Hoshizaki KML-250MAH User manual

Hoshizaki
©HOSHI AKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com
CUBER DIMENSIONS
WxDxH
KML-250/350M_H
9/06
Item # 13126
LOW PROFILE MODULAR CRESCENT CUBER
Warranty
Valid in United States, Canada, uerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
Three Year - arts & Labor on entire machine.
Five Year - arts & Labor on: Evaporator.
Five Year - arts on: Compressor, air-cooled condenser coil.
KML-250/350M_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
KML-250/350M_H
30 x 273/8 x 22
*AutoCad available on KCL
KML-250M_H
•Up to 314 lbs. of ice production per 24 hours
•Complies with California Energy Commission guidelines (CEC)
KML-350M_H
•Up to 354 lbs. of ice production per 24 hours
KML-250M_H & KML-350M_H
•Durable stainless steel exterior
•Individual crescent cube
•Protected by HoshiGuard Antimicrobial Agent
•CycleSaver®Design
•EverChec ®alert system
•Stainless steel evaporator
•Removable air filters (Air-cooled models only)
•Lower height for restricted areas (stairwells, low ceilings)
•R-404A Refrigerant
KML-250MAH
Air-Cooled
Shown on an optional
B-500
KML-250MWH
Water-Cooled
KML-350MAH
Air-Cooled
KML-350MWH
Water-Cooled
®
ICE
DISPENSER
HOSHIZAKI
DB-200
B-500
B-250
Also available on
Bins:
B-700PF/SF
B-800PF/SF
B-900PF/SF
Large Bins:
B-1150SS
B-1300SS
B-1500SS
B-1650SS

Hoshizaki
DIMENSIONS
WxDxH
©HOSHI AKI AMERICA, INC.
KML-250/350M_H
LOW PROFILE MODULAR CRESCENT CUBER
UTILITY CONSUMPTION
AIR-COOLED - KML-250/KML-350
Model Number
70˚
50˚ 70˚
307 / 350
90˚
80˚
90˚
Ice Production
Per Cycle
KWH per
100 LBS.
Potable
Water
Gal. per
100 lbs.
Lbs. Cubes
KML-250MWH
Air Temp˚ F.
Water Temp˚ F.
SPECIFICATIONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
7.5 20 165 lbs.
Water-Cooled
KML-250MWH
8.2 35.2
292 / 344
287 / 342
287 / 342
260 / 331
267 / 309
245 / 287
220 / 282
6.6 360
238 / 322
90/70
Condenser
Water
Gal. per
100 lbs.
N/A
O P E R AT I N G L I M I T S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water ressure 10 - 113psig
• Voltage Range 104 - 127V
ELECTRICAL&PLUMBING/KML-250/350M_H
• 115/60/1
• 20 amp Max Fuse/HACR Breaker Size
• 1/2” OD copper or equivalent independent potable water supply
• 3/4” F T independent drain connection
SER ICE
• anels easily removed and all components
accessible for service.
• Removable/cleanable air filters.
(Air-cooled models only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshiza i.com Printed in U.S.A.
KML-250/350M_H
30 x 273/8 x 22
WATER-COOLED - KML-250/KML-350
70˚
50˚ 70˚
314 / 354
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
308 / 349
306 / 347
306 / 347
296 / 338
290 / 330
277 / 316
269 / 310
287 / 331
KML-250MAH
6.3 34.9
6.6 360 120
8.2 20 165 lbs.
Air-Cooled
KML-250MAH
STORAGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
KML-350MWH
7.4 24.6
7.3 360 N/A
KML-350MAH
6.6 25.9
7.3 360 112
10.5 20 180 lbs.
Water-Cooled
KML-350MWH
11 20 180 lbs.
Air-Cooled
KML-350MAH
FRONT IEW SIDE IEW
ICE DROP ZONE
AIR-COOLED UNIT
WATER-COOLED UNIT
• Air-cooled
• Water-cooled
B-250 250 lbs. 230 lbs.
B-800 800 lbs. 600 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-1300 1275 lbs. N/A
B-1500 1490 lbs. N/A
B-1650 1605 lbs. N/A
