HPA-Faip B 235 Evo User manual

Italiano Manuale d’uso
English Operator’s manual
Français Utilisation et entretien
Deutsch Betriebs und Wartungsanleitung
Español Uso y mantenimiento
Cod. 4-119454 del 09/2015
EQUILIBRATRICE
WHEEL BALANCER
ÉQUILIBREUSE
AUSWUCHTMASCHINE
EQUILIBRADORA
B 235 Evo

Operator's Manual B 235 Evo 73
CONTENTS
INTRODUCTION.............................................................................................. 75
TRANSPORT, STORAGE AND HANDLING................................................... 76
INSTALLATION................................................................................................ 79
ELECTRICAL HOOK-UP.................................................................................. 84
COMPRESSED AIR HOOK-UP ...................................................................... 85
SAFETY REGULATIONS.................................................................................. 85
MAIN FEATURES............................................................................................. 87
TECHNICAL DATA........................................................................................... 88
STANDARD ACCESSORIES............................................................................ 89
OPTIONAL ACCESSORIES ............................................................................. 90
GENERAL CONDITIONS OF USE.................................................................. 90
DISPLAY PANEL .............................................................................................. 91
DISPLAY PANEL - STATUS ICON................................................................... 91
DISPLAY PANEL - CONTROL KEYPAD ......................................................... 92
1. SWITCHING ON THE MACHINE ......................................................... 93
1.1. USING THE AUTOMATIC WHEEL CLAMPING C............................... 94
2. BALANCING PROGRAMME SELECTION ........................................... 96
3. ENTERING WHEEL DIMENSIONS (EXCEPT FOR ALU 1P
AND ALU 2P PROGRAMMES) ............................................................. 97
4. ENTERING WHEEL DIMENSIONS IN THE ALU 1P AND
ALU 2P BALANCING PROGRAMMES ............................................... 103
5. ENTERING DIMENSIONS IN THE MOTORCYCLE
PROGRAMMES.................................................................................... 105
6. WHEEL SPIN ....................................................................................... 105
7. UNBALANCE DISPLAY WITHOUT ROUNDING-OFF....................... 106
8. BALANCING WEIGHT APPLICATION................................................ 106
9. APPLYING BALANCING WEIGHTS IN ALU 1P OR
ALU 2P PROGRAMMES...................................................................... 108
10. PROGRAMME FOR POSITIONING THE WEIGHTS
BEHIND THE SPOKES “HIDDEN WEIGHT” (ONLY WITH
ALU 1P AND ALU 2P PROGRAMMES).............................................. 110
11. PROGRAM FOR SPLITTING THE WEIGHT ON EITHER
SIDE OF THE SPOKE “SPLIT WEIGHT” (ONLY WITH
MOTORCYCLE PROGRAMMES)........................................................ 112
12. OPTIMISATION PROGRAMME “OPT”............................................... 113
13. ENABLING THE OTHER OPERATOR................................................ 115
ORIGINAL INSTRUCTIONS
COMIM - Code 4-119454 of 09/2015.

