HORN LHD6001+ User manual

LHD6001+

INSTALLATION MANUAL
Hybrid alarm system

1
1
2
3
3
3
3
4
5
5
6 Remote controller
7
7
8 Siren alarming
8
8
8
9
10
System Installation Info…t
Packing List
System Installation Diagram
Indicator signification
Buzzer signification
Siren signification
Term Definition
Main features and functions
Zone Type Definition
Zone Number
Keypad introduction
Keypad LED indication
Locke and unlocke the Keypad
Code Access
Keypad Operation
Remote Operation and indication
Telephone Operation
Installation
Programming
Appendix
Operation
1
3
11
15
38
CONTENT
General 11
11
11
11
11 AC
12
12
13 Siren output
13
13
13
13
14
14
15
38
39
39
40
41
41
Attention
Basic Requirement
Installation of control panel
Tamper switch connection
power connection
Backup power connection
Installation of keypad
PGM Output
AUX power output
Anti-Tamper switch
Loop input
Telephone line connection
AC power connection
Parameter Setting
CMS communication Code
Wireless Detector Code
System Restriction
Trouble shooting
Specification
zone Type Setting Form

Note: 1. Accessories bag 1 includes Screw and Expansion (4PC), EOL resisters(2.2K, 8PCS), key(1PC),
2. Accessories bag 2 includes crew and Expansion (4PC).
3. Accessories in bag 1 is used to install panel and 2 for keypad.
Packing list
INSTALLATION INFO
user Name
User Address
Fax
Tel of Control panel
Note: Please make sure all the above information filled in and confirmed by the installer or the installation company.
Installer
Installation Company
Installation Date
Tel of Installation Company
of Installation Company
Center Stations Address
Tel of Center Stations 1
Tel of Center Stations 2
The components of the product are packed in a box as followed. Open the box and check it carefully. If finding
deficiency, please fetch the provider in time.
No.
1
2
3
4
5
Quantity
1
1
1
1
2
Accessories Bag
Installation Manual
Keyfob
Control Panel
GENERAL
-1-
Description
Keyfob
Fuse (2.0A,2P ；0.5A,2PCS).CS

14
+12VAC 220V AC 14V
F5
F4 1A
1A
F6 2A
ARM
EAR T H
POWER
Use
Default
220V
天线
315mA
红色
红色
绿色
绿色
GPRS T CP /IP
RELAY +12V
BELL+ BELL-
-2-
N.O.
detector
AUX POWER
Transformer
Power
AUX POWER
Controlled element
Wireless module
GENERAL

LED Indication
Power
Alarm away (Red)
Disarm (Green)
Prog
Zone 1～16
GPRS
PSTN
TCP/IP
Panic
Off
-
Disarm
-
Q programminguit
Zone Invalid
Not used
Not used or
before dialing to CMS）
Not used
Normal
Flash Slowly
AC Power lose
Arm Stay
-
Programming
-
Dialing the CMS
-
Flash Quickly
Low battery
-
Panel/Keypad tamper alarm /Module lose
-
Alarming
Server disconnected
CMS communication failed
Server disconnected
Panic Alarm from keypad or remote controller
ON
Normal
Arm Away
Disarm
Keypad lose
Zone activated
Module loss
PSTN loss
Module loss
-
1.
3.
4. Three DI in operation or programming mans operation failed or wrong programming.
Continuous beeping indicates Entry/exit delay, alarming. Please check “Buzzer indication”in
2. “DI DI” in every 2 minutes means system trouble happened which includes AC Power lose, low battery, CMS communication
failure, bell short circuit, break circuit .
“DI…” means programming success or arm/disarm success.
page 7 for detailed information.
Buzzer indication
1.
2.
3.
Continuous sound means alarming.
1 sound reminds of successful disarm.
2 sounds remind of successful arm.
4. 4 sounds remind of disarm/arm failure.
Bell signification
Term Definition
Oper
-3-
The LED of the zones except those with 24hours zone type will be off when they are disarmed one by one,
or bypassed, or under disarm status. And the LED will be on to show the zones availability.
Server connected
Server connected
Detector: A facility that detects intrusion and abnormal state automatically via some electric or physical
methods and outputs switch signals or wireless signals to the system for disposal, then sends out
alarm signals, such as infrared detector, smoke detector, etc.
Zone: An area within the detection range of one or one ground detectors, described by numbers in the system.
Bypass: Close one of the zones temporarily, so that it can not alarm while activating the zones freely.
Arm-away: The armed state while going out. All the zones without bypass are in alarm state.
Arm-stay: The armed state at night. All the zones are in alarm state except active zone.
Disarm: Cancel the alarm information that has happened. Close the entry/exit zones, active zones,

