EXERCISE BIKE OWNER’S MANUAL
EXERCISE BIKE OWNER’S MANUAL
Read the BIKE GUIDE before using this OWNER’S MANUAL.
PAGO 4PAGO 3

23
IMPORTANT PRECAUTIONS
SAVE THESE INSTRUCTIONS
When using an exercise product, basic precautions should always be followed, including the following: Read all instructions
before using this exercise bike. It is the responsibility of the owner to ensure that all users of this exercise bike are adequately
informed of all warnings and precautions. If you have any questions after reading this owner’s manual, contact your local dealer.

45
READ AND SAVE ALL INSTRUCTIONS BEFORE ASSEMBLING OR USING THIS
EXERCISE BIKE. IT IS STRONGLY RECOMMENDED TO TAKE THE FOLLOWING SAFETY
INSTRUCTIONS.
• CAUTION: If you experience chest pains, nausea, dizziness or shortness of breath, stop exercising immediately and consult your
physician before continuing.
• Use this exercise bike for its intended purpose as described in this manual. Do not use attachments that have not been
recommended by the manufacturer.
• Never operate the exercise bike if it is not working properly, or if it has been damaged. Contact the authorized dealers for
examination and repair.
• Do not use the exercise bike without proper footwear. NEVER operate the exercise bike with bare feet.
• Do not wear any clothing that might catch on any moving parts of this exercise bike.
• Keep hands and feet clear at all times from moving parts to avoid injury. Never turn the pedal cranks by hand.
• Do not dismount the exercise bike until the pedals are at a complete STOP.
• Do not attempt to ride the exercise bike in a standing position at high RPMs until you have practiced at slower speeds.
• Do not insert any object, hands or feet into any openings, or expose hands, arms or feet to the drive mechanism or other potentially
moving part of the exercise bike.
• Do not use any equipment that is damaged or has worn or broken parts. Use only replacement parts supplied by the authorized
dealers.
• Do not operate where aerosol (spray) products are being used or when oxygen is being administered.
• Close supervision is necessary when used near children, invalids or disabled people.
• When the exercise bike is in use, young children and pets should be kept at least 3 meters / 10 feet away.
• Ensure that adjustment levers (seat and handlebar fore-and-aft) are properly secured and do not interfere with range of motion
during exercise.
WARNING ASSEMBLY
There are several areas during the assembly process that special attention must be paid. It is very important to follow the assembly
instructions correctly and to make sure all parts are firmly tightened. If the assembly instructions are not followed correctly, the
exercise bike could have parts that are not tightened and will seem loose and may cause irritating noises. To prevent damage to
the exercise bike, the assembly instructions must be reviewed and corrective actions should be taken.
Before proceeding, find your exercise bike’s serial number located on
the front stabilizer tube and enter it in the space provided below.
ENTER YOUR SERIAL NUMBER AND MODEL NAME IN THE BOX BELOW:
» Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
MODEL NAME: HORIZON EXERCISE BIKE
WARNING
SERIAL NUMBER:
BK
SERIAL NUMBER LOCATION

6 7
PAGO 3
SHOWN
PAGO 4
SHOWN
CR ANK
WATE R BOTTLE HOLDE R
PULSE GRIP HANDLEBARS
RE AR STABILIZER TUB E
POWER CORD SOCKET
CONSOLE
SE AT POSITION ADJUSTME NT KNOB
SE AT POST TUBE
SE AT HEIGHT ADJUSTMENT KNOB
FRONT STABILIZER TUB E
SE AT
PE DALS
SHROUD
CONSOLE MAST
CR ANK
WATE R BOTTLE HOLDE R
PULSE GRIP HANDLEB ARS
RE AR STABILIZER TUB E
POWER CORD SOCKET
CONSOLE
SE AT POSITION ADJUSTME NT KNOB
SE AT POST TUBE
SE AT HEIGHT ADJUSTM ENT KNOB
FRONT STABILIZER TUB E
SE AT
PE DALS
SHROUD
CONSOLE MAST

