28 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
An Overview of the VISUALIZE fx Graphics
Accelerator Hardware
Three graphics accelerator products with different levels of performance are
based on varying combinations of five custom integrated circuits. In addition,
these products are the first ones from Hewlett-Packard to provide native
acceleration for the OpenGLAPI.
The VISUALIZE fx family of graphics subsystems consists of three
products, fx6, fx4, and fx2, and an optional hardware texture mapping module.
These products are built around a common architecture using the same
custom integrated circuits. The primary difference between these controllers
is the number of custom chips used in each product (see Table I).
Table I
Number of custom chips in the different
VISUALIZE fx products
Product Texture Chip Geometry Chip Raster Chip
fx2— 1 2
fx41 2 2
fx62 3 4
A chip-level block diagram of the VISUALIZE fx6product is shown in Figure 1.
This is the most complex configuration and also the one with the highest
performance in the product line. The VISUALIZE fx4and the VISUALIZE fx2
products use subsets of the chips used in the fx6. The fx6and fx4subsystems
have support for the optional hardware-accelerated texture map module,
which contains a local texture cache for storage of texture map images. If the
texture accelerator is not present, the bus between the interface chip and the
first raster chip is directly connected.
Noel D. Scott
Daniel M. Olsen
Ethan W. Gannett

29 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
Figure 1
A chip-level diagram of the VISUALIZE fx
6
product.
200 MHz/
41 Bits
200 MHz/
33 Bits
Up to 8
Geometry
Chip
Geometry
Chip
Geometry
Chip
Interface
Chip
PCI2.1
66 MHz/
64 Bits
Geometry Accelerator
Raster
Chip
Host
SGRAM SGRAM SGRAM SGRAM
Rasterizer
Frame Buffer RAM
Texture
Chip Texture Chip
SDRAM SDRAM
Texture Accelerator
Texture Cache RAM
Filtered Texture Data
200 MHz/41 Bits
Video
Chip
Video Control Bus
RGB
Video
Data
Video Refresh Data
Interface Chip
•I/O Buffering
•3D Geometry Workload Distribution
and Concentration
•2D and 3D Data Path Arbitration
•2D Acceleration
•YUV to RGB Conversion Support
•Pixel Level Pan and Zoom
•Pixel Level Image Rotations
Geometry Chip
•3D Geometry and Lighting Acceleration
Texture Chip
•Texture Rasterization
•Texture Map Cache Controller
•Texture Memory Control
•Texture Interpolation
Raster Chip
•Fragment Processing
•Frame Buffer Control Functions
Video Chip
•Color Lookup Tables
•Video Timing
•Digital-to-Analog Conversion
•Video-Out Data
Raster
Chip Raster Chip Raster Chip
Interface Chip
The interface chip provides a PCI 2.1 (also referred to as
PCI 2X) compliant interface.*It operates at up to 66 MHz
in 64-bit mode. Special efforts have been made in the
* PCI +Peripheral Component Interconnect.
design of the buffering and the interface to the PCI. As a
result, the driver is able to sustain writes of 3D geometry
commands to the PCI at almost the theoretical maximum
rates that could be computed for the PCI. The article on
page 51 discusses PCI capability.

30 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
Occlusion Culling
The HPfast-breakprogram (page 8) enabled us to understand
customer requirements by analyzing what is important in
OpenGL graphics today. As a result, we developed a technol-
ogy called
occlusionculling as an extension to OpenGL and
implementeditintheVISUALIZEfxgraphicshardware.
We found that the data sets many graphics workstation cus-
tomers are trying to visualize are very complex. These data
sets have large numbers of small, complex components that
are not always visible in the final images. For instance, when
rendering an airplane, all of the MCAD parts are present in the
data set represented by potentially millions of polygons that
must be processed. However, when this airplane is viewed
from the outside only the outer surfaces are visible, not the fan
blades of the engine or the seats or bulkheads in the interior.
In a traditional 3D z-buffered graphics system, all polygons in
ascenemust be processed by the graphics pipeline because it
is not known a priori which polygons will be visible and which
oneswillbeoccluded (not visible). The notion of occlusion
culling,orremovalofoccludedobjects,hasbeentalkedabout
intheresearchcommunityforseveralyears.However,imple-
mentations tend to be in software where the performance is
notat a satisfactory level.
Inthe VISUALIZE fx series of graphics devices, HP developed
a very efficient algorithm that tests objects for visibility.
