Hoshizaki AM-50BAE-ADDS User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
AM-50BAE-D
4/08
Item # 13172
ELF-CONTAINED CUBER WITH BUILT-IN TORAGE BIN
Warranty
Valid in nited States, Canada, Puerto Rico, & .S.Territories. Contact factory for warranty in
other countries.
Two Y ar - Parts & Labor on entire machine.
AM-50BAE-(AD)DS*
Hoshizaki reserves the right to change specifications without notice.
AM-50BAE-DS
•Undercounter design is less t an 34 inc es tall
AM-50BAE-ADDS
•Undercounter design is less t an 32 inc es tall, w ic complies wit t e Americans
wit Disabilities Act (ADA)
AM-50BAE-DS & AM-50BAE-ADDS
•Up to 55 lbs. of ice production per 24 ours
•UL approval for outdoor use
•Up to 22 lbs. of built-in storage capacity
•Power switc accessible wit out panel removal
•Easily disassembled water circuit for easy cleaning
•Front in, front out airflow
•Fewer moving parts for longer life
•Swing style reversible door
•Side trim kit available
•Optional drain pump HS-0190
•R-134A Refrigerant
Item #
Project:
Qty:
(ADA Compliant with Customized Door ystem)
CCUUBBEERR DDIIMMEENNIIOONN
W x D x H
AM-50BAE-ADDS
147/8 x 225/8 x 311/2
AM-50BAE-DS
147/8 x 225/8 x 331/2
*Designed to accommodate custom
cabinetry to affix to stainless door.
AM-50BAE-DS*
Air-Cooled
Shown
with Custom Cabinetry
AM-50BAE-ADDS*
Air-Cooled
ADA Compliant nit
*AutoCad available on KCL
AM-50BAE-DS
AM-50BAE-(AD)DS
*Customer responsible for providing cabinetry

Hoshizaki
DDIIMMEENNIIOONN
W x D x H
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
AM-50BAE-(AD)DS*
SELF-CONTAINED CUBER WITH BUILT-IN STORAGE BIN
O P E R AT I N G L I M I T S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 95˚F
• Water Pressure 7 - 113psig
• Voltage Range 104 - 127V
OPTIONS
• Side trim kit available
ELECTRICAL&PLUMBING
• 115V/60/1ø
• 15 amp Max Fuse
• 1/2" FPT Water Inlet
• 1/2" FPT Drain
TOP DIMENSIONS
FRONT DIMENSIONS SIDE DIMENSIONS BACK DIMENSIONS
FRONT DIMENSIONS
(ADA com liant unit)
SIDE DIMENSIONS
(ADA com liant unit)
BACK DIMENSIONS
(ADA com liant unit)
UTILITY CONSUMPTION ( AI R 7 0ºF /WATE R 50 ºF )
AIR-COOLED
Mod l Numb r
70˚
50˚
Ic Production
Pr Cycl
KWH p r
100 LBS.
Potabl
Wat r
Gal. p r
100 lbs.
Lbs. Cub s
AM-50BAE-(AD)DS
Air
T mp˚ F.
Wat r T mp˚ F.
SPEC I F ICAT I ONS
Mod l Numb r Cond ns r Amp rag Min. Circuit
Ampacity Shipping
W ight
3.4 15 115 lbs.*
AM-50BAE-(AD)DS
9.9 53.7
55 lbs.
Air-Cooled
0.65 24
Cond ns r
Wat r
Gal. p r
100 lbs.
N/A
AM CUBE DIMENSIONS
* Without allet
AM-50BAE-DS
147/8 x 225/8 x 331/2
AM-50BAE-ADDS
147/8 x 225/8 x 311/2
• Air-cooled
• Air-cooled, ADA compliant
*Designed to accommodate custom cabinetry to affix to stainless door.
