BV(BLV ）copper
（aluminum）core PVC plastic insulated wire，widely used in 500V or less than 500V AC and
DC power distribution system. The temperature for the data listed in the above table is 35℃、
the safe carrying capacity value for the wire on single coved.
7. Safety Instructions
Information for Your Own Safety

This manual does not contain all of the safety measures for operation of this equipment (module, device)
because special operating conditions, local code requirements or local regulations may necessitate
further measures. However, it does contain information which must be adhered to for your own personal
safety and to avoid damage to the equipment. This information is highlighted by a warning triangle with
an exclamation mark or a lightning bolt depending on the severity of the warning.
Warning
Means that failure to observe the instruction can result in death, serious injury or considerable material
damage.
Caution
Means hazard of electric shock and failure to take the necessary safety precautions will result in death,
serious injury or considerable material damage.
Qualified personnel
Installation and operation of this equipment described in this manual may only be performed by
qualified personal.
Only people that are authorized to install, connect and use this equipment and have the proper
knowledge about labeling and grounding electrical equipment and circuits and can do so according to
safety and regulatory standards are considered qualified personnel in the manual.
Use for the intend purpose
We have checked the contents of this publication and every effort has been made to ensure that the
descriptions are as accurate as possible. However, deviations from the description cannot be completely
ruled out, so that no liability can be accepted for any errors or omissions in the information given. The
data in this manual is checked regularly and the necessary corrections will be included in subsequent
editions. If you have any suggestions, please let us know.
General Warning
After removing the packaging make sure the integrity of the unit. If in doubt don't use the equipment
and contact technical staff.
Mounting of electric appliances must be carried out only by skilled electricians. It is imperative to
observe the generally applicable safety measures.

Product Manual
Honeywell | Smart Energy
Elster Kent Metering (Pty) Ltd
60 Commando Road, Industria Ext 2
Johannesburg, 2093
South Africa
In case of failure and /or malfunctioning of the device, turn off it. For any repair only contact technical
staff. Failure to comply with the above may compromise the device safety.
