HP t5740e - Thin Client User instructions

Front
FrontFront
Front Back
BackBack
Back
1. Power button (with integrated power indicator light) 1. Cabling exit from secure USB compartment
2. Flash drive activity indicator light 2. WIFI antenna connector (depends on model)
3. Audio connector (headphone/speaker out) 3. Ethernet RJ-45 connector
4. Audio connector (mic in) 4. USB connectors (four)
5. USB connectors (two) 5. DisplayPort monitor connector
6. Removable stand for vertical orientation 6. VGA monitor connector
7. Mounting points for HP Quick Release or other VESA mount 7. PS/2 keyboard connector
8. Secure USB compartment cover 8. PS/2 mouse connector
9. Cable lock slot (secures unit and secure USB compartment) 9. Serial connector
10. +19V DC power input
11. Power cable retention slot
12. Mounting location for four (4) horizontal mounting feet
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 6 — May 3, 2011 Page 1

Top
TopTop
Top
1. Cable lock slot - secures unit and secure USB compartment 2. Secure USB compartment with cover removed - 2 USB
connectors
with optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
with optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kitwith optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
with optional HP t5740/t5745 PCIe x4/PCI Expansion Module Kit
Front
FrontFront
Front Back
BackBack
Back
1. Power button (with integrated power indicator light) 1. Cabling exit from secure USB compartment
2. Flash drive activity indicator light 2. WIFI antenna connection (depends on model)
3. Audio connector (headphone/speaker out) 3. Ethernet RJ-45 connector
4. Audio connector (mic in) 4. USB connectors (four)
5. USB connectors (two) 5. DisplayPort monitor connector
6. Removable stand for vertical orientation 6. VGA monitor connector
7. Mounting points for HP Quick Release or other VESA mount 7. PS/2 keyboard connector
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 6 — May 3, 2011 Page 2

8. Secure USB compartment - 2 USB connectors 8. PS/2 mouse connector
9. Cable lock slot (secures unit and secure USB compartment) 9. Serial connector
10 +19V DC power input
11. Power cable retention slot
12. Mounting location for four (4) horizontal mounting feet
13. Second serial connector
14. PCIe x4/PCI expansion module slot
15. Parallel connector
At A Glance
At A GlanceAt A Glance
At A Glance
Hardware features
Hardware featuresHardware features
Hardware features :
Intel Atom N280 * processor, with Intel GL40 chipset ( *Intel's numbering is not a measurement of higher performance )
4 GB flash memory provides ample storage for drivers and applications
2 GB * DDR3/667MHz system memory (64 MB minimum reserved for graphics memory)
Available empty DDR3 SO-DIMM slot (and RAM upgrade options) for dual-channel system memory expansion
NOTE:
NOTE:NOTE:
NOTE: Minimum of 1GB and a maximum of 4GB* (2 X 2GB) can be supported (*Up to 1 GB may not be available with 32-
bit operating systems due to system resource requirements.)
Built in dual monitor support (VGA and DisplayPort native)
Integrated wireless (802.11 a/b/g/n * ) technology (select models) *Wireless access point and Internet required.
Optional Expansion Module with PCIe x4/PCI slot for installing a wide range of devices (includes a parallel and second serial
port)
Secure USB compartment is ideal for protecting USB wireless and USB Flash devices as well as for protecting USB keyboard
and mouse connectors
Additional SATA II connector for adding optional secondary solid state Flash drive 8 USB 2.0 ports
Legacy support includes parallel (via Expansion Module), serial, and PS/2 connections
Software features
Software featuresSoftware features
Software features :
Preinstalled with new Microsoft® Windows® Embedded Standard 7 with support for local applications
Excellent rich multimedia experience and enhanced USB device support in VDI environments
Enhanced Write Filter and File-Based Write Filter provide complete flexibility to protect the entire Flash disk, or configure areas
of the disk for persistent access by local applications
Microsoft Firewall for enhanced data security
HP TeemTalk Terminal Emulator enables connection and communication with applications on mainframes and midrange
systems
HP ThinState Tools offers in-box, easy-to-use image deployment and recovery tools
Enterprise class HP Device Manager lets you remotely manage devices from a central location
Support for HP Client Automation and Microsoft System Center Configuration Manager for easy management
HP Universal Print Driver (available as an add-on) supports a variety of printers
Warranty
WarrantyWarranty
Warranty :
HP Total Care Warranty and Services: limited three-year hardware warranty in most regions. HP Care Pack Services extend service
contracts beyond your standard warranties. For more details visit: http://www.hp.com/go/lookuptool .
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Overview
DA - 13720 North America — Version 6 — May 3, 2011 Page 3