8 9
TOOLS INCLUDED:
F13/15mm Flat Wrench
F5mm L-Wrench (w/ Screw driver)
F4mm L-Wrench
PARTS INCLUDED:
F1 Bike Frame
F1 Console
F1 Console Mast
F1 Front Stabilizer Tube
F1 Rear Stabilizer Tube
F1 Seat
F1 Seat Post Tube
F1 Pulse Grip Handlebar Set
F2 Pedals
F1 Water Bottle Holder
F1 Power Cord
F1 Hardware Kit
UNPACKING
Unpack the product where you will be using it. Place the exercise bike carton on a
level flat surface. It is recommended that you place a protective covering on your
floor. Never open box when it is on its side.
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place
and partially threaded in before completely tightening any ONE bolt.
NOTE: A light application of grease may aid in the installation of hardware. Any
grease, such as lithium bike grease is recommended.
If you have questions or if
there are any missing parts,
contact your local dealer.
NEED HELP?
PRE ASSEMBLY ASSEMBLY STEP 1
A Open HARDWARE FOR STEP 1.
B Attach the REAR FOOT TUBE to the MAIN FRAME
using 2 ARC WASHERS(B), 2 BOLTS(A).
C Attach the FRONT FOOT TUBE to the MAIN FRAME
using 2 ARC WASHERS(B), 2 BOLTS(A).
HARDWARE FOR STEP 1 :
PAGO 3
PAGO 4
BOLT (A)
M10x1.5Px75L
Qty: 4
ARC WASHER (B)
Φ10.2xΦ20.0x1.5T
Qty: 4
BOLT(A)
REAR FOOT TUBE
FRONT FOOT TUBE
MAIN FRAME
MAIN FRAME
ARC WASHER(B)
BOLT(A)
ARC WASHER(B)

10 11
ASSEMBLY STEP 2
A Open HARDWARE FOR STEP 2.
B Unfold the wire harness located in the frame bracket.
Wrap the end of the wire tie, located at the bottom of
the console mast, around the end of the wire harness.
Pull the wire tie and wire harness up through the
console mast while simultaneously sliding the mast
over the frame bracket.
C Attach the CONSOLE MAST using 4 BOLTS (C), 4
SPRING WASHERS (D) and 4 ARC WASHERS (E).
HARDWARE FOR STEP 2 :
PAGO 3
PAGO 4 BOLT (C)
M8x1.25Px15L
Qty: 4
SPRI NG WASHER (D)
Φ8.2xΦ15.4x2.0T
Qty: 4
ARC WASHER (E)
Φ8.4xΦ17.0x1.0T
Qty: 4
ASSEMBLY STEP 3
A Slide the heart rate wires of the handlebar through
the hole in the handlebar bracket on the CONSOLE
MAST.
B Attach the HANDLEBAR to the CONSOLE MAST
using 4 PRE-INSTALLED SCREWS.
PAGO 3
PAGO 4
NOTE: Be careful not to pinch any wires while attaching
the console mast.
NOTE: Be careful not to pinch any wires while attaching
the handlebar.
BOLT(C)
SPRING WASHER(D)
ARC WASHER(E)
MAIN FRAME
CONSOLE MAST
PRE-INSTALLED SCREW
CONSOLE MAST

12 13
ASSEMBLY STEP 4
A Remove the 4 PRE-INSTALLED SCREWS from the
CONSOLE.
B Attach the 2 heart rate wires and 1 console cable to
the CONSOLE.
C Carefully tuck the CONSOLE CABLES into the
CONSOLE MAST before attaching the CONSOLE.
D Attach CONSOLE to the CONSOLE MAST using the
4 PRE-INSTALLED SCREWS.
ASSEMBLY STEP 5
A Remove the 2 PRE-INSTALLED SCREWS from the
console mast.
B Attach BOTTLE HOLDER to the CONSOLE MAST
using the 2 PRE-INSTALLED SCREWS.
PAGO 3
PAGO 4
PAGO 3
PAGO 4
PRE-INSTALLED SCREWS
CONSOLE MAST
CONSOLE
WATER BOTTLE HOLDER CONSOLE MAST
PRE-INSTALLD SCREWS
NOTE: Be careful not to pinch any wires while attaching
the console.

14 15
PAGO 3
PAGO 4
ASSEMBLY STEP 6
A Slide the SEAT POST TUBE into bike frame and
then tighten with the SEAT HEIGHT ADJUSTMENT
KNOB.
B Attach the SEAT to SEAT POST TUBE.
ASSEMBLY STEP 7
PAGO 3
PAGO 4
PEDAL
CRANK
PEDAL STRAP
SEAT POST TUBE
SEAT HEIGHT ADJUSTMENT KNOB
SEAT
A Attach the PEDAL STRAP onto the PEDAL.
B Attach the PEDAL onto the CRANK and then tighten
with the reserved tool 13/15 mm Flat Wrench .
C Repeat A-B steps on the opposite of bike.

