Leading-edge professional graphics
Family data sheet
HP Workstations
graphics card
options
Quick reference guide
HP recommends Windows.
March 2014

2
A full range of graphics cards to meet your performance needs—compare features
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment Integrated Graphics†
Graphics model Intel HD Graphics 2500 Intel HD Graphics 4000 Intel HD Graphics P4000
Positioning statement Readily available entry graphics for your oce
or entertainment needs
Readily available entry graphics for your oce
or entertainment needs
Readily available entry graphics for your 3D
and oce work or entertainment needs
Processor support Intel Core i3-3xxx; Intel Core i5-3xxx Intel Core i3-3xxx; Intel Core i5-3xxx;
Intel Core i7-3xxx
Intel Xeon E3-12x5 v2
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1 • •
HP Z1 G2
HP Z220 SFF • • •
HP Z220 CMT • • •
HP Z30 SFF
HP Z230 Tower
Supported operating systems1
Graphics memory2Shared with system Shared with system Shared with system
Other notes
Outputs
Z1 1 DP 1 DP
Z1 G2
Z220 SFF 1 VGA; 1 DP 1 VGA; 1 DP 1 VGA; 1 DP
Z220 CMT 1 DVI-I; 1 DP 1 DVI-I; 1 DP 1 DVI-I; 1 DP
Z230 SFF
Z230 Tower
Orderable cables/adapters (please
check HP System specications for
which adapters apply)
DP to DVI-D
DP to DLDVI-D
DP to VGA
DVI to VGA
DP to DVI-D
DP to DLDVI-D
DP to VGA
DVI to VGA
DP to DVI-D
DP to DLDVI-D
DP to VGA
DVI to VGA
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 2048x1536
DVI 1920x1200 1920x1200 1920x1200
DP 2560 x1600 2560x1600 2560x1600
Number of active displays supported 2 2 2
Host interface Integrated with CPU Integrated with CPU Integrated with CPU
Number of PCle slots required 0 0 0
ISV certications no no limited
OpenGL Version 3.2 3.2 3.2
Vertex and pixel shaders Shader Model5.0 Shader Model5.0 Shader Model5.0
DirectX version DX 11 DX 11 DX 11
Max. power consumption Shared with system Shared with system Shared with system

3
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment Integrated Graphics†
Graphics model Intel HD Graphics 4600 Intel HD Graphics P4600
Positioning statement Newly enhanced entry graphics for your oce or
entertainment needs
Newly enhanced available entry graphics for your 3D and media
workows or entertainment needs
Processor support Intel Core i5-4xxx; Intel Core i7 4xxx Intel Xeon E3-12x5 v3
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z1 G2 • •
HP Z220 SFF
HP Z220 CMT
HP Z30 SFF • •
HP Z230 Tower • •
Supported operating systems1
Graphics memory2Shared with system Shared with system
Other notes
Outputs
Z1 G2 1 DP; 1 TB (Optional) 1 DP; 1 TB (Optional)
Z230 SFF 3 DP 3 DP
Z230 Tower 1 DVI-I; 2 DP 1 DVI-I; 2 DP
Orderable cables/adapters (please check
HP System specications for which
adapters apply)
DP to DVI-D
DP to DLDVI-D
DP to VGA
DVI to VGA
DP to DVI-D
DP to DLDVI-D
DP to VGA
DVI to VGA
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536
DVI 1920x1200 1920x1200
DP 2560x1600 2560x1600
Number of active displays supported 3 3
Host interface Integrated with CPU Integrated with CPU
Number of PCle slots required 0 0
ISV certications No Yes
OpenGL Version 4.0 4.0
Vertex and pixel shaders Shader Model5.0 Shader Model5.0
DirectX version DX 11.1 DX 11.1
Max. power consumption Shared with system Shared with system

