Errata
Title & Document Type:
Manual Part Number:
Revision Date:
HP References in this Manual
This manual may contain references to HP or Hewlett-Packard. Please note that Hewlett-
Packard's former test and measurement, semiconductor products and chemical analysis
businesses are now part of Agilent Technologies. We have made no changes to this
manual copy. The HP XXXX referred to in this document is now the Agilent XXXX.
For example, model number HP8648A is now model number Agilent 8648A.
About this Manual
We’ve added this manual to the Agilent website in an effort to help you support your
product. This manual provides the best information we could find. It may be incomplete
or contain dated information, and the scan quality may not be ideal. If we find a better
copy in the future, we will add it to the Agilent website.
Support for Your Product
Agilent no longer sells or supports this product. You will find any other available
product information on the Agilent Test & Measurement website:
www.tm.agilent.com
Search for the model number of this product, and the resulting product page will guide
you to any available information. Our service centers may be able to perform calibration
if no repair parts are needed, but no other support from Agilent is available.
16532A Digitizing Oscilloscope Service Manual
16532-97002
July 1993

SERVICE MANUAL
HP 16532A
1 GSa/s Digitizing
Oscilloscope
COPYRIGHT HEWLETT-PACKARD COMPANY,
COLORADO SPRINGS DIVISION 1991-1993
1900 GARDEN OF THE GODS ROAD, COLORADO SPRINGS, COLORADO U.S.A.
ALL RIGHTS RESERVED
Manual Part No. 16532-97002 PRINTED: JULY 1993

GENERAL - This is a Safety Class I instrument (provided with
terminal for protective earthing).
OPERATION - BEFORE APPLYING POWER verify that the
power transformer primary is matched to the available line
voltage, the correct fuse is installed, and Safety Precautions
are taken (see the following warnings). In addition, note the in-
strument’s external markings which are described under
"Safety Symbols."
•Servicing instructions are for use by service-trained per-
sonnel. To avoid dangerous electric shock, do not perform
any servicing unless qualified to do so.
•BEFORE SWITCHING ON THE INSTRUMENT, the protec-
tive earth terminal of the instrument must be connected to
the protective conductor of the (mains) powercord. The
mains plug shall only be inserted in a socket outlet pro-
vided with a protective earth contact. The protective action
must not be negated by the use of an extension cord
(power cable) without a protective conductor (grounding).
Grounding one conductor of a two-conductor outlet is not
sufficient protection.
•If this instrument is to be energized via an auto-trans-
former (for voltage reduction) make sure the common ter-
minal is connected to the earth terminal of the power
source.
•Any interruption of the protective (grounding) conductor
(inside or outside the instrument) or disconnecting the pro-
tective earth terminal will cause a potential shock hazard
that could result in personal injury.
•Whenever it is likely that the protection hasbeen im-
paired, the instrument must be made inoperative and be
secured against any unintended operation.
•Only fuses with the required rated current, voltage, and
specified type (normal blow, time delay, etc.) should be
used. Do not use repaired fusesor short circuited fuse-
holders. To do so could cause a shock or fire hazard.
•Do not operate the instrument in the presence of flamma-
ble gasses or fumes. Operation of any electrical instru-
ment in such an environment constitutesa definite safety
hazard.
•Do not install substitute parts or perform any unauthorized
modification to the instrument.
•Adjustments described in the manual are performed with
power supplied to the instrument while protective covers
are removed. Energy available at many points may, if con-
tacted, result in personal injury.
•Any adjustment, maintenance, and repair of the opened in-
strument under voltage should be avoided asmuch as
possible, and when inevitable, should be carried out only
by a skilled person who is aware of the hazard involved.
•Capacitorsinside the instrument may still be charged
even if theinstrument hasbeen disconnected from its
source of supply.
SAFETY SYMBOLS
Instruction manual symbol. The product will be
marked with this symbol when it is necessary for
the user to refer to the instruction manual in order
to protect against damage to the product.
Earth terminal (sometimesused in manual to in-
dicate circuit common connected to grounded
chassis).
The WARNING sign denotes a hazard. It
calls attention to a procedure, practice,
or the like, which, if not correctly per-
formed or adhered to, could result in personal injury. Do not
proceed beyond a WARNING sign until the indicated condi-
tions are fully understood and met.
The CAUTION sign denotes a hazard. It
calls attention to an operating procedure,
practice, or the like, which, if not cor-
rectly performed or adhered to, could result in damage to or
destruction of part or all of the product. Do not proceed be-
yond a CAUTION sign until the indicated conditions are fully
understood or met.
SAFETY CONSIDERATIONS
Indicateshazardous voltages
SC1D984

