OPERATOR’S MANUAL PRESSURE WASHER
4
INTRODUCTION & IMPORTANT SAFETY INFORMATION
Thank you for purchasing this Pressure Washer.
We reserve the right to make changes at any time
without incurring any obligation.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this pressure washer.Warning information
should be emphasized and understood. If the operator
is not fluent in English, the manufacturer’s instructions
and warnings shall be read to and discussed with
the operator in the operator’s native language by the
purchaser/owner, making sure that the operator com-
prehends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’ instructions.
The operator must know how to stop the machine
quickly and understand the operation of all controls.
Never permit anyone to operate the engine without
proper instructions.
SAVE THESE INSTRUCTIONS
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number. Use only identical replacement parts.
This machine is to be used only by trained operators.
IMPORTANT SAFETY
INFORMATION
READ OPERATOR’S
MANUAL THOROUGHLY
PRIOR TO USE.
WARNING: To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Read the owner's manual
thoroughly. Failure to follow
instructions could cause mal-
function of the machine and
result in death, serious bodily
injury and/or property damage.
2. Know how to stop the machine and bleed pressure
quickly. Be thoroughly familiar with the controls.
3. Stay alert — watch what you are doing.
4. All installations must comply with local codes.
Contact your electrician, plumber, utility company
or the selling distributor for specific details. If your
machine is rated 250 volts or less, single phase will
be provided with a ground fault circuit interrupter
(GFCI). If rated more than 250 volts, or more than
single phase this product should only be connected
to a power supply receptacle protected by a GFCI.
DANGER: Improper connection of the equip-
ment-grounding conductor can result in a risk
of electrocution. Check with a qualified electri-
cian or service personnel if you are in doubt as
to whether the outlet is properly grounded. Do
not modify the plug provided with the product
- if it will not fit the outlet, have a proper outlet
installed by a qualified electrician. Do not use
any type of adaptor with this product
WARNING
KEEP WATER
SPRAY AWAY FROM
ELECTRICAL WIRING.
WARNING: Keep wand, hose, and
water spray away from electric
wiring or fatal electric shock may
result.
5. To protect the operator from
electrical shock, the machine
must be electrically grounded.
It is the responsibility of the
owner to connect this machine
to a UL grounded receptacle of proper voltage and
amperage ratings. Do not spray water on or near
electrical components. Do not touch machine with
wet hands or while standing in water. Always dis-
connect power before servicing.
WARNING: Flammable liquids
can create fumes which can ig-
nite, causing property damage or
severe injury.
WARNING: Risk of explosion —
Do not spray flammable liquids.
6. Do not allow acids,
caustic or abrasive fluids to pass through the pump.
7. Never run pump dry or leave spray gun closed
longer than 1-2 minutes.
8. Keep operating area clear of all persons.
WARNING
USE PROTECTIVE
EYE WEAR
AND CLOTHING
WHEN OPERATING
THIS EQUIPMENT.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne
and fly at high speeds. To avoid
personal injury, eye, hand and
foot safety devices must be
worn.
9. Eye, hand, and foot pro-
tection must be worn when
using this equipment.
WARNING
RISK OF EXPLOSION:
DO NOT SPRAY
NEAR FLAMMAMBLE
LIQUIDS

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
5
PRESSURE WASHER OPERATOR’S MANUAL
IMPORTANT SAFETY INFORMATION
TRIGGER GUN KICKS
BACK - HOLD WITH
BOTH HANDS
WARNING
WARNING: Grip cleaning wand
securely with both hands before
starting. Failure to do this could
result in injury from a whipping
wand.
RISK OF INJECTION
OR SEVERE INJURY
TO PERSONS. KEEP
CLEAR OF NOZZLE.
WARNING
WARNING: High pressure devel-
oped by these machines will
cause personal injury or equip-
ment damage. Keep clear of
nozzle. Use caution when oper-
ating. Do not direct discharge
stream at people, or severe in-
jury or death will result.
10. To reduce the risk of injury, close supervision is
necessary when a machine is used near children.
Do not allow children to operate the pressure
washer. This machine must be attended during
operation.
11. Never make adjustments on machine while in op-
eration.
12. Be certain all quick coupler fittings are secured
before using pressure washer.
WARNING
PROTECT FROM
FREEZING
WARNING: Protect machine from
freezing.
