HP 6735b - Compaq Business Notebook User instructions

1. Optional VGA webcam 11. Hard drive activity / HP 3D DriveGuard LED indicator
2. Volume mute button with LED indicator 12. Battery charging LED indicator
3. Volume scroll zone with up/down LED indicators 13. Power/standby LED indicator
4. Serial port 14. Wireless on/off LED indicator
5. Optical drive/Upgrade Bay 15. Power button with LED indicator
6. Media Card Reader 16. HP Info Center/ HP QuickLook 2 button with LED
indicator
7. (2) USB 2.0 ports 17. HP Presentation button with LED indicator
8. Touchpad with scroll zone 18. Wireless on/off button with LED indicator
9. Optional HP Fingerprint Sensor 19. Integrated microphone (dual-microphone array with
webcam)
10. Touchpad buttons 20. WLAN and WWAN antennas (select models)
QuickSpecs
HP Compaq 6735b Notebook PC
Overview
DA - 13055 North America — Version 24 — June 17, 2010 Page 1

1. Stereo speakers 8. ExpressCard/54 slot or optional Smart Card Reader
2. Stereo headphone/line out 9. Kensington Lock slot
3. Stereo microphone in 10. RJ-11/modem port
4. Display release latch 11. RJ-45/Ethernet port
5. Power connector 12. VGA/external monitor connector
6. (2) USB 2.0 ports 13. S-Video TV out
7. 1394a port
QuickSpecs
HP Compaq 6735b Notebook PC
Overview
DA - 13055 North America — Version 24 — June 17, 2010 Page 2

1. Docking connector 5 Secondary battery connector
2. WLAN module compartment (select models) 6. SIM slot for WWAN (select models) – inside battery bay
3. Hard drive bay 7. Battery release latch
4. Bluetooth module compartment 8. Battery bay
At A Glance
Genuine Windows 7 Professional, Genuine Windows XP Professional available through downgrade rights from Windows 7
Professional, Genuine Windows 7 Home Premium, Genuine Windows Vista Business, Genuine Windows Vista Home Basic,
Genuine Windows XP Professional available through downgrade rights from Windows Vista Business, or FreeDOS
Widescreen 15.4-inch diagonal display with wide-viewing angle, optional BrightView and HP Privacy Filter support
AMD Turion™ X2 Ultra Dual-Core Mobile Processor, AMD Turion™ X2 Dual-Core Mobile Processor, AMD Athlon™ X2 Dual-Core
Processor
Thin, lightweight design starting at 5.93 lb/2.69 kg and 1.32 inch/33.6 mm thin at front
Upgrade Bay for easy optical drive upgrade or optional second hard drive
Flexible wireless connectivity options:
Integrated HP un2400 EV-DO/HSPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology
Integrated 802.11 a/b/g/n draft 2.0 or b/g wireless LAN module
Bluetooth®
Enhanced security features including HP ProtectTools, HP SpareKey, TPM 1.2; * optional Smart Card Reader and HP Fingerprint
Sensor
Optional integrated VGA webcam with dual-microphone array
HP QuickLook 2 for instant access to e-mail, calendar, and contact information
Up to 500 GB 5400 rpm or 320 GB 7200 rpm user-removable hard drive with HP 3D DriveGuard protection
Enhanced reliability with magnesium alloy support structure and HP DuraFinish
Touch-sensitive controls for HP Info Center / HP QuickLook, HP Presentation button, wireless on/off, mute, and volume up,
volume down
QuickSpecs
HP Compaq 6735b Notebook PC
Overview
DA - 13055 North America — Version 24 — June 17, 2010 Page 3

Media Card Reader
Up to 8 GB of 800 MHz DDR2 SDRAM supported, dual-channel memory support
ATI Radeon™ HD 3200 Graphics
Broadcom NetLink Gigabit Ethernet Controller (10/100/1000 NIC)
Touchpad with scroll zone
* TPM module disabled where not permitted by law (for example, Russia and China).
QuickSpecs
HP Compaq 6735b Notebook PC
Overview
DA - 13055 North America — Version 24 — June 17, 2010 Page 4