4
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment MXM6
Graphics model NVIDIA Quadro 500M NVIDIA Quadro 1000M NVIDIA Quadro K3000M NVIDIA Quadro K4000M
Positioning statement Excellent entry level
professional 3D graphics.
High-end performance and
capabilities at an attractive
mid-range price.
Get the latest NVIDIA GPU
technology providing great
performance improvements over
its predecessor, the
Quadro 3000M.
Get the latest NVIDIA GPU technology
providing great performance
improvements over its predecessor,
the Quadro 4000M. Experience
the ultimate acceleration for your
most demanding applications and
datasets for your HP Z1.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1 • • • •
HP Z1 G2
Supported operating systems1
Graphics memory21 GB DDR3 2 GB DDR3 2 GB GDDR5 4 GB GDDR5
Memory bandwidth 12.8 GB/s 28.8 GB/s 89.6 GB/s 89.6 GB/s
Other notes HP Z1 Internal Panel can be driven
from external source via HP Z1 DP
connector
HP Z1 Internal Panel can be driven
from external source via HP Z1 DP
connector
HP Z1 Internal Panel can be driven
from external source via HP Z1 DP
connector
HP Z1 Internal Panel can be driven
from external source via HP Z1 DP
connector
Outputs
HP Z1 1 DP 1 DP 1 DP 1 DP
HP Z1 G2
Orderable cables/adapters DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 2048x1536 2048x1536
DVI 1920x1200 1920x1200 1920x1200 1920x1200
DP Internal Panel: 2560x1440
External Panel: 2560x1600
Internal Panel: 2560x1440
External Panel: 2560x1600
Internal Panel: 2560x1440
External Panel: 2560x1600
Internal Panel: 2560x1440
External Panel: 2560x1600
Number of active displays
supported per graphics card
2 2 2 2
Host interface MXM 3.0 MXM 3.0 MXM 3.0 MXM 3.0
Number of PCle slots required
ISV certications yes yes yes yes
OpenGL Version 4.2 4.3 4.3 4.3
Vertex and pixel shaders Shader Model 5.0 Shader Model 5.0 Shader Model 5.0 Shader Model 5.0
DirectX version DX 11 DX 11 DX 11 DX 11
Max. power consumption <35 Watts 42 Watts 75 Watts 100 Watts

5
Graphics segment MXM6
Graphics model NVIDIA Quadro K610M NVIDIA Quadro K2100M NVIDIA Quadro K3100M NVIDIA Quadro K4100M
Positioning statement Second generation Kepler GPU
technology for excellent entry level
3D graphics.
New Kepler GPU technology for
mid range 3D graphics workloads.
Latest Kepler GPU technology
delivering robust performance with
4GB memory for larger workloads.
Highest performing 3D graphics for
the HP Z1 G2 workstation. Easily
handles the toughest workloads for
your demanding applications.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z1 G2 • • • •
Supported operating systems1
Graphics memory21 GB GDDR5 2 GB GDDR5 4 GB GDDR5 4 GB GDDR5
Memory bandwidth 20.8 GB/s 48 GB/s 102.4 GB/s 102.4 GB/s
Other notes Z1 Internal Panel can be driven
from external source via Z1 DP
connector
Z1 Internal Panel can be driven
from external source via Z1 DP
connector
Z1 Internal Panel can be driven from
external source via Z1 DP connector
Z1 Internal Panel can be driven
from external source via Z1 DP
connector
Outputs
HP Z1
HP Z1 G2 1 DP 2 TB (Optional) 1 DP 2 TB (Optional) 1 DP 2 TB (Optional) 1 DP 2 TB (Optional)
Orderable cables/adapters DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 2048x1536 2048x1536
DVI 1920x1200 1920x1200 1920x1200 1920x1200
DP Internal Panel: 2560x1440
External Panel: 3840x2160
Internal Panel: 2560x1440
External Panel: 3840x2160
Internal Panel: 2560x1440
External Panel: 3840x2160
Internal Panel: 2560x1440
External Panel: 3840x2160
Number of active displays
supported per graphics card
4 (with TB Option) 4 (with TB Option) 4 (with TB Option) 4 (with TB Option)
Host interface MXM 3.0 MXM 3.0 MXM 3.0 MXM 3.0
Number of PCle slots required
ISV certications yes yes yes yes
OpenGL Version 4.3 4.3 4.3 4.3
Vertex and pixel shaders Shader Model 5.0 Shader Model 5.0 Shader Model 5.0 Shader Model 5.0
DirectX version DX 11.1 DX 11.1 DX 11.1 DX 11.1
Max. power consumption <35 Watts 50 Watts 75 Watts 100 Watts
Family datasheet | HP Workstations HP recommends Windows.

