Honeywell SmartLine RMA801 User manual

Honeywell Process Solutions
RMA801 Remote Indicator
User's Guide
34-ST-03-62
Revision 2.0
March 2019

Revision 2 RMA803 Remote Indicator User's Guide ii
Copyrights, Notices and Trademarks
© Copyright 2019 by Honeywell, Inc.
Revision 2, March 2019
While this information is presented in good faith and believed to be accurate, Honeywell disclaims the implied
warranties of merchantability and fitness for a particular purpose and makes no express warranties except as may
be stated in its written agreement with and for its customers.
In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and
specifications in this document are subject to change without notice.
Honeywell, PlantScape, Experion PKS, and TotalPlant are registered trademarks of Honeywell International Inc.
Other brand or product names are trademarks of their respective owners.
Honeywell Process Solutions
1250 W Sam Houston Pkwy S
Houston, TX 77042

iii RMA803 Remote Indicator User's Guide Revision 2
About This Document
This guide provides the details of Honeywell RMA801 Remote Indicator for applications involving DE
and/or analog (4-20 mA) protocol.
Release Information
Document Name
RMA801 Remote Indicator User's Guide
Document ID
#34-ST-25-62
Release
Number
Publication Date
First Release 1 February 2019
Approval updates 2 March 2019
References
The following list identifies all documents that may be sources of reference for material discussed in
this publication.
•34-ST-25-63 Quick Start Installation Guide
Support and Contact Information
For Europe, Asia Pacific, North and South America contact details, see back page or refer to the
appropriate Honeywell Solution Support web site:
Honeywell Corporate www.honeywellprocess.com
Honeywell Process Solutions https://www.honeywellprocess.com/remote-meter-assemblies
Training Classes www.honeywellprocess.com/en-US/training
Telephone and Email Contacts
Area Organization Phone Number
United States and
Canada Honeywell Inc. 1-800-343-0228 Customer Service 1-800-423-9883 Global Technical Support
Global Email
Support
Honeywell Process
Solutions
[e-mail]
EMEA and Asia Pacific + 80012026455 or
[phone]
Knowledge Base search engine
http://bit.ly/2N5Vldi
Field Product Sales
Honeywell Process
Solutions [e-mail]

Revision 2 RMA803 Remote Indicator User's Guide iv
Symbol Definitions
The following table lists those symbols used in this document to denote certain conditions.
Symbol Definition
ATTENTION: Identifies information that requires special
consideration.
TIP: Identifies advice or hints for the user, often in terms of
performing a task.
REFERENCE -EXTERNAL: Identifies an additional source of
information outside of the bookset.
REFERENCE - INTERNAL: Identifies an additional source of
information within the bookset.
CAUTION
Indicates a situation which, if not avoided, may result in equipment
or work (data) on the system being damaged or lost, or may result in
the inability to properly operate the process.
CAUTION: Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also be used
to alert against unsafe practices.
CAUTION symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING: Indicates a potentially hazardous situation, which, if not
avoided, could result in serious injury or death.
WARNING symbol on the equipment refers the user to the product
manual for additional information. The symbol appears next to
required information in the manual.
WARNING, Risk of electrical shock: Potential shock hazard where
HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4 Vpeak, or
60 VDC may be accessible.
ESD HAZARD: Danger of an electro-static discharge to which
equipment may be sensitive. Observe precautions for handling
electrostatic sensitive devices.
Protective Earth (PE) terminal: Provided for connection of the
protective earth (green or green/yellow) supply system conductor.
Functional earth terminal: Used for non-safety purposes such as
noise immunity improvement. NOTE: This connection shall be
bonded to Protective Earth at the source of supply in accordance
with national local electrical code requirements.

v RMA803 Remote Indicator User's Guide Revision 2
Symbol Definition
Earth Ground:Functional earth connection. NOTE: This
connection shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.
Chassis Ground: Identifies a connection to the chassis or frame of
the equipment shall be bonded to Protective Earth at the source of
supply in accordance with national and local electrical code
requirements.