13. To keep machine in best
operating conditions, it is
important you protect machine
from freezing.Failure to protect
machine from freezing could
cause malfunction of the
machine and result in death,
serious bodily injury, and/or property damage. Fol-
low storage instructions specified in this manual.
14. Inlet water must be clean fresh water and no hotter
then 90°F.
15. Manufacturer will not be liable for any changes
made to our standard machines or any components
not purchased from us.
16. The best insurance against an accident is precau-
tion and knowledge of the machine.
WARNING
RISK OF INJURY
FROM FALLS WHEN
USING LADDER.
WARNING: Be extremely careful
when using a ladder, scaffolding
or any other relatively unstable
location. The cleaning area
should have adequate slopes
and drainage to reduce the pos-
sibility of a fall due to slippery
surfaces.
17. Do not overreach or stand on unstable support.
Keep good footing and balance at all times.
18. Do not operate this machine when fatigued or under
the influence of alcohol, prescription medications,
or drugs.
Follow the maintenance instructions
specified in the manual.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
OPERATOR’S MANUAL PRESSURE WASHER
6
COMPONENT IDENTIFICATION
High Pressure Hose - Connect one end to water pump
discharge nipple and the other end to spray gun.
Nozzle Quick Coupler - Allows quick change of
nozzles.
Pump - Develops high pressure.
Spray Gun - Controls the application of water and
detergent onto cleaning surface with trigger device.
Includes safety latch.
Wand - Must be connected to the spray gun.
Flex Wand - Allows operator flexibility in spray angle.
(Standard on PLUS models only).
Plug
Power
Supply
Pressure
Nozzle
Water
Faucet
Water Supply
Hose
(not included)
Trigger
High
Pressure
Hose
Oil Dip
Stick
Spray
Gun
Quick
Coupler
Nozzle
Quick
Coupler
Inlet
Connector
Discharge
Nipple
Electric
Motor
Wand
Flex Wand
Pump

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
7
PRESSURE WASHER OPERATOR’S MANUAL
ASSEMBLY INSTRUCTIONS
STEP 1: Attach the high pressure
hose to the spray gun with quick
coupler.
STEP 4: Release the coupler collar
and push the nozzle until the collar
clicks. Pull the nozzle to make sure
it is seated properly.
STEP 6: Connect the high pressure
hose to the pump discharge fitting.
Push coupler collar forward until
secure.
STEP 2: Attach nozzle extension
to spray gun/wand. Tighten both
by hand.
STEP 3: Pull the spring-loaded col-
lar of the wand coupler back to insert
your choice of pressure nozzle.
STEP 7: Connect the garden hose
to pump inlet. Inspect inlets.
CAUTION: Do not run the pump
without water or pump damage
will result.
Safety
Latch
Spray
Gun
High
Pressure Hose
Nozzle
Extension
Spray Gun/
Wand
Wand
Coupler
Pressure
Nozzle
Pressure
Nozzle
Wand
Coupler
Wand
Collar
Pump Discharge
Fitting
High
Pressure
Hose
Pump Water Inlet
Garden
Hose
Coupler
Collar
STEP 5: Remove shipping cap and
install oil dipstick. Check pump oil
level by using dipstick. Use 40 wt.
non detergent oil.
Dipstick

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
OPERATOR’S MANUAL PRESSURE WASHER
8
OPERATING INSTRUCTIONS
STEP 1: Connect garden hose
to the cold water source and turn
water on completely. Never use hot
water.
STEP 2: Trigger the spray gun to
eliminate trapped air then wait for a
steady flow of water to emerge from
the spray nozzle.
Cold
Water
Source
Garden
Hose
WARNING! Never replace
nozzles without engaging the
safety latch on the spray gun
trigger.
Safety
Latch
STEP 3: Connect to appropriate
power supply.
STEP 4: Turn machine on by press-
ing remote control box (if equipped)
or by flipping the switch at the rear
of the motor and by triggering the
spray gun.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
9
PRESSURE WASHER OPERATOR’S MANUAL
Pump Storage
CAUTION: Always store your pres-
sure washer in a location where the
temperature will not fall below 32° F
(0° C). The pump in this machine is
susceptible to permanent damage if
frozen.
FREEZE DAMAGE IS NOT COVERED
BY WARRANTY.