16 17
PAGO 3
ECB Magnetic Brake System
Max. User Weight: 136 kg / 300 lbs
Product Weight: 37 kg / 81 lbs.
Overall Dimension: 104x58x130 cm / 41” x 23” x 51”
ASSEMBLY COMPLETE!
PAGO 3
SHOWN
PAGO 4
Induction Brake System
Max. User Weight: 136 kg / 300 lbs
Product Weight: 40 kg / 88 lbs.
Overall Dimension: 104x58x130 cm / 41” x 23” x 51”
PAGO 3
SHOWN

18 19
BIKE OPERATION
This section explains how to use your bike’s console and programming.
The BASIC OPERATION section in the BIKE GUIDE has instructions for the following:
• LOCATION OF THE BIKE
• POWER/GROUNDING INSTRUCTIONS
• SEAT POSITIONING
• MOVING THE BIKE
• LEVELING THE BIKE
• USING THE HEART RATE FUNCTION

20 21
CONSOLE CONTROLS
Click 3 seconds hold 5 seconds hold
• Increase
• Next item
• Decrease
• Previous item
• Quick start
• Select item
• Start the workout
• Enter to the next
step
• Finish inputting
user ’s name

• Stop the workout
• Back to the
previous step
• Reset • Language selection
• Metric /British
selection
NOTE
These two display at left shows your performance and achieving
rate of your fitness goals. (refer to program file for more
information.)
ENERGY SAVER
If the machine is unused for 15 minutes, the console will automatically enter
into power save mode and could be quickly waken up with a touch of a
button or pedal movement.
CONSOLE OPERATION
QUICK START
1) Make sure the power is on.
2) Simply press the “START” key and begin exercising.
SETUP YOUR PERSONAL DATA
This console is able to store your personal data which includes name, gender, age and weight. This allows you to start your workout
more quickly and monitor your exercise information more accurately. Please setup your personal data before you use the machine for
the first time. To set up your data, please follow the procedure as below,
1) Select (Pago 3) user 1, 2 or (Pago 4) user 1, 2 , 3
2) Select your gender
3) Select your age
4) Select your weight
5) Input your name
6) Hold the “START” key for 3 seconds to finish your setup
The console is able to store up to 3 users’ data. If you would like to modify your personal data, please select “USERS SETTING” for
modification.
START YOUR WORKOUT
1) Select the user. (If your personal data has been entered, just select the program and then you can start your workout).
2) Select your gender.
3) Select your age.
4) Select your weight.
5) Select the program you preferred.
6) Start your workout.

22 23
• FIT-TEST (PAGO 4 ONLY): Test your current level of
physical fitness.At completion of the program,it will provide
feedback regarding your fitness level for you to monitor your
progress.
• STEP TEST (PAGO 4 ONLY): Test your current level of
physical fitness.At completion of the program,it will provide
feedback regarding your fitness level for you to monitor your
progress.
• GAME 1 (PAGO 4 ONLY): This warm up game simulates
a Car Racing Game. To control the car up and down, you
pedal faster or slower. Try to avoid those barriers and keep on
track. You only have 11 chances to complete the circuit, so
be careful .
PROGRAM PROFILES
• MOUNTAIN: Improves performance and stamina by raising
the resistance level to high peaks to simulate the most
difficult outdoor terrains.
• FOOT HILL (PAGO 3 ONLY): Improve heart and lung
capacity by continuing exercise.
• CROSS COUNTRY (PAGO 3 ONLY): Improve your
cardiovascular system by lowering resistance to simulate
country stroll.
• WEIGHT LOSS: Promotes weight loss by raising and
lowering the resistance level, while keeping you in your fat
burning zone.
• AFTER BURNER: Recover your heart and muscles by
gradually cooling down after intensive workout.
• WATTS CONTROL: Exercise at a set work level. As you
increase your pedal rate(RPM), your resistance will decrease;
if you decrease your pedal rate (RPM), your resistance will
increase.
NOTE: When using WATTS control program, the bar at the
bottom shows your current watt and percentage meter at left
shows your achieving rate. You must get 100% to reach your
target set.
PROGRAM PROFILES
• MANUAL: Allows you to adjust the resistance level to your
preference, without a preset program.
• INTERVALS: Improves your strength, speed, and endurance
by raising and lowering the resistance levels throughout your
workout to involve both your heart and muscles.
• ROLLING: Maintains weight by gradually raising and
lowering the resistance level to gradually raise and lower your
heart rate.