Revision 2 RMA803 Remote Indicator User's Guide vi
Terms and Acronyms
Term Definition
AWG American Wire Gauge
DMM Digital Multimeter
DE Digital Enhanced Communications Mode
Device A physical entity capable of performing one or more specific functions. Examples
include Remote Indicators, actuators, controllers, operator interfaces.
EEPROM Electrically Erasable Programmable Read Only Memory
EMI Electromagnetic Interference
Event An instantaneous occurrence that is significant to scheduling block execution and
to the operational (event) view of the application.
Field Device A fieldbus-compatible device that contains and executes function blocks.
HART Highway Addressable Remote Transmitter
Hz Hertz
IDE Integrated Development Environment
inH 2 O Inches of Water
LRL Lower range Limit
LRV Lower Range Value
MCT Multi Communication Toolkit
mmHg Millimeters of Mercury
mV Millivolts
NVM Non-Volatile Memory
PSI Pounds per Square Inch
PV Process Variable
PWA Printed Wiring Assembly
RFI Radio Frequency Interference
RMA Remote Meter Assembly (refered to as a Remote Indicator)
SAT Smartline anytime Tool to upgrade the firmware
SCT SmartLine Configuration Tool
URL Upper Range Limit
URV Upper Range Value
VCC An electronics designation that refers to voltage from a power supply connected to
the "collector" terminal of a bipolar transistor.
Vdc Volts Direct Current

vii RMA803 Remote Indicator User's Guide Revision 2
Contents
COPYRIGHTS, NOTICES AND TRADEMARKS........................................................II
INTRODUCTION ................................................................................................1
1.1 About the RMA801 Remote Indicator.................................................................................... 1
1.2 Features and Options ............................................................................................................. 1
1.3 RMA801 major assembly and electronic housing components......................................... 2
1.4 Dimensions .............................................................................................................................. 3
1.5 RMA801 Remote Indicator Nameplate .................................................................................. 3
1.6 Safety Certification Information............................................................................................. 3
1.7 Display Options – Standard Display ..................................................................................... 4
1.8 Two Integrated-Button Assembly (Standard Display)......................................................... 5
INSTALLATION AND STARTUP.......................................................................6
2.1 Installation Site Evaluation .................................................................................................... 6
2.2 Display Installation Precautions............................................................................................ 6
2.3 Mounting Remote Indicator.................................................................................................... 7
2.3.1 Mounting Dimensions .......................................................................................................................7
2.3.2 Bracket Mounting Procedure ............................................................................................................7
2.4 Wiring a Remote Indicator.................................................................................................... 10
2.4.1 Overview.........................................................................................................................................10
2.4.2 Terminal Block................................................................................................................................10
2.4.3 Wiring Procedure............................................................................................................................13
2.4.4 Supply Voltage Limiting Requirements...........................................................................................13
PERFORMANCE SPECIFICATIONS ..............................................................14
OPERATION ....................................................................................................15
4.1 Overview ................................................................................................................................ 15
4.2 Configuration using SCT or MCT Toolkit for DE Models .................................................. 15
4.3 Configuration using Standard Display................................................................................ 16
4.3.1 Menu Navigation.............................................................................................................................17
4.3.2 Data Entry.......................................................................................................................................17
4.3.3 Editing a Numeric Value .................................................................................................................18
4.3.4 Selecting a new setting from a list of choices .................................................................................18
4.3.5 The Standard Display Menu ...........................................................................................................18
4.3.6 Standard Display Abbreviations:.....................................................................................................22
4.4 Changing the Write protect Direction ................................................................................. 23
4.5 Monitoring the Standard Display......................................................................................... 25

