HP R7000 INTL User manual

The innovative Minimally Switched Technology used in the new HP R7000 UPS improves the performance over traditional line-
interactive UPS designs while reducing the cost, weight, and size of traditional double-conversion online UPS designs. The digital signal
processing (DSP) enables complete digital control of the UPS resulting in increased power conditioning, lower system cost, and
enhanced user interface interactivity.
DSP technology enables the practical implementation of sophisticated UPS topologies and controls. The DSP can simultaneously control
multiple power converters to optimize system efficiency and other performance characteristics such as: enhanced battery management
for extended battery life, and improved output voltage regulation. The result is a higher performance UPS in smaller, lighter, more
reliable designs-an advantage for space-constrained equipment racks and cost conscious, co-located data center applications.
Front View: Rear View:
1. Escape Button 1. Load segment 1 circuit breaker (controls L6-30R receptacle
Item 3)
2. Scroll up button 2. Load segment 2 circuit breaker (controls L6-30R receptacle
Item 15)
3. Scroll down button 3. Large output NEMA L6-30R receptacle or IEC-60309 32A
receptacle on short cords associated with load segment 1
4. Enter/Select button 4. Cord retention clip attachment locations
5. Power button 5. Load segment 1 circuit breaker (controls the C19 receptacles,
but does not control the large output receptacle)
6. 3 x IEC C19 receptacles on load segment 1
7. HP UPS Network Module
8. Input power line cord with NEMA CS8265C plug or IEC-309-
32A plug
9. Ground bonding screw
10. Serial communications port
11. USB communications port
12. REPO port
13. 3 x IEC C19 receptacles on load segment 2
14. Load segment 2 circuit breaker (controls the C19 receptacles,
but does not control the large output receptacle)
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Overview
DA - 14110 North America — Version 5 — August 23, 2013 Page 1

15. Large output NEMA L6-30R receptacle or IEC-60309 32A
receptacle on short cords associated with load segment 2
16. ERM communication port
17. ERM connector for the large plug on the split ERM cable
Models
NOTE: #0D1 will appear after the part number on the sales order if HP factory integration is indicated.
HP R7KVA 4U 50A High Voltage Uninterruptible Power System AF462A
Kit Contents HP UPS R7000
HP UPS Network Module
Power Products Documentation CD
Depth adjustable fixed rack mounting rails, mounting brackets, cord retention clips
Communications cable
Two 7xC13 Extension Bars
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Overview
DA - 14110 North America — Version 5 — August 23, 2013 Page 2

Key Features High power density with up to 7200
VA /7200 Watts of power packed in just 3U rack space
Greater system uptime with support for Extended Runtime Modules (ERM)
Easy configuration through enhanced front panel display
Enterprise-wide intelligent manageability with bundled UPS Network Module and HP Power
Protector software
More efficient voltage regulation with revolutionary technology
Ultimate long-term battery reliability with HP Enhanced Battery Management
Enhanced system flexibility with two independently controlled load segments
Support for Remote Emergency Power Off (REPO) circuitry
Easy serviceability through modular design
Hot-Swappable Battery
Backed by a three year warranty with the first year including parts and labor. HP's Pre-Failure
warranty, and a $250,000 load protection guarantee * . (Certain restrictions and exclusions apply;
*Load protection guarantee available in North America only. )
Optional Extended Runtime Modules (ERM) increase batter runtime during a power failure
4U Power Packed Design Rated at unity power at 7200VA /7200W the HP UPS R7000 packs more power in space-conserving rack-
mount design, allowing you to support more critical equipment in your rack.
Increase System Uptime
with Extended Runtime
Modules
The Extended Runtime Modules are rack mounted battery modules that occupy 3U (5.25 inches) of rack
space. The HP UPS R7000 supports up to four Extended Runtime Modules (ERM), which extend your overall
battery runtime.
Lower Cost of Ownership
with Innovative
Technology
The HP UPS R7000 utilizes a the Digital Signal Processing industry-leading technology that continually
conditions and regulates power without using the battery, thereby increasing the life of the battery. The
output voltage is automatically regulated, based on the connected load and the input voltage.
Investment Protection
with HP Enhanced Battery
Management
HP UPS R7000 incorporates Enhanced Battery Management: an exclusive, patented technology that
doubles battery service life, optimizes battery recharge time, and provides advance notice of pending
battery failure. With Enhanced Battery Management, you can save 2-3 battery replacements over the life
of the UPS saving hundreds of dollars giving you a lower total cost of ownership while still receiving the
power protection for your critical equipment.
Enhanced Flexibility Six C19 outlets, and two L6-30 outlet provide a wide range of connection options. Two included Extension
Bars provide an addition 14 C13 outlets if needed. Adding additional HP PDU Extension Bars, AF500A,
provides additional C13 outlets making the R7000 and extremely flexible UPS for all environments.
Remotely Monitor UPSs on
the Network
The installed UPS Network Module enables network administrators to remotely monitor UPSs and reboot
network devices. It provides SNMP functionality, including power event alerts, network power diagnostics,
and remote UPS reboot and testing. Used in conjunction with HP Systems Insight Manager or other SNMP
capable Network Management Software, power-related problems on the network are quickly discovered
and remedied.
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Standard Features
DA - 14110 North America — Version 5 — August 23, 2013 Page 3