An application program can very quickly use the occlusion
culling visibility test to determine if a simple bounding box
representation of a more complex part is visible. Since a
bounding box, or more generally a bounding volume, com-
pletely encloses the more complex part, it is possible to know
a priori that if the bounding volume is not visible then the
complex part it encloses is not visible. Thus, the part that is
not visible does not need to be processed through the graphics
pipeline.Thereal benefit of occlusion culling comes when a
verycomplexpartconsistingofmanyverticescanberejected,
avoiding the expenditure of valuable time to process it.
For very complex data sets, such as the airplane mentioned
aboveoranautomobile,atremendousperformanceincrease
canberealized by using the HP occlusion culling technology.
Todate,severalISVshavebegunusingocclusioncullingin
their applications and are seeing a 25 to 100 percent increase
ingraphicsperformance.Thismagnitudeofperformancebene-
fit typically costs a customer several thousand dollars for the
extracomputationalhorsepower.HPincludes this technology
asstandardinall VISUALIZE fx series graphics accelerators,
giving even better price and performance results to our
customers.
The future of 3D graphics will continue toward visualizing ever
more complex objects and environments. Occlusion culling
together with HP’sDirectModel technology (page 19) are
well positioned to be industry leaders in providing the technol-
ogyfor3D modeling applications.
The primary responsibility of the interface chip is to sepa-
rate the streams of data that arrive from the host SPU into
three paths and arbitrate access among those paths.
3D Path. Typically data from the host CPU looks very
much like the OpenGL API functions themselves. Data
following this first path is routed to the geometry chips.
The geometry chips process the data and return the re-
sults to the interface chip. These results are then sent on
to the texture chips or directly to the raster chips if the
texture mapping subsystem is not installed. In either case
the data is transmitted to and through all the texture and
raster chips in the system.
Unbuffered Path. This path passes data directly through
the interface chip to the texture and raster chips. This
provides a bypass method that allows traffic to get around
other pending operations. An example would be a texture
cache download that is required to complete a primitive
that is currently being rasterized, a situation that would
lead to deadlock without the unbuffered path.
2D Path. This path runs directly through the interface chip
to the texture and raster chips. The 2D path differs from
the unbuffered path in the way its priority is handled. The
interface chip manages priority among the three paths as
they all converge on the same set of wires between the
interface chip and the first texture chip. The unbuffered
path goes directly through the interface chip to those
wires and has priority over the other two paths. Data
targeting the 2D path is held off until all preceding 3D
work in the geometry chip has been flushed through to
the first texture chip.

31 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
There is also special circuitry in the interface chip that is
used to accelerate many operations commonly done by
X11 or other 2D APIs.
Buses
The three primary buses in the system are each run at
200 MHz, allowing sustainable transfer rates of more
than 800 Mbytes per second. To control the loading on
the interconnections for these buses, they are built as
point-to-point connections from one chip to the next.
Each chip receives the signals and then retransmits them
to the next chip in the sequence. This requires more pins
on each part, but limits the number of loads on each wire
to a single receiver as well as limiting the wiring length
that signals must traverse. This allows for reliable com-
munications despite the high frequency of the buses.
The first of these three buses distributes work to the
geometry chips. This bus starts at the interface chip
and runs through all the geometry chips in the system.
Each geometry chip monitors the data stream as it flows
through the bus and picks off work to operate upon based
on an algorithm that selects the least busy geometry chip.
The second of these buses starts at the last geometry chip
and passes through the others back to the interface chip.
The results of the work done by the geometry chips is
placed on this bus in the same sequence as it was moved
along the first bus. This strict ordering control prevents
certain artifacts from showing up in the final image.
The third bus ties the interface chip to the texture and
frame buffer subsystems. It is wired in a loop that goes
back to the interface chip from the last chip in the chain.
3D operations typically flow from the interface chip to
the chips along this bus, and when they eventually get
back to the end of the loop, they are thrown away.
For 2D operations, such as moving blocks of pixels
around the frame buffer, the operation of the third bus is
somewhat different. The movement of pixel data operates
as a sequence of reads followed by a sequence of writes.
The reads cause data to be dumped from the frame buffer
locations onto the bus and the results travel back to the
interface chip. This data is then associated with new
addresses and sent as writes back down the bus, ending
up back at the frame buffer but in different locations.
Besides the three primary buses mentioned above,
there are three secondary buses in the system. The first
bus connects the interface chip to the video chip. This
provides video control, download of color maps, and
cursor control. The second bus is a connection from each
raster chip to the video chip. This path is used to provide
video refresh data to display frame buffer contents. The
final secondary bus is a connection from each texture
chip to two of the raster chips. This path allows the flow
of filtered texture data into the raster chips for combina-
tion with nontexture fragment data.