24 25
• HRC 2 (PAGO 4 ONLY): Benefits weight loss by
maintaining an optimum exercise level to burn fat, while
adjusting the resistance to keep you in your target heart rate
zone.
• CUSTOM 1.2: Customized workout, time defaults to 15
minutes.
• CUSTOM 3 (PAGO 4 ONLY): Customized workout, time
defaults to 15 minutes.
SYNCING BIKE WITH PASSPORT
1) Using the arrow key on the passport remote control to scroll to the setup icon and
press the Select.
2) Follow the on-screen prompt to press and hold the RESISTANCE UP and STOP
buttons on the equipment’s console.
3) Once your sync is success, your bike message bar will change from RF Sync to
Passport Ready.
4) Besides point 3, the message displayed on-screen will notify you if the sync was
completed or failed.
RESISTANCE UP STOP
ACCESSING MEDIA THROUGH ON-SCREEN MENU
1) You can access the Virtual Active content or your personal movies are stored on the
USB drive. Select either the Virtual Active icon or the Media icon using the remote
control.
2) Follow the on-screen prompts to select a video and begin your workout.
3) You will have to Press START on your equipment’s console to begin playing a video.
Note: See Passport Owner’s Manual for more information.
RESISTANCE UP STOP
PROGRAM PROFILES
• GAME 2 (PAGO 4 ONLY): This warm up game simulates
a Fishing Game. To control the fishhook to go deeper or
shallower, you pedal faster or slower. After the fish has been
caught by you fishhook, then pedal faster until the fishhook
is off of the screen. Some of the fish are harder to catch than
others, but you will get more points from catching these fish.
• HRC 1: Benefits weight loss by maintaining an optimum
exercise level to burn fat, while adjusting the resistance to
keep you in your target heart rate zone.
NOTE: When using HRC program, the percentage meter at right
will show your current HR and your achieving rate. You must get
100% to reach your target set.

26 27
PAGO 3 EXPLODED VIEW PAGO 3 PARTS LIST
NO. DESCRIPTION
1CONSOLE MAST SET;SA;CB161;
2
SEAT PAD TRANSPORTSET;SA;CB160
3 ARM REST SET;SA;CB161;
4STABILIZER SET;SA;F;CB160;
5STABILIZER SET;SA;B;
6
BELT PULLEY SET;SA;
7 IDLER SET;SA;CB160;
AD1 SEAT TUBE;LETTERING;CB161
AN1 CONSOLE SET;SA;CB161-2KM;
B19
SCREW;BH;M8X1.25PX20L;HS;BAN;
B20 SCREW;BH;M6X1.0PX35L-23L;HS;P-T
C06 RACK;KETTLE;STEEL;FC07
C07 SCREW;BH;M5X0.8PX15L;PH;BZN;
D06
BUSHING;SEAT TUBE;
D09 SEAT PAD; PAHS;CB131
D10 KNOB;SEATPADTRANSPORTS;CB117
D11 CAP;SEAT PAD TRANSPORTS TUBE;CB117-D11C
D13
SEMI-ASSY;SEATPA DA DJPULLPIN;CB117
D14 SCREW;RND;M4X0.7PX10L;PH;BZN;
G07 SC REW;BH;M5X0.8PX10L;PH;BAN;
G11 COVER;H ANDLEBAR;L;CB118
G12 COVER;HANDLEBAR;R;C B118
G15 KNOB;CB118-G 09A
J10 SC REW;BH;M5X0.8PX12L;CT;PH;BZN;
N09 SCREW;BH;M5X0.8PX12L;CT;PH;BZN;
NO. DESCRIPTION
P01 WIRE;SENSOR;250MM;OKI SENSOR CKM254301-3P
P02
WIRE;CONSOLE;2000(CKM254301-08X2);
P04 SCREW;RND;Φ3X10L;TC;PH;BZN;POT
P06 POWER WIRE;DC;600MM(DC+CKM 25430101-2P)
P10 POWER ADAPTOR
P21
SENSOR WIRE;PULSE;700(XHS-2Y+110FEMALE)
Q01 COVER;LEFT;PAINTING;CB131;
Q02 COVER;RIGHT;PAINTING;CB131;
Q03 COVER;UP;75140;CB131;
Q04
COVER;REAR;PAINTING;BL;CB131
Q05 BOOT;SEAT TUBE;PVC;CB131;
Q06 BOOT;CRANK;75140;CB131;
Q07 COVER;POWER;75140;CB131;
Q08
CLIP; STANDARD; FE; ZNC
Q09 SCREW;BH;Φ4X15L;SM;PH;WZN;POT
Q10 BRACKET SIDE COVER
Q11 SCREW;BH;Φ4X12L;SM;PH;BAN;POT
Q12
BO OT;CONSOLE M AST;7514 0;CB131
R01 INSIDE ECB CONTROLLER;8.5KG;CB131
R02 BELT;POLY-V;420-J5;
R06 NUT;HX;3/8 -26UNCX9H;SS41;G10. 9(G10);BZ N;
R07 WASH ER;FLT;Φ10.2XΦ20.0X1.0T;
S01 ECB SET;8KG;EUP;
S02 STEEL ROPE;CB131
S03 SCREW;BH;M4X0.7PX12L;PH;BAN;
P10

