Hoshizaki F-1001MAH User manual

Hoshizaki
©HOSHIZAKI AMERICA, INC.
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com
FLAKER DIMENSIONS
WxDxH
F-1001M_H
4/08
Item # 13108
MODULAR FLAKER ICE MACHINE
Warranty
Valid in United States, Canada, Puerto ico, & U.S.Territories. Contact factory for warranty in
other countries.
Two Year - Parts & Labor on entire machine.
Five Year - Parts on compressor, air-cooled condenser coil.
F-1001M_H
Item #
Project:
Qty:
Hoshizaki reserves the right to change specifications without notice.
F-1001M_H
22 x 273/8 x 2515/16
SLIM-LINE SERIES
*AutoCad available on KCL
•Up to 970 lb . of ice production per 24 hour
•Durable tainle teel exterior
•CleanCycle12®De ign
•15 minute flu h cycle every 12 hour
•Remove ediment
•Cleaner ice
•Longer life and ea y maintenance
•R-404A Refrigerant
®
B-900
B-800
B-700
B-500
B-300
F-1001MAH
Air-Cooled
Shown on an optional
B-700
F-1001MWH
Water-Cooled
F-1001MRH
emote Air-Cooled
Also availabl on Larg Bins:
B-1150SS
B-1300SS
B-1500SS
B-1650SS

Hoshizaki
DIMENSIONS
WxDxH
F-1001M_H
22 x 273/8 x 2515/16
©HOSHIZAKI AMERICA, INC.
F-1001M_H FLAKER ICE MACHINE
SLIM-LINE MODULAR SERIES
UTILITY CONSUMPTION
AIR-COOLED
Model Number
70˚
50˚ 70˚
970
90˚
80˚
90˚
Approximate
Electrical
KWH per
100 LBS.
90/70 70/50
F-1001MAH
Air Temp˚ F.
Water Temp˚ F.
SPECIFICATIONS
Model Number Condenser Amperage Min. Circuit
Ampacity Shipping
Weight
8.1 15 210 lbs.
Air-Cooled
F-1001MAH
5.7 N/A
855
755
930
820
890
785
695
F-1001MWH Water-Cooled 7.2 15 210 lbs.
1755 1530
740
90/70 70/50
3.8
Condenser Water
Gal. per 100 lbs.
N/A
O P E R AT I N G L I M I T S
• Ambient Temp ange 45 - 100˚F
• Water Temp ange 45 - 90˚F
• Water Pressure 10 - 113psig
• Voltage ange 187 - 253V
ELECTRICAL&PLUMBING/F-1001M_H
• 208-230V/60/1 (3 wire with dedicated neutral for 115V)
• 1/2” OD copper or equivalent independent potable water supply
• 3/4” FPT independent drain connection
SER ICE
• Panels easily removed and all components
accessible for service.
• emovable/cleanable air filter.
(Air-Cooled model only)
618 Hwy. 74 S., Peachtree City, GA 30269 TEL [phone] FAX [phone] www.hoshizaki.com Printe in U.S.A.
•Air-cooled
• Water-cooled
• emote Air-cooled
WAT E R - C O O L E D
70˚
50˚ 70˚
890
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
820
770
855
805
840
785
735
755
F-1001MWH 4.1 63
1248 1245 3.1 34
90/70 70/50
STORAGE BINS
Model Number Application Capacity ARI-Rated Capacity
B-500 500 lbs. 360 lbs.
B-700 700 lbs. 550 lbs.
B-300 300 lbs. 260 lbs.
B-900 900 lbs. 660 lbs.
B-1150 1150 lbs. N/A
B-800 800 lbs. 600 lbs.
B-1500 1490 lbs. N/A
B-1650 1605 lbs. N/A
B-1300 1275 lbs. N/A
REMOTE AIR-COOLED
70˚
50˚ 70˚
930
90˚
80˚
90˚
Air Temp˚ F.
Water Temp˚ F.
835
750
895
805
865
780
700
745
F-1001MRH 4.9 N/A
1520 1570 4.1 N/A
F-1001MRH Remote
Air-Cooled 10.2 15 210 lbs.
FRONT IEW SIDE IEW
AIR-COOLED UNIT WATER-COOLED UNIT
REMOTE AIR-COOLED UNIT
ICE DROP ZONE
22
15 3/4
32 13/16
URC-6F
Air Flow
21/2
13/4
18 1/8
18
24
Liqui Refrigerant
Line
Discharge Line
Electrical Con uit
Access
Pre-Charged Tubing Kits
(Sold Separately)
20’ 404-2046-2
35’ 404-3546-2
URC-6F Remote Condenser (Sold Separately)
For Use with F-1001M H
oltage supply for the URC Remote
Condenser is supplied from the Ice Maker.
No additional circuit is required.
