Horizon Hobby E-flite UMX Turbo Timber User manual

Instruction Manual
Bedienungsanleitung
Manuel d’utilisation
Manuale di Istruzioni
UMX™Turbo Timber®

2
EN
WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before
operating. Failure to operate the product correctly can result in damage to the product, personal property and
cause serious injury.
This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic
mechanical ability. Failure to operate this product in a safe and responsible manner could result in injury or damage
to the product or other property. This product is not intended for use by children without direct adult supervision. Do
not use with incompatible components or alter this product in any way outside of the instructions provided by Horizon
Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly and
avoid damage or serious injury.
Safety Precautions and Warnings
• Always keep a safe distance in all directions around
your model to avoid collisions or injury. This model is
controlled by a radio signal subject to interference from
many sources outside your control. Interference can
cause momentary loss of control.
• Always operate your model in open spaces away from
full-size vehicles, traffic and people.
• Always carefully follow the directions and warnings for
this and any optional support equip-ment (chargers,
rechargeable battery packs, etc.).
• Always keep all chemicals, small parts and anything
electrical out of the reach of children.
• Always avoid water exposure to all equipment not
specifically designed and protected for this purpose.
Moisture causes damage to electronics.
• Never place any portion of the model in your mouth as
it could cause serious injury or even death.
• Never operate your model with low transmitter batteries.
• Always keep aircraft in sight and under control.
• Always use fully charged batteries.
• Always keep the transmitter powered on while aircraft
is powered.
• Always remove batteries before disassembly.
• Always keep moving parts clean.
• Always keep parts dry.
• Always let parts cool after use before touching.
• Always remove batteries after use.
• Always ensure failsafe is properly set before flying.
• Never operate aircraft with damaged wiring.
• Never touch moving parts.
Meaning of Special Language:
The following terms are used throughout the product literature to indicate various levels of potential harm when
operating this product:
WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superficial injury.
CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a
possibility of serious injury.
NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no
possibility of injury.
NOTICE
All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon
Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the support
tab or resources for this product.
Age Recommendation: Not for children under 14 years. This is not a toy.

3
EN
18.4 in (467mm)
27.6 in (700mm)
Specifications
Table of Contents
Wing Area: 119.0 sq In (7.7 sq Dm)
Weight: 4.37oz (124g)
Preflight Checklist
Installed
Motor: BL180 Brushless Outrunner 3,400Kv (EFLUM6960)
Receiver : DSM2®6 Ch. UM AS3X®RX BL-ESC (EFLU4864)
Servos : (2) 2.3-Gram Performance Linear Long Throw
Offset Servo (SPMSA2030LO)
Required to Complete
Battery: 280mAh 2S 7.4V 30C Li-Po, (EFLB2802S30)
Battery Charger: Celectra™ 2S 7.4V DC Li-Po Charger
(EFLUC1007)
Recommended Transmitter: Full range Spektrum™
DSM2®/DSMX®with dual-rates (DXe and up)
1. Charge flight battery.
2. Install flight battery in aircraft (once it has been fully
charged).
3. Bind aircraft to transmitter.
4. Make sure linkages move freely.
5. Perform Control Direction Test with transmitter.
6. Perform AS3X control Direction Test with aircraft.
7. Set dual rates.
8. Adjust center of gravity.
9. Perform a radio system Range Check.
10.Find a safe and open area.
11.Plan flight for flying field conditions.
12.Set fight timer for 5 minutes for first flight.
Specifications...................................................................3
Preflight Checklist.............................................................3
Transmitter and Receiver Binding......................................4
SAFE®Select Technology..................................................4
Transmitter Setup .............................................................5
Dual Rates and Expos .......................................................5
ESC/Receiver Arming, Battery Installation
and Center of Gravity ........................................................6
Control Direction Tests ......................................................7
Control Centering .............................................................8
Control Horn Settings........................................................8
Low Voltage CutOff ...........................................................8
Flying Tips and Repairs.....................................................9
Post Flight Checklist .........................................................9
Power Components Service ............................................10
Slat Installation (Optional) ...............................................11
Float installation (Optional)..............................................11
AS3X Troubleshooting Guide ...........................................12
Troubleshooting Guide ....................................................12
Troubleshooting Guide (Continued)..................................13
Limited Warranty ............................................................13
Warranty and Service Contact Information ......................15
FCC Information..............................................................15
IC Information.................................................................15
Compliance Information for the European Union..............16
Replacement Parts..........................................................58
Optional Parts and Accessories .......................................59