Models without integrated WIFI adapter
Models without integrated WIFI adapterModels without integrated WIFI adapter
Models without integrated WIFI adapter
Worldwide:
XL424AA
Americas and EMEA:
XL424AT
(Smart Buy/Top Value)
US only:
XL426AA
1
Processor/Chipset
Processor/ChipsetProcessor/Chipset
Processor/Chipset Intel Atom N280 * 1.66 GHz/Intel GL40
*Intel's numbering is not a measurement of higher performance.
Operating System
Operating SystemOperating System
Operating System Microsoft Windows Embedded Standard 7
Flash Memory
Flash MemoryFlash Memory
Flash Memory 4 GB
Memory
MemoryMemory
Memory 2 GB DDR-3 SODIMM (1 x 2 GB SODIMM)
NOTE:
NOTE:NOTE:
NOTE: 64 MB minimum reserved for graphics memory.
Graphics
GraphicsGraphics
Graphics Intel GL40 graphics
Keyboard
KeyboardKeyboard
Keyboard USB or PS/2 (varies by region)
Mouse
MouseMouse
Mouse USB or PS/2 (varies by region)
1
Product complies with U.S. Trade Agreement (TAA). Available in U.S only.
Models with integrated WIFI adapter
Models with integrated WIFI adapterModels with integrated WIFI adapter
Models with integrated WIFI adapter
Worldwide:
XL425AA
Americas and EMEA:
XL425AT
(Smart Buy/Top Value)
US only:
XL427AA
1
Processor/Chipset
Processor/ChipsetProcessor/Chipset
Processor/Chipset Intel Atom N280 * 1.66 GHz/Intel GL40
*Intel's numbering is not a measurement of higher performance.
Operating System
Operating SystemOperating System
Operating System Microsoft Windows Embedded Standard 7 preinstalled
Flash Memory
Flash MemoryFlash Memory
Flash Memory 4 GB
Memory
MemoryMemory
Memory 2 GB DDR-3 SODIMM (1 x 2 GB SODIMM)
NOTE:
NOTE:NOTE:
NOTE: 64 MB minimum reserved for graphics memory.
Graphics
GraphicsGraphics
Graphics Intel GL40 graphics
Integrated Wireless
Integrated WirelessIntegrated Wireless
Integrated Wireless
2
Atheros 802.11 a/b/g/n Wi-Fi adapter
Keyboard
KeyboardKeyboard
Keyboard USB or PS/2 (varies by region)
Mouse
MouseMouse
Mouse USB or PS/2 (varies by region)
1
Product complies with U.S. Trade Agreement (TAA). Available in U.S only.
2
A standard WLAN (Wi-Fi) infrastructure with wireless access points is required and is not included.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Standard Features - Models
DA - 13720 North America — Version 6 — May 3, 2011 Page 4

NOTE:
NOTE:NOTE:
NOTE: Optional accessories are available as separate purchase. Part Number
Part NumberPart Number
Part Number
Accessories
AccessoriesAccessories
Accessories HP t5740/t5745 PCIe x4/PCI Expansion Module
1
AZ551AA
HP Quick Release Kit EM870AA
HP Integrated Work Center Stand GN783AA
HP/Kensington Cable Lock PC766A
65 Watt External Power Supply replacement AZ552AA
Communications
CommunicationsCommunications
Communications
2, 3
Cisco Aironet 802.11a/b/g Wireless PCI Adapter AIR-PI21AG-A-K9
Allied Telesis PCIe x1 Fast Ethernet Fiber Network Interface Card AT-2711FX
Allied Telesis PCIe x1 Gigabit Fiber Network Interface Card AT-2972SX
Input Devices
Input DevicesInput Devices
Input Devices HP PS/2 Standard Keyboard DT527A
HP USB Standard Keyboard DT528A
HP USB Smartcard Keyboard ED707AA
HP USB CCID Smartcard Keyboard (BFR/PVC free) BV813AA
HP PS/2 2-Button Optical Mouse EY703AA
HP USB 2-Button Optical Scroll Mouse DC172B
Monitors
MonitorsMonitors
Monitors
4
HP L5009tm Touchscreen Monitor VK202AA
ELO Touch 1529L Flat Panel - USB/serial combo
2,5
E926109
Graphics
GraphicsGraphics
Graphics HP DisplayPort to DVI-D Adapter FH973AA
FH973AT
Storage
StorageStorage
Storage HP USB External CD/DVD R/RW Drive (read only support) FS943AA
FS934UT
Apacer 4GB AH522 USB 2.0 Flash Drive
2
91.HDE2S.HP00C
Apacer 8GB AH522 USB 2.0 Flash Drive
2
91.HDF2S.HP00C
Apacer 16GB AH522 USB 2.0 Flash Drive
2
91.HDG2S.HP00C
Security
SecuritySecurity
Security HP USB Smartcard Keyboard ED707AA
HP USB CCID Smartcard Keyboard (BFR/PVC free)
2
BV813AA
Gemalto PC USB-TR Card Reader
2
HWP117685
Gemalto .NET v2+ Smart Card
2
HWP115303B
HWP115647C
SCM SCR331 USB Smart Card Reader
2904054
HP Keyed Cable Lock (BFR/PVC free) BV411AA
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Options
DA - 13720 North America — Version 6 — May 3, 2011 Page 5