Processors AMD Turion X2 Ultra Dual-Core Mobile Processor ZM-84 (2.3 GHz, 2 MB L2 cache)
AMD Turion X2 Ultra Dual-Core Mobile Processor ZM-82 (2.2 GHz, 2 MB L2 cache)
AMD Turion X2 Ultra Dual-Core Mobile Processor ZM-80 (2.1 GHz, 2 MB L2 cache)
AMD Turion X2 Dual-Core Mobile Processor RM-74 (2.2 GHz, 1 MB L2 cache)
AMD Turion X2 Dual-Core Mobile Processor RM-70 (2.0 GHz, 1 MB L2 cache)
AMD Athlon X2 Dual-Core Processor for Notebook PCs QL-64 (2.1 GHz, 1 MB L2 cache)
AMD Athlon X2 Dual-Core Processor for Notebook PCs QL-62 (2.0 GHz, 1 MB L2 cache)
AMD Athlon X2 Dual-Core Processor for Notebook PCs QL-60 (1.9 GHz, 1 MB L2 cache)
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional*
Genuine Windows XP Professional available through downgrade rights
from Windows 7 Professional*†
Genuine Windows 7 Home Premium*
Genuine Windows Vista Business **
Genuine Windows Vista Home Basic **
Genuine Windows XP Professional available through downgrade rights
from Windows Vista Business**††
FreeDOS
Supported Genuine Windows 7 Professional*
Genuine Windows 7 Enterprise*
Genuine Windows 7 Ultimate*
Genuine Windows Vista Business**
Genuine Windows Vista Enterprise**
Genuine Windows Vista Ultimate**
Genuine Windows XP Professional
Certified SuSE Linux Enterprise Desktop 10
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality. See:
http://www.microsoft.com/windows/windows-7/ for details.
** Certain Windows Vista product features require advanced or additional hardware. See:
http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx and
http://www.microsoft.com/windowsvista/getready/capable.mspx for details. Windows Vista Upgrade
Advisor can help you determine which features of Windows Vista will run on your computer. To download
the tool, visit: http://www.windowsvista.com/upgradeadvisor .
† Windows XP Professional is preinstalled on this system and includes end user rights and media for
Windows 7 Professional. You may only use one version at a time. You must back up all data (files, photos,
etc.) before uninstalling and installing operating systems to avoid loss of your data.
†† Windows XP Professional is preinstalled on this system and includes end user rights and media for
Windows Vista Business. You may only use one version at a time. You must back up all data (files, photos,
etc.) before uninstalling and installing operating systems to avoid loss of your data.
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 5

Chipset AMD M780G
Graphics ATI Radeon HD 3200
Microsoft DirectX 10 capable
Display Internal 15.4-inch diagonal WXGA anti-glare (1280 x 800 resolution)
15.4-inch diagonal WXGA BrightView (1280 x 800 resolution)
15.4-inch diagonal WSXGA+ WVA anti-glare (1680 x 1050 resolution)
HP Privacy Filter support
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI-D (single link) video signal available through DVI port in optional HP
Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard 800 MHz DDR2 SDRAM; two slots supporting dual-channel memory
1024 MB, 2048 MB, or 4096 MB
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower
memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-bit or
Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
Communications Integrated Broadcom NetLink Gigabit Ethernet Controller (10/100/1000 NIC) *
56K V.92 modem **
* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
** Designed for downloads from 56K modem compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is
subject to country regulatory approval.
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 6

Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Wireless LAN is factory configurable or available as an option to be
added later. Broadband Wireless (WWAN) requires Windows Vista Business or Windows XP Professional
and is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth is
also available (factory configurable only) and can be combined with any of the supported wireless LAN and
wireless WAN options.
HP un2400 EV-DO/HSPA
Mobile Broadband Module
Integrated WWAN module with Gobi global mobile Internet technology that
provides worldwide connection to both CDMA (EVDO) and UMTS (HSPA)
wireless networks.
NOTE: Separately purchased mobile network operator service is required.
Two 850/900/1800/1900/2100 MHz antennas integrated in the top of the
display panel support current and future WWAN technologies.
All 802.11 integrated
wireless LAN options
Wi-Fi Certified *
Cisco Compatible Extensions support
Wired Equivalent Privacy (WEP) support up to 128-bit keys
Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC,
PEAP-MSCHAPv2, and LEAP
Advanced Encryption Standard (AES) support
Dual antennas integrated in the display enclosure
Broadcom 4322AGN
802.11a/b/g/draft-n Wi-
Fi Adapter
Integrated support for 802.11a, b, g, and n draft 2.0 *
Up to 300 mbps data rate
Broadcom 4312G
802.11b/g
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54 mbps data rate
HP Integrated Module
with Bluetooth Wireless
Technology
Bluetooth Specification v2.0 compliant
Works with a wide range of Bluetooth devices
* The specifications for 802.11n draft 2.0 are draft specifications and are not final. If the final
specifications differ from the draft specifications, it may affect the ability of the notebook to communicate
with other 802.11n WLAN devices. In countries where n draft 2.0 is not allowed, this capability is not
enabled.
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop
keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right
control and alt keys, and 12 function keys. U.S. and International key layouts are available. Other features
include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and
other features, 19 x 19 mm key pitch (center-to-center spacing), 2.5 mm stroke, and comfort-dished
keycaps.
Touch-sensitive controls Touch-sensitive controls provide easy access to the following features: HP Info Center, HP QuickLook 2,
HP Presentation button, wireless on/off, mute, and volume up, volume down
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 7

