release notes
hp StorageWorks
SAN switch 2/32
Product Version: 4.0.2b
Second Edition (February 2003)
Part Number: AV-RTT4B-TE
This document summarizes late-breaking and supplemental information for hp StorageWorks
SAN Switch 2/32 products. In the event of conflicting information between these Release Notes
and other documents contained in this product release, the Release Note content takes
precedence.
For the latest version of these Release Notes and other product documentation, visit the HP
Storage website at:
http://www.hp.com/country/us/eng/prodserv/storage.html

2 SAN switch 2/32 Version 4.0.2b Release Notes
© 2003 Hewlett-Packard Company
Hewlett-Packard Company makes no warranty of any kind with regard to this material, including, but not limited to,
the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for
errors contained herein or for incidental or consequential damages in connection with the furnishing, performance,
or use of this material.
This document contains proprietary information, which is protected by copyright. No part of this document may be
photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard.
The information contained in this document is subject to change without notice.
Compaq Computer Corporation is a wholly-owned subsidiary of Hewlett-Packard Company.
Microsoft®, Windows®, and Windows NT® are U.S. registered trademarks of Microsoft Corporation.
UNIX® is a registered trademark of The Open Group.
BROCADE, the Brocade B weave logo, Brocade: the Intelligent Platform for Networking Storage, SilkWorm, and
SilkWorm Express, are trademarks or registered trademarks of Brocade Communications Systems, Inc. or its
subsidiaries in the United States and/or in other countries.
All other product names mentioned herein may be trademarks of their respective companies.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The
information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties
for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products.
Nothing herein should be construed as constituting an additional warranty.
Printed in the U.S.A.
SAN switch 2/32 Version 4.0.2b Release Notes
Second Edition (February 2003)
Part Number: AV-RTT4B-TE

About this Document
3SAN switch 2/32 Version 4.0.2b Release Notes
About this Document
This section describes the content reflected in this document, including:
■Intended Audience, page 4
■Related Documentation, page 4
■Software CD, page 5
■Features Summary, page 6
■Optional Upgrades and Software, page 7
■Obtaining Software License Keys, page 8
■Orderable Hardware, page 8
■Hardware Updates, page 9
■HP Recommendations, page 10
■Firmware Overview, page 10
■Prerequisites for Upgrading or Restoring Firmware, page 11
■Firmware Upgrade Procedures, page 12
■Firmware Enhancements, page 16
■Fabric OS Commands, page 21
■Updating the Core Switch PID Format, page 48
■Additional CLI commands, page 50
■Adding the SAN Switch 2/32 to an Existing Fabric, page 51
■Java Runtime Environment for HP-UX, page 53
■Compatibility, page 54
■Standards Compliance, page 56
■Known Issues, page 57
■Documentation Anomalies, page 62

Intended Audience
4 SAN switch 2/32 Version 4.0.2b Release Notes
Intended Audience
This document is intended for HP technicians and customers who purchased the
SAN Switch 2/32.
Related Documentation
The SAN Switch 2/32 kit includes the following documents:
Note: The SAN Switch 2/32 Installation Guide and both sets of Release Notes ship in
hard copy format with the switch. With the exception of the Release Notes, all listed
documents are provided in soft copy on the
hp StorageWorks SAN Switch Software
v4.0.2b CD
, part number AG-RTQXB-BE.
■hp StorageWorks SAN Switch 2/32 Version 4.0.x Installation Guide, part
number AA-RTQVB-TE
■hp StorageWorks SAN Switch 2/32 Version 4.0.2b Release Notes, part number
AV-RTT4B-TE (this document)
■hp StorageWorks Common Software and Switch Options Version 3.0.x/4.0.x
Release Notes, part number AV-RTQUB-TE
■hp StorageWorks Fabric OS Version 3.0.x/4.0.x Reference Guide, part number
AA-RS24B-TE
■hp StorageWorks Fabric OS Procedures Version 3.0.x/4.0.x User Guide, part
number AA-RS23B-TE
■hp StorageWorks Diagnostics and System Error Messages Version 3.0.x/4.0.x
Reference Guide, part number AA-RS22B-TE
■hp StorageWorks Web Tools Version 3.0.x/4.0.x User Guide, part number
AA-RS25B-TE
■hp StorageWorks Advanced Performance Monitoring Version 3.0.x/4.0.x User
Guide, part number AA-RTS4B-TE
■hp StorageWorks ISL Trunking Version 3.0.x/4.0.x User Guide, part number
AA-RTSAB-TE
■hp StorageWorks Extended Fabric Version 3.0.x/4.0.x User Guide, part
number AA-RTSDB-TE