Care Pack Services
Care Pack ServicesCare Pack Services
Care Pack Services
6
9x5 Next-Business-Day Advanced Exchange - 3 Years 331653-001;
U4847E
7
9x5 Next-Business-Day On-Site Coverage - 3 Years 331655-001;
U4849E
7
Hardware Installation 331686-001;
U4865E
1
The PCIe/PCI Expansion Module should not be used if the HP 16GB SATA module is installed.
2
Option, drivers, warranty, and support are available directly from third party.
3
Wireless access point and Internet access required. Availability of public wireless access points limited.
4
Drivers must be installed. For a complete list of monitors compatible with HP thin clients, it is important to cross-reference the
supported video resolutions of the HP thin client to the supported resolutions of the monitor. Most HP monitors have one or more
supported resolutions that match HP thin client products.
5
Only serial is supported.
6
Service levels and response times for HP Care Pack Services may vary depending on your geographic location. Restrictions and
limitations apply. For details, visit: www.hp.com/go/carepack .
7
4U4847E is available in all regions; U4849E is available in Americas and Asia-Pacific/Japan.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Options
DA - 13720 North America — Version 6 — May 3, 2011 Page 6

Memory Configurations
Memory ConfigurationsMemory Configurations
Memory Configurations
Flash Memory
Flash MemoryFlash Memory
Flash Memory Memory Slot 1
Memory Slot 1Memory Slot 1
Memory Slot 1 (DDR-3) Memory Slot 2
Memory Slot 2Memory Slot 2
Memory Slot 2 (DDR-3)
4 GB 2 GB Empty
Processor
ProcessorProcessor
Processor Intel Atom N280 1.66 GHz
Memory
MemoryMemory
Memory Flash Memory
Flash MemoryFlash Memory
Flash Memory 4 GB (for boot drive)
System Memory
System MemorySystem Memory
System Memory 2 GB DDR-3 SODIMM in standard configurations (up to 8 GB supported)
NOTE:
NOTE:NOTE:
NOTE: 64 MB minimum reserved for graphics memory (Intel GL40 chipset
dynamically allocates graphics memory)
Graphics
GraphicsGraphics
Graphics Intel GL40 graphics with support for two high-resolution monitors up to 2048 x 1536, or up to 32 bit color
depth *
Mode
ModeMode
Mode Color depth
Color depthColor depth
Color depth Refresh rate (Hz)
Refresh rate (Hz)Refresh rate (Hz)
Refresh rate (Hz)
640 x 480 8/16/32bit 60, 70, 75, 85
800 x 600 8/16/32bit 60, 75, 85
1024 x 768 8/16/32bit 60, 70, 75, 85
1280 x 720 8/16/32bit 60, 75, 85
1280 x 768 8/16/32bit 60, 75, 85
1280 x 1024 8/16/32bit 60, 75, 85
1400 x 1050 8/16/32bit 60, 75, 85
1440 x 900 8/16/32bit 60, 75, 85
1600 x 1200 8/16/32bit 60, 75 ,85
1680 x 1050 8/16/32bit 60
1920 x 1080 8/16/32bit 60, 75, 85
1920 x 1200 8/16/32bit 60, 75
2048 x 1536 8/16/32bit 60
NOTE:
NOTE:NOTE:
NOTE: This table represents a sample of possible modes that this controller is capable of displaying but
various factors such as the capability and EDID information returned by the attached monitor, the interface
used (D-SUB/DisplayPort or optional DVI-D with dongle), and dual monitor mode may limit the availability
of modes, color depth, and/or refresh rate.
Input/Output/
Input/Output/Input/Output/
Input/Output/
Peripheral Support
Peripheral SupportPeripheral Support
Peripheral Support
Keyboard
KeyboardKeyboard
Keyboard USB or PS/2 (varies by region)
Mouse
MouseMouse
Mouse USB or PS/2 (varies by region)
Printer
PrinterPrinter
Printer Local and/or network printers (RDP, ICA, LPD)
Video
VideoVideo
Video Intel GL40 graphics
Audio
AudioAudio
Audio Output
OutputOutput
Output Internal amplified speaker, 1/8-inch mini, full 16-bit stereo, 44-kHz sample rate.
Input
InputInput
Input 1/8-inch mini microphone
Hardware Security
Hardware SecurityHardware Security
Hardware Security Security lock slot (cable lock sold separately)
Secure USB compartment with 2 USB 2.0 ports
Networking
NetworkingNetworking
Networking 10/100/1000 Gigabit Ethernet (RJ-45)
TCP/IP with DNS and DHCP
Point-to-Point Protocol (PPP), Direct Connection through RS-232, Point-to-Point over Ethernet (PPPoE),
Point-to-Point Tunneling Protocol (PPTP), Layer-2 Tunneling Protocol (L2TP), Wake on LAN (WOL), PXE
Server Network Time Protocol (SNTP)
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications
DA - 13720 North America — Version 6 — May 3, 2011 Page 7