Pointing device Touchpad with scroll zone, two pick buttons
Expansion card slots
ExpressCard/54 slot Supports ExpressCard/54 and ExpressCard/34
or
Optional Integrated
Smart Card Reader
(replaces ExpressCard/54
slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Media Card Reader Supports SD (Secure Digital), HC-SD (High Capacity Secure Digital), MultiMedia
Card, HS-MultiMedia Card (MultiMedia Card Plus), Sony Memory Stick, Sony
Memory Stick Pro, Memory Stick Duo*, Picture card
Additionally, the following cards are supported via passive adapters (sold
separately): Mini-Secure Digital (Mini-SD), Transflash (Micro-SD), Reduced size
Multimedia card (RS-MultiMedia Card), Reduced size Dual voltage Multimedia
card, MultiMedia Card Mobile Cards, MultiMedia Card Micro Cards, Memory
Stick Duo (MS Duo) * , Memory Stick Duo Pro (MS Duo Pro) * , Memory Stick M2
Micro
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card directly
into your notebook could damage the memory card and/or notebook.
Storage Hard drives 120/160/250/320/500 GB 5400 rpm SMART SATA II
160/250/320 GB 7200 rpm SMART SATA II
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles. Up
to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Upgrade Bay Fixed 12.7 mm SATA
optical drive
DVD+/-RW SuperMulti DL LightScribe Drive
DVD/CD-RW Combo Drive
DVD-ROM Drive
or
Second hard drive 250 GB 5400 rpm SMART SATA II Hard Drive
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 8

Interfaces ExpressCard/54 slot One (or optional Smart Card Reader)
External monitor One (VGA)
1394a One
Stereo microphone in One
Stereo headphone/line
out
One
Power connector One
RJ-11/modem One
RJ-45/Ethernet One
S-video TV out One (Support for NTSC/PAL)
USB 2.0 Four
Serial port One
Docking connector One
Secondary battery
connector
One
Audio/Visual High Definition Audio support w/24-bit DAC
Integrated stereo speakers
Integrated microphone (dual-microphone array when equipped with optional VGA webcam)
Touch-sensitive controls for volume up, volume down, and mute
Stereo headphone/line out
Stereo microphone in
Optional VGA webcam
Supports videoconferencing and still image capture
Large image sensor for excellent color matching and good low light sensitivity
Up to 30 frames/sec
Fixed focus lens
Video capture up to 640x480 pixels
16-bit true color (camera sensors output YCrCb format among others)
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 9

Software Preinstalled software
with Windows Vista or
Windows XP
HP Recovery Manager (Vista only)
HP Help and Support Center
HP QuickLook 2
HP Universal Print Driver
HP ProtectTools Security Manager:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
Embedded Security for HP ProtectTools
HP Quick Launch Buttons
HP Wireless Assistant
Microsoft Office Ready with 60-day Office Professional 2007 Trial Edition
(select models)
PDF Complete SE
Intervideo WinDVD – DVD Player
Roxio Creator Business (for optional DVD+/-RW and DVD/CDRW drives)
McAfee Total Protection*
Synaptics Touchpad Driver
Microsoft Windows Live Messenger (select models)
HP Webcam Software (with optional VGA webcam)
Additional software
available from the web
HP SoftPaq Download Manager
HP Client Manager Software
HP Client Management Solutions
Java Card Security for HP ProtectTools
* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to
receive updates. First update included. Subscription required for updates thereafter.
HP Recovery Manager Each unit is shipped with HP Recovery Manager. HP Recovery Manager enables fast recovery of the factory
preinstalled image if the system becomes corrupted or if important system files are accidentally deleted.
Up to 10 GB of the hard drive is reserved for the system recovery software.
SMBIOS Version 2.4 System Management BIOS, previously known as DMI BIOS, is used to store system management
information.
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 10