Revision 2 RMA803 Remote Indicator User's Guide viii
MAINTENANCE............................................................................................... 28
5.1 Overview.................................................................................................................................28
5.2 Preventive Maintenance Practices and Schedules ............................................................28
5.3 Replacing the Local Display and Communication Electronic Assembly ........................28
5.4 Upgrading the firmware ........................................................................................................30
CALIBRATION................................................................................................. 31
6.1 Remote Indicator calibration when connected in loop with HART transmitter...............31
6.2 Remote Indicator calibration when connected in loop with DE tansmitter .....................32
TROUBLESHOOTING..................................................................................... 33
7.1 Overview.................................................................................................................................33
7.2 Critical Diagnostics Screens ................................................................................................33
7.2.1 Fault Conditions and recommended Corrective Actions................................................................. 34
7.3 Important Notes .....................................................................................................................34
7.3.1 Notes on PV ................................................................................................................................... 34
7.3.2 Notes on Saturation........................................................................................................................ 34
SECURITY ....................................................................................................... 35
8.1 Security guidelines................................................................................................................35
SPARE PARTS LIST .......................................................................................36
9.1 Overview.................................................................................................................................36
CERTIFICATIONS AND APPROVALS ........................................................... 38
10.1 European Directive Information (CE Mark) .....................................................................38
INDEX .............................................................................................................. 50

ix RMA803 Remote Indicator User's Guide Revision 2
Tables
Table 1: Feature and Options................................................................................................. 1
Table 2: Display Characteristics............................................................................................. 4
Table 3: Two-Button Functions ............................................................................................ 16
Table 4: Two-Button Data Entry........................................................................................... 17
Table 5: RMA801: Standard Display Menu .......................................................................... 19
Table 6: The Standard Display abbreviations....................................................................... 22
Table 7: Write Protect Jumpers............................................................................................ 24
Table 8: Standard Display with PV Format Display Indications ............................................ 25
Table 9: Fault Conditions and Recommended Corrective Actions........................................ 34
Table 10: Summary List of Recommended Spare Parts....................................................... 36
Table 11: Pipe and Wall Bracket Parts (Refer to Figure 19) ................................................. 36
Table 12: Remote Indicator Major Assemblies ..................................................................... 37
Figures
Figure 1: RMA801 Electronic Housing ................................................................................... 2
Figure 2: Electronic Housing components.............................................................................. 2
Figure 3: Dimensions of Remote Indicator ............................................................................. 3
Figure 4 –Typical RMA801 Nameplate................................................................................... 3
Figure 5: Typical Pipe Mounted Installations .......................................................................... 7
Figure 6: Mounting Bracket Secured to a Remote indicator.................................................... 8
Figure 7: Pipe Mounting Bracket Secured to a Horizontal or Vertical Pipe ............................. 8
Figure 8: Remote Indicator Secured to a Wall Mounting Bracket ........................................... 9
Figure 9: Remote Indicator connected on the negative side of loop (analog mode).............. 10
Figure 10: Remote Indicator connected on the positive side of loop (analog mode) ............. 11
Figure 11: Remote Indicator connected on the negative side of loop (DE mode) ................. 11
Figure 12: DE/ANALOG Terminal Block............................................................................... 12
Figure 13: RMA801 Terminal Block...................................................................................... 12
Figure 14: RMA HANDHELD WIRING – DE MODE (Analog/Digital).................................... 15
Figure 15: Two-Button Option .............................................................................................. 16
Figure 16: Locating Simulation and Write Protect Jumpers .................................................. 23
Figure 17: Module Replacement .......................................................................................... 28
Figure 18: Local Display Fault Diagnostic Conditions........................................................... 33
Figure 19: Pipe and Wall Bracket Parts................................................................................ 36
Figure 20: Electronic Housing, Terminal Block End.............................................................. 37