Simple Network Management Protocol (SNMP)
Wireless LAN
Wireless LANWireless LAN
Wireless LAN
(select models)
Adapter
AdapterAdapter
Adapter Atheros 802.11a/b/g/n WIFI Adapter
Form Factor
Form FactorForm Factor
Form Factor PCI-Express Half Mini Card
Security
SecuritySecurity
Security
7
Supports 64- and 128-bit WEP, WPA, WPA2, AES, TKIP, 802.1x authentication
types EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-FAST, LEAP.
I/O ports and
I/O ports andI/O ports and
I/O ports and
connectors
connectorsconnectors
connectors
Eight USB 2.0 ports (two in front, four in rear, two in secure USB compartment), 1 VGA, 1 DisplayPort, 2
PS/2, 1 serial, 1 RJ-45, and 1 optional Expansion Module with X4 PCIe or PCI slot, also including 1
parallel and second serial port
Server OS
Server OSServer OS
Server OS
Compatibility/
Compatibility/Compatibility/
Compatibility/
Support
SupportSupport
Support
Citrix XenApp 5 and 6
Citrix XenDesktop 3 and 4
Citrix Presentation Server 4.0
Windows Server 2008 Terminal Services
Windows 2000/2003 Server families, Windows 2000/2003 Server Terminal Services
VMware Virtual Desktop Infrastructure using RDP
Software
SoftwareSoftware
Software Operating System/
Operating System/Operating System/
Operating System/
Protocols/Components
Protocols/ComponentsProtocols/Components
Protocols/Components
Preinstalled:
Microsoft Windows Embedded Standard 7
Microsoft RDP 7 (RDP7.1 with RemoteFX available online)
Citrix Online Plugin 12.0 (Citrix Online Plugin 12.1 available online) Microsoft
Internet Explorer 8
Windows Media Player 12
HP TeemTalk Terminal Emulator 7
Adobe Flash Player 10.1
Security
SecuritySecurity
Security Configure to use Enhanced Write Filter or File-based Write Filter
Microsoft Firewall
Administrator and user passwords
HP USB Config utility to restrict access to USB storage devices
Session Brokers
Session BrokersSession Brokers
Session Brokers Preinstalled
PreinstalledPreinstalled
Preinstalled :
Citrix Desktop Delivery Controller
enabled through web browser
VMware View Manager 4.0.1
Available as download
Available as downloadAvailable as download
Available as download :
HP Session Allocation Manager (SAM) 3.1
Available from vendors website:
VMware View Manager 4.5
Leostream Desktop Connection Broker
Provision Networks (Quest) broker
Multimedia and USB
Multimedia and USBMultimedia and USB
Multimedia and USB
Redirection solutions
Redirection solutionsRedirection solutions
Redirection solutions
HP Remote Graphics Software Receiver 5.3 for VMware View and Microsoft
Terminal Services
Citrix HD-X support for XenApp
Citrix HD-X support for XenDesktop
Management
ManagementManagement
Management HP Device Manager agent
HP Client Automation agent
HP ThinState for rapid deployment
Other add-on software available (see: www.hp.com/support for latest list of available add-ons)
Languages
LanguagesLanguages
Languages (MUI) English, French, German, Spanish, Dutch, Norwegian, Korean, Simplified Chinese, Traditional Chinese,
and Japanese
Dimensions HxWxD
Dimensions HxWxDDimensions HxWxD
Dimensions HxWxD
(approximate)
Without stand
Without standWithout stand
Without stand 10.04 x 1.73 x 8.74 in (255 x 44 x 222 mm)
With stand
With standWith stand
With stand 10.39 x 1.73 x 8.74 in (266.7 x 44 x 222 mm)
With Expansion Module
With Expansion ModuleWith Expansion Module
With Expansion Module 10.04 x 2.91 x 8.74 in (255 x 74 x 222 mm)
Weight
WeightWeight
Weight (approximate) With stand
With standWith stand
With stand 3.48 lb (1.58 kg)
With Expansion Module
With Expansion ModuleWith Expansion Module
With Expansion Module 4.14 lb (1.88 kg)
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications
DA - 13720 North America — Version 6 — May 3, 2011 Page 8