CONTENTS
SECTION I
General Information
1-1. Introduction .............................................................................................................................. 1-1
1-2. Module Covered by This Manual ............................................................................................ 1-1
1-3. Safety Requirements ............................................................................................................... 1-1
1-4. Product Description ................................................................................................................. 1-2
1-5. Accessories Supplied .............................................................................................................. 1-2
1-6. Accessories Available............................................................................................................... 1-2
1-7. Specifications ........................................................................................................................... 1-2
1-8. Operating Characteristics ....................................................................................................... 1-2
1-9. Recommended Test Equipment ............................................................................................. 1-2
SECTION II
Installation
2-1. Introduction ............................................................................................................................. 2-1
2-2. Initial Inspection ...................................................................................................................... 2-1
2-3. Preparation for Use ................................................................................................................ 2-1
2-4. Power Requirements .............................................................................................................. 2-1
2-5. Safety Requirements .............................................................................................................. 2-1
2-6. Module Installation ................................................................................................................. 2-1
2-7. Operating Environment .......................................................................................................... 2-4
2-8. Storage .................................................................................................................................... 2-4
2-9. Packaging ............................................................................................................................... 2-4
2-10. Tagging for Service ................................................................................................................ 2-4
SECTION III
Performance Tests
3-1. Introduction .............................................................................................................................. 3-1
3-2. Recommended Test Equipment ............................................................................................. 3-1
3-3. Test Record .............................................................................................................................. 3-1
3-4. Performance Test Interval ....................................................................................................... 3-1
3-5. Performance Test Procedures ................................................................................................ 3-1
3-6. DC CAL OUTPUTTest ............................................................................................................. 3-2
3-7. AC CAL OUTPUTTest ............................................................................................................. 3-3
3-8. Input Resistance ...................................................................................................................... 3-4
3-9. Voltage Measurement Accuracy ............................................................................................. 3-6
3-10. Offset Accuracy ....................................................................................................................... 3-9
3-11. Bandwidth ................................................................................................................................ 3-11
3-12. Time Measurement Accuracy .................................................................................................. 3-13
3-13. Trigger Sensitivity .................................................................................................................... 3-15
HP 16532A - Table of Contents
v

SECTION IV
Calibration
4-1. Introduction............................................................................................................................... 4-1
4-2. Safety Requirements................................................................................................................ 4-1
4-3. Calibration Interval.................................................................................................................... 4-1
4-4. Maintaining System Integrity.................................................................................................... 4-1
4-5. Calibration Protection Switch................................................................................................... 4-1
4-6. Recommended Test Equipment..............................................................................................4-2
4-7. Instrument Warmup.................................................................................................................. 4-2
4-8. Calibration................................................................................................................................. 4-2
4-9. Setting the PROTECT/UNPROTECTSwitch to UNPROTECT................................................ 4-3
4-10. Equipment Required for Calibration....................................................................................... 4-4
4-11. Loading the Default Calibration Factors................................................................................. 4-4
4-12. Self Cal Menu Calibrations...................................................................................................... 4-5
4-13. Setting the PROTECT/UNPROTECTSwitch to PROTECT.................................................... 4-8
4-14. Sealing the Mainframe............................................................................................................. 4-8
Section V
Replaceable Parts
5-1. Introduction .............................................................................................................................. 5-1
5-2. Abbreviations ........................................................................................................................... 5-1
5-3. Replaceable Parts List ............................................................................................................. 5-1
5-4. Ordering Information ............................................................................................................... 5-1
5-5. Exchange Assemblies ............................................................................................................. 5-1
5-6. Direct Mail Order System ........................................................................................................ 5-2
SECTION VI
Service
6-1. Introduction .............................................................................................................................. 6-1
6-2. Safety Requirements ............................................................................................................... 6-1
6-3. Recommended Test Equipment ............................................................................................. 6-1
6-4. Module Block Diagram and Theory of Operation................................................................... 6-1
6-5. Attenuator Theory of Operation............................................................................................... 6-1
6-6. Main Assembly Theory of Operation....................................................................................... 6-1
6-7. Self-Tests .................................................................................................................................. 6-4
6-8. Troubleshooting ....................................................................................................................... 6-10
6-9. Oscilloscope Module Removal and Replacement ................................................................. 6-18
6-10. Trigger Cable Removal and Replacement ............................................................................. 6-20
6-11. Attenuator Removal and Replacement .................................................................................. 6-21
HP 16532A - Table of Contents
vi