Here are the main features and functions of this alarm system.
Support 8 remote controllers and remote 1~7 for Arm/Disarm and compatible to EV1527, Remote 8 for
system status check.
ystem can work without keypad after installation.
2 CMS numbers,1 number for free arm, 1 number for free disarm,4 user numbers.
Compatible with: ADEMCO 4+1 , Contact ID.
1 Bell output
1 PGM output, N.O/N.C optional, Dozens of trigger ways optional.
Support 4 keypads at most, 1 Warning board
10 codes: 1 for installer, 1 for master,7 for users and duress.
Siren call back optional to confirm the success of arm or disarm.
255 Event Logs
Support Patrol function
Support wireless detector low voltage reminding and Supervision function
Single zone arm/disarm
Supporting Testing Mood
1. 8 wired zones and 8 wireless zones.
2.
3. S
4.
5. Messages to CMS optional to save cost.
6. 4 numbers for message sending, event type can be chose.
7. 2 CMS setting optional.
8.
9. GPRS, PSTN or TCP/IP supported, AND&OR optional.
10. Telephone line remote programming, CMS remotely arm or disarm operation, remote controller operation.
11.
12.
13.
14.
15.
16.
17. Anti tamper on panel and keypad, anti-cut on keypad and siren.
18. AC lose, low battery, PSTN lose, siren lose trouble alarm etc..
19. DC 12V
20. Disarm, Arm, panic alarm from keypad and remote control.
21.
22.
23.
24.
25. system reset via hardware or programming optional.
Main features and functions
-4-
Oper
24-hour zone: No matter armed or disarmed, it is in effective detecting status. It is usually used in fire alarm,
plunder alarm and other emergent alarm which can be cancelled only by password holder.
Center Monitoring Station(CMS):Alarm message will be sent to CMS via telephone line which
can take action accordingly after it received the alarm message.
Entry delay: A period for user to enter detection area, activate the delay zone and disarm before the system
alarms. During the period,user can activate several specified zones (entry zone etc) without alarm
immediately. While exceeding the time, the system alarms if not disarmed. Zones with entry delay
refer 7.1 zone type instructions .
Exit delay: A period for user to leave detecting area once the system armed. Zones with exit delay will not alert
during exit delay
Patrol Zone: Security guard can trigger patrol zone of alarm system to send a signal to the CMS center to tell
them they are patrolling this area.
This product transmits alarm information to the user via PSTN, GPRS or TCP/IP and can be remotely controlled to deal
with emergencies in time, ensuring user's personal and property safety. With full functions, flexibility, high resistance to
broken and convenient operations, it is very suitable for residential, store, factory, warehouse, bank, school and
hospital, etc.
Note：Funcitons related to GPRS andTCP/IP are only present in version 2.0.

Zones on panel: Zone 01～08 is wired zones.
Zone 09～16 is wireless zones.
Zone 17 is panic alarm from keypad and remote controller.
Zones on keypad: Zone 31～34 is for anti-tamper alarm from keypad1 to keypad 4.
and zone 51～54 for line lose from keypad1 to keypad4.
GPRS: Zone 55 is for the GPRS lose.
TCP/IP: Zone 56 is for TCP/IP module lose.
Zone defination
Zone type and definitions
Zone
type Disarm Arm way Arm stay Exti delay Entry delay
Flash & Sound
Alarm
Installation place
or detector
Gate
Access control
Type number
09
02
03
04
05
06
07
08
01
81
Entry/Exit zone
Active zone
Panic zone
Fire zone
Gas zone
Tamper zone
Duress zone
24h Zone
Non alarm zone
Note: (1) Key zone is used just for arm or disarm and will not alarm after it triggered.。
Note: (1)
2
Keypad will trigger Zone 51~54 Tamper Alarm if it stops working without cancellation.
( ) When use a walling board, shall not use the 4 keypad
th
-5-
Ineffective
Ineffective Ineffective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
EffectiveEffective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Effective
Yes
Yes
Yes
Yes
No
No
No
No
No
No No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Indoor
Perimeter zone
Ineffective Effective Effective No No Yes
Balcony window
Panic button
Fire detector
Gas detector
Anti-tamper switch
Fence
Panic button
Oper
Key zone