HP ProtectTools Security
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. Modules currently available are:
BIOS Configuration for HP ProtectTools
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Set-up Wizard for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Java Card Security for HP ProtectTools
Security Standard Features HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Configuration Control Hardware
Memory Change Alert
Ownership Tag
Setup Password
Power-On Password
TPM 1.2 Embedded Security Chip*
TPM Enhanced DriveLock*
HP Disk Sanitizer
HP 3D DriveGuard
Kensington Lock slot
Support for Computrace / LoJack for Laptops (must be purchased separately)
Optional Features Smart Card Reader
(replaces ExpressCard/54
slot)
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
HP Fingerprint Sensor Enhanced sensor scans the fingerprint to uniquely
identify and authenticate a person.
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor
* TPM module disabled where use is restricted by law; for example, Russia and China.
NOTE: For more information on HP security solutions refer to: http://www.hp.com/go/security .
Power Supply External 90-watt Smart AC adapter, 6-foot (1.8 meter) power cord included.
Total length including external AC adapter is 12 feet (3.66 meter).
HP Fast Charge *
* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast Charge does not apply to 12-cell
Ultra-Capacity batteries or the HP Long Life Battery.
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 11

Battery Primary battery 6-cell (55 WHr) Li-Ion battery
Optional HP Extended Life
Battery
8-cell (52 WHr) high capacity Li-Ion battery
Optional HP Ultra-
Capacity Battery
12-cell (95 WHr) high capacity Li-Ion battery
Battery Life 6-cell (55 WHr) Primary
Primary battery Up to 4 hours and 15 minutes
Primary battery and
optional HP Extended Life
Battery
Up to 8 hours and 45 minutes
Primary battery and
optional HP Ultra-
Capacity Battery
Up to 11 hours and 45 minutes
NOTE: The listed battery life measurements were taken on models running Microsoft Windows Vista
Business. Battery life will vary depending on the product configuration, product model, applications
loaded on the product, power management settings of the product, and the product features used by the
customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
System Standby Time Up to 1 week
Power Conservation ATI PowerPlay technology
Hibernation
Standby
ACPI compliance
Docking and Stands HP 2008 120W Docking Station
HP 2008 150W Docking Station
HP 2008 150W Advanced Docking Station
HP 2008 180W Advanced Docking Station
HP Mobile Port Replicator
HP Monitor Stand
HP Adjustable Notebook Stand
HP Dual Monitor Stand
HP's shared docking solutions provide simple and convenient port replication and cable management.
Features include Gigabit NIC pass through, modem pass through, legacy parallel and serial ports, S-video
TV out, USB 2.0 ports, integrated security mechanism * , integrated MultiBay II and ExpressCard ** slots.
These docking solutions are compatible across multiple Business Notebook platforms enabling a lower
total cost of ownership.
* HP/Kensington Cable Lock required (purchased separately)
** HP Advanced Docking Station only
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 12

Service and Support HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country;
1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. HP
Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of
service for your HP product, use the HP Care Pack Services Lookup Tool at:
http://www.hp.com/go/lookuptool . Additional HP Care Pack Services information by product is available
at: http://www.hp.com/hps/carepack .
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp .
QuickSpecs
HP Compaq 6735b Notebook PC
Standard Features
DA - 13055 North America — Version 24 — June 17, 2010 Page 13