LIST OF TABLES
TABLE TITLE PAGE
1-1. HP 16532A Specifications........................................................................................................ 1-3
1-2. HP 16532A Operating Characteristics..................................................................................... 1-4
1-3. Recommended Test Equipment..............................................................................................1-9
3-1. Performance Test Record........................................................................................................ 3-17
4-1. Calibration Sequence............................................................................................................... 4-2
5-1. Reference Designator and Abbreviations................................................................................ 5-3
5-2. Replaceable Parts List.............................................................................................................. 5-5
LIST OF FIGURES
FIGURE TITLE PAGE
2-1. Endplate Overlap - Top Sequence........................................................................................... 2-2
2-2. Endplate Overlap - Bottom Sequence..................................................................................... 2-3
3-1. Voltage Measurement Accuracy Test........................................................................................ 3-7
4-1. Endplate Overlap - Top Sequence........................................................................................... 4-3
4-2. Location of the PROTECT/UNPROTECTSwitch..................................................................... 4-3
4-3. Default Calibration Display....................................................................................................... 4-4
4-4. Ext Trig Null Calibration Connections...................................................................................... 4-7
4-5. End of Calibration Display........................................................................................................ 4-8
4-6. Endplate Overlap - Top Sequence .......................................................................................... 4-8
5-1. Parts Identification.................................................................................................................... 5-4
6-1. HP 16532A Oscilloscope Block Diagram................................................................................ 6-2
6-2. Startup Screen.......................................................................................................................... 6-4
6-3. Load Test System Screen........................................................................................................ 6-5
6-4. Test System Screen.................................................................................................................. 6-5
6-5. Functional Tests Screen........................................................................................................... 6-6
6-6. Main Test Menu ........................................................................................................................ 6-6
6-7. A/D Test Run Screen................................................................................................................ 6-7
6-8. Stop Field.................................................................................................................................. 6-7
6-9. Exit Test System Screen .......................................................................................................... 6-8
6-10. Troubleshooting Flowchart...................................................................................................... 6-13
6-11. Endplate Overlap - Top Sequence........................................................................................... 6-18
6-12. Endplate Overlap - Bottom Sequence..................................................................................... 6-19
6-13. Oscilloscope Module Exploded View...................................................................................... 6-20
HP 16532A - Table of Contents
vii

TABLE OF CONTENTS
General Information
1-1. Introduction...........................................................................................................................1-1
1-2. Module Covered by Manual.................................................................................................1-1
1-3. Safety Requirements.............................................................................................................1-1
1-4. Product Description..............................................................................................................1-2
1-5. Accessories Supplied...........................................................................................................1-2
1-6. Accessories Available...........................................................................................................1-2
1-7. Specifications........................................................................................................................1-2
1-8. Operating Characteristics.....................................................................................................1-2
1-9. Recommended Test Equipment ..........................................................................................1-2

SECTION I
General Information
1-1. Introduction
The service policy for this instrument is replace-
ment of defective assemblies. This service guidel
contains information for finding a defective
assembly by testing and servicing the HP 16532A
1 GSa/s Oscilloscope Module. Also included in
the guide are installation procedures and a list of
recommended test equipment. This guide is
divided into six sections as follows:
I - General Information
II - Installation
III - Performance Tests
IV- Calibration
V- Replaceable Parts
VI - Service
The General Information Section includes safety
requirements, a product description, and a list of
accessories supplied and of accessories available.
Also included are tables listing specifications and
operating characteristics, and a list of
recommended test equipment.
To complete the service documentation for your
HP 16500 Logic Analysis System, place this
service manual in the 3-ring binder with your other
logic analysis system Service Guides.
1-2. Module Covered by This Manual
The information covered in this manual is for the
HP 16532A 1 GSa/s Oscilloscope Module.
1-3. Safety Requirements
Specific warnings, cautions, and instructions are
placed wherever applicable throughout the
manual. These must be observed during all
phases of operation, service, and repair of the
module. Failure to comply with them violates
safety standards of design, manufacture, and
intended use of this module.
Hewlett-Packard assumes no liability for the failure
of the customer to comply with these safety
requirements.
HP 16532A - General Information
1-1