74 Operator's Manual B 235 Evo
14. WHEEL SPIN COUNTER .................................................................... 116
15. GENERAL CONFIGURATIONS - SET UP .......................................... 117
15.1. SET UP - SELECTING THE TYPE OF VEHICLE
(CAR/MOTORCYCLE).......................................................................... 117
15.2. SET UP - UNBALANCE MEASUREMENT UNIT ............................... 119
15.3. SET UP - UNBALANCE ROUNDING-OFF......................................... 119
15.4. AUTOMATIC POSITION SEARCH ..................................................... 120
15.5. SET UP - WARNING OPT.................................................................... 121
15.6. SET UP - RIM DIAMETER VISUALISATION
MEASUREMENT UNIT ....................................................................... 122
15.7. SET UP - RIM WIDTH VISUALISATION
MEASUREMENT UNIT ....................................................................... 122
15.8. SET UP - BEEPER................................................................................ 123
15.9. SET UP - ADHESIVE WEIGHT APPLICATION POSITION................ 124
15.10. SET UP - LED LIGHT ......................................................................... 125
15.11. SET UP - LASER INDICATOR ........................................................... 125
16. UNBALANCE CALIBRATION WITH CALIBRATION WEIGHT.......... 126
17. CALIBRATION OF THE ULTRASONIC WIDTH SENSOR
(IF INSTALLED) .................................................................................. 127
18. MESSAGES ON THE DISPLAYS ........................................................ 129
19. OTHER MESSAGES ............................................................................ 131
CHECK FOR CORRECT FUNCTIONING OF BALANCING
ACCESSORIES ............................................................................................... 133
TROUBLESHOOTING ................................................................................... 133
MAINTENANCE............................................................................................. 135
INFORMATION REGARDING MACHINE DEMOLITION ........................... 135
ENVIRONMENTAL INFORMATION............................................................. 136
FIRE-EXTINGUISHING MATERIALS TO BE USED .................................... 137
GLOSSARY ..................................................................................................... 137
ELECTRICAL SYSTEM GENERAL DIAGRAM ............................................. 139
PNEUMATIC DIAGRAM ................................................................................ 141

Operator's Manual B 235 Evo 75
INTRODUCTION
The purpose of this manual is to provide the owner and operator with effective and safe
instructions for the use and maintenance of the wheel balancer.
Follow all of the instructions carefully and your machine will assist you in your work and
give long-lasting and efficient service, in keeping with manufacturer traditions.
The following paragraphs define the levels of danger regarding the machine, associated
with the warning captions found in this manual.
DANGER
Refers to immediate danger with the risk of serious injury or death.
CAUTION
Dangers or unsafe procedures that can cause serious injury or death.
WARNING
Dangers or unsafe procedures that can cause minor injuries or damage to property.
Read these instructions carefully before starting the machine. Keep this manual and all
illustrative material supplied with the machine in a folder near it where it is readily ac-
cessible for consultation by the operators.
The technical documentation supplied is considered an integral part of the machine; in
the event of sale all relative documentation must remain with the machine.
The manual is only to be considered valid for the machine model and serial number
indicated on the data plate.
CAUTION
Adhere to the contents of this manual: the producer declines all liability in the case
of actions not specifically described and authorised in this manual.
NOTE
Someof theillustrationscontainedinthismanualwere derivedfrom photosofprototypes:
the standard production machines may differ in some details.
These instructions are for the attention of personnel with basic mechanical skills. We have
therefore condensed the descriptions of each operation by omitting detailed instructions
regarding, for example, how to loosen or tighten the fixing devices on the machine. Do not
attempt to perform operations unless properly qualified and with suitable experience.
If in need of assistance, call an authorised assistance centre.

76 Operator's Manual B 235 Evo
TRANSPORT, STORAGE AND HANDLING
Handling prior to installation
The basic wheel balancer packaging consists of 1 wooden crate containing:
- the wheel balancer (Fig.8)
- equipment;
- the wheel guard and corresponding mounting tube (C, Fig.4a - D, Fig. 4a).
Before installation, the wheel balancer must be shipped in its original packaging, making
sure that the machine is maintained in the position indicated on the outer packaging.
The machine can be moved by placing the packaging on a wheeled trolley or inserting
the forks of a fork lift truck in the relative slots in the pallet (Fig. 1).
1
- Packaging dimensions:
Length Depth Height Weight Packaging weight
(mm) (mm) (mm) (kg) (kg)
1410 890 1260 193 (vers. NO C) 80
197 (vers. C)
- The machine must be stored in an environment meeting the following requirements:
• relativehumidityrangingfrom20%to95%;
• temperaturerangingfrom-10°to+60°C.