Memory HP 1 GB (DDR2 800 MHz) SODIMM KT292AA
HP 2 GB (DDR2 800 MHz) SODIMM KT293AA
HP 4 GB (DDR2 800 MHz) SODIMM KT294AA
Storage HP Notebooks USB Diskette Drive DC361B
HP Primary SATA 120 GB 7200 rpm Hard Drive AH920AA
HP Primary SATA 250 GB 5400 rpm Hard Drive AK072AA
HP Upgrade Bay SATA 250 GB 5400 rpm Hard Drive AK868AA
HP Upgrade Bay SATA DVD+/-RW SuperMulti DL LightScribe Drive AK869AA
HP Primary SATA 120 GB 5400 rpm Hard Drive RT080AA
MultiBay II Storage
(9.5-mm)
NOTE: Requires HP
Advanced Docking Station
or HP External MultiBay II
HP MultiBay II DVD-ROM Drive PA849A
HP MultiBay II DVD+/-RW SuperMulti DL Drive PA851A
Expansion Solutions HP 2008 120W Docking Station KP080AA#ABA
HP 2008 150W Docking Station KQ751AA#ABA
HP 2008 150W Advanced Docking Station KP081AA#ABA
HP 2008 180W Advanced Docking Station KQ752AA#ABA
HP Mobile Port Replicator AK155AA
HP Monitor Stand PA507A
HP Adjustable Notebook Stand PA508A
HP Dual-Monitor Stand AK084AA
HP External MultiBay II PA509A#ABA
Power HP 1-Bay Battery Charging Station RW635AA#ABA
HP 5-Bay Battery Charging Station RW636AA#ABA
HP Battery Adapter Kit KV829AA
HP 90W Smart AC Adapter ED495AA#ABA
HP 90W Smart Combo Adapter AJ652AA#ABA
HP 6-Cell Li-Ion Primary Battery KU531AA
HP 12-Cell Ultra-Capacity Battery EJ092AA
HP 8-cell Extended Life Battery (2008 ID) AJ359AA
HP Long Life Battery AU213AA
HP 90W Smart Auto Adapter ED493AA
HP 65W AC/Auto/Air Combo Smart Adapter ED993AA#ABA
QuickSpecs
HP Compaq 6735b Notebook PC
Options
DA - 13055 North America — Version 24 — June 17, 2010 Page 14

Carrying Cases HP Basic Carrying Case AJ078AA
HP Value Nylon Case RR314AA
HP Universal Nylon Case RR315AA
HP Executive Leather Case RR316AA
HP Deluxe Nylon Backpack RR317AA
HP Deluxe Roller Case GD405AA
Security HP ExpressCard Smart Card Reader with Java Card AJ451AA
HP ProtectTools Java Card - 10 units EL348AA
HP/Kensington MicroSaver Security Lock PC766A
HP 15.4" Display Privacy Filter AJ358AA
Input/Output Devices HP PS/2 Keyboard & Mouse Bundle RC464AA#xxx
HP USB Keyboard & Mouse Bundle RC465AA#xxx
HP USB/PS2 Optical 2-Button Scroll Mouse DC369A
HP USB Optical Travel Mouse RH304AA
QuickSpecs
HP Compaq 6735b Notebook PC
Options
DA - 13055 North America — Version 24 — June 17, 2010 Page 15

800 MHz DDR2 SDRAM
Two DIMM slots supporting dual-channel memory
DIMM sizes supported: 1024 MB, 2048 MB, and 4096 MB
Standard Memory 1024 MB (1024 MB x 1)
2048 MB (2048 MB x 1 or 1024 MB x 2)
3072 MB (2048 MB + 1024 MB)
4096 MB (2048 MB x 2)
Optional Memory
Upgrades
Support for up to 8192 MB of memory with the installation of optional DDR2 SDRAM memory kits. Both
memory slots are user-accessible. Please refer to the Hardware and Software Guide for installation
procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in both
memory slots.
Up to Slot 1 Slot 2
1024 MB 1024 MB Empty
2048 MB 2048 MB Empty
2048 MB 1024 MB 1024 MB
3072 MBB 2048 MB 1024 MB
4096 MB 2048 MB 2048 MB
8192 MB 4096 MB 4096 MB
NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party
memory modules, we strongly recommend using only HP- branded memory modules to ensure compatibility. If you mix memory
speeds, the system will perform at the lower memory speed. Full availability of 4 GB or more of memory requires Windows Vista
Business 64-bit or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your
configuration, so that above 3 GB all memory may not be available due to system resource requirements.
Memory Upgrades HP 1 GB (DDR2 800 MHz) SODIMM KT292AA
HP 2 GB (DDR2 800 MHz) SODIMM KT293AA
HP 4 GB (DDR2 800 MHz) SODIMM KT294AA
QuickSpecs
HP Compaq 6735b Notebook PC
Memory
DA - 13055 North America — Version 24 — June 17, 2010 Page 16

Upgrade Bay Drive Support
Quantity Supported Drive Bay
DVD+/-RW SuperMulti DL
LightScribe Drive
One Upgrade Bay
DVD/CD-RW Combo Drive One Upgrade Bay
DVD-ROM Drive One Upgrade Bay
250 GB 5400 rpm SMART
SATA II Hard Drive
One Upgrade Bay
Internal Storage Device
Quantity Supported Drive Bay
Hard Drives
500 GB 5400 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
320 GB 5400 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
250 GB 5400 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
160 GB 5400 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
120 GB 5400 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
320 GB 7200 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
250 GB 7200 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
160 GB 7200 rpm SMART
SATA II Hard Drive
One Dedicated hard drive bay
QuickSpecs
HP Compaq 6735b Notebook PC
Storage
DA - 13055 North America — Version 24 — June 17, 2010 Page 17