1-4. Product Description
The HP 16532A Oscilloscope Module is a 1 GSa/s
digitizing oscilloscope. Some of the main features
are:
•1 GSa/s digitizing for 250 MHz bandwidth sin-
gle shot analysis.
•8000 samples per channel.
•Automatic pulse parameters, displays time be-
tween markers, acquires until specified time
between markers is captured, performs statis-
tical analysis on time between markers.
•Lightweight miniprobes.
1-5. Accessories Supplied
The following accessories are supplied with the
HP 16532A Oscilloscope module. Quantity one
unless shown otherwise.
•User’s Reference and Programming Refer-
ence set
•Service Guide
•HP 10441A 10:1 probes, Qty 2
•Right angle BNC adapters, Qty 2
•BNC miniprobe adapter
•Master-slave trigger cable
•Operating System Software
1-6. Accessories Available
•10:1, 100:1, 50 Ω, 10 pf resistive divider probe
set, 1.2 m (HP 10020A)
•BNC-to-BNC cable, 1.2 m (HP 10503A)
•24-pin IC test clip (HP 10211A)
•BNC-to-BNC ac coupling capacitor
(HP 10240B)
10:1 Probe:
•1-MΩ, 7.5-pf miniprobe, 1 m (HP 10435A)
1:1 Probes:
•40-pf miniprobe, 1 m (HP 10438A)
•64-pf miniprobe, 2 m (HP 10439A)
•50-Ωminiprobe, 2 m (HP 10437A)
100:1 Probe:
•10-MΩ, 2.5-pf miniprobe, 2 m (HP 10440A)
1-7. Specifications
Module specifications are listed in table 1-1. These
specifications are the performance standards
against which the module is tested.
1-8. Operating Characteristics
Table 1-2 is a listing of the module operating
characteristics. The operating characteristics are
not specifications, but are the typical operating
characteristics included as additional information
for the user.
1-9. Recommended Test
Equipment
Equipment required to test and maintain the
HP 16532A Oscilloscope Module is listed in table
1-3. Other equipment may be substituted if it
meets or exceeds the critical specifications listed
in the table.
HP 16532A - General Information
1-2

Table 1-1. HP 16532A Specifications
HP 16532A SPECIFICATIONS
Type: 2-channel simultaneous acquisition
Bandwidth(*,1):dc to 250 MHz (real time, dc-coupled)
Maximum Sample Rate: 1 Gigasample per second
Number of Channels: 2, 4, 6, 8 simultaneous channels using the same time base setting(s)
OR
Up to 10 channels with independent time bases for each pair of channels.
Up to 18 channels with the HP16501A Expansion Frame.
Rise Time(2):1.4 ns
ADC: 8-bit real time
Vertical Resolution: 8 bits over 4 vertical divisions (±0.4%)
Waveform Record Length: 8000 points
Time Interval Measurement Accuracy(*,3,6):±[(0.005% X ∆t)+ (2 x 10−6x delay setting)+ 150 ps]
Vertical (dc) Gain Accuracy(4):±1.5%of full scale
DC Offset Accuracy(*):±(1.0%of channel offset + 2.0%of full scale)
Voltage Measurement Accuracy(*,5):±[(1.5%of full scale + offset accuracy) + (0.008 x V/div)]
Trigger Sensitivity(*): dc to 50 MHz: 0.063 x full scale, 50 to 250 MHz: 0.125 x full scale
Input Coupling: 1 MΩ: ac and dc, 50 Ω: dc only
Input R (selectable) (*):1 MΩ: ±1%, 50 Ω: ±1%
Input C: Approximately 7 pF
___________________________________________________________________________________________
NOTES:
* Specifications (valid within ±10°C of auto-calibration temperature, excluding bandwidth−see
note 1 for bandwidth specification.)
1. Upper bandwidth reduces by 2.5 MHz for every degree C above 35°C.
2. Rise time is calculated from the formula:
t
r
=0.35
bandwidth
3. Specification applies to the maximum sampling rate. At lower rates, the specification is:
±[(0.005% x ∆t)+ (2 x 10-6 x delay setting) + (0.15 x sample interval)] for bandwidth limited signals
(tr= 1.4 x sample interval). Sample interval is defined as 1
sample rate
4. Vertical gain accuracy decreases 0.08% per degree C from software calibration temperature.
5. Digitizing level = (# vertical divisions)(1
2)( 1
LSB
), where LSB= 2# bitsinADC
6. The Time Interval Measurement Accuracy deteriorates across multiple modules connected as one
unit with each added module.
HP 16532A - General Information
1-3