Remote controller
1. Wireless remote controller have 4 keys which can achieve operations of arm away/stay, disarm and panic alarm
without user password. Press keys on the remote controller towards the control panel to perform corresponding
operations. Press the panic button for 2 seconds to trigger the alarm.
Panic
Arm stay
Arm away Disarm
Correct direction of the antenna Wrong direction of the antenna (the remote should not point to
the vertical direction of antenna of panel).
-6-
Wooden Wall
Panel
Transmitter
A
Concrete wall
Please notice several things as below to make sure best receiving and transmitting.
Install the panel in the middle of all the wireless devices;
Far away from the places with noise, magnetic interfering, such as the place with air conditioner, heater,
and electronic box,etc.
Shorten the distance between the panel and detector;
Try to make the obstacles as less as possible;
The concrete wall will shorten the distance between the receiver and transmitter.
Oper
Transmitter
B
Transmitter
A
Transmitter
B
2. Force Arm: If the zones except 24h zones are triggered, which are set type1 by command 47, the panel will
still arm by pressing the button on remote controller one more time after the first arm failure. After this
operation, the triggering zones will be automatically bypassed. After restore the zones, zone bypassing will
be automatically cancelled. Please note, the force arm couldn't activated if it is alarming or entry delaying.
3. When there is no keypad working with this system, one remote controller can be learned to NO8 remote to
check the status of this system. Press any button of this registered remote controller, the panel will beep one
time to show disarm status, and twice for Arm.
4. The users also can set by command 69 a remote controller to arm or disarm all the zones or arm some zones
by pressing button one time. Please this doesn't work for the zones without exit delay which will arm immediately.
5. If the remote controller is built with antenna, the usage should be what stated in the below pictures.

Siren can be set to sound twice when arm way or disarm the system, and once when disarm,
four times when operation failed.
When no keypad is connected to the system, when arm or disarm this system, siren will sound no matter siren is set on or off.
Keypad locked and unlocked
If the password is input wrong for 5 times, the keypad will be locked, then the panel couldn’be operated except the operations
which don't need password. The back-light will shine for 3 times under other operations which requires password input, like
disarm. Command 52 is to set the times of wrong inputting password.
If keypad locked without alarm and then there is alarm for control panel, the panel will be unlocked, and the user can disarm.
If the keypad is locked when there is alarm and have not been disarmed, the panel will be locked when it alarm again, it will be
unlock itself 30 minutes later or you can unlock it by re-power the system.
Code Access
System support 10 codes: 1 Installer code,1 master code, 7 user code and 1 remote programming code. Duress code can be
generated respectively based on Master code and user code by plus “1” to the last place.
The right of different code is as below:
Code
Installer Code
master code
user code1~7
Remote programming code
Duress code
Programming
√
×
×
√
×
Arm/Disarm All
×
√
√
√
√①
Arm/Disarm partly
×
√
×
√①
-8-
Oper
Siren Signification
Note: ①The duress code has the same right with master code and user's code
Keypad operation
Arm or disarm all zones
The user will arm all the zones by pressing the ARM AWAY or ARM STAY button on the keypad, or by using the
user's code which has the right to arm all the zones. The arm all zones action can be showed by the LED of
Arm or disarm.
Here are the instruction of how to arm or disarm all zones by keypad.
1. Arm stay all zones: when the panel is under disarm status and without any panic alarm, the panel will arm all
the zone by pressing the arm-stay button. Under arm away status, press the arm stay button , mater code or
user's code and # to arm stay this system. When panic alarm happens, it should be disarmed first. It will beep
twice when in arm stay status.
2. Arm away all the zones: When there is no panic alarm happened, the panel will arm away all the zones if the
arm away button pressed. During this operation, the buzzer in the keypad will keep beeping till the exit delay
finished. But if there is panic alarm, the panel should be disarmed first. The buzzer will beep twice to show
that panel is under arm away status.
3. Disarm all the zones: It should input master code or user's code and # to disarm all the zones. Code is
needed in every disarm. Disarm will stop calling to users but not the communicating with the CMS.