Operator's Manual B 235 Evo 77
WARNING
Do not stack more than two packs to avoid damaging them.
Handling for installation
The machine may be handled and manoeuvred for installation as follows:
•Removethethreebracketsanchoringthemachinetothepallet
•Liftthemachinewithahoistinghookfortheweightofthemachine,appliedtothe
specific eye-bolt fixed to the machine for lifting as illustrated in figure 2
•Movethemachineintothedesiredpositionandsetdownontheoor
•Detachthehoistinghookfromthemachine
•Removetheeye-bolt,thentthespecicplugsuppliedinthehole.
2
CAUTION
When moving the machine, do not use:
- the wheel shaft
- the weight tray
- the display head
as a gripping point.

78 Operator's Manual B 235 Evo
Handling and manoeuvring after installation
The machine may be handled and manoeuvred after installation as follows:
•Disconnectthepowercablefromthesocket
•Removethepluginoneofthetraysoftheweightholdercover
•Screwtheeye-boltsuppliedcompletelyontothethreadedpininthehole
•Liftthemachinewithahoistinghooksuitablefortheweightofthemachine,appliedto
the specific eye-bolt fixed to the machine for lifting as illustrated in figure 2a
•Movethemachineasrequiredandsetdownontheoor
•Detachthehoistinghookfromthemachine
•Removetheeye-bolt,thenrettheplugremovedpreviouslyfromtheweighttraycover
2a
CAUTION
When moving the machine, do not use:
- the wheel shaft
- the weight tray
- the display head
as a gripping point.

Operator's Manual B 235 Evo 79
INSTALLATION
CAUTION
Take the utmost care when unpacking, assembling, lifting and setting up the machine
as indicated below.
Failure to observe these instructions can damage the machine and compromise the
operator's safety.
Remove the original packaging materials after positioning them as indicated on the
packaging and keep them intact so the machine can be safely shipped at a later date
if necessary.
CAUTION
Choose the place of installation in compliance with local regulations on occupational
safety.
In particular, the machine must only be installed and used in protected environments
where there is no risk of anything dripping onto it.
IMPORTANT: for the correct and safe operation of the machine, the lighting level in the
place of use should be at least 300 lux.
Theoormustbestrongenoughtosupportaloadequaltotheweightoftheequipment
plusthemaximumloadallowed.Thesupportbaseontheoorandtheenvisagedxing
means must also be taken into account.
Environmental operating conditions must comply with the following requirements:
-relativehumidityrangingfrom30%to80%(withoutcondensation);
-temperaturerangingfrom0°to+50°C.
WARNING
For information concerning the technical features, warnings and maintenance instruc-
tions consult the related operator manuals provided with the documentation of the
machine.
CAUTION
The machine must not be operated in potentially explosive atmospheres.
The machine is supplied partially disassembled and is to be assembled according to
the procedures described below.

80 Operator's Manual B 235 Evo
Head assembly (Fig.3/3a/3b)
- loosen the screws M8 (A, Fig.3) that fasten the head to the body on the rear side of the
machine;
3
- turn the head to a vertical position and position it on the weight tray cover as shown in
the figure 3a placing the cables inside the machine;

3a
- fix the head by first tightening the two screws A and then the two screws B shown in
the previous figure;
- Fit the closing plate for the weight tray cover A using the supplied screws B (Fig.3b).

Operator's Manual B 235 Evo 81
CAUTION
Correctly fit the plate as shown below in the figure.

3b
Installing the wheel guard with the corresponding mounting (Fig. 4)
- Install the bush (A, fig. 4) on the rotation pivot (B, fig. 4). While doing this, ensure that
the groove on the pivot is aligned with the pin in the bush;
4
- Fasten the tube on the pivot using the M12 screw supplied.
- Insert the metal tube (D, Fig. 4a) into the two plastic guard front holes (C, Fig. 4a);
- Couple the guard to the rear side of the tube by inserting it into the correct position

