CUBER DIMENSIONS
WxDxH
KML-631M_H
4/08
Item # 13192
LOW-PROFILE MODULAR CRESCEN CUBER
Warranty
Valid in United States, Canada, Puerto Rico, & U.S.Territories. Contact factory for warranty in
other countries.
hree Year - Parts & Labor on entire machine.
Five Year - Parts & Labor on: Evaporator
Five Year - Parts on: Compressor, air-cooled condenser coil.
KML-631M_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
KML-631M_H
30 x 273/8 x 26
*AutoCad available on KCL
•Up to 636 lbs. of ice productio per 24 hours
•Durable stai less steel exterior
•I dividual cresce t cube
•Protected by HoshiGuard a timicrobial age t
•CycleSaver®Desig
•EverCheck®alert system
•Stai less steel evaporator
•Removable air filters (Air-cooled models o ly)
•R-404A Refrigera t
•Complies with Califor ia E ergy Commissio guideli es (CEC)
* The KML-631MRH is ENERGY STAR certified.
KML-631MAH
Air-Cooled
Shown on an optional
B-500
KML-631MWH
Water-Cooled
KML-631MRH
Remote Air-Cooled
®
ICE
DISPENSER
HOSHIZAKI
DB-200
B-500
B-250
*

Hoshizaki
DIMENSIONS
WxDxH
©HOSHIZAKI AMERICA, INC.
KML-631M_H
LOW-PROFILE MODULAR CRESCEN CUBER
U ILI Y CONSUMP ION
AIR-COOLED
Model Number
70˚
50˚ 70˚
575
90˚
80˚
90˚
Ice Production
Per Cycle
KWH per
100 LBS.
Potable
Water
Gal. per
100 lbs.
Lbs. Cubes
KML-631MWH
Air Temp˚ F.
Water Temp˚ F.
SPECIFICA IONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
6.8 20 A 220 lbs.
Water-Cooled
KML-631MWH
6.2 26.0
558
553
553
525
515
481
459
9.0 480
501
90/70
Condenser
Water
Gal. per
100 lbs.
N/A
O P E R A I N G L I M I S
• Ambient Temp Range 45 - 100˚F
• Water Temp Range 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage Range 187 - 253V
C O N D E N S I N G U N I
• Voltage Range 104 - 127V
• Ambient Temp Range -22 - 122˚F
ELEC RICAL&PLUMBING/KML-631M_H
• 208-230/60/1(3 wire with dedicatedneutral for 115V)
• 20 Amp Max Fuse/HACRBreaker Size
• 1/2” D copper or equivalent independent potable water supply
• 3/4” FPT independent drain connection
SERVICE
• Panels easily removed and all components
accessible for service.
• Removable/cleanable air filters
(Air-cooled models only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com Printed in .S.A.
KML-631M_H
30 x 273/8 x 26
WA ER-COOLED
70˚
50˚ 70˚
632
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
632
631
631
631
593
572
579
630
KML-631MAH
4.4 24.8
9.7 480 119
7.6 20 A 220 lbs.
Air-Cooled
KML-631MAH
S ORAGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
B-800 800 lbs. 600 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-1300 1275 lbs. N/A
B-1500 1500 lbs. N/A
B-1650 1605 lbs. N/A
•Air-cooled
• Water-cooled
• Remote Air-cooled
B-250 250 lbs. 230 lbs.
REMO E AIR-CO O L E D
70˚
50˚ 70˚
636
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
626
622
622
604
578
545
535
589
KML-631MRH 5.3 24.0
9.4 480 N/A
7.8 20 A 220 lbs.
Remote
Air-Cooled
KML-631MRH
FRONT IEW SIDE IEW
AIR-COOLED UNIT
WATER-COOLED UNIT
REMOTE AIR-COOLED UNIT
ICE DROP ZONE
32 3/16
15 11/16
36 15/16
URC-9F
Air Flow
211/16
21/2
18 1/8
2115/16
34 5/16
Liquid Refrigerant
Line
Discharge Line
Electrical
Conduit
Access
Pre-Charged ubing Kits
(Sold Separately)
20’ R404-2068-2
35’ R404-3568-2
Voltage supply for the URC Remote
Condenser is supplied from the Ice Maker.
No additional circuit is required.
URC-9F Remote Condenser (Sold Separately)
For Use with KML-631MRH
