Hozelock Superhoze Assembly instructions

Superhoze Hints & Tips
July 2021

A “how To” video can also be accessed via the
Superhoze web page under the “Instructions” section:
https://www.hozelock.com/product/superhoze/
How To Use Superhoze
Superhoze
instructions for
use can be found
inside the box

An International version of the Superhoze instructions can be viewed and
downloaded from the Hozelock website:
https://www.hozelock.com/support/instruction-leaflets/
Instructions on the Website

To ensure the correct ‘open’ and ‘close’ operation of
the nozzle follow the steps below:
1. Press nozzle into fitting
2. Grip grey sleeve
3. Turn yellow nozzle in both
directions to open and close
water flow
Nozzle Operation

The expansion controller shown below is an integral
part of the Superhoze design. Please do not confuse
this with being a blocked hose.
Expansion Controller

If the water pressure is low (less than 2 bar) the hose may not fully
expand to maximum length. During use the end of the hose appears
to retract slightly as shown on the photographs. This will not affect
the product’s performance.
Low Pressure/Hose Not Fully Expanded

If for any reason the hose connectors are removed from the
Superhoze please ensure the correct re-assembly procedure is
conducted as detailed below:
1. Hold the fabric with one hand and slide expansion retainer up
to the adapter moulding. Ensure it is firmly pressed against the
adapter.
Adapter moulding
Expansion retainer
Connector Assembly

2. Insert the adapter moulding/expansion retainer assembly
into the connector fitting ensuring all connector teeth are
inside the face of the expansion retainer as shown below.
Connector teeth Expansion retainer

3. Screw nut onto the connector ensuring there's no cross
threading and no connector teeth deformed/trapped,
continue until it is fully tightened.

✓

Superhoze Spares
▪The Superhoze Aqua Stop connectors
can be replaced and will be available
as existing spare Z21615
▪The ‘tail’ or nut of the Superhoze
connector is permanently fixed, so
the nut in the spare will not be needed
Replaceable
9mm Aqua Stop Connector
Z21615
(93252-000)
▪The above instruction leaflet will be sent out with the
replacement connector and illustrate that the nut supplied
with the spare should be removed and recycled.
▪It is supplied with the nut to protect the “teeth” of the
connector during transit.