-9-
Oper
4. Disarm the panic alarm: Press the disarm button, duress code and # to disarm when panic alarm happened.
Duress code is produced according to mater code or user's code. For example, if master code is 8889, the
duress code will be 8880, and 9990 if the master code is 9999. When disarm the system, after inputting this
duress code, the panel will call to alarm, but the siren will not siren even if it is set on.
5. For ARM the zones: After disarm or arm failure, press again the button again for 3S to force Arm the system.
This is not working for the conditions if there is alarm happened or during the entry delaying.
Arm or disarm the zone one by one
1. Arm single zone: Input user's code with #, then zones to which the input code has the right to control will be armed
2. Arm some zones: Press disarm button on the keypad, input user's code and # to disarm some zones.
3. Force arm some zones: Input user's code, then 1 with # to force arm the system if previous arm action invalid.
Then the zones under the control right of the input code will be force armed. For example, if user's code 5678
has the right to control zone 3,5 and 8. Press disarm button, input user's code 5678 confimed with #, then
zone 3,5 and 8 will be disarmed.
After installed correctly, the keypad can be cancelled and the system can be operated as the instructions as below:
use the remote controller, key zone or telephone lines to Arm or disarm the system.
Power LED on the main board of panel will be on when AC power or backup battery connected, and ARM LED
will be on when the whole system in Arm way status and flash when arm stay and off when disarm.
The buzzer will beep in every two minutes to show the system trouble of AC lose, low battery, PSTN lose, and
siren trouble for 30 minutes.
The bell will turn on if no keypad is connected when the users use remote controller to arm or disarm this
sytem, no matter what is set by command 44.
Operation without keypad

-10-
Telephone alarm
Oper
When there is alarm, the master controller dials the number, and the user will hear “Di Di Di”, and sounds after
2s, the sound will repeat for 5 times. And after 2s, the master controller hangs up. Before the hang up, user can
control the panel by telephone buttons. Press “0” means confirming the alarm, but no dial. But it will send alarm
to center station.
Before master controller hangs up, the users can operate the system by pressing telephone buttons. The
operations details are as below:
Press 3 to disarm when the system sounds “Di Di Di”;
After disarmed, press 1 to arm away, or press 2 to arm stay.
To turn off the siren, press 6 and press 7 to turn on the siren.
The siren will keep on for the time same with what set by command 29.
Note: Do not press any buttons on the telephone when voice alarming, or it will cause alarm message receiving failure. It will
stop the system to call to alarm just by turn off or turn on the siren, and it will be only stopped by pressing 0 button on
the telephone or disarm this system.
Remote Phone Operation
User can dial master phone of the system, and perform the operations: arm away/stay, disarm and field monitor
and hearing alarms. Operate as following:
User dials the number→the system picks up the phone, press#→input password →X→Press #→Hang up
X＝1: arm away
X＝2: arm stay
X＝3: disarm
X＝6: siren off
X＝7: siren on. The siren will keep on for the time same with what set by command 29.
X＝0: hangs up
Dialing the master phone for more than ringing attempts set. The system will answer automatically and
announce the user with a sound “Di”. Then user presses “#+4digits user password + 1digit operand+#”, the
system will operate corresponding commands. Operand has 4digits, 1 means arm away, 2 means arm stay,
3 means disarm, and 0 means hang up. For example, user password is 1234. To disarm the system, user can
press “# 1 2 3 4 #”after switching on the system. If the operations are performed correctly, “Di” will be heard
once, if the operations are performed incorrectly, “Di” will be heard twice. If password is wrong, user can input
password and operand again without inputting “#” in advance. The master controller will hang up if password is
input incorrectly three times or user does not press any key in 30s during the operation.
Note: Do not press any key during sounds “Di”, or message can not be received correctly. When dialing the master phone, the
users can continue operating the system without inputting the passwords again. When dialing the master controller,
after picked up, the users can arm, disarm all the zones or partially by inputting different passwords with #.