Power supply
Power supplyPower supply
Power supply Worldwide auto-sensing 100-240 VAC, 50-60 Hz energy-saving automatic power-down, surge-tolerant,
ENERGY STAR® 2.0 qualified 65-watt power supply
Environmental
EnvironmentalEnvironmental
Environmental Temperature range
Temperature rangeTemperature range
Temperature range Operating: 50° to 104° F (10° to 40° C)
Operating, using Quick Release with a flat panel monitor:
50° to 95° F (10° to 35° C)
Operating, using PCI Expansion Unit: 50° to 104° F (10° to 40° C)
Non-operating:-22° to 140° F (-30° to 60° C)
NOTE:
NOTE:NOTE:
NOTE: Specifications are at sea level with altitude derating of 1° C/300m (1.8°
F/1000ft) to a maximum of 3 Km (10,000 ft), with no direct, sustained sunlight.
Upper limit may be limited by the type and number of options installed.
Humidity
HumidityHumidity
Humidity 20% to 80% condensing
10% to 90% non-condensing
Regulatory Compliance
Regulatory ComplianceRegulatory Compliance
Regulatory Compliance Ergonomics
ErgonomicsErgonomics
Ergonomics German ZH1/618; EN29241-3, approved
Safety
SafetySafety
Safety UL 1950, CSA 950; TÜV-GS (EN60 950) approved
RF Interference
RF InterferenceRF Interference
RF Interference FCC Class B; CE Mark; EN55022B; VCCI
Warranty
WarrantyWarranty
Warranty Three-year limited hardware warranty.
NOTE:
NOTE:NOTE:
NOTE: Certain restrictions apply. Consult the HP Customer Support Center for details.
Emulations
EmulationsEmulations
Emulations Emulation
EmulationEmulation
Emulation Terminal ID
Terminal IDTerminal ID
Terminal ID
ADDS A2
AIXTerm
ANSI BBS
AT 386
ATT4410
HP 700-92/96 70092, 70094, 70096, 2392A, 2622A
HZ1500
IBM3151 Mod11, Mod31
IBM3270 3278-2 (24x80), 3278-3 (32x80), 3278-4 (43x80), 3278-5 (27x132), 3278-2-
E (24x80), 3278-3-E (32x80), 3278-4-E (43x80), 3278-5-E (27x132), 3279-2
(24x80), 3279-3 (32x80), 3279-4 (43x80), 3279-5 (27x132), 3287-1
IBM5250 5291-1, 5292-2, 5251-11, 3179-2, 3196-A1, 3180-2, 3477-FC (27x132),
3477-FG (24x80), 3486-BA, 3487-HA, 3487-HC, 3812-1
SCO Console
Stratus V102
TA6530
TVI910
TVI920
TVI925
TVI950
TVI955
VT52, VT100, VT100+,
VT500 (7- or 8-bit)
VT100, VT101, VT102, VT125, VT131, VT132, M2200, VT220, VT240, VT320,
VT340, VT420, VT510, VT520, VT525
VT HP220,
VT UTF8
VT100, VT101, VT102, VT125, VT220, VT240, VT320, VT340, VT420, VT131,
VT132, M2200, VT510, VT520, VT525
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications
DA - 13720 North America — Version 6 — May 3, 2011 Page 9