If you must store your pressure washer in a location
where the temperature is below 32° F, you can minimize
the chance of damage to your machine by draining your
machine as follows:
SHUTTING DOWN AND CLEAN-UP
STEP 1: Remove deter-
gent suction tube from
container and insert into
one gallon of fresh water.
Slide nozzle forward for
low pressure or to connect
black detergent nozzle.
Pull trigger on spray gun
and siphon water for one
minute.
STEP 2: Turn off machine
by flipping switch on rear
of motor or by pressing the
switch on the remote con-
trol box (if equipped).
STEP 5: Disconnect the
garden hose from the wa-
ter inlet on the machine.
STEP 6: Disconnect the
high pressure hose from
high pressure outlet.
STEP 7: Engage the spray
gun safety lock.
STEP 4: Press trigger to
release water pressure.
Pump
Water
Inlet
High
Pressure
Outlet
Safety
Latch
STORAGE
CAUTION
STEP 3: Turn off water
supply.
1. Stop the pressure washer and detach supply hose
and high pressure hose. Squeeze the trigger of the
spray gun to drain all water from the wand and
hose.
2. Restart pressure washer and let it run briefly (about
5 seconds) until water no longer discharges from
the high pressure outlet.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
PRESSURE WASHER Troubleshooting Guide
10
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
PUMP RUNNING
NORMALLY BUT
PRESSURE LOW ON
INSTALLATION
Pump sucking air Check water supply and possibility of air seep-
age.
Check valves sticking Check and clean or replace if necessary.
Unloader valve seat faulty Check and replace if necessary.
Nozzle incorrectly sized Check and replace if necessary.
Worn piston packing Check and replace if necessary.
FLUCTUATING
PRESSURE
Valves worn Check and replace if necessary.
Blockage in valve Check and replace if necessary.
Pump sucking air Check water supply connections.
Worn piston packing Check and replace if necessary.
Insufficient water Check filter and hose for breakage/clogging
PRESSURE LOW
AFTER PERIOD OF
NORMAL USE
Nozzle worn Check and replace if necessary.
Suction or delivery valves worn Check and replace if necessary.
Suction or delivery lines blocked Check and clean if necessary.
Unloader valve seat worn Check and replace if necessary.
Worn piston package Check and replace if necessary.
Water temperature excessive Reduce to below 140oF.
PUMP NOISY Air in suction line Check water supply and connections on suction
line.
Broken or weak suction or delivery
valve spring.
Check and replace if necessary.
Foreign matter in valves Check and clean if necessary.
Worn bearings Check and replace if necessary.
Water temperature excessive Reduce to below 160oF.
PRESENCE OF WATER
IN PUMP OIL
Oil seal worn Check and replace if necessary.
High humidity in air Check and replace if necessary.
Piston packing worn Check and replace if necessary.
WATER DRIPPING
FROM UNDER PUMP
Piston packing worn Check and replace if necessary.
O-ring plunger retainer worn Check and replace if necessary.
WATER DRIPPING FROM
PUMP PROTECTOR
Water supply pressure too high
(over 90 psi)
Lower water supply pressure using regulator.
Spray gun is in the off position for over
1-2 minutes
Turn machine off if not in use for over 1-2 min-
utes.
OIL DRIPPING Oil seal worn Check and replace if necessary.
EXCESSIVE VIBRATION IN
HIGH PRESSURE HOSE
Irregular functioning of the pump
valves
Check and replace if necessary.
MOTOR DOES NOT START
WHEN SWITCHED ON
Plug not well connected or lack of
power supply
Check plug, cable and switch.
WHEN SWITCHING ON THE
MACHINE, MOTOR HUMS
BUT DOES NOT RUN
Main voltage is insufficient, lower than
the minimum required.
Check to make sure main power supply is
adequate.
The pump is stuck or frozen Check by turning the motor manually.
MOTOR STOPS Tripped thermal overload due to over-
heating
Check that main voltage corresponds to specifica-
tions for the machine. Wait a few minutes before
turning on the machine again by resetting the
GFCI on the cord.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
11
PRESSURE WASHER OPERATOR’S MANUAL
This pressure washer was produced with the best available materials and quality craftsmanship. However, you
as the owner have certain responsibilities for the correct care of the equipment. Attention to regular preventative
maintenance procedures will assist in preserving the performance of your equipment. Contact your dealer for
maintenance. Regular preventative maintenance will add many hours to the life of your pressure washer. Perform
maintenance more often under severe conditions.