Easy Configuration via
Enhanced Front Panel
Display
LCD system integrated into the front panel with five button controls (three buttons for UPS power control
and one button under the front bezel for configuration)
Independently
Controllable Load
Segments
With two load segments, you have the flexibility to configure scheduled startups and shutdowns, in
addition to independently control the separate load segments. Working in conjunction with HP UPS
Network Module, the HP UPS R7000 can be configured to extend the runtime for more critical devices.
Ease of Maintenance with
Hot-Swappable Batteries
and Electronics Modules
The UPS R7000 is modular in design, and both the battery and the electronics modules are hot swappable.
HP UPSs are designed with simple access through the front panel. Users can safely install new batteries
without ever powering down connected server and server options.
Extended Runtime Module
(ERM), R7000
The UPS R7000 supports up to four Extended Runtime Modules. Each module is 3U (5.25 inches), a rack
mountable battery module that extends your overall battery runtime.
HP Quality HP's hardware qualification is the toughest in the industry. Extensive evaluation, testing, product
improvement, and an unsurpassed warranty guarantee the highest level of system protection, electrical
performance, product quality and compatibility.
Compatibility Compatible with all HP servers, storage, racks, rack options, and other rack mountable HP equipment. For
PDU options please refer to the UPS/PDU compatibility matrix on www.hp.com/products/ups .
Warranty The HP UPS R7000 is covered by a three year warranty, with the first year including parts and labor. Also,
standard on all HP UPS units, is our exclusive Battery Pre-Failure Warning which extends the advantage of
a HP three-year, limited warranty by applying it to the battery before it actually fails. This warranty is
offered worldwide. Specifically, the Pre-Failure Battery Warranty ensures that when customers receive
notification from the HP UPS Network Module that the battery may fail, the battery is replaced free of
charge under the warranty.
All HP Rackmount UPSs are also automatically covered to the full service level of ProLiant Care Packs in the
same rack so there is no need to purchase additional Care Packs for the UPSs. Batteries are not covered
under Care Pack Coverage
NOTE: $250,000 Computer/Load Protection Guarantee is also provided in, in addition to the HP three year,
limited warranty.
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Standard Features
DA - 14110 North America — Version 5 — August 23, 2013 Page 4

Service and Support HP Technology Services
HP Technology Services offers you consultants and support experts to solve your most complex
infrastructure problems. We help keep your business running, boost availability and avoid downtime.
Protect your business beyond warranty with HP Care Pack Services
When you buy HP Options, it's also a good time to think about what level of service you may need. HP Care
Pack services provide total care and support expertise with committed response choices designed to meet
your IT and business need.
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services 3-Year HP 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an HP authorized representative who will arrive on
site any time and day of the year to begin hardware maintenance service within 4 hours of the service
request being logged.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE
HP ProLiant Server Hardware Installation
Provides for the basic hardware installation of HP branded servers, storage devices and networking
options to assist you in bringing your new hardware into operation in a timely and professional manner
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-9356EN
Related HP Care Pack Services to enhance your HP product experience
Related Services 3-Year HP 6 hour Hardware Support Onsite Call-to-Repair Service
Provides an IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 hours of the initial service request to
the HP Global Solution Center
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EN
HP Proactive Select Service
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months. http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN
Insight Remote Support Delivers secure remote monitoring and support for HP servers and storage, 24x7 at no additional cost.
Available as part of HP Warranty, Care Pack and Service Contract offers.
Parts and materials HP will provide HP-supported replacement parts and materials necessary to maintain the covered
hardware product in operating condition, including parts and materials for available and recommended
engineering improvements. Supplies and consumable parts will not be provided as part of this service;
standard warranty terms and conditions apply. Parts and components that have exceeded their maximum
supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating
manual or the technical product data sheet will not be provided, repaired or replaced as part of this service.
Coverage For ProLiant servers and storage systems, this service covers HP-branded hardware options qualified for
the server, purchased at the same time or afterward, internal to the enclosure, as well as external
monitors up to 22" and tower UPS products; these items will be covered at the same service level and for
the same coverage period as the server unless the maximum supported lifetime and/or the maximum
usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms
and conditions apply.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by HP due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have
not failed. SSD/Flash Drives that are specified by HP as consumable parts and/or that have exceeded
maximum supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Service and Support
DA - 14110 North America — Version 5 — August 23, 2013 Page 5

manual or the technical data sheet are not eligible for the defective media retention service feature option.
For more information To learn more on services for HP ESSN Options, please contact your HP sales representative or HP
Authorized Channel Partner. Or visit: http://www.hp.com/services/proliant or
www.hp.com/services/bladesystem
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Service and Support
DA - 14110 North America — Version 5 — August 23, 2013 Page 6