4
EN
Binding is the process of programming the receiver to recognize the GUID (Globally Unique Identifier) code of a single
specific transmitter. You need to ‘bind’ your chosen Spektrum™DSM2/DSMX technology equipped aircraft transmitter to
the receiver for proper operation. Any full range Spektrum DSM2/DSMX transmitter can bind to the DSM2/DSMX receiver.
Transmitter and Receiver Binding
Binding Procedure
CAUTION: When using a Futaba transmitter with a Spektrum DSM®module, you must reverse the throttle
channel and rebind. Refer to your Spektrum module manual for binding and failsafe instructions. Refer to your
Futaba transmitter manual for instructions on reversing the throttle channel.
1. Refer to your transmitter’s unique instructions for binding to a receiver (location of transmitter’s Bind control).
2. Make sure the flight battery is disconnected from the aircraft.
3. Power off your transmitter.
4. Set the aircraft upright on its wheels and connect the flight battery in the aircraft. The receiver LED will begin
to flash rapidly (typically after 5 seconds)
5. Make sure the transmitter controls are neutral and the throttle and throttle trim are in low position.
6. Put your transmitter into bind mode. Refer to your transmitter’s manual for binding button or switch instructions.
7. After 5 to 10 seconds, the receiver status LED will turn solid, indicating that the receiver is bound to the
transmitter. If the LED does not turn solid, refer to the Troubleshooting Guide at the back of the manual.
For subsequent flights, power ON the transmitter for 5 seconds before connecting the flight battery.
SAFE®Select Technology
The evolutionary SAFE®Select technology can offer an extra level of protection so you can perform the first flight
with confidence. No complex transmitter programming is required. Just simply flip your GEAR switch to position 1
(Channel 5) to make the SAFE Select system active. Flip the Gear switch back to turn OFF SAFE Select and fly with just
the assistance of AS3X®technology.
When activated, bank and pitch limitations keep you from over-controlling and automatic self-leveling makes recovery
from risky or confusing attitudes as simple as releasing the sticks. In fact, with the aileron, elevator and rudder sticks in
the neutral position, SAFE Select will automatically keep the airplane in a straight and level attitude.

5
EN
To obtain the best flight performance, we recommend using a DSM2®/DSMX®
transmitter capable of Dual Rates. Before binding, ensure that you are starting
with a blank acro model in your transmitter.
IMPORTANT: After you set up your model, always rebind the transmitter
and receiver to set the desired failsafe positions.
Program Your Transmitter
1. Start with a new ACRO Model.
2. Set Aircraft Type: Wing >1Ail 1Flap
: Tail > Normal
3. Leave all settings at their default values.
The Gear Switch (ch 5) will control the Safe mode function.
• Switch position 0 = SAFE Mode
• Switch position 1 = AS3X Mode
Computerized Transmitter Setup
(DX6e, DX6 G2, DX7 G2, DX8 G2, DX9,
DX18 and DX20)
Start all transmitter programming with a blank
ACRO model (do a model reset), then name
the model.
Set Servo Travel to: 100%
F-Mode Setup
Switch 1 Inhibit
Switch 2 Inhibit
Channel Assign
Channel Input Config
1 Throttle
2 Aileron
3 Elevator
4 Rudder
5 Gear SAFE/AS3X
6 Aux 1 FLAP
Frame Rate
22mz
DSMX
Function List
Timer 6:00
Set FLAP SYSTEM:
SELECT SWITCH
POS 0: -90% FLAP
POS 1: 0% FLAP
POS 2: 90% FLAP
Transmitter Setup
Dual Rates and Expos
The suggested settings shown here are the recommended starting settings.
Adjust according to the individual preferences after the initial flight.
NOTICE: Do not set your transmitter travel adjust over 100%. If
the TRAVEL ADJUST is set over 100%, it will not result in more control
movement, it will overdrive the servo and cause damage.
It is normal for linear servos to make significant noise. The noise is not an
indication of a faulty servo.
TIP: For the first flight, fly the model in low rate.
Dual Rates
Low High
Aileron, Elevator, Rudder 70% 100%
100%
x 5
100%
Mode 1 and 2 Transmitters
1. Power on the transmitter.
2. Power on the aircraft.
3. Hold both transmitter sticks to the outside bottom
corners and toggle the Gear switch 5 times
(1 toggle = full up and down). The control surfaces
of the aircraft will move, indicating SAFE Select has
been enabled or disabled.
Repeat the process again to re-enable or disable
SAFE Select.
To enable and disable SAFE®Select Technology use the following steps.

