User’s Guide
HP 8712ET and HP 8714ET
RF Network Analyzers
HP Part No. 08714-90011
Printed in USA
Print Date: October 1999
Supersedes: November 1998
© Copyright 1998, 1999 Hewlett-Packard Company

ii ET User’s Guide
Notice
The information contained in this document is subject to change without
notice. Hewlett-Packard makes no warranty of any kind with regard to
this material, including but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard
shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance,
or use of this material.
Key Conventions
This manual uses the following conventions:
This represents a key physically located on the
instrument (a “hardkey”).
This indicates a “softkey,” a key whose label is
determined by the instrument’s firmware, and is
displayed on the right side of the instrument’s screen
next to the eight unlabeled keys.
Screen Text
This indicates text displayed on the instrument’s screen.
Safety Information
For safety and regulatory information see Chapter 10, “Safety and
Regulatory Information.” For warranty and assistance information see
Chapter 9, “Specifications.”
FRONT PANEL KEY
Softkey

ET User’s Guide iii
Firmware Revision
This manual documents analyzers with firmware revisions E.06.00 and
above.
Acknowledgments
Portions of the software include source code from the Info–ZIP group.
This code is freely available on the Internet by anonymous ftp
asftp.uu.net:/pub/archiving/zip/unzip51/.tar.Z, and from CompuServe
asunz51.zip in the IBMPRO forum, library 10, (data compression).
Lotus® 1-2-3® are U.S. registered trademarks of Lotus Development
Corporation.
Windows, Word97, and Excel97are registered trademarks of
Microsoft Corp.

iv ET User’s Guide
Introducing the Analyzer
The HP 8712ET and HP 8714ET are easy-to-use RF network analyzers
optimized for production measurements of reflection and transmission
parameters. The instrument integrates an RF synthesized source,
transmission/reflection test set, multi-mode receivers, and display in one
compact box.
The source features 1 Hz resolution, 40 ms (or faster) sweep time, and up
to +16 dBm output power.
The three-channel, dual mode receivers provide dynamic range of
greater than 100 dB in narrowband measurement mode. For
measurements of frequency-translating devices, the network analyzer
features broadband internal detectors and external detector inputs. The
receivers incorporate digital signal processing and microprocessor
control to speed operation and measurement throughput.
Two independent measurement channels and a large display show the
measured results of one or two receiver channels in several
user-selectable formats. An external VGA monitor can be connected to
the rear panel for enhanced measurement viewing in color.
Measurement functions are selected with front panel hardkey and
softkey menus. Measurements can be printed or plotted directly with a
compatible peripheral. Instrument states can be saved to the internal
floppy disk, internal non-volatile memory, or internal volatile memory.
Built-in service diagnostics are available to simplify troubleshooting
procedures
Measurement calibrations and data averaging provide performance
improvement and flexibility. Measurement calibrations consist of
normalizing data, utilizing the internal factory calibration, or calibrating
with external standards. Measurement calibration reduces errors
associated with crosstalk, directivity, frequency response, and source
match. Refer to Chapter 9, “Specifications,” for error correction
specifications.

ET User’s Guide v
How to Use This Guide
The first 6 chapters of this guide explain how to perform measurements,
calibrate the instrument, and use the most common instrument
functions.
Chapters 7 through 11 are reference material. Use these chapters to look
up information such as front panel features, specific key functions, and
specifications.

vi ET User’s Guide
HP 8712ET and HP 8714ET
Network Analyzer
Documentation Map
The CDROM provides the contents of all of the documents
listed below.
The User’s Guide shows how to make measurements,
explains commonly-used features, and tells you how to get
the most performance from the analyzer.
The LAN Interface User’s Guide Supplement shows
how to use a local area network (LAN) for programming and
remote operation of the analyzer.
The Automating Measurements User’s Guide
Supplement provides information on how to configure and
control test systems for automation of test processes.
The Programmer’s Guide provides programming
information including HP-IB and SCPI command references,
as well as short programming examples.
The Example Programs Guide provides a tutorial
introduction using BASIC programming examples to
demonstrate the remote operation of the analyzer.

ET User’s Guide vii
The Service Guide provides the information needed to
adjust, troubleshoot, repair, and verify analyzer conformance
to published specifications.
The HP Instrument BASIC User’s Handbook describes
programming and interfacing techniques using
HP Instrument BASIC, and includes a language reference.
The HP Instrument BASIC User’s Handbook
Supplement shows how to use HP Instrument BASIC to
program the analyzer.
The Option 100 Fault Location and Structural Return
Loss Measurements User’s Guide Supplement provides
theory and measurement examples for making fault location
and SRL measurements. (Shipped only with Option 100
analyzers.)
The CATV Quick Start Guide provides abbreviated
instructions for testing the quality of coaxial cables.
(Shipped only with Option 100 analyzers.)
The Cellular Antenna Quick Start Guide provides
abbreviated instructions for verifying the performance of
cellular antenna systems. (Shipped only with Option 100
analyzers.)

viii ET User’s Guide