HP UPS Options HP R5KVA and R7KVA 3U Extended Runtime Module
NOTE: #0D1 will appear after the part number on the sales order if HP factory
integration is indicated.
AF464A
HP Care Pack HP Install Universal Power Supply 3KVA to Below 6KVA Service U4693E
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Related Options
DA - 14110 North America — Version 5 — August 23, 2013 Page 7

High Voltage Models
Part Number Operating
Voltage Settings
Power Out
(VA/Watts)
Input Connection Output Connection
AF462A 200/208 * 7200VA/7200W Hubble CS8265C,
3m cord
LS1: 15A CB - 3 x C19 + 1 x L6-30R
LS2: 15A CB - 3 x C19 + 1 x L6-30R
* Factory default setting.
QuickSpecs
R7000 Uninterruptible Power System (UPS)
UPS Model Matrix
DA - 14110 North America — Version 5 — August 23, 2013 Page 8

All Models
Load (Percent * ) Estimated battery runtime
(minutes)
With One Extended Runtime
Module (Minutes)
With Four Extended Runtime
Modules (Minutes)
20 52 98 301
50 13 33 103
80 6 18 57
100 4 13 39
NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions.
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Estimated Backup Times Chart (Minutes)
DA - 14110 North America — Version 5 — August 23, 2013 Page 9

Unit Dimensions (HxWxD) 6.75 in (17.1 cm) x 17.2 in (43.7 cm) x 28.9 in (73.4 cm)
Unit Weight 165 lbs/75 kg
Shipping Weight 210 lbs/100 kg
BTU Break Down BTU On Line 581
BTU On Battery 1501
Battery String Voltage 216V
Battery Type 12V 45W
Battery Quantity 18
Electrical Input Voltage Range 160-253V at 200/208V nominal
Frequency 50/60 Hz
Input Plug Part number AF462A: Hubble CS6285C, 3m cord
Online Efficiency 95%
REPO Remote Emergency Power-Off disables AC power to load
Electrical Output Online Regulation -10% to +6% of nominal voltage
On battery Regulation ±5% of nominal voltage
Voltage Wave Form Sine wave
Connections See Model Selection Matrix; divided into 2 Load Segments
Output Protection Re-settable circuit protectors
Battery Type Maintenance-free, sealed, valve-regulated lead acid (VRLA)
Extended Batteries Up to four ERMs supported
Backup Time See Backup Times Chart
Recharge Time <3 hours to 80% usable capacity; <48 hours for complete recharge
Battery String Voltage 216V
Battery Type 12V 45W
Battery Quantity 18
Maximum wattage based
on voltage input
AF426A 200-240V: 7200VA/7200W
Communications Serial Ports Standard DB-9 ports (ships with communication cable)
Included HP UPS Network Module
LED Indicators LED and switch membrane integrated into the front panel; with four-button
control (three buttons for UPS power control and one button under the front
bezel for configuration).
Environmental and Safety Operating Temperature 50° to 104° F (10° to 40° C )
Transit Temperature -13° to 131° F (-25° to 55° C)
Storage Temperature 32° to 77° F (0° to 25° C )
Operating Humidity 20% to 80% (non-condensing)
Storage Humidity 5% to 95%
Operating Altitude Up to 6,562 ft (2000 m) above sea level
Transit Altitude 49,212 ft (15,000 m) above sea level
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Technical Specifications
DA - 14110 North America — Version 5 — August 23, 2013 Page 10

Audible Noise <46db (at 1m from surface of unit)
Safety Markings NA/JPN: UL, cUL
Int'l: GS, CE, GOST
Safety Certifications UL1778, UL60950-1; CSA22.2 No.107.3, No.60-1950; EN50091-1-1;
EN60950-1 IEC62040-1-1
EMC Markings NA/JPN: FCC, VCCI, ICES, CISPR
Int'l: BSMI, C-Tick, CISPR
Emissions FCC CFR 47, Part 15 Class A, EN50091-2
Immunity IEC 801-2, IEC 801-3, IEC 801-4, IEC 801-5
REPO Port Meets NEC code 645-11 intent and UL requirements
Environment-friendly
Products and Approach
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to:
http://www.hp.com/go/green . To recycle your product, please go to:
http://www.hp.com/go/green or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at: http://www.hp.com/go/green . These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
© Copyright 2013 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
QuickSpecs
R7000 Uninterruptible Power System (UPS)
Technical Specifications
DA - 14110 North America — Version 5 — August 23, 2013 Page 11
