Honeywell 5834 Assembly instructions

5834
Wireless Key Transmitter
INSTALLATION AND SETUP GUIDE
GENERAL INFORMATION
The 5834 key transmitter is a portable wireless transmitter for
use only with wireless alarm systems that support 5800
Series receivers. Note the following:
•Buttons are typically used for arming and disarming, but
can be programmed for any zone response.
•A button must be pressed and held for at least 1/2 second
to activate the transmitter. This feature minimizes the
possibility of accidental transmissions.
•The factory-installed replaceable lithium battery provides
power for up to five (5) years.
•The 5834-4 transmitter provides up to eight (8) functions and
has an optional high security (encrypted) mode that sends
rolling-code encrypted messaging to the RF receiver.
High Security Mode Note: If used in high security mode,
must be used with a receiver or control that supports high
security mode. i.e., 5881EN, 5883, 6150RF, or 6160RF
receiver or a LYNXR Series control panel (Revision 13.1 or
higher).
5834-009-V0
KEY KEY
KEY KEY
A
C
B
D
5834-4
4-Button Transmitter
Using a Button: To activate a programmed function, press and
hold the appropriate key(s) for at least ½ second.
PROGRAMMING
For complete details on how to program the transmitter at the
control panel, see the control unit's Installation Instructions.
When programming, note the following:
•Each 5834 transmitter has two unique serial numbers
assigned during manufacture.
•Each button on the unit also has a distinct "loop" number
(refer to Loop Number diagrams below) that you must
program into the control panel during installation.
•Assign each button to an individual zone and designate the
Input Type as "BR" (Button Type RF).
•When prompted for the serial number, press and release
the appropriate button twice, or, manually enter the serial
number at the keypad.
NOTE: Serial #2 is one (1) digit higher than serial #1,
which is printed on the rear of the transmitter.
•To enroll serial number 1 for use in High Security mode,
simultaneously press and hold the A - B - C buttons
To enroll serial number 2 for use in High Security mode,
simultaneously press and hold the B - C - D buttons
5834-008-V0
SERIAL #1
LOOP 4
SERIAL #1
LOOP 1
SERIAL #2
LOOP 1
SERIAL #2
LOOP 3
SERIAL #1
LOOP 3
SERIAL #2
LOOP 4
SERIAL #1
LOOP 2
SERIAL #1 FUNCTIONS ACTIVATE WHEN THE RESPECTIVE
BUTTON IS HELD DOWN AT LEAST 1/2 SECOND.

SERIAL #2 FUNCTIONS ACTIVATE WHEN THE TWO
RESPECTIVE SERIAL #2 BUTTONS ARE PRESSED AT THE
SAME TIME AND HELD DOWN AT LEAST 1/2 SECOND.
NOTE
1.


2.
SERIAL #2
LOOP 2
Loop Numbers for the 5834 Keyfob Buttons
SELECTING STANDARD OR HIGH-SECURITY MODE
If used with LYNXR Series controls earlier than
Revision 13.1, the Standard Mode must be selected.
To select Standard or High Security mode, simultaneously
press and hold the indicated buttons for five seconds.
For Standard Mode B - C - D
For High-Security Mode A - C - D
The LED flashes green when transmitting in Standard Mode
and red when transmitting in High-Security Mode.
ASSIGNING A WIRELESS KEY TO A USER
•On most control panels, if the wireless key is assigned to
arm and disarm the system, you must assign it to a user
in order for it to operate. This is accomplished through
User Code programming at the control panel. See the
control panel’s Installation and Setup Guide for specific
instructions on programming User Codes. The table on
the next page summarizes the procedures.
• If you are programming arming and disarming functions
on both serial numbers, each serial number must be
assigned to a separate user.