Software CD
5SAN switch 2/32 Version 4.0.2b Release Notes
■hp StorageWorks Fabric Watch Version 3.0.x/4.0.x User Guide, part number
AA-RTSGB-TE
■hp StorageWorks Zoning Version 3.0.x/4.0.x User Guide, part number
AA-RS26B-TE
■hp StorageWorks Remote Switch Version 3.0.x/4.0.x User Guide, part number
AA-RTS7B-TE
Soft copy of the hp StorageWorks Core Switch 2/64 Version 4.0.x Installation
Guide, part number AA-RS2WB-TE, is also provided on the CD, which is shared
with 2/64 Core Switch products.
Hardcopy of the hp StorageWorks SAN Switch Universal Rack Mount Kit
Installation Addendum, part number AV-RU6YA-TE, is supplied with the hp
StorageWorks SAN Switch Universal Rack Mount Kit, now included with your
switch.
For the latest supported configurations, please refer to the hp StorageWorks SAN
Design Reference Guide, part number AA-RMPNF-TE, available at:
http://h18006.www1.hp.com/storage/saninfrastructure.html
For reference data on MIB files, refer to the hp StorageWorks mib reference
version 3.0/4.0, available from the HP website at:
http://h200005.www2.hp.com/bc/docs/support/SupportManual/lpg29296/lpg29296
.pdf
Additional documentation, including white papers and best practices documents,
are available via the HP website at:
http://welcome.hp.com/country/us/eng/prodserv/storage.html
Software CD
HP StorageWorks SAN Switch 2/32 products ship with the latest version of the
firmware installed. A copy of the latest version of the firmware, v4.0.2b, is also
contained on the hp StorageWorks SAN Switch Software v4.0.2b CD, part number
AG-RTQXB-BE. The v4.0.2b firmware and future upgrades are also available on
the HP website at:
http://h18006.www1.hp.com/products/storageworks/fcsanswitch232/index.html
Configuration File
HP supplies the following configuration file, included on the CD:
DSGGE\firmware\FW232.TXT

Features Summary
6 SAN switch 2/32 Version 4.0.2b Release Notes
The FW232.TXT configuration file is used with the SAN Switch 2/32. This file
includes switch and Fabric Watch default parameters. All parameters (except the
Fabric Watch default parameters) can be downloaded to a switch when logged on
as the “admin” user.
Note: Performing a configdownload with these files only appends or changes those
parameters within this file. It will not change any other parameter on the switch which
may have been changed at the customer site. Remember that all switches in a fabric
must have the same configuration settings.
Features Summary
The following section summarizes the management features available with SAN
Switch 2/32 products.
SAN Switch 2/32
The SAN Switch 2/32 ships with the following features enabled, and ready to use:
■Full Fabric—Provides Full Fabric OS.
■Web Tools—Provides a graphical user interface (GUI) to monitor and manage
the entire fabric.
■Zoning—Allows partitioning of the SAN into logical groupings of devices
that access each other.
SAN Switch 2/32 Power Pak
The SAN Switch 2/32 Power Pak ships with the following features enabled, and
ready to use:
■Full Fabric—Provides Full Fabric OS.
■Web Tools—Provides a graphical user interface (GUI) to monitor and manage
the entire fabric.
■Zoning—Allows partitioning of the SAN into logical groupings of devices
that access each other.
■Fabric Watch—Monitors the performance and status of HP StorageWorks
SAN Switches, and alerts network managers as problems arise.

Optional Upgrades and Software
7SAN switch 2/32 Version 4.0.2b Release Notes
■ISL Trunking—Using ISL trunking, high speed links ensure that
server-to-storage performance is efficient.
■Advanced Performance Monitoring—Provides a comprehensive tool for
monitoring the performance of storage devices within the network.
The following features are built into the switch firmware, but not enabled.
■Extended Fabric—Creates a fabric interconnected at distances greater than 5
km for 2 Gbps interswitch links. To enable, use the Web Tools Extended
Fabrics Tab, or use the telnet portCfgLongDistance command.
■Remote Switch—Enables a switch to work with a separately purchased
network bridge, in order to interconnect fabrics. To enable, use the Web Tools
Extended Fabrics Tab. See the hp StorageWorks Common Software and Switch
Options Version 3.0.x/v4.0.x Release Notes for Remote Switch limitations.
Optional Upgrades and Software
The following optional upgrades and software are also available for SAN Switch
2/32 products.
Note: Options purchased separately require you to obtain a license. See the next
section, Obtaining Software License Keys, page 8, for more details.
Power Pak Upgrade Bundle
The SAN Switch 2/32 Power Pak Upgrade Bundle is available as a separate option
for the SAN Switch 2/32, and includes licenses for Fabric Watch, ISL Trunking,
Advanced Performance Monitoring, Extended Fabric and Remote Switch options.
Fabric Manager
Fabric Manager is a separately purchased product that provides a graphical
interface, allowing the administrator to monitor and manage an entire fabric from
a standard workstation. Fabric Manager can be used to manage fabrics containing
integrated fabrics, in addition to individual switches.