Geometry Chip
The geometry and lighting chips are responsible for taking
in geometric primitives (points, lines, triangles, and quad-
rilaterals) and executing all the operations associated
with the transform stage of the graphics pipeline (see the
article on page 9 for more about the graphics pipeline).
These operations include:
HTransformation of the coordinates from model space to
eye space
HComputing a vertex color based on the lighting state,
which consists of up to eight directional or positional
light sources
HTexture map calculations that include:
VEnvironment map calculations for texture mapping
VTexture coordinate transformation
VLinear texture coordinate generation
VTexture projection
HView volume clipping and clipping against six arbitrary
application-specified planes to determine whether a
primitive is completely visible, rejected because it is
completely outside the view area, or needs to be
reduced into its visible components
HPerspective projection transformation to cause
primitives to look smaller the further away from
the eye they are
HSetup calculations for rasterization in the raster chip.
There were some interesting problems to solve in the
design of the distribution and coalescing of work up and
down the geometry chip daisy chain. For example, load
balancing, maintaining strict order in the output stream,
and ensuring that operations, such as binding of colors
and normals to vertices, perform as required by OpenGL.

32 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
Fast Virtual Texturing
Texture mapping, which is wrapping a picture over a three
dimensional object, has been used over the years as a key
feature to enhance photorealism, reduce data set sizes, per-
form visual analysis, and aid in simulations (see Figure 1).
Since texturing calculations are computationally expensive
and memory access for large textures can be prohibitively
slow, variousworkstationgraphics vendors have provided
hardware-acceleratedtexture mapping as a key differentiator
fortheir product.
Aprimarydrawbackoftheseattemptsathardware accelera-
tionisthat dedicated local hardware texture memory is limited
Figure 1
A 3D textured skull. The VISUALIZE fx
4
and fx
6
subsystems
support a texture map acceleration option. Pictured here
is the use of 3D texture mapping OpenGL extensions with
this option. This feature allows visualization of 3D data
sets such as MRI images.
in size and is expensive. To take advantage of the perfor-
manceboost, graphics applications were constrained to tex-
tures that fit in the local hardware texture memory. In other
words, the application was responsible for managing this
hardwareresource.
Noticing this obvious artificial application limitation in texturing
functionality,performance, and portability,Hewlett-Packard
introduced,inthe VISUALIZE-48, a new concept in hardware
texturemappingcalled
virtualtexturemapping . Virtualtexture
mappinguses the dedicated local hardware texture memory
as a true texture cache, swapping in and out of the cache the
portions of textures that are needed for rendering a 3D image.
Thus, fortexturing applications, these limitations were elimi-
nated. The application could define and use a texture mapof
any size (up to a theoretical limit of 32K texels ×32K texels*)
thatwouldbehardware accelerated, eliminating the need for
the application to be responsible for managing local texture
memory.
Using the local hardware texture memory as a cache also
means that this memory uses only the portions of the texture
maps needed to render the image. This efficiency translates
to more and larger texture maps being hardware accelerated
at the same time. Applications that previously could not run
because of texture size limits can now run because of the
unlimited virtual texture size. Also, with only the used por-
tions of the texture map being downloaded to the cache, far
lessgraphics bus traffic occurs.
Thesystem design of virtual texture mapping involved changes
intheHP-UXoperating system to support graphics interrupts,
onboardfirmwaresupport for these interrupts, the introduction
of an asynchronous texture interrupt managing daemon pro-
cess,and the associated texturing hardware described in this
*A texel is one element of a texture.
The output of the geometry chip’s daisy chain is passed
back through the interface chip. Generally, for triangle
based primitives, the output takes the form of plane equa-
tions. As these floating-point plane equations are returned
from the geometry chip to the interface chip and passed
on to the texture chips, certain addressed locations in the
interface chip will result in the floating-point values being
converted to fixed-point values as they pass through.
These fixed-point values are in a form the raster chips
need to rasterize the primitive.
The daisy-chain design allows up to eight of the geometry
chips to be used although only three are applied in the
case of the VISUALIZE fx6product at this time.

33 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
Figure 2
A shadow texture image.
Figure 3
A specular lit texture image. Correct specular lighting of
textured images can be achieved with VISUALIZE fx
4
and
fx
6
texture mapping options.
article. Having a centralized daemon process manage the
cacheallows for cache efficiency,parallel handling of texture
downloadswhile3D graphics rendering is occurring, and shar-
ingtextures among graphics contexts.