Revision 2 RMA803 Remote Indicator User's Guide 1
Introduction
1.1 About the RMA801 Remote Indicator
The RMA801 Remote Indicator provides a means of remote-mounting a meter (display) that is
associated with a Honeywell Smartline Transmitter or any transmitter operating in a 4-20 mA current
loop.
The RMA801 is a DE/Analog Remote Indicator which can be connected anywhere along the current
loop, providing easy access to data from devices that are mounted in inaccessible locations.
For analog PV, the RMA801 measures the loop current and displays the equivalent PV value on the
display.
The RMA801 will autoconfigure when connected to Honeywell STT700/STT250 DE transmitters when
a database upload is performed.
The RMA801 - Remote Indicator can be used in hazardous environments or in ordinary
environments. When used in hazardous environments, the remote housing must be configured as per
local installation codes.
The display module fitting allows for rotation in 90 degree increments, allowing the RMA801 to be
mounted in various orientations.
1.2 Features and Options
Table 1: Feature and Options
Feature/Option Standard/Available Options
Communication Protocols Analog (4-20 mA), Honeywell DE (STT250/STT700)
PV Display •Display mA or percent value for any analog (4-20 mA)
transmitters
•Temperature and Pressure units support.
Device Configuration •Manual - using display buttons
•Autoconfiguration for DE devices (STT250/STT700)
Human-Machine Interface
(HMI)
Standard Display:
•0, 90, 180 & 270 degree viewing position adjustments
•Two-mode operations: PV display and Menu Navigation
Display language: English only
Device Diagnostics
Approvals ATEX, CSA, FM, IECx. Refer to Appendix A for details.
Mounting Brackets Pipe mounting and wall mounting brackets in carbon steel and 316
stainless steel.
Firmware Upgrade SAT tool for firmware upgrade

Revision 2 RMA803 Remote Indicator User's Guide 2
1.3 RMA801 major assembly and electronic housing components
The following illustrations depict the electronic housing components.
Figure 1: RMA801 Electronic Housing
Figure 2: Electronic Housing components

3 RMA803 Remote Indicator User's Guide Revision 2
1.4 Dimensions
Figure 3: Dimensions of Remote Indicator
1.5 RMA801 Remote Indicator Nameplate
The Remote Indicator nameplate mounted on the bottom of the electronics housing (see Figure 1,
“approvals” nameplate) lists model number, physical configuration, electronics options, accessories,
certifications, and manufacturing specialties.
Figure 4 –Typical RMA801 Nameplate
Identification of the series and basic Remote Indicator type is captured in the last digit in the key
number. The last digit represents itype.
•A value of 1 in the last digit means the Remote Indicator type is RMA801 DE/Analog
For a complete selection breakdown of model number, refer to the appropriate specification and Model
Selection Guide provided as separate documents.
1.6 Safety Certification Information
An “approvals” nameplate is located on the bottom of the electronics housing; see Figure 1 for the exact
location. The approvals nameplate contains information and service marks that disclose the Remote
Indicator compliance information. Refer to Appendix A of this document for safety certification
requirements and details.

Revision 2 RMA803 Remote Indicator User's Guide 4
1.7 Display Options – Standard Display
The RMA801 Remote Indicator includes Honeywell’s Standard Display option.
Table 2: Display Characteristics
Standard Display
•360°rotation in 90°increments
•2 lines, 16 characters
•Standard temperatue and pressure engineering units of
measurement:
Temperature: °C, °F, °R, K, mV, Ohm
Pressure: inH2O@39ºF, mH2O@4ºC, cmH2O@4ºC, Torr,
mmH2O@68ºF, ftH2O@68ºF, inH2O@68ºF, inH2O@60ºF,
atm, Pa, kPa, MPa, gf/cm2, kgf/cm2, psi, mbar, bar,
inHg@0ºC, mmHg@0ºC, mmH2O@4ºC.
•Diagnostic messages
•Supports 2-button for menu navigation
•Device configuration
•English language only