82 Operator's Manual B 235 Evo
with snap-in coupling (E, Fig. 4a);
- Secure the wheel guard by tightening the screw provided (F, Fig. 4a).
4a
Assembly of the ultrasonic sen-
sor and its “optional accessory
supplied on request” support
for automatic width measure-
ment
- insert the ultrasonic sensor cable in the
slots on the metal pipe (see fig.5), fixing
the cable in place with hose clamp sup-
plied (A, fig.5)
-fasten the ultrasonic sensor support to
the guard pipe using the three M8 screws
provided (fig. 5a);
5
5a

Operator's Manual B 235 Evo 83
- connect the sensor cable to the connector on the side of the casing (A, fig.6)
IMPORTANT: after installing the ultrasonic sensor, calibrate the sensor as described
in the paragraph “Calibrating ultrasonic width measuring sensor”.
After assembling the machine, position it in the selected place and make sure that the
spaces surrounding it are at least equal to the ones indicated in fig.7.
Main working parts (Fig. 8)
8
(A) Automatic diameter and distance measuring arm
(B) Automatic ultrasonic sensor for measuring the width (optional)
(C) Head
(D) Display panel
(E) Flange holder
76

84 Operator's Manual B 235 Evo
(F) weight tray
(G) wheel support shaft
(H) cone holder
(I) anvil
(J) wheel guard
(L) control pedal C
ELECTRICAL HOOK-UP
On request, the wheel balancer can be set up by the manufacturer to operate with the
power supply available in the place of installation. The set-up data for each machine are
given on the machine data plate and on a special label attached to the power supply
connection cable.
CAUTION
Any operations for hooking up to the workshop electrical board must be carried out
only by qualified technicians in compliance with the regulations in force, under the
responsibility and at the charge of the customer.
- The electric hook-up must be performed according to:
• absorbedpowerspecicationsindicatedonthemachinedataplate.
• thedistancebetweenthemachineandtheelectrichook-uppoint,sothatvoltage
dropsunderfullloaddonotexceed4%(10%whenstartingup)oftheratedvoltage
specified on the data plate.
- The user must:
• taplugthatrespectsthecurrentregulationsontothepowersupplycable;
• connectthemachinetoitsownelectricalconnectionttedwithasuitable30-mAcur-
rent sensitive circuit breaker;
• tpowersupplyprotectionfusessizedincompliancewithspecicationsinthemain
wiring diagram of this manual;
• providetheworkshopelectricinstallationwithanefcientgroundingcircuit.
- prevent unauthorised use of the machine, always disconnect the power supply plug
when the machine is not used (switched off) for extended periods of time.
- If the machine is connected directly to the power supply by means of the main electrical
board and without the use of a plug, install a key-operated switch or suitable lock-out
device to restrict machine use exclusively to qualified personnel.
CAUTION
For the machine correct functioning it is vital to have a good ground connection. NEVER
connect the machine ground wire to a gas pipe, water pipe, telephone cable or any
other unsuitable object.

Operator's Manual B 235 Evo 85
COMPRESSED AIR HOOK-UP
CAUTION
All compressed air hook-ups must be carried out by qualified personnel only.
- The hook-up to the workshop's pneumatic system must ensure a minimum pressure of
7 bar (100 psi). Lower pressure levels may prevent the machine's AUTOMATIC WHEEL
LOCKING SYSTEM C from working properly.
- A universal union is used for connection to the compressed air system. No special or
additional adaptor is needed for connection. A pressure-resistant hose with 6mm inner
diameter and 14mm outer diameter must be fastened to the notched union using the
clamp provided with the machine.
SAFETY REGULATIONS
CAUTION
Non-compliance with the instructions and danger warnings can cause serious injuries
to the operator or other persons.
Do not operate the machine until you have read and understood all the danger/warn-
ing notices in this manual.
In order to operate the machine correctly, it is necessary to be a qualified and authorised
operator, able to be trained and to know the safety regulations. Operators are expressly
forbiddenfromusingthemachineundertheinuenceofalcoholordrugscapableof
affecting physical and mental capacity.
The following conditions are essential:
- the operator must be able to read and understand the contents of this manual;
- have a thorough knowledge of the features and characteristics of the machine;
- keep unauthorised persons well clear of the working area;
- make sure that the machine has been installed in compliance with all relevant standards
and regulations in force;
- make sure that all machine operators are suitably trained, that they are capable of using
the machine correctly and safely and that they are adequately supervised during work.
- do not touch power lines or the inside of electric motors or any other electrical equip-
ment before making sure that they have been powered off;
- read this booklet carefully and learn how to use the machine correctly and safely;
- always keep this user manual in a place where it can be readily consulted and do not
fail to refer to it.
CAUTION
Do not remove or deface the DANGER, WARNING, CAUTION or INSTRUCTION decals.
Replace any missing or illegible decals. If one or more decals have been detached or
damaged, they can be replaced by your nearest manufacturer dealer.
- When using and carrying out maintenance on the machine, observe the unified indus-