6
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment Professional 2D
Graphics model NVIDIA Quadro NVS 310 NVIDIA Quadro NVS 315 NVIDIA NVS 300 NVIDIA NVS 510
Positioning statement The new business standard for
multi-display desktop graphics.
Improved business graphics
solution for your legacy
muliti-display desktop. Super-
sedes the NVIDIA NVS 300.
Business graphics solution to drive
all your legacy displays.
Excellent four display capable graph-
ics in a low prole design. Replaces
the NVS Quadro 450. For the most
demanding business applications and
ideal for creating display walls.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z220 SFF •• •• •
HP Z220 CMT •• •• •
HP Z230 SFF •• •• •
HP Z230 Tower •• •• •
HP Z420 ••• ••• ••• ••
HP Z620 •••• •••• ••
HP Z820 •• + 1 AMO •• + 2 AMO •• + 2 AMO •• (AMO only)
Supported operating systems1
Graphics memory2512 MB DDR3 1 GB DDR3 512 MB DDR3 2 GB DDR3
Memory bandwidth 14 GB/s 14 GB/s 12.6 GB/s 28.5 GB/s
Other notes Low Prole, Active Cooling,
Mosaic and nView
Low Prole, Active Cooling,
Mosaic and nView
Low Prole, Active Cooling,
Mosaic and nView
Low Prole, Active Cooling,
Mosaic and nView
Outputs 2 DP 1 DMS-59 1 DMS-59 4 mini-DP
Orderable cables/adapters DP to DVI-D3
DP to DLDVI-D
DP to VGA
DP to HDMI
DMS-59 to dual DVI4
DMS-59 to dual VGA
DMS-59 to dual DP
DMS-59 to dual DVI4
DMS-59 to dual VGA
DMS-59 to dual DP
4 mini-DP to DP4
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 1920x1080 2048x1536
DVI 1920x1200 1920x1200 1920x1200 1920x1200
DP 2560x1600 2560x1600 2560x1600 3840x2160
Number of active displays
supported per graphics card
2 2 2 4
Host interface PCI Express Gen2x16 PCI Express Gen2x16 PCI Express Gen2x16 PCI Express Gen2x16
Number of PCle slots required 1 1 1 1
ISV certications No No No No
OpenGL Version 4.1 4.1 3.3 4.3
Vertex and pixel shaders Shader Model 5.0 Shader Model 5.0 Shader Model 4.1 Shader Model 5.0
DirectX version DX 11 DX 11 DX 10.1 DX 11
Max. power consumption 19.5 Watts 20 Watts 17.5 Watts 35 Watts

7
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment Entry 3D Midrange 3D
Graphics model NVIDIA Quadro 410 AMD FirePro™ V3900 NVIDIA Quadro K600 NVIDIA Quadro K2000
Positioning statement Powerful entry level 3D
graphics at a great price.
Blazing entry level professional 3D
graphics at an unbelievable price.
Step up to the new Kepler GPU
architecture and experience better
performance with entry level
professional workows.
Step up to the new Kepler GPU
architecture and experience
segment leading performance/
watt in medium sized professional
workows.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z220 SFF • • •
HP Z220 CMT • • • •
HP Z230 SFF • • •
HP Z230 Tower •• •• • •
HP Z420 •• •• •• ••
HP Z620 •• •• •• ••
HP Z820 •• •• •• •••
Supported operating systems1
Graphics memory2512 MB DDR3 1 GB DDR3 1 GB DDR3 2 GB GDDR5
Memory bandwidth 14 GB/s 28.8 GB/s 29 GB/s 64 GB/s
Other notes Low Prole, Active Cooling,
Mosaic and nView
Low Prole, Active Cooling Low Prole, Active Cooling,
DisplayPort HBR2 and MST,
Mosaic and nView
DisplayPort HBR2 and MST,
Mosaic and nView
Outputs 1 DL DVI-I
1 DP
1 DL DVI-I
1 DP
1 DL DVI-I
1 DP
1 DL DVI-I
2 DP
Orderable cables/adapters DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 2048x1536 2048x1536
DVI 1920x1200 1920x1200 1920x1200 1920x1200
DP 2560x1600 2560x1600 3840x2160 3840x2160
Number of active displays
supported per graphics card
2 2 2 3 Direct, 4 using DP MST
Host interface PCI Express Gen2 x16 PCI Express Gen2 x16 PCI Express Gen2 x16 PCI Express Gen2 x16
Number of PCle slots required 1 1 1 1
ISV certications Yes Yes Yes Yes
OpenGL Version 4.3 4.2 4.3 4.3
Vertex and pixel shaders Shader Model 5.0 Shader Model 5.0 Shader Model 5.0 Shader Model 5.0
DirectX version DX 11 DX 11 DX 11 DX 11
Max. power consumption <35 Watts <50 Watts 41 Watts 51.1 Watts