VT PCTerm
Wyse PCTerm
WY50
WY50+
WY60
7
Wireless features, performance and support may vary depending on environmental variables such placement, settings and firmware
of your access points. Please contact your wireless vendor for support of your wireless environment.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications
DA - 13720 North America — Version 6 — May 3, 2011 Page 10

Eco-Label Certifications &
Eco-Label Certifications &Eco-Label Certifications &
Eco-Label Certifications &
Declarations
DeclarationsDeclarations
Declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US Energy Star
IT ECO declaration
EPEAT Silver where HP registers commercial desktop products. See http://www.epeat.net for
registration status in your countrys
System Configuration
System ConfigurationSystem Configuration
System Configuration The configuration used for the Energy Consumption and Declared Noise Emissions data for the Ultra-
slim Desktop model is based on a typically configured product
Energy Consumption
Energy ConsumptionEnergy Consumption
Energy Consumption 115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation 13.27 W 13.88 W 14.22 W
Off 0.37 W 0.43 W 0.39 W
Heat Dissipation
Heat DissipationHeat Dissipation
Heat Dissipation * 115 VAC
115 VAC115 VAC
115 VAC 230 VAC
230 VAC230 VAC
230 VAC 100 VAC
100 VAC100 VAC
100 VAC
Normal Operation 45 BTU/hr 47 BTU/hr 49 BTU/hr
Off 1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.
Batteries
BatteriesBatteries
Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium Ion
Additional Information
Additional InformationAdditional Information
Additional Information This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive -
2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Silver where HP registers
commercial desktop products. See http://www.epeat.net for registration status in your country.
Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and
ISO1043.
This product contains 0% post consumer recycled plastic (by wt.)
This product is 95% recyclable when properly disposed of at end of life.
Packaging Materials
External:
Corrugated Carton – 780.1g
Carboard & Misc – 162g
Paper / Carboard – 111.4g
Internal:
Polyethylene low density foam – 42 g
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications – Environmental Data
DA - 13720 North America — Version 6 — May 3, 2011 Page 11

The Corrugated Carton packaging material is made from 90% recycled content.
The Carboard & Misc packaging material is made from 90% recycled content.
The Paper / Carboard packaging material is made from 90% recycled content.
The Polyethylene low density foam packaging material is made from 90% recycled content.
RoHS Compliance
RoHS ComplianceRoHS Compliance
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations,
including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to
exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis.
By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for
all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is
no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
Material Usage
Material UsageMaterial Usage
Material Usage This product does not contain any of the following substances in excess of regulatory limits (refer to the
HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries \
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Nickel finishes that release greater than 0.5 micro-grams/cm
2
/week, measured according to EN
1811:1998, are not used on any product surface designed to be frequently handled or touched
by users. )
Packaging
PackagingPackaging
Packaging HP follows these guidelines to decrease the environmental impact of product packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in packaging materials.
Use readily recyclable packaging materials such as paper and corrugated materials.
Reduce size and weight of packages to improve transportation fuel efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas.
To recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest HP
sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications – Environmental Data
DA - 13720 North America — Version 6 — May 3, 2011 Page 12

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each
product type for use by treatment facilities. This information (product disassembly instructions) is posted
on the Hewlett Packard web site at: http://www.hp.com/go/recyclers . These instructions may be used by
recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP
equipment.
Hewlett-Packard
Hewlett-PackardHewlett-Packard
Hewlett-Packard
Corporate Environmental
Corporate EnvironmentalCorporate Environmental
Corporate Environmental
Information
InformationInformation
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/envmanagement.html
© 2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice and is
provided "as is" without warranty of any kind. The warranties for HP products and services are set forth in the express limited warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft and Windows are trademarks of the
Microsoft Group of Companies. ENERGY STAR is a registered mark owned by the U.S. government.
QuickSpecs
HP t5740e Thin Client
HP t5740e Thin ClientHP t5740e Thin Client
HP t5740e Thin Client
Technical Specifications – Environmental Data
DA - 13720 North America — Version 6 — May 3, 2011 Page 13