6
EN
1-2-3-4-5 Sec.
1
3
4
2
ESC/Receiver Arming, Battery Installation and Center of Gravity
28mm
AS3X
The AS3X®system will not activate until the throttle
stick or trim is increased for the first time. Once active,
the control surfaces may move rapidly and noisily on
the aircraft. This is normal. AS3X technology will remain
active until the battery is disconnected.
1. Remove the battery hatch from the fuselage.
2. Install the flight battery in the center of the battery
tray. Ensure the battery is secured by the hook and
loop strip.
Center of Gravity (CG)
Measure back 28mm from the leading edge of
the top wing, where the wing meets the fuselage
and place a mark. Balance the airplane on this CG
mark. The easiest way to achieve CG is to balance
the aircraft upright.
3. Lower the throttle and throttle trim to the lowest
settings on your transmitter. Power on your
transmitter, then wait 5 seconds.
4. Connect the battery to the ESC, noting proper polarity.
Keep the aircraft upright (on its gear)and immobile
and away from wind for 5 seconds to allow the AS3X
system to initialize. A series of tones and a continuous
LED indicates a successful connection.
CAUTION: Always disconnect the Li-Po battery
from the ESC when not flying to eliminate power
supplied to the motor. The ESC does not have an arming
switch and will respond to any transmitter input when a
signal is present.
CAUTION: Always disconnect the Li-Po battery
from the ESC when not flying to avoid over-
discharging the battery. Batteries discharged to a voltage
lower than the lowest approved voltage may become
damaged, resulting in loss of performance and potential
fire when batteries are charged.
CAUTION: Always keep hands away from the
propeller. When armed, the motor will turn the
propeller in response to any throttle movement.
Arming the ESC/receiver also occurs after binding as
previously described, but subsequent connection of a
flight battery requires the following steps.

7
EN
Aircraft movement AS3X Reaction
1. Advance the throttle above 25%
to activate the AS3X system.
2. Fully lower the throttle.
3. Move the entire aircraft as
shown and ensure the control
surfaces move in the direction
indicated in the graphic. If the
control surfaces do not respond
as shown, do not fly the aircraft.
Refer to the receiver manual for
more information.
Once the AS3X system is active,
control surfaces may move rapidly.
This is normal. AS3X is active until
the battery is disconnected.
ElevatorAileronRudder
Control Direction Tests
Traditional Control Direction Test
You should bind your aircraft and transmitter before doing these tests. Move the controls on the transmitter to make sure
the aircraft control surfaces move correctly and in the proper direction. Make sure the tail linkages move freely and that
paint or decals are not adhered to them.
AS3X®Control Direction Test
This test ensures that the AS3X®control system is functioning properly.

8
EN
Control Centering
Control Horn Settings
The illustration shows linkage positions chosen for the best
aerobatic response. Linkage connections on the control
horns directly affect aircraft response.
Aileron RudderElevator
Before your first flight, make sure the aircraft’s control
surfaces are centered.
1. Power on the transmitter and then the aircraft.
2. Set all transmitter trims and sub-trims to zero.
3. Check the control surfaces to make sure they are
centered.
4. If centering is required, use a pair of pliers to carefully
bend the metal linkage (see illustration).
In flight trimming may be required.
During your first flight, the aircraft should fly straight and
level. Use your transmitter trims to fine-tune the aircraft’s
flight path until it has been corrected. Any transmitter trim
that requires 4 or more clicks of trim (per channel), should
be mechanically centered. Note the control surface’s
postion and return the transmitter trim to zero. Adjust the
linkages mechanically so that the control surfaces are in
the flight trimmed position.
Make the U-shape narrower to make the connector shorter.
Make the U-shape wider to make the linkage longer.
LVC is a feature built into your ESC to protect the battery
from over-discharge. When the battery charge becomes too
low, LVC limits power supplied to the motor. When you hear
the motor power pulse, land the aircraft immediately and
recharge the flight battery.
NOTICE: Do not rely on LVC to determine when to land
your aircraft. Set a flight timer to the recommended flight
time. Repeated flying to LVC will damage the battery.
Low Voltage CutOff