28 29
NO. DESCRIPTION
S24 CABLE TIE;NYLON;BLACK;160L
T02
CRANK;L;ROHS;CR PLATE;CB104;CB104-T02
T03 CRANK;R;ROHS;CR PLATE;CB104;CB104-T03
T05 PEDAL;WITH BELT;FP-J016(9/16-21);PAHS
T12 SCREW;TRHW;M8X1.0PX20L;BP
T14
COVER CRANK ARM;ABS;CB01
T17 WASHER;DSP;Φ8.0XΦ18.0X0.9T;
U08 SPRING;EXT;CB131
U09 WASHER;FLT;Φ8.2XΦ27.0X2.0T;
U10
WASHER;FLT;Φ12.0XΦ30.0X1.0T;TFN;
U11 NUT;NLK;M6X1.0P;BAN;
Z01 WASHER;ARC;Φ8.4XΦ17.0X1.0T;BZN;
Z02 WASHER;SPL;Φ8.2XΦ15.4X2.0T;BZN;
Z03
SCREW;BH;M8X1.25PX15L;HS;BZN;
Z06 WASHER;ARC;Φ10.2XΦ20.0X1.5T;CHM;
Z08 SCREW;HEX;M10X1.5PX75L(15#)
PAGO 4 EXPLODED VIEW