General requirements of engineering installation
Control panel installation
Work out a protection scheme based on user's protection zone requirements, then decide the type and rating
the detector.
Confirm the installation position and wiring direction according to the specific environment. Make sure the
position invisible without affecting its reliability. It is better to wire in concealed way.
The construction scheme and engineering drawings must be filed for maintenance later.
of
Mount the control panel in a position invisible and convenient to connect AC power and telephone line.
Please use backup battery to ensure the control panel can work normally when electric network fails.
Note: Only professional engineering installer can install, connect power line and provide service.
Disconnect the powers supply while open the cabinet.
Don't disassemble the control panel and the keypad panel randomly to avoid accidents and damages.
Please connect AC power to the control panel after ensuring the installation correct completely.
Please use standby power (accumulator) to ensure the control panel can work normally when electric
network fails.
If the user has any problem while using, call our company for help.
Before installation, please read the requirements as below:
220VAC input, 15V/2A output, 50Hz transformer.
Connect 14V output port( of transformer to '14VAC IN' of the control panel.two green wires)
Transformer-secondary supplies power only for the control panel; Can not share with other units.
Total current of the detector and the control panel should be less than 1.5A.The current for
extendable module should be less than 1.5A.
If AC power disconnects and the system is connected to standby power, the control panel
will alarm for AC power failure. AC indicator on keypad will be on, and buzzer will chirp twice
in every two minutes until chirps 15 times(30minutes) ; when AC power restores, AC power
indicator will be off.
AC power connection
-11-
Notice before usage
SYSTEM INSTALLATION
Panel anti-tamper connection
There are two anti-tamper switches, open case anti-tamper and offwall tamper.
It is suggested to connect the open case anti-tamper to zone 7 which is defaulted as anti-tamper zone and
bypassed. For off-wall anti-tamper, connect to Zone 8 which is defaulted as anti-tamper and bypassed as well.
Note: 1. Use the 2.2K resistor to connect the tamper switch to the zones.
2. After connection, dis-bypass both anti-tamper zones and do not change the zone type.
Transformer

Back-up battery connection
The control panel uses 12V/7.0Ah sealed lead-acid rechargeable battery as standby power.
There is a red and a black power cords with plugs in the master controller for standby
power connection. Connect the red power cord to the positive terminal of standby power
and the black power cord to the negative terminal of standby power.
Standby power is offered overload protection by fast-blow fuse F6(2A). If the fuse
opens, remove the short or overload condition, and then replace the fuse before restoring
power. Do not substitute a higher rated fuse.
The system checks automatically the state of battery. If disconnect to standby power or
voltage of standby power , the control panel will take operation of low-voltage, "Lowvoltage"
indicator on keypad will be on, and buzzer will chirp twice in every two minutesuntil chirps 15 times(30minutes).
Under AC powered, the panel will self-check the back-up battery once in every 15 minutes, and check all the
time under AC power disconnected situation.
Note: If low voltage is still indicated on the keypad after 24 hours charging, the battery might be out of use.
Keypad installation
TERMIALS
KDATAGNDV_KEY
Terminals
V_KEY:
GND: GND Power
KDATA:
Power input terminal on the keypad
Data line for communication between
keypad and the master controller
Connection between the wiring board of keypad
and the control panel: Connect V_KEY, KDATA
and GND port in the control panel to those in the keypad wiring board respectively, and fix them by screws.
Wiring gate
Digram of rear of the keypad
When more than 1 keypad should be connected, different address should be setted
for different keypad to avoid conflict which can be done through
jumping the cap on the rear of the keypad. Do the setting as the
what in right.
Keypad address
1(NO1 keypad)
2(NO2 keypad)
3(NO3 keypad)
4(NO4 keypad)
-12-
Connect the keypad to the terminals in the panel as below.
SYSTEM INSTALLATION
Battery
Sealed lead Acid Accumulator
12ID
OFF
ON
OFF
ON
OFF
OFF
ON
ON
Note: “ ON stands for on and OFF for off.” “ ”
POWER ARM
DISARMPROG
PANIC
*#
Away
Stay
Disarm
PROG/Panic