OIL CHANGE RECORD
PREVENTATIVE MAINTENANCE
Pump Oil Inspect Daily, Inspect the oil level
Change After first 50 hours, then every 500 hours
or annually
Replace High Pressure Nozzle Every 6 months
Replace Quick Connects Annually
Replace Clean Water Screen/Filter Weekly
Replace HP Hose Annually if there is any sign of wear
Grease Motor Every 10,000 hours or annually
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
Date Oil Changed
Month/Day/Year
Estimated Operating
Hours Since Last
Oil Change
General Inspection Inspect the motor at regular intervals, approximately every 500 hours of operation,
or every 3 months, whichever occurs first. Keep the motor clean and the ventilation
openings clear. The following steps should be performed at each inspection:
WARNING: Do not touch electrical connections before you first ensure that power
has been disconnected. Electrical shock can cause serious or fatal injury. Only
qualified personnel should attempt the installation, operation and maintenance of
this equipment.
1. Check that the motor is clean. Check that the interior and exterior of the mo-
tor is free of dirt, oil, grease, water, etc. Oily vapor, paper pulp, textile lint, etc.
can accumulate and block motor ventilation. If the motor is not properly ven-
tilated overheating can occur and cause early motor failure.
2. Check all electrical connectors to be sure that they are tight.
Lubrication & Bearings Bearing grease will lose its lubricating ability over time, not suddenly. The lubricating
ability of a grease (over time) depends primarily on the type of grease, the size of
the bearing, the speed at which the bearing operates and the severity of the operat-
ing conditions. Good results can be obtained if the following recommendations are
used in your maintenance program.
Type of Grease A high grade ball or roller bearing grease should be used. Recommended greases
standard service conditions are: Shell Dolium R (Factory installed) or Chevron
SRI.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
OPERATOR’S MANUAL PRESSURE WASHER
12
OPTIONAL WALL MOUNT - 8.903-613.0
Instruction label should be placed
next to the machine and within
easy view of all users.

ZE/ZEF-ET-HD-HE • 8.914-001.0 • 8.941-457.0 • 9.800-088.0 • 8.919-017.0 • Rev. 11/15
13
PRESSURE WASHER OPERATOR’S MANUAL
HOSE & SPRAY GUN ASSEMBLY
HOSE & SPRAY GUN ASSEMBLY PARTS LIST
5
3
1
2
6
11
4
9
10
8
ITEM PART NO. DESCRIPTION QTY
1 9.802-166.0 Coupler, 3/8" Female 1
9.802-100.0 ▲Quick Coupler O-Ring 1
2 8.739-133.0 Hose, 3/8" x 25', LA
1-wire, Tuff-Skin
(ZE and ZEF models) 1
8.739-106.0 Hose, 3/8" x 25',
1-wire, HO, Tuff Skin
(ET models) 1
8.739-124.0 Hose, 3/8" x 25',
1-wire, KA,Tuff Skin
(HD and HE) 1
3 8.754-769.0 Spray Gun, Shut-Off 1
4 9.802-220.0 Wand, Straight 1
ITEM PART NO. DESCRIPTION QTY
5 9.802-164.0 Coupler, 1/4” Female 1
9.802-096.0 ▲ Quick Coupler O-Ring 1
6 9.802-296.0 Nozzle, 4.0 15° Yellow
(Remote Switch Option) 1
9.802-288.0 Nozzle, 3.0 15° Yellow
(1400 PSI AXD/BXD) 1
9.804-624.0 Nozzle, 3.75 15° Yellow
(1000 PSI AXD/BXD) 1
8 9.802-170.0 Nipple, 3/8” NPT Female 1
9 8.904-449.0 Flex Wand Assembly
(ZE2-14024D Models) 1
10 9.802-169.0 Coupler, 3/8 Male 1
11 8.712-398.0 Nozzle, Soap Black 1
▲Not Shown

Form #8.941-457.0 • Revised 11/15 • Printed in U.S.A. or Mexico
If you need SERVICE on your pressure washer, contact your local Hotsy
dealer or visit www.Hotsy.com. Smart phone users scan the code below to
link directly to the Service Request page.
To REGISTER your pressure washer, please visit our Warranty Registra-
tion page at www.hotsy.com/WarrantyRegistration.aspx or scan the code
below with your smart phone.