On Vista 32/40/50/50P/100, and up
You must assign a user to the button in order for it to operate.
To assign a user number to the Arm/Disarm button:
1. Enter [4-digit User Code] + [8] + [User No.] + [4-digit new
User Code].
2. Answer Yes or No to the “Open/Close Report ?” question.
3. Answer Yes to the “RF Button ?” question.
4. Enter the zone number assigned to the Arm/Disarm
button.
5. Keypad shows the summary of user information on its
display.
6. Test Arm/Disarm button to make sure it operates correctly.
On Vista-20P/15P/10P and variants
You must assign a user to the button in order for it to operate,
and must enter a sequence of keystrokes as described
below.
NOTE: There is a two-second timeout for keystroke
commands on Vista P series panels, therefore you must
enter the keystrokes as quickly as possible.
1. Enter [4-digit Master Code] + [8] + [User Number] + [# 4]
+ [two digit zone number] assigned to the fob.
2. Test Arm/Disarm and other functions to confirm proper
operation.
REPLACING THE BATTERY
The LED will not flash during transmission if the battery is
low. Replace the battery as follows.
1. Remove the screw from the case back, then remove the
case back.
2. Insert the blade of a small screwdriver under the battery
as shown below.
3. Twist the screwdriver to release the battery.
4. With the Positive (+) end of a new battery facing UP,
insert the battery as shown, sliding it under the gold tab,
then pressing down to snap into place.
IMPORTANT: Positive (+) end must face up.
Use Maxell CR2032 or Duracell DL2032 lithium battery
only.
5. Replace the case back and replace the screw to secure
the case.
!
•
••
•Improper installation will result in
damage to the battery.
•
••
•Do not remove the printed circuit board.
Failure of Replaceable Batteries
This wireless key has been designed to provide several
years of battery life under normal conditions. The
expected battery life is a function of the device
environment, usage and type. Ambient conditions such
as high humidity, high or low temperatures, or large
temperature fluctuations may reduce the expected
battery life.
This device will report a low battery condition to the
control panel as a trouble condition, when the batteries
need to be replaced. In addition the LED will not flash
when a button is pressed. However, if the device is
unused for a long period of time, it may fail to operate as
expected. Regular testing and maintenance will keep the
system in good operating condition for the lifetime of the
product.
IMPORTANT! This wireless key is intended as a
convenience to the user and should not be considered as
a life safety device. If life safety is important, please
select a supervised wireless key (e.g. type 5802MN).
WARRANTY INFORMATION
For the latest warranty information, please go to:
http://www.security.honeywell.com/hsc/resources/wa/index.html
5834-004-V0
GOLD
TAB
BATTERY
TO REMOVE, SLIDE
SCREWDRIVER BLADE
UNDER BATTERY HERE
Removing the Battery
5834-005-V0
INSTALL WITH POSITIVE (+)
SIDE UP. SLIP BATTERY
UNDER GOLD TAB THEN
PRESS DOWN
IMPORTANT
POSITIVE (+)
SIDE MUST
FACE UP
BATTERY
INSTALL UNDER GOLD TAB
BATTERY
THEN PRESS DOWN
Installing the Battery
SPECIFICATIONS
Unit Dimensions: 2.25" x 1.25" x 0.5"
(57mm x 31.75mm x 12.7mm)
Battery: 3V, 210mAh, Maxell CR2032, Duracell DL2032
REFER TO THE INSTALLATION INSTRUCTIONS FOR
THE CONTROL WITH WHICH THIS DEVICE IS USED
FOR LIMITATIONS OF THE ENTIRE ALARM SYSTEM.
FEDERAL COMMUNICATIONS COMMISSION STATEMENTS:
The user shall not make any changes or modifications to the
equipment unless authorized by the installation Instructions or
User's Manual. Unauthorized changes or modifications could void
the user's authority to operate the equipment.
FCC NOTICE
This device complies with Part 15 of FCC Rules, and RSS 210 of
IC. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that
may cause undesired operation.
Cet appareil est conforme à la partie 15 des règles de la FCC & de
RSS 210 des industries Canada. Son fonctionnement est soumis
aux conditions suivantes: (1) Cet appareil ne doit pas causer
d'interferences nuisibles. (2) Cet appareil doit accepter toute
interference reçue y compris les interferences causant une
reception indesirable.