86 Operator's Manual B 235 Evo
trial accident prevention regulations for high voltage industrial equipment and rotating
machinery.
- Any unauthorised modification to the machine releases the manufacturer of all liability
in the event of damage or personal injury resulting from said modification. Specifically,
tampering with or removal of the machine safety devices is a breach of the regulations
relating to Safety at Work.
CAUTION
During work and maintenance operations, always tie back long hair and do not wear
loose clothing, ties, necklaces, wristwatches or any other items that may get caught
up in the moving parts.
Key to caution and instruction labels
Never use the wheel spin shaft as a lifting point for the machine.
Unplug the power supply plug before performing any maintenance/
repair operations on the machine.
Do not lift up the guard when the wheel is turning.
Please use centring accessories with hole diameter 40 mm.

Operator's Manual B 235 Evo 87
MAIN FEATURES
- Low balancing speed:
• minimiseswheelspintimes;
• reducesriskduetorotatingparts;
• savesenergy.
- Automatic sensor for measuring the distance and diameter
- AWD (Auto Width Device) programme for measuring the width using an ultrasonic sensor
(if fitted).
- “AWC” (Auto Width Calculation) programme for enabling the manual insertion of the
width.
- Automatic brake for stopping the wheel at the end of the spin.
- Wheel-holder shaft locking brake
- STOP button to stop the machine immediately.
-Sideangeholders.
- Top tray to take weights of all types.
- Automatic start by lowering the guard.
- Luminous digital display unit double display and 3D graphics.
- Microprocessor processing unit (16 bit).
-Resolution:1g(1/10oz).
- Wide selection of programmes making the machine easy to use.
- Unbalance value display in grams or ounces.
- Unbalance display rounding-off setting.
- Balancing modes available:
• Standard dynamic on both rim sides
• Alu/ALUP seven different routines for alloy rims
• MotorcycleDynamicon both sides of motorcycle rims
• MotorcycleALU dynamic on both sides of alloy motorcycle rims
• Static on a single side.
- “Shift planes” programme (in ALU P) for using multiple five gram weights, i.e.: available
without the need for partial cuts.
- “Hidden Weight” programme (in ALU P) in order to divide the outer side balancing
adhesive weights into two equal weights positioned behind the spokes of the rim.
- “Split Weight” programme (motorcycle programmes) to divide the weight into two
equivalent values to be placed on either side of the spoke.
- “OPT flash” programme for rapid optimisation of operating noise reduction.
- “FSP” (Fast Selection Program) programme for the automatic selection of the balancing
programme.
- General utility programmes:
•Calibration
•Service
•Diagnostics
- Independent working environments that allow a maximum of two operators to work in
parallel without needing to reset any data.
- RPA: - Automatic wheel positioning in the position where the balancing weight has to
be applied.
- Possibility to select the position for applying the adhesive weight:
- Vertical plane in the lower part of the wheel (H6) using the LASER line.