System Unit Dimensions (HxWxD) 1.32 in (at front) x 14.02 in x 10.46 in
33.6 mm (at front) x 356.0 mm x 265.4 mm
Weight Starting at 5.93 lb (2.69 kg)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by
configuration and components. Weight includes 6-cell battery, hard drive, and optical drive. Weight varies
by configuration and components.
Stand-Alone Power
Requirements
(AC Power)
Nominal Operating Voltage 18.5 V
Average Operating Power 22.5 W (Turion)
24.5 W (Athlon)
Max Operating Power < 90 W
Temperature Operating 332° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating -4° to 140° F (-20° to 60° C)
Relative Humidity Operating 10% to 90%, non-condensing
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum wet bulb
temperature
Shock Operating 125 G, 2 ms, half-sine
Non-operating 200 G, 2 ms, half-sine
Random Vibration Operating 0.75 grms
Non-operating 1.50 grms
Altitude
(unpressurized)
Operating –50 to 10,000 ft (–15.24 to 3,048 m)
Non-operating –50 to 40,000 ft (–15.24 to 12,192 m)
Industry Standard
Certifications
UL Yes
CSA Yes
FCC Compliance Yes
ENERGY STAR
®
Yes †*
EPEAT Gold **
ICES Yes
GS TBD
Australia / NZ A-Tick
Compliance
Yes
CCC Yes
Japan VCCI Compliance Yes
MIC Yes
BSMI Yes
CE Marking Compliance Yes
BNCI or BELUS Yes
CIT Yes
GOST Yes
Saudi Arabian Compliance
(ICCP)
Yes
QuickSpecs
HP Compaq 6735b Notebook PC
Technical Specifications
DA - 13055 North America — Version 24 — June 17, 2010 Page 18

SABS Yes
UKRSERTCOMPUTER Yes
† When configured with AMD Turion or AMD Sempron processor
* Configurations of the HP Compaq 6735b that are ENERGY STAR qualified are identified as
HP Compaq 6735b ENERGY STAR on HP websites and on www.energystar.gov .
** EPEAT registration varies by country. See www.epeat.net for registration status by country.
EPEAT status listed above applies to U.S.
NOTE: For accessibility information on HP products, please visit: http://www.hp.com/accessibility .
HP 90W Smart AC Adapter Dimensions 5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)
Weight 0.82 lb (370 g)
Input 100 to 240 VAC
Input Efficiency 83% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version
2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version
Output Output power 65W 90W
DC output 19.0V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
–4° to 149° F (–20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark – full compliance with LVD and EMC directives; Worldwide safety
standards – IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals –
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF– over 200,000 hours at 25°C ambient condition.
QuickSpecs
HP Compaq 6735b Notebook PC
Technical Specifications
DA - 13055 North America — Version 24 — June 17, 2010 Page 19

Optional HP Ultra-
Capacity Battery
Dimensions (H x W x L) 1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)
Weight 1.77 lb (0.803 kg)
Cells/Type 12-cell Li-Ion
Energy Watt-hour Capacity 95 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time Smart Adapter 3 to 4 hours
System ON 4 to 5 hours (depending on system power
consumption)
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
Optional HP Extended Life
Battery
Dimensions (H x W x L) 1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)
Weight 1.00 lb (0.455 kg)
Cells/Type 8-cell Li-Ion
Energy Watt-hour Capacity 52 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
3 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on battery
6-Cell (55 WHr) Li-Ion
battery
Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm)
Weight 0.737 lb (0.335 kg)
Cells/Type 6-cell Li-Ion
Energy Watt-hour Capacity 55 WHr
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 140° F (–10° to 60° C)
Non-operating –4° to 140° F (–20° to 60° C)
Battery Re-Charge Time System in OFF mode or
Standby
2.5 hours
System ON 3 to 5 hours (depending on system power
consumption)
HP Fast Charge Technology Charges the battery up to 90% within 90 minutes
when system is OFF
QuickSpecs
HP Compaq 6735b Notebook PC
Technical Specifications
DA - 13055 North America — Version 24 — June 17, 2010 Page 20