5 RMA803 Remote Indicator User's Guide Revision 2
1.8 Two Integrated-Button Assembly (Standard Display)
The iIntegrated two-button assembly for the Standard Display provides the following features and
capabilities:
•Menu and enter key functionality.
•With the menu-driven display:
oComprehensive on-screen menu for navigation.
oRMA Configuration – Select PV, Select Unit, Enter LRV, Enter URV, BUNIT.
oRMA Calibration
oDisplay Configuration - Contrast
oRMA Diagnostics.
Lower range value (LRV):
A display parameter (Standard display),
which allows users to enter the measuring value for which the analog
output will be scaled to 4mA.
Upper range value (URV): A display parameter (Standard display),
which allows users to enter the measuring value for which the analog
output will be scaled to 20mA
Note: User should configure LRV nad URV when connected to analog transmitters. For DE
transmitters LRV and URV are autoconfigured from device when upload databse is performed.

Revision 2 RMA803 Remote Indicator User's Guide 6
Installation and Startup
2.1 Installation Site Evaluation
Evaluate the site selected for the Remote Indicator installation with respect to the process system design
specifications and Honeywell’s published performance characteristics for your particular model. Some
parameters that you may want to include in your site evaluation are:
•Environmental Conditions:
oAmbient Temperature
oRelative Humidity
•Potential Noise Sources:
oRadio Frequency Interference (RFI)
oElectromagnetic Interference (EMI)
•Vibration Sources
oMotorized System Devices (e.g., pumps)
oValve Cavitation
•Process Parameters
oTemperature
oMaximum Pressure Rating
2.2 Display Installation Precautions
Temperature extremes can affect display quality. The display can go blank if the temperature is below -
20°C or above +70°C; however, this is only a temporary condition. The display will again be readable
when temperatures return to within operable limits.

7 RMA803 Remote Indicator User's Guide Revision 2
2.3 Mounting Remote Indicator
Remote Indicator models can be attached to a two-inch (50.8 millimeter) vertical or horizontal pipe
using Honeywell’s optional pipe mounting bracket. The Remote Indicator can also be wall mounted
using Honeywell’s optional wall mounint bracket as shown in Figure 5.
2.3.1 Mounting Dimensions
Refer to Honeywell drawing number 51455045
*
for detailed electronic housing dimensions. Refer to
Honeywell drawing numbers 32306827
*
for detailed pipe mounting dimensions, 50124813
*
for
Detailed Pipe Angle mounting dimenisons and 32306828
*
for detailed wall mounting dimensions.
Abbreviated overall dimensions are also shown on the Specification Sheets for the Remote Indicator
models. Its assumed that the mounting dimensions have already been considered and the mounting area
can accommodate the Remote Indicator.
2.3.2 Bracket Mounting Procedure
1. Pipe Mount Option -Refer to Figure 6. Align the two mounting holes at the bottom of the
Remote Indicator with the two slots in the mounting bracket and assemble the (2) M8 hex cap
screws, (2) lockwashers and (2) flat washers provided.
2. Rotate the Remote Indicator assembly to the desired position and torque the M8 hex cap screws
to 27,0 Nm/20,0 Lb-ft maximum
* Honeywell drawings can be supplied on request.
Figure 5: Typical Pipe Mounted Installations

Revision 2 RMA803 Remote Indicator User's Guide 8
Figure 6: Mounting Bracket Secured to a Remote indicator
3. Position the bracket on a 2-inch (50.8 mm) horizontal or vertical pipe, and install a “U” bolt
around the pipe and through the holes in the bracket. Secure the bracket with (2) M10 hex nuts,
(2) flat washers and (2) lock washers provided. Refer Figure 7.
Figure 7: Pipe Mounting Bracket Secured to a Horizontal or Vertical Pipe

9 RMA803 Remote Indicator User's Guide Revision 2
4.
Wall Mount Option - Refer Figure 8 Position the bracket on the mounting surface at the desired
location and secure the bracket to the mounting surface using the appropriate hardware (Wall
mounting hardware requirements to be determined and supplied by the end user).
Figure 8: Remote Indicator Secured to a Wall Mounting Bracket