Bell output terminal(Bell+, Bell-)
Auxiliary power output terminal
Anti-tamper switch installation
Bell (BELL) normial voltage： AC powered，output voltage will be12V，and about12v for battery
powered, with protected by fuse F5(1A) fo short circuited.
Con to the nnnect the two power lines of the bell to "BELL+" and "BELL-" terminals i the control panel.
When Siren testing on, buzzer will beep one time in very two minutes if siren is not connected,
cut or short circuited. This will be stopped after 15 times, or disalarmed or siren connected correctly.
The biggest load capacity of relayterminal (KG1,KG2) is 30V /3A,
The relay can be set to NO or NC. If it is NO, both sides will be connected if it is triggered and
disconnected if it is set NC.
Please connect the detector between the power and the relay as the way stated in right picture.
The V_AUX terminal provides positive 11 12VDC for wire detector
The V_AUX terminal is offered overload protection by fast-below fuse V_SENSOR(1A). If the
fuse b , remove the short or overload condition, then replace the fuse. Do not substitute
a higher rated fuse.
to , with 1A current.
urned ed
Loop input
This panel can be connected to 8 wired zones with NO or NC detectors, by using a 2.2k resistor, which will be packed
with panel.
Connection diagram for Nc detector Connection diagram for NO detector
NC detector
Zone
GND
2.2KΩ EOL
NO detector
Zone
GND
2.2KΩ EOL
-13-
Relay output terminal
SYSTEM INSTALLATION
RELAY
Controlled element
Power
Note: Two sides will be disconnected if there is no power of this system no matter the relay is set NO or NC.
Detector
Note: 1. 2.2k resistor should be connected to key zone, And the loop resistor can be 1.8k to 2.6K.
2. It will take 0.5s to trigger the zones, any triggering less than 0.5 will be considered as fault alarm which will be
ignored by the system.
3. For safety reasons, please install the resistor inside the detector.
Fix anti-tamper switches in cabinet of the control panel, mounting on the rim and the side near the wall of the
cabinet respectively. It is suggested to connect the anti-tamper switches to zone 7 and Zone 8. Please refer
to Panel anti-tamper connection in Page 11.

If divider is different with what in the picture, please check whether there is noise from the telephone when
using the internet. No noise means it is installed correctly.
PSTN
PSTN
The siren can be set ON as the step “ prog →installer code →67→81→1→when PSTN lost and
alarming is the same with the time when the system alarm. It is defaulted off.
When telephone line is lost in self checking status the control panel will alarm for telephone line lost
indicator will be on and buzzer chirps twice in every two minutes until chirps 15 times 30minutes
When telephone line is restored indicator will be off
- , .
" " , ( ).
, " .
” “ ” “ # ”
Telephone line connection
AC power connection
Check line connection again, ensuring all lines are connected correctly.
Switch on AC power, power indicator on the keypad will be on; buzzer will beep twice; back light of the keypad,
alarm indicator and Keypad begins initialization. and then buzzer continuously beeps till the initiation finished.
Telephone line
Telephone line
L_IN1 L_IN2 L_OUT1 L_OUT2
Connect telephone line
Connect telephone or facsimile machine to “
interface of the master controller, which can ensure no effect on
telephone or facsimilemachine.
to terminal “ L_IN 1 L_IN2 as what in the right diagram.”, “ ”
L_OUT1 ”, “ L_OUT2 ”
ADSL Modem
Panel Telephone
TEL
With TCP/IP
-14-
SYSTEM INSTALLATION
Divider
Without TCP/IP

Parameter setting
Press “ PROG →Installer code→to set the system, PROG LED will flash slowly, and then the users can
program the telephone numbers, parameters etc. by inputting commands.
” “ # ”
Press “ # ” to confirm the command. If buzzer beep twice, it means it is programmed wrongly and couldn’t be
recognized by the system. If buzzer beep once, it means the previous setting is activated by the system and the
users can continue next setting. Keep pressing “ * ” “ # ” until quit the programming.
X=1~2,
YY=00~31, means
the content of the message. Please refer
to page 20 for detailed messages content
means the series No of CMS
telephone numbers;
How long to dial automatically
after off-hook XX=01～99, unit:100ms
X=1~8, means the series No of
telephone numbers,
1&2 is the CMS number;
3 is the free of charge number to arm;
4is the free of charge number to disarm;
From5 to 8 is for users’ telephone number.
Y should be set with the telephone numbers.
19
20
20
20
Edit the telephone numbers
Message type reported to
CMS
→ → → …Y→ 11 X Y #
→ 12 → X → Y Y →#
None
Y =19
Dual CMS MODE → 13 → X→ #X=1
Operation on keypadSetting
referring
page
Description Default
Alarm message sending times → → → 14 XX # XX=08
X=0~5 21
Battery checking times
→ → →15 X # X=3
21
21
21
21
05 Means 500ms
Edit user's ID
Edit user’s code
→ 20 → ...... → X X #
→ → → 21 X YYYY #→ 0808
22
22
Calling period
Period interval
→ → →17 XX #
→ → → 18 XX #
→ → →19 XX YY #→
X=1~9, Count circle
XX=01~24, Unit:15minutes，XX=02 Means
30 minutes
X=1
→ → →16 X #
22
Edit Installer code
→ → → 22 XXXX # 1234
22
→ → → 23 X # X=6
PROGRAMMING
-15-
Note: 1. Buzzer will beep once any button is pressed, and the back light will be on which will be off, if there is no further button press.
If there is no operation on keypad for 3 minutes, the command not confirmed by # will be lost.
2. The system can be programmed by the commands in the list as below. All the programming can only be done under the
status of disarm.
1
2
3
4
6
5
7
8
9
10
11
12
13
X=1: Sending message to CMS1,
CMS2; X=2: Sending message to
CMS2 if it is not success to send
message to CMS1.
XX=01~10,
Setting sending message count
XX=01~16 digits of telephone
number, 1st, 2nd…16th.
YY=01~25, period between two
digits, Unit:100ms
1000ms between
1st digits and 2nd
digits.100ms
between others
Period between two
DTMF digits
Setting telephone ring
attempts before picking-up
of the panel
X……X=4 user address or 8 user
address
1234 (4 user
address code)
X=0, YYYY = 4 digits of host's
password;
X= 1~7. YYYY =4 digits of normal
user's password
XXXX= 4 digits installer's password
X=0~9 (X=0 means the panel is
not allowed to be controlled by a
telephone elsewhere
No.