30 31
PAGO 4 PARTS LIST
NO. DESCRIPTION
1CONSOLE MAST SET;SA;CB161;
2
SEAT PAD TRANSPORTSET;SA;CB160
3 ARM REST SET;SA;CB161;
4STABILIZER SET;SA;F;CB160;
5STABILIZER SET;SA;B;
6
BELT PULLEY SET;SA;CB163;
7 IDLER SET;SA;CB163;
AD1 WELDING;SEAT TUBE SET;CB117-AD1
AN1 CONSOLE SET;SA;CB163-2KM;
B23
SCREW;BH;M8X1.25PX20L;HS;BAN;
C06 RACK;KETTLE;STEEL;FC07
C07 SCREW;BH;M5X0.8PX15L;PH;BZN;
D06 SLEEVE SEAT POST
D09
SEAT PAD;SB-31;320X300MM;BASE1.2
D10 KNOB;SEATPADTRANSPORTS;CB117
D11 CAP;SEAT PAD TRANSPORTS TUBE;CB117-D11C
D13 SEMI-ASSY;SEATPADADJPULLPIN;CB117
D14
SC REW;RND;M4X0.7PX10L;PH;BZN;
G07 SCREW;BH;M5X0.8PX10L;PH;BAN;
G11 COVER;H ANDLEBAR;L;CB118
G12 COVER;HANDLEBAR;R;C B118
G15 KNOB;CB118-G 09A
J10 SC REW;BH;M5X0.8PX12L;CT;PH;BZN;
M40 MAGNETIC CONTROL;ELECTROMAGNET;260W;510R
M41 CTL BOARD;AC;MLH1003HCPC;C02;JIS
NO. DESCRIPTION
M42 SCREW;SH;M6X1.0PX45L;HS;BZN;
M47
NUT;NLK;M6X1.0P;BAN;
M48 WASHER;FLT;Φ6.5XΦ19.0X2.0T;BZN;
M52 SCREW;BH;M4X0.7PX15L;CT;PH;BZN;
N09 SCREW;BH;M5X0.8PX12L;CT;PH;BZN;
P01
WIRE;SENSOR;300MM;OKI SENSOR TZT:2.54-3P
P02 WIRE;CONSOLE;1600(CKM254301-08P,TZT:2.54-8P)
P03 POWER SWITCH;SOCKET
P04 SCREW;RND;Φ3X10L;TC;PH;BZN;POT
P07
BREAKER 3A 125V/250V
P08 WIRE POWER BLACK 16AWG
P09 WIRE POWER WHITE 16AWG
P10 NPUT FILTER;220V/3A
P11
SCREW;BH;Φ4X12L;SM;PH;BAN;POT
P12 POWER CORD
P15 SCREW;BH;Φ4X12L;SM;PH;YZN;POT
P21 SENSOR WIRE;PULSE;700(XHS-2Y+110FEMALE)
P22
WIRE;PWR EXCHANGE;DOWN;BLACK/RED;CB163;
Q01 COVER;LEFT;PAINTING;CB131;
Q02 COVER;RIG HT;PAINTING;CB131;
Q03 COVER;UP;75140;CB131;
Q04 COVER;REAR;PAINTING;BL;CB131
Q05 BO OT;SEAT TUBE;PVC;CB131;
Q06 BO OT;CR ANK;75140;CB131;
Q07 COVER;POWER;75140;CB132;
NO. DESCRIPTION
Q08 CLIP; STANDARD; FE; ZNC
Q09
SCREW;BH;Φ4X15L;SM;PH;WZN;POT
Q10 BRACKET SIDE COVER
Q11 SCREW;BH;Φ4X12L;SM;PH;BAN;POT
Q12 BOOT;CONSOLE MAST;75140;CB131
S06
CABLE TIE;NYLON;BLACK;160L
T02 CRANK;L;ROHS;CR PLATE;CB104;CB104-T02
T03 CRANK;R;ROHS;CR PLATE;CB104;CB104-T03
T05 PEDAL;WITH BELT;9/16''-20L;PAHS;CB132
T12
SCREW;TRHW;M8X1.0PX20L;BP
T14 COVER CRANK ARM;ABS;CB01
T17 WASHER;DSP;Φ8.0XΦ18.0X0.9T;
T18 BELT;POLY-V;400-J5;
T25
FOAM;CB132
U07 SCREW;BH;M5X0.8PX10L;PH;BAN;
U08 SCREW;BH;M8X1.25PX50L;HS;BZN;
U09 NUT;HX;M8X1.25P;SS41;BAN;
U10
SC REW;BH;M5X0.8PX6L;PH;B ZN;
Z01 WASHER;ARC;Φ8.4XΦ17.0X1.0T;BZN;
Z02 WASH ER;SPL;Φ8.2XΦ15.4X2.0T;BZN;
Z03 SC REW;BH;M8X1.25PX15L;HS;BZ N;
Z06 WASH ER;ARC;Φ10.2XΦ20.0X1.5T;CH M;
Z08 SC REW;HEX;M10X1.5PX75L(15#)

D: Entsorgungshinweis
HORIZON Fitness - Produkte sind recyclebar. Führen Sie das Gerät am Ende der Nutzungsdauer einer
sachgerechten Entsorgung zu (örtliche Sammelstelle).
GB: Waste Disposal
HORIZON Fitness products are recyclable. At the end if its useful life please dispose of this article correctly and
safely (local refuse sites).
F: Remarque relative à la gestion des dèchets
HORIZON Fitness sont recyclables. A la fin sa durrèe d`utilisation, remettez I´appareil à un centre de gestion
de dèchets correct (collecte locale).
NL: Verwijderingsaanwijzing
HORIZON Fitness producten zijn recycleerbaar. Breng het apparaat aan het einde van de gebruiksduur naar
een op recycling gespecialiseerd bedrijf (plaatselijk verzamelpunt).
E: Informaciones para la evacuaciòn
HORIZON Fitness son riciclables. Cuando se termina la vida ùtil de un aparato o una màquina, entrèguelos an
una impresa local de eleiminaciòn de residuos para su reciclaje.
I: Indicazione sullo smaltimento
HORIZON Fitness sono reciclabill. Quando I`apparecchio non servirà più, portatelo in un apposito punto di
raccolta della Vostra città (Punti di raccolta comunall).
PL: Wskazòwka dotyczàca usuwania odpadòw.
Producty firmy HORIZON Fitness podlegajà recyklingowi. Pod koniec okresu o`ywalnoÈcl pros`z oddac
urzàdzenie do wlaÈciwego punkto usuwania odpadòw (lokalny punkt zbiorczy).

EXERCISE BIKE OWNER’S MANUAL
Pago 3 & Pago 4 Owner’s Manual 082212’ Rev. 2.0 © 2012 Horizon Fitness