9
EN
Post Flight Checklist
1. Disconnect the flight battery from the ESC
(Required for safety and battery life).
2. Power OFF the transmitter.
3. Remove the flight battery from the aircraft.
4. Recharge the flight battery.
5. Store the flight battery apart from the aircraft and
monitor the battery charge.
6. Make note of the flight conditions and flight plan
results, planning for future flights.
Flying Tips and Repairs
We recommend flying your aircraft outside in calm
conditions. Always avoid flying near houses, trees, wires
and buildings. You should also be careful to avoid flying
in areas where there are many people, such as busy
parks, schoolyards or soccer fields. Consult local laws and
ordinances before choosing a location to fly your aircraft.
Takeoff
Place the aircraft in position for takeoff (facing into the
wind if flying outdoors). Set dual rates to low position and
gradually increase the throttle to ¾ to full and steer with
the rudder. Pull back gently on the elevator and climb to
check trim. Once the trim is adjusted, begin exploring the
flight envelope of the aircraft.
Landing
Land into the wind. This is very important for this model.
Fly the aircraft to approximately 6 inches (15cm) or less
above the runway, using a small amount of throttle for
the entire descent. Keep the throttle on until the aircraft is
ready to flare.
During flare, keep the wings
level and the airplane pointed
into the wind. Gently lower the
throttle while pulling back on
the elevator to bring the aircraft
down on all three wheels.
Failure to lower the throttle
stick and trim to the lowest
possible positions during a
crash could result in damage
to the ESC in the receiver
unit, which may require
replacement.
Over Current Protection (OCP)
This aircraft is equipped with Over Current Protection
(OCP). This feature protects the ESC from overheating. OCP
stops the motor when the transmitter throttle is set too high
and the propeller cannot turn. The OCP will only activate
when the throttle stick is positioned just above 1/2 throttle.
After the ESC stops the motor, fully lower the throttle to
re-arm the ESC.
NOTICE: Crash damage is not covered under the warranty.
Repairs
Repair the aircraft using foam-compatible CA
(cyanoacrylate adhesive) or clear tape. Only use foam-
compatible CA, as other types of glue can damage the
foam. When parts are not repairable, see the Replacement
Parts List for ordering by item number.
For a listing of all replacement and optional parts, refer to
the list at the end of this manual.
NOTICE: Use of foam-compatible CA accelerant on your
aircraft can damage paint. DO NOT handle the aircraft
until the accelerant fully dries.
NOTICE: When you are finished flying, never leave the
aircraft in direct sunlight or in a hot, enclosed area such
as a car. Doing so can damage the foam.
CAUTION: Always
decrease throttle
at propeller strike.

10
EN
Power Components Service
Disassembly
CAUTION: DO NOT handle the propeller
while the flight battery is connected to
the ESC. Personal injury could result.
Propeller
1. Carefully remove the screw (A) and propeller (B)
from the motor shaft.
D
C
F
E
Assembly
Assemble in reverse order.
• Connect the motor wire connector to the ESC/receiver.
• The propeller size numbers (5.75x2.5) must face out
from the motor for correct propeller operation.
• Ensure the propeller adapter and motor mount are fully
connected to the motor.
Motor
1. Remove the battery hatch by gripping the front of the
hatch, then pulling it up and away from the fuselage.
2. Disconnect the motor wire connector from
the ESC/receiver connector.
3. Remove the screw (C) and motor (D) from the motor
mount.
4. Remove 3 screws (E) and the prop adapter (F)from
the motor. The motor magnet may attract screws to
the motor.
A
B