The VISUALIZE fx4and VISUALIZE fx6texture mapping
optionsincorporate the second generation advances in virtual
texturemapping.FullOpenGL1.1texturemaphardwaresup-
port has brought about dramatic improvements in texture
mapdownload performance and switching between texture
mapsandnewextendedfeaturessuch as 3D texture mapping,
shadows(Figure 2), and proper specular lighting on textures
(Figure 3).Thesefeatureshave made these products very
appealingsystems for texturing applications onworkstation
graphics.
The texture mapping performance on these systems is very
competitive. The VISUALIZE fx6texture fill rate is about twice
that of the VISUALIZE fx4texture option. However, fill rates
alone do not describe how these systems perform in a true
applicationenvironment. Aggressive texturemapping applica-
tion performance comparisons show two to three times per-
formance superiorityoversimilarly priced graphics workstation
products.
Texture Chip
The texture chip is responsible for accelerating texture
mapping operations. Towards this end, it performs three
basic functions:
HMaintains a cache of texture map data, requesting cache
updates for texture values required by current rendering
operations as needed (see “Fast Virtual Texturing” on
page 32)
HGenerates perspective corrected texture coordinates
from plane equations representing triangles, points, or
lines
HFetches and filters the texture data as specified by the
application based on whether the texture needs to be
magnified or minimized to fit the geometry it is being
mapped to and passes the result on to the raster chips.

34 May 1998 •The Hewlett-Packard JournalArticle 4 •1998 Hewlett Packard Company
Raster Chip
The raster chip rasterizes the geometry into the frame
buffer. This means it determines which pixels are to be
potentially modified and, if so, whether they should be
modified based on various current state values (including
the contents of the z buffer). The raster chip also controls
access to the various buffers that make up the frame
buffer. This includes the image buffer for storing the image
displayed on the screen (potentially two buffers if double
buffering is in effect), an overlay buffer that contains im-
ages that overlay the image buffer, the depth or z buffer
for hidden surface removal, the stencil buffer,*and an
alpha buffer** on the VISUALIZE fx6. To accomplish its
work the raster chip performs four basic functions:
HRasterize primitives described as points, lines, or
triangles
HApply fragment operations as defined by OpenGL (such
as blending and raster operations)
HControl of and access to buffer memory, including all
the buffers described earlier
HRefresh the data stream for the video chip, including
handling windows and overlays.
Video Chip
The video chip provides video functions for controlling
the data flow from the frame buffer to the display and
* A stencil buffer is per pixel data that can be updated when pixel data is written and used
to restrict the modification of the pixel.
** An alpha buffer contains per pixel data that describes coverage information about the
pixel and can be used when blending new pixel values with the current pixel value.
mapping data from values to color. The features of the
video chip include:
HData mapping to colors:
VTwo independent 4096-by-24-bit lookup tables
VFour independent 256-by-3-by-8-bit lookup tables
for image planes
VA bypass path for 24-bit true color data
VTwo independent 256-by-8-bit lookup tables for
overlay planes
HDigital-to-analog conversion
HVideo timing
HVideo output.
Conclusion
The VISUALIZE fx family of products currently has a sub-
stantial lead in not only price/performance measurements,
but it also leads in performance independent of cost.
For information regarding how these systems compare
against the competition, visit the SPEC (an industry stan-
dard body of benchmarks) web page at:
http://www.spec.org/gpc
Acknowledgments
We would like to thank Paul Martz for the shadow texture
image (Figure 2 on page 33).
Noel D. Scott
Noel Scott is a senior
engineer at the HP Work-
station Systems Division.
He is responsible for product definition,
performance projections, and modeling. He
designed the I/O bus for the geometry chip
described in the article. He came to HP in
1981 after receiving a BS degree in computer
engineering from the University of Kansas.
Daniel M. Olsen
A software engineer in
the graphics products
laboratory at the HP
Workstation Systems Division, Daniel Olsen
is responsible for the development of new 3D
products for HP workstations. He has been
with HP since 1994. He has a BSEE degree
(1991) from North Dakota State University
and an MS degree in computer engineering
(1997) from Iowa State University. Daniel
was born in Des Moines, Iowa, is married and
has two daughters. His leisure time activities
include skiing, home projects, scuba diving,
and aviation.
Ethan W. Gannett
Ethan Gannett is a lead
engineer for graphics
software development
at the HP Workstation Systems Division. He
came to HP in 1988 after receiving an MS
degree in computer science from Iowa State
University. He also holds a BS degree in
physics (1983) and a BS degree in astronomy
(1983) from the University of Iowa. Born in
Davenport, Iowa, he is married and has one
daughter. He enjoys kayaking, backcountry
camping, telemarking, and hiking.
"Go to Next Article "Go to Journal Home Page