Table 1-2. HP 16532A Operating Characteristics
HP 16532A OPERATING CHARACTERISTICS
VERTICAL (at BNC)
Vertical Sensitivity Range (1:1 Probe):
4 mV/div to 10 V/div in 1-2-4 increments
DC Offset Range (1:1 Probe):
Vertical Sensitivity Available Offset
4 mV/div to 100 mV/div ±2 V
> 100 mV/div to 500 mV/div ±10 V
> 500 mV/div to 2.5 V/div ±50 V
> 2.5 V/div to 10 V/div ±250 V
Probe Factors:
Any integer ratio from 1:1 to 1000:1
Maximum Safe Input Voltage:
1 MΩ: ±250 V [dc + peak ac (< 10 KHz)]
50 Ω: ±5 VRMS
Channel-to-Channel Isolation:
dc to 50 MHz: 40 dB, 50 MHz to 250 MHz: 30 dB
TIMEBASE
Range:
1 ns/div to 5 s/div
Resolution:
20 ps
Delay Pre-trigger Range:
Time/div Setting Available Delay
1 µs to 5 s/div -8 x (s/div)
1 ns to 500 ns/div -4 µs
Delay Post-trigger Range:
Time/div Setting Available Delay
100 ms to 5 s/div 2.5 ks
1 µs to 50 ms/div 33,500 x (s/div)
1ns to 500 ns/div 16.7 ms
HP 16532A - General Information
1-4

Table 1-2. HP 16532A Operating Characteristics (cont.)
TRIGGERING
Trigger Level Range:
Within display window (full scale and offset)
Trigger Modes:
Immediate:
Triggers immediately after arming condition is met.
Edge:
Triggers on rising or falling edge of any internal channel or external trigger,
count adjustable from 1 to 32,000.
Pattern:
Triggers on entering, exiting, duration greater than, duration less than, and
duration in range for a specified pattern of both internal channels and external
trigger, count adjustable from 1 to 32,000. Duration time range is adjustable
from 20 ns to 160 ms in 10 ns steps. Duration accuracy is approximately ±3%
±2 ns.
Auto-Trigger:
If enabled, the module will self-trigger if no trigger condition is found within
approximately 50 ms after arming.
Events Delay:
The trigger can be set to occur on the nth edge or pattern, as specified by the
user. The number of events (n) can be set from 1 to 32,000 events. Maximum
count frequency is 70 MHz.
Intermodule:
Arms another measurement module or triggers the rear panel BNC.
External:
If enabled, the oscilloscope will trigger on an ECL level signal (-1.3 V).
DIGITIZER
Resolution: 8 bits (1 part in 256)
Digitizing Rate: Up to 1 Gigasample per second
Digitizing Technique: Real-time digitizing; each 8000 samples are acquired on a single acquisition
Acquisition Memory Size: 8000 samples per channel
HP 16532A - General Information
1-5

Table 1-2. HP 16532A Operating Characteristics (cont.)
WAVEFORM DISPLAY
Displayed Waveforms:
Eight waveform windows maximum, with scrolling across 96 waveforms.
Display Formats:
Waveforms can be displayed in an overlapping and/or non-overlapping format.
Display capability of A−B and A+ B is also provided.
Display Resolution:
500 points horizontal, 240 points vertical
DISPLAY MODES
Normal (Single):
New acquisition replaces old acquisition on screen.
Accumulate:
New acquisition is displayed in addition to previous acquisitions until screen is
erased.
Average:
New acquisitions are averaged with old acquisitions, with the updated waveform
displayed until erased. Maximum number of averages is 256.
Overlay:
Up to 8 acquired waveforms from separate channels can be overlayed in the
same display area.
Connect-the-dots:
Provides a display of the sample points connected by straight lines.
Waveform Reconstruction:
When there is insufficient data to fill every horizontal location, a post acquisition
reconstruction filter fills in missing data points for time base < 50 ns/div.
Waveform Math:
Display capability of A−B and A+ B functions is provided.
HP 16532A - General Information
1-6