Zone type
→ 40 → XX → Y→ Y #
Relay output → 42 → XX →#
→ 41 → X →#
Relay output itme
Siren sounding when arm
or disarm
→ 43 → XX → #
→ 44 → X → #
XX=05 (50s)
X = 1
25 26
26 26
26
28
27
30
29
27
27
27
X = 1
X = 0
→ 39 → →X #
19
20
21
24
23
25
→ 38 →X →X #
→ 31 → XXX → #25
25
→ 37 →X →X # XX = 05
→ 30 → XXX → #25
→ 27 → → Y→ X #
→ 26 → → Y→ X #
→ 28 → → YY→ X #
→ 29 → XX → #
23
23
24
01
24
Relay NC or NO
→ 24 → X → Y→#
→ 25 →X #→
X=1
Y=1 23
23
0
31 27
Using key to disarm or arm → 45 → →Y
→Z →
XX
#
-16-
PROGRAMMING
14
15
16
17
18
No. Operation on keypadSetting
referring
page
Description Default
Turning on/ off siren
Turning on/ off detecting siren
X=0 means turning off siren.
X=1: turning on siren
Y=0 means turning off detecting siren,
Y=1: tuning on detecting siren
Sending installing message
to user or not
X=0~1.
0 means off; 1: on
On/off detecting telephone
line, AC power and battery
X=1,means choosing telephone line;
X=2:choosing AC power;
X=3:choosing battery.
Y=1means on; Y=0:off
Turning on detecting
telephone line;
Tuning off detecting
AC power and battery
Protocol option
X=1~2 means the series number of CMS
Y=0~1:series number of protocol,
Y=0:Contact ID, Y=1:4 +1
Contact ID for
CMS1 and
CMS2
Message option thru GSM X(X=1~4): series number of GSM
device; YY: message option
Lasting time of siren working XX=00～30, unit: 1minute
Working time 0~30 minutes
XX=10,
10s
Exit delay time adjustment XXX=000~300
Time delay 0~300 seconds
XXX=100,
100s
Entry delay time adjustment XXX=000~300
Time delay 0~300 seconds
XX=040,
40s
22 25
X=3
X=3~9
→ 34 → →X #
Ring attempts thru a free of
charge of telephone line
Attempts to send the same
message to a CMS
XX=00~99, Attempts to send the
same message to a CMS
Setting period of sending
the same alarm by only
one wired zone
XX=00~99,
Unit: 10 seconds
XX = 03
30s
Siren works again or not
when only a zone alarms
more than two times
X=1 means the siren works again when
a zone alarms more than 2 times.
X=0:siren works only one time
XX=01～16(01~08: 8 wired zones,
09~16:8 wireless zones)
Y=01~09,81,82
7th and 8th zone
are tamper type.
The others are
perimeter type
X=0/1, 0 means NO; 1: NC
XX=00~99, not all figures can be set,
refer the detail of setting 42XX
XX=00,
none-use
XX=00~60; 00 means relay output
until disarm. For example XX=02
means relay output for 02 seconds
X＝0:Siren keeps silence,
X＝1: Siren sounds after arm or
disarm
XX means the series number of a
zone; Y:panel's action after zone
XX triggers; Z:panel acts by zone
XX triggers or recover.
3 means panel
stay-arm after
Zone XX triggers
