HPE Cloudline CL3150 G4 Assembly instructions

MF877-00 Page 1
Template Revision A
HPE instructions for this template are available at MF877-01
Product End-of-Life Disassembly Instructions
Product Category: Servers
Marketing Name / Model
[List multiple models if applicable.]
HPE Cloudline CL3150 G4 Server
Purpose: The document is intended for use by end-of-life recyclers or treatment facilities. It provides the basic instructions
for the disassembly of HPE products to remove components and materials requiring selective treatment, as defined by EU
directive 2002/96/EC, Waste Electrical and Electronic Equipment (WEEE).
1.0 Items Requiring Selective Treatment
1.1 Items listed below are classified as requiring selective treatment.
1.2 Enter the quantity of items contained within the product which require selective treatment in the right column, as
applicable.
Item Description
Notes
Quantity
of items
included
in product
Printed Circuit Boards (PCB) or Printed Circuit
Assemblies (PCA)
With a surface greater than 10 sq cm
2
Batteries
All types including standard alkaline and lithium
coin or button style batteries
1
Mercury-containing components
For example, mercury in lamps, display backlights,
scanner lamps, switches, batteries
0
Liquid Crystal Displays (LCD) with a surface
greater than 100 sq cm
Includes background illuminated displays with gas
discharge lamps
0
Cathode Ray Tubes (CRT)
0
Capacitors / condensers (Containing PCB/PCT)
0
Electrolytic Capacitors / Condensers measuring
greater than 2.5 cm in diameter or height
5
External electrical cables and cords
0
Gas Discharge Lamps
0
Plastics containing Brominated Flame Retardants
weighing > 25 grams (not including PCBs or PCAs
already listed as a separate item above)
0
Components and parts containing toner and ink,
including liquids, semi-liquids (gel/paste) and toner
Include the cartridges, print heads, tubes, vent
chambers, and service stations.
0
Components and waste containing asbestos
0
Components, parts and materials containing
refractory ceramic fibers
0

MF877-00 Page 2
Template Revision A
HPE instructions for this template are available at MF877-01
Item Description
Notes
Quantity
of items
included
in product
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Torx Driver
T-20
Philps screwdriver
#2
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. System Board Battery - Remove the top cover and locate the battery on the system board.
2. Capacitors in ATX power supply=> 2.5 cm () - Remove the power supply from the system with a T-15 torx driver. With
a #2 Philips screw driver remove the screws securing the top cover then locate the capacitors and pry from the PCB
with a flat head screw driver or Long Nose Plier () and dispose of properly.
3.
4.
5.
6.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Remove Battery

MF877-00 Page 3
Template Revision A
HPE instructions for this template are available at MF877-01
Remove PDB Board

MF877-00 Page 4
Template Revision A
HPE instructions for this template are available at MF877-01
1. Pull out the power supply of chassis.