Table 1-2. HP 16532A Operating Characteristics (cont.)
MEASUREMENT AIDS
Time Markers:
Two vertical markers, Xand O, are provided for measurements of time and
voltage. Capabilities are: measure voltage at point where Xand O markers
cross each analog waveform; measure time from trigger to X, trigger to O, and
Xto O; automatic marker placement by specifying percentage of edge, edge
number, and rising or falling edge type; run until Xto O > than, < than, in
range, and not in range provides selective event search; X to O statistics (mean,
max, and min) provide analysis of time interval deviation.
Automatic Search:
Searches for a percentage or an absolute voltage level at a positive or negative
edge, count adjustable from 1 to 100.
Auto Search Statistics:
Mean, maximum, and minimum values for elapsed time from Xto O markers for
multiple runs. Number of valid runs and total number of runs available.
Automatic Measurements:
The following pulse parameter measurements can be performed automatically:
Frequency Rise time + pulse width
Period Fall time −pulse width
V p-p Preshoot V amplitude*
Overshoot
(*gives difference between top and base
voltages; only available over bus)
Grid:
Graticules can be displayed in backround of waveform.
Voltage Markers:
Two horizontal markers, Aand B, are provided for voltage measurements.
These markers can each be placed on any acquisition channel trace. A delta
voltage display provides delta Vbetween markers on the same channel or
between two channels.
HP 16532A - General Information
1-7

Table 1-2. HP 16532A Operating Characteristics (cont.)
SETUP AIDS
Autoscale:
Autoscales the vertical and horizontal ranges, offset, and trigger level to display
the input signals. Requires a frequency between 50 Hz and 250 MHz.
Presets:
Scales the vertical range, offset, and trigger level to predetermined values for
displaying ECL or TTL waveforms.
Calibration:
Vertical, trigger, delay, and all defaults. Calibration factors stored in NV-RAM on
the circuit board.
Probe Compensation Source:
External BNC supplies a square wave approximately 0.0 mVto -800 mV into the
open circuit at approximately 1000 Hz.
OPERATING ENVIRONMENT
Temperature:
Instrument, 0°to 55°C (+ 32°to 131°F). Probes and cables, 0°to 65°C (+ 32°
to 149°F).
Humidity:
Instrument, up to 95%relativehumidity at + 40°C (+ 104° F). Recommended
disk media, 8% to 80% relative humidity at + 40°C (+ 104° F).
Altitude:
To 4600 m (15,000 ft).
Vibration
Operation:
Random vibration 5-500 Hz, 10 minutes per axis, ~ 0.3 g (rms).
Non-operating:
Random vibration 5-500 Hz, 10 minutes per axis, ~ 2.41 g (rms); and swept
sine resonant search, 5-500 Hz, 0.75 g (0- peak), 5 minute resonant dwell @ 4
resonances per axis.
HP 16532A - General Information
1-8

Table 1-3. Recommended Test Equipment
EQUIPMENT CRITICAL SPECIFICATIONS RECOMMENDED MODEL USE*
Signal Generator Frequency: 1 - 250 MHz at approx .
170 mV RMS resolution
Output Accuracy: ±1 dB
1 MHz time base accuracy 0.25 ppm
HP 8656B Option 001 P
Dc Power Supply Range: −35.000 to + 35.000 Vdc, ±1 mV HP 6114A P
Digital Multimeter 0.1 mVresolution
Accuracy: better than 0.005%
Resistance measurement: better than
0.25% accuracy
HP 3458A P
Power Meter/Sensor 1 - 250 MHz ±3% accuracy HP 436/8482A P
Power Splitter Outputs differ by < 0.15dB HP11667B P
Blocking Capacitor 50 ΩBNC (m-to-f), 0.18 µF, ±200 V HP 10240B P
Adapter 50 ΩBNC (m)(m) HP 1250-1236 C
Adapter 50 Ω Type N(m)-to-BNC(m) HP 1250-0082 P
Adapter 50 ΩBNC(f)-to-Dual Banana Plug HP 1251-2277 P
Adapter 50 ΩType N(m)-to-BNC(f) HP 1250-0780 P
Tee Adapter 50 ΩBNC (m)(f)(f) HP1250-0781 P,C
Cable Type N(m-to-m) 24-inch HP 11500B P
Cable 50 Ω BNC (m-to-m) 48-inch HP 10503A P
Cable 50 Ω BNC (m-to-m) 9 inch HP 10502A C
Cable 50 ΩBNC-SMB HP 16532-61601 C
*P= Performance Tests C= Calibrations
HP 16532A - General Information
1-9

