Hoshizaki KM-461MAH User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com
C BER DIMENSIONS
WxDxH
KM-461M_H
4/08
Item # 13185
SLIM-LINE MOD LAR CRESCENT C BER
Warranty
Valid in United States, Canada, Puerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
Three Year - Parts & Labor on entire machine.
Five Year - Parts & Labor on: Evaporator
Five Year - Parts on: Compressor, air-cooled condenser coil.
KM-461M_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
KM-461M_H
22 x 273/8 x 305/16
*AutoCad available on KCL
•Up to 452 lbs. of ice production per 24 hours
•Durable stainless steel exterior
•Individual crescent cube
•Protected by HoshiGuard antimicrobial agent
•CycleSaver®Design
•EverChec ®alert system
•Stainless steel evaporator
•Mount two units side-by-side, in only 44" of floor space, for 904 lbs. per 24 hours
•Removable air filters (Air-cooled models only)
•R-404A Refrigerant
•Complies with California Energy Commission guidelines (CEC)
* The KM-461MRH is ENERGY STAR certified.
KM-461MAH
Air-Cooled
Shown on an optional
B-300
KM-461MRH
Remote Air-Cooled
®
B-500
B-700
B-900
B-800
B-300
Also availabl on Larg Bins:
B-1150SS
B-1300SS
B-1500SS
B-1650SS
*

Hoshizaki
DIMENSIONS
WxDxH
©HOSHIZAKI AMERICA, INC.
KM-461M_H
SLIM-LINE MOD LAR CRESCENT C BER
TILITY CONS MPTION
AIR-COOLED
Model Number
70˚
50˚ 70˚
452
90˚
80˚
90˚
Ice Production
Per Cycle
KWH per
100 LBS.
Potable
Water
Gal. per
100 lbs.
Lbs. Cubes
Air Temp˚ F.
Water Temp˚ F.
SPECIFICATIONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
6.3 18.0
438
434
434
409
398
368
349
10 480
389
90/70
Condenser
Water
Gal. per
100 lbs.
N/A
O P E R AT I N G L I M I T S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage Range 104 - 127V
ELECTRICAL&PL MBING/KM-461M_H
• 115/60/1
• 20 Amp ax Fuse/HACR Breaker Size
• 1/2” OD copper or equivalent independent potable water supply
• 3/4” FPT independent drain connection
SERVICE
• Panels easily removed and all components
accessible for service.
• Removable/cleanable air filters
(Air-cooled model only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com Printed in .S.A.
KM-461M_H
22 x 273/8 x 305/16
KM-461MAH
12.0 20 175 lbs.
Air-Cooled
KM-461MAH
STORAGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
B-800 800 lbs. 600 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-1300 1275 lbs. N/A
B-1500 1500 lbs. N/A
B-300 300 lbs. 260 lbs.
FRONT IEW SIDE IEW
ICE DROP ZONE
AIR-COOLED UNIT
REMOTE AIR-COOLED
70˚
50˚ 70˚
446
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
435
431
431
412
399
373
359
396
KM-461MRH 6.0 18.0
10.4 480 N/A
12.1 20 175 lbs.
Remote
Air-Cooled
KM-461MRH
REMOTE AIR-COOLED UNIT
22
15 3/4
32 13/16
URC-5F
Air Flow
18
24
Liquid Refrigerant
Line
Discharge Line
Electrical
Conduit
Access
Pre-Charged Tubing Kits
(Sold Separately)
20’ R404-2046-2
35’ R404-3546-2
RC-5F Remote Condenser (Sold Separately)
For Use with K -461 RH
Voltage supply for the RC Remote
Condenser is supplied from the Ice Maker.
No additional circuit is required.
C O N D E N S I N G N I T
• Ambient Temp Range -20 - +122˚F
• Voltage Range 104 - 127V
• Air-cooled
• Remote Air-cooled
21/2
13/4
18 1/8
B-1650 1605 lbs. N/A