8
Family datasheet | HP Workstations HP recommends Windows.
Graphics segment High 3D
Graphics model NVIDIA Quadro K4000* AMD FirePro™ W7000* NVIDIA Quadro K5000*
Positioning statement New Kepler GPU architecture unleashes new
heights in performance compared to previ-
ous graphics solutions delivering outstand-
ing performance in medium to large design
workows.
New GCN GPU architecture provides superb
graphics performance for medium to large
design workloads and oers seamless GPU
computing capabilities previously unseen in
this class of card.
Step up to the latest NVIDIA Kepler GPU
technology to uidly handle demanding
product design and digital creation workloads.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z220 SFF
HP 220 CMT • (AMO only) • (AMO only)
HP Z230 SFF
HP Z230 Tower • • (AMO only)
HP Z420 • • •
HP Z620 •• •• ••
HP Z820 •• •• ••
Supported operating systems1
Graphics memory23 GB GDDR5 4 GB GDDR5 4 GB GDDR5
Memory bandwidth 134 GB/s 153.6 GB/s 173 GB/s
Other notes DisplayPort HBR2 and MST, Mosaic
and nView, 3rd party Stereo connector
AMD Eyenity Technology,
DisplayPort HBR2 and MST
NVIDIA SLI Connector, Stereo Adaptor
available, ECC memory support, DisplayPort
MST and HBR2, Mosaic and nView
Outputs 1 DL DVI-I
2 DP
4 DP 2 DP
1 Dual-Link DVI-I
1 Dual-Link DVI-D
1 Stereo (optional)
Orderable cables/adapters DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D
DP to DLDVI-D
DP to VGA
DP to HDMI
DP to DVI-D5
DP to DLDVI-D
DP to VGA
DP to HDMI
Max display resolution (may require appropriate adapters)
VGA 2048x1536 2048x1536 2048x1536
DVI 1920x1200 1920x1200 1920x1200
DP 3840x2160 4096x2160 3840x2160
Number of active displays
supported per graphics card
3 Direct, 4 using DP MST 4 Direct, 6 using DP MST 4
Host interface PCI Express Gen2 x16 PCI Express Gen3 x16 PCI Express Gen2 x16
Number of PCle slots required 1 1 2
ISV certications yes yes yes
OpenGL Version 4.3 4.2 OGL 4.3
Vertex and pixel shaders Shader Model 5.0 Shader Model 5.0 Shader Model 5.0
DirectX version DX 11 DX 11.1 DX11
Max. power consumption 80 Watts <150 Watts 122 Watts

Family datasheet | HP Workstations HP recommends Windows.
Graphics segment Ultra 3D Maximus
Graphics model NVIDIA Quadro K6000* NVIDIA Tesla K20c*
Positioning statement The most powerful Professional graphics in the Z workstation
lineup. Superb performance with 12 GB of ultra-fast GDDR5
graphics memory and advanced GPU capabilities to speed through
huge visualization and analysis workloads.
New Tesla K20c oers signicant performance enhancements
over the previous generation Tesla C2075 to blaze through
GPU computing workloads.
Supported HP Workstations (• single; •• dual; ••• triple; •••• quad)
HP Z1
HP Z220 SFF
HP Z220 CMT
HP Z230 SFF
HP Z230 Tower
HP Z420 • (AMO only) •
HP Z620 • •
HP Z820 •• ••
Supported operating systems1
Graphics memory212 GB GDDR5 5 GB GDDR5
Memory bandwidth 288 GB/s 208 GB/s
Other notes Quadro Boost, SLI Connector, DisplayPort MST and HBR2, 3D Stereo
adapter avaialble, ECC memory support, Mosaic and nView
Must be congured with supported Quadro Kepler series
graphics card. Requires CUDA, or OpenACC enabled
applications. OpenCL enabled.
Outputs 2 DP; 1 Dual-Link DVI-I; 1 Dual-Link DVI-D; 1 Stereo (optional) 0
Orderable cables/adapters DP to DVI-D5; DP to DLDVI-D; DP to VGA; DP to HDMI 0
Max display resolution (may require appropriate adapters)
VGA 2048x1536 N/A
DVI 1920x1200 N/A
DP 3840 x 2160 N/A
Number of active displays supported per
graphics card
2N/A
Host interface PCI Express Gen3 x16 PCI Express Gen2 x16
Number of PCle slots required 2 2
ISV certications Yes yes
OpenGL Version OGL 4.3 N/A
Vertex and pixel shaders Shader Model 5.0 N/A
DirectX version DX 11 N/A
Max. power consumption 234 Watts <225 Watts

Congure and buy HP personal workstations online at hp.com/zworkstations.
© 2009–2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products
and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional
warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Intel is a trademark of Intel Corporation in the U.S. and other countries. AMD and Eyenity are trademarks of Advanced Micro Services, Inc. All other trademarks are the
property of their respective owners.
4AA4-6106ENW, March 2014
* Supported only in the Z420 600W power supply chassis.
† Available on select processor configurations. Please see product QuickSpecs for details.
1. All graphics oerings are supported on Microsoft Windows 8, Microsoft Windows 7, SUSE Linux Enterprise Desktop, Red Hat Enterprise Linux®, HP Linux Installation Kit with any exceptions
called out in t he “Other notes” row of the above charts.
2. Shared graphics memory uses part of the total system memory for video performance. System memory dedicated to video performance is not available for other use by other programs.
3. Two DP to DVI-D adapters included in AMO kit oering.
4. Adapter(s) included in CTO and AMO kit oerings.
5. Adapter included in AMO kit oering.
6. Mobile PCIe Module
Screen image courtesy of ANSYS.