TABLE OF CONTENTS
Installation
2-1. Introduction ......................................................................................................................... 2-1
2-2. Initial Inspection .................................................................................................................. 2-1
2-3. Preparation for Use ............................................................................................................. 2-1
2-4. Power Requirements .......................................................................................................... 2-1
2-5. Safety Requirements ........................................................................................................... 2-1
2-6. Module Installation .............................................................................................................. 2-1
2-7. Operating Environment ...................................................................................................... 2-4
2-8. Storage ................................................................................................................................ 2-4
2-9. Packaging ........................................................................................................................... 2-4
2-10. Tagging for Service ............................................................................................................. 2-4

SECTION II
Installation
2-1. Introduction
This section explains how to initially inspect the
HP 16532A Oscilloscope Module, then how to
prepare it for use, storage, and shipment. Also
included are procedures for module installation.
2-2. Initial Inspection
Inspect the shipping container for damage. If the
shipping container or cushioning material is
damaged, it should be kept until the contents of
the shipment have been checked for
completeness and the module has been checked
mechanically and electrically. The contents of the
shipment should be as listed in the "Accessories
Supplied" paragraph located in Section I.
Procedures for checking electrical performance
are in Section III. If the contents of the container
are incomplete, there is mechanical damage or
defect, or the instrument does not pass the
performance tests, notify the nearest
Hewlett-Packard sales office.
If the shipping container is damaged, or the
cushioning material shows signs of stress, notify
the carrier as well as the Hewlett-Packard sales
office. Keep the shipping material so the carrier
can inspect it. The Hewlett-Packard office will
arrange for repair or replacement at
Hewlett-Packard’s option without waiting for claim
settlement.
2-3. Preparation for Use
Read the Safety Considerations in the front of
this manual and in Section Ibefore installing
or operating this module.
2-4. Power Requirements
All power supplies required for operating the
HP 16532A Oscilloscope Module are supplied to
the module through the backplane connector in
the mainframe.
2-5. Safety Requirements
Specific warnings, cautions, and instructions are
placed wherever applicable throughout the
manual. These must be observed during all
phases of operation, service, and repair of the
module. Failure to comply with them violates
safety standards of design, manufacture, and
intended use of this module.
Hewlett-Packard assumes no liability for the failure
of the customer to comply with these safety
requirements.
2-6. Module Installation
Do not install, remove, or replace the module
in the instrument unless the instrument power
is turned off.
The HP 16532A Oscilloscope Module will take up
one slot in the card cage. For every additional
HP 16532A Oscilloscope Module you install, you
will need an additional slot. They may be installed
in any slot and in any order. The installation
procedure for the module is continued,
step-by-step, on the next page.
HP 16532A - Installation
2-1

Module Installation (cont.)
The effects of ELECTROSTATIC DISCHARGEcan damage electronic compo-
nents. Use grounded wrist straps and mats when you are performing any kind of
service to this module.
Installation Considerations
•The HP 16532A Oscilloscope Modules can be installed in any available card slot.
•For multiple modules connected as one unit, the master card must be placed in the slot above the
expander cards. The master card and expander cards must be in adjoining slots.
•Cards or filler panels below the empty slots intended for module installation do not have to be re-
moved to install a module above them.
Procedure:
1. Turn instrument power switch off, unplug power cord and disconnect any input connections.
2. Starting from the top, loosen the thumb screws on the filler panels and cards.
3. Starting from the top, begin pulling out the cards and filler panels halfway. See figure 2-1.
Figure 2-1. Endplate Overlap - Top Sequence
HP 16532A - Installation
2-2