88 Operator's Manual B 235 Evo
•Verticalplaneintheupperpartofthewheel(H12)
•CLIP:usingtheweight-holderterminalintheALUPbalancingprogrammes(inallthe
other H12 balancing programmes)
- LED light
- LASER indicator
TECHNICAL DATA
- Single-phase power supply voltage ................ 100/115±10%,200/230V±10%,50/60Hz
- Rated power................................................................................................................... 100 W
- Rated current ....................................................................1A at 100-115V, 0.5A at 200-230V
- Balancing speed ....................................................................................................90/130 rpm
- Maximum unbalance value calculated ................................................................ 999 grams
- Average spin time (with 5”x14” wheel).........................................................................7 sec
- Shaft diameter .............................................................................................................40 mm
- Ambient work temperature ...................................................................................5°to40°C
Machine dimensions (Fig. 9-9a)
• depthwithguardclosed......................................................................................1166 mm
• depthwithguardopen ........................................................................................ 1142 mm
• widthwithguard ................................................................................................... 1601 mm
• heightwithguardclosed .................................................................................... 1563 mm
• heightwithguardopen........................................................................................1672 mm
9

Operator's Manual B 235 Evo 89
9a
Working range
•settablerimwidth...................................................................................... from 1.5" to 20"
•rimdiametermeasurablewiththesensor
(version with automatic sensor) ................................................................ from 11” to 28”
•settablerimdiameterfrom ...................................................................................1" to 35"
•max.wheel/machinedistance................................................................................ 360 mm
•max.wheelwidth(withguard) ...............................................................................600 mm
•max.wheeldiameter(withguard)...................................................................... 1117 mm
- Max. wheel weight ..........................................................................................................75 kg
- Machine weight with guard (without accessories) and without the external
measuring sensor ..........................................................................................................193 kg
- Machine weight with guard (without accessories) and with the external
measuring sensor ..........................................................................................................200 kg
- Noise level in operation ...................................................................................... < 70 dB(A)
STANDARD ACCESSORIES
The following parts are supplied together with the machine.
Weight pliers
Threaded hub
Calliper for wheel width measurement
Hexagonwrench,size10
Calibration weight
Power cable
Small cone
Medium cone
Large cone
Small wheel fixing cap protection

90 Operator's Manual B 235 Evo
Spacer cap
Small wheel fixing cap
Quick fastener ring for locking wheel
OPTIONAL ACCESSORIES
Please refer to the relevant accessories catalogue.
GENERAL CONDITIONS OF USE
The equipment is intended for professional use only.
CAUTION
Only one operator at a time can work with the machine.
The wheel balancers described in this manual must be used exclusively to measure the
extent and position of car wheel unbalances, within the limits specified in the Technical
specification section. Furthermore, models equipped with motors must be provided with a
suitableguard, fittedwith asafety device,whichmustbeloweredduringthe spinoperation.
CAUTION
Any use of the machine other than the described use is to be considered as improper
and unreasonable.
WARNING
Do not start the machine without the wheel locking equipment.
CAUTION
Do not use the machine without the guard and do not tamper with the safety device.
WARNING
Do not clean or wash the wheels mounted on the machine with compressed air or jets
of water.
CAUTION
When working, never use equipment not manufactured by the manufacturer.
CAUTION
Get to know your machine: The best way to prevent accidents and obtain top perfor-
mance from the machine is to ensure that all operators know how the machine works.
Learn the function and location of all the controls.
Carefully check that all controls on the machine are working properly.
To prevent accidents and personal injury, all the equipment must be correctly installed,
correctly operated and correctly serviced.

Operator's Manual B 235 Evo 91
DISPLAY PANEL
DISPLAY PANEL - STATUS ICON
STATUS ICON DESCRIPTION
Unbalance
rounding-off
Unbalance rounding-off to 5 grams or 0.25
ounces.
If off, the rounding-off is to 1 gram or 0.10 ounce
Car environ-
ment
Car environment active, the balancing pro-
grammes are dedicated to wheels for cars and
lightweight transport vehicles
Motorcycle
environment
Motorcycle environment active, the balancing
programmes are dedicated to motorcycle wheels