Obtaining Software License Keys
8 SAN switch 2/32 Version 4.0.2b Release Notes
Obtaining Software License Keys
If you’ve purchased optional software, or need to reinstall software features due to
a motherboard replacement in your switch, you will need to retrieve the software
license keys from the HP Authorization Center.
Obtain software license keys as follows:
■If you have your HP Registration Number, (located on your software
entitlement certificate) go to:
http://webkey.external.hp.com/welcome.asp
■If your HP Registration Number is unavailable, contact the Authorization
Center directly:
— Canada and United States, (Monday through Friday 6:00 am to 6:00 pm,
[phone] or [phone].
— Asia, (Monday through Friday 9:00 am to 5:00 pm MST),
[phone] or [phone].
— Europe, Middle East, Africa and Netherlands (Monday through Friday
9:00 am to 6:00 pm), [phone].
Orderable Hardware
Table 1 lists HP hardware accessory options for SAN Switch 2/32 products
Table 1: SAN Switch 2/32 Orderable Hardware
Accessory Part Number
Short wavelength SFP A6515A* or 300834-B21**
Long wavelength SFP, 10 km A6516A* or 300835-B21**
Long wavelength SFP, 35km 300836-B21**
2m LC-to-LC Fibre Channel (fc) cable C7524A*
2m LC-to-LC multi-mode fc cable 221692-B21**
16m LC-to-LC fc cable C7525A*
5m LC-to-LC multi-mode fc cable 221692-B22**
50m LC-to-LC fc cable C7526A*
15m LC-to-LC multi-mode fc cable 221692-B23**
200m LC-to-LC fc cable C7527A*

Hardware Updates
9SAN switch 2/32 Version 4.0.2b Release Notes
* premerger HP part number
** premerger Compaq part number
Hardware Updates
The following section lists hardware updates for the SAN Switch 2/32.
Important Information Regarding Rack Mounting Hardware
The hp StorageWorks SAN Switch Universal Rack Mount Kit is included with
your switch. See the hp StorageWorks SAN Switch Universal Rack Mount Kit
Installation Addendum, part number AV-RU6YA-TE, supplied with the rack
mount kit for installation instructions.
Note: HP highly recommends installing the switch in racks with only the hardware
supplied with your switch. Using longer than recommended screws to install your switch
into a rack will result in physical damage to the switch motherboard.
30m LC-to-LC multi-mode fc cable 221692-B26**
50m LC-to-LC multi-mode fc cable 221692-B27**
2m LC-to-SC fc cable C7529A*
2m LC-to-SC multi-mode fc cable 221691-B21**
16m LC-to-SC fc cable C7530A*
5m LC-to-SC multi-mode fc cable 221691-B21**
15m LC-to-SC multi-mode fc cable 221691-B23**
30m LC-to-SC multi-mode fc cable 221691-B26**
50m LC-to-SC multi-mode fc cable 221691-B27**
SC female to SC female adapter C7534A*
2m LC male to SC male adapter kit C7534A*
Universal Rack Mount Kit 331148-B21
Table 1: SAN Switch 2/32 Orderable Hardware
Accessory Part Number

HP Recommendations
10 SAN switch 2/32 Version 4.0.2b Release Notes
HP Recommendations
HP always recommends redundant fabrics and multi-pathing software for
uptime-sensitive environments. Examples of scenarios protected by redundant
fabrics include, but are not limited to:
■Add / Move / Change operations for devices or switches
■Changing the core PID format
■Changing any other fabric-wide parameters (for example, ED_TOV)
■Erroneous zoning changes / user error
■Major upgrades / changes to fabric architecture
■Physical disasters, for example, water pipe breaks above “fabric A” rack
HP recommends strongly against using drivers that bind by PID. There are several
routine maintenance procedures which may result in a device receiving a new
PID; the core PID format update is just one example of such a procedure.
Examples include, but are not limited to:
■Changing “Compatibility Mode” settings
■Changing switch domain IDs
■Merging fabrics
■Relocating devices to new ports or new switches (that is, for Add, Move,
Change type operations)
■Updating the core PID format
■Using hot spare switch ports to deal with failures
Firmware Overview
Firmware v4.0.2b works with HP StorageWorks 2 Gbps switch models only. The
firmware will not work if loaded onto HP StorageWorks 1 Gbps switch models.
HP recommends that all switches supported by the 4.0.x code stream be updated
to Version 4.0.2b together, so all supported switches operate with the same version
code.
Firmware Version 4.0.2b contains the fully supported Web Tools Graphical User
Interface (GUI). Instructions for downloading the firmware are contained on the
Software CD.
