HTC HTC Touch Dual User manual

www.htc.com
Touch Phone
User Manual

2
Please Read Before Proceeding
THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S
OUTER CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and
stipulate that you must inform the person with whom you are speaking that the
conversation is being recorded. Always obey the relevant laws and regulations of your
country when using the recording feature of your device.
INTELLECTUAL PROPERTY RIGHT INFORMATION
Copyright © 2007 High Tech Computer Corp. All Rights Reserved.
, , and ExtUSB are trademarks and/or service marks of High
Tech Computer Corp.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile,
Windows XP, Windows Vista, ActiveSync, Windows Mobile Device Center, Internet
Explorer, Windows Live, MSN, Hotmail, Outlook, Excel, PowerPoint, Word, and Windows
Media are either registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
microSD is a trademark of SD Card Association.
Java, J2ME and all other Java-based marks are trademarks or registered trademarks of
Sun Microsystems, Inc. in the United States and other countries.
Copyright © 2007, Adobe Systems Incorporated.
Copyright © 2007, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are
trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or Adobe
Systems Incorporated.
Copyright © 2007, JATAAYU SOFTWARE (P) LTD. All Rights Reserved.
Copyright © 2007, Dilithium Networks, Inc. All Rights Reserved.
Copyright © 2007, Tao Group Limited. All Rights Reserved.
ArcSoft MMS Composer™ Copyright © 2003-2007, ArcSoft, Inc. and its licensors. All
Rights Reserved. ArcSoft and the ArcSoft logo are registered trademarks of ArcSoft, Inc.
in the United States and/or other countries.

3
Sprite Backup is a trademark or service mark of Sprite Software.
All other company, product and service names mentioned herein are trademarks,
registered trademarks or service marks of their respective owners.
HTC shall not be liable for technical or editorial errors or omissions contained herein,
nor for incidental or consequential damages resulting from furnishing this material.
The information is provided “as is” without warranty of any kind and is subject to
change without notice. HTC also reserves the right to revise the content of this
document at any time without prior notice.
No part of this document may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying, recording or storing in a
retrieval system, or translated into any language in any form without prior written
permission of HTC.
Disclaimers
THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS”
AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly
disclaim any and all representations and warranties, express or implied, arising by law
or otherwise, regarding the Weather Information, Data, Documentation, or any other
Products and services, including without limitation any express or implied warranty of
merchantability, express or implied warranty of fitness for a particular purpose, non-
infringement, quality, accuracy, completeness, effectiveness, reliability, usefulness, that
the Weather Information, Data and/or Documentation will be error-free, or implied
warranties arising from course of dealing or course of performance.
Without limiting the foregoing, it is further understood that HTC and its Providers
are not responsible for Your use or misuse of the Weather Information, Data and/or
Documentation or the results from such use. HTC and its Providers make no express
or implied warranties, guarantees or affirmations that weather information will
occur or has occurred as the reports, forecasts, data, or information state, represent
or depict and it shall have no responsibility or liability whatsoever to any person or
entity, parties and non-parties alike, for any inconsistency, inaccuracy, or omission
for weather or events predicted or depicted, reported, occurring or occurred.
WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE
THAT THE WEATHER INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE
INACCURACIES AND YOU WILL USE COMMON SENSE AND FOLLOW STANDARD SAFETY
PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA
OR DOCUMENTATION.

4
Limitation of Damages
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL
HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT,
SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, IN
CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE,
LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS
OF PROFITS ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY,
PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF THE WEATHER
INFORMATION, DATA OR DOCUMENTATION HEREUNDER REGARDLESS OF THE
FORESEEABILITY THEREOF.
Important Health Information and Safety Precautions
When using this product, the safety precautions below must be taken to avoid possible
legal liabilities and damages.
Retain and follow all product safety and operating instructions. Observe all warnings in
the operating instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment,
observe the following precautions.
ELECTRICAL SAFETY
This product is intended for use when supplied with power from the designated
battery or power supply unit. Other usage may be dangerous and will invalidate any
approval given to this product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION
CAUTION: Connecting to an improperly grounded equipment can result in an electric
shock to your device.
This product is equipped with a USB cable for connecting the product to a desktop
or notebook computer. Be sure your computer is properly grounded (earthed) before
connecting the product to the computer. The power supply cord of a desktop or
notebook computer has an equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet which is properly installed and
grounded in accordance with all local codes and ordinances.
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
• Use the correct external power source
A product should be operated only from the type of power source indicated
on the electrical ratings label. If you are not sure of the type of power source
required, consult your authorized service provider or local power company. For a
product that operates from battery power or other sources, refer to the operating
instructions that are included with the product.

5
• Handle battery packs carefully
This product contains a Li-ion battery. There is a risk of fire and burns if the battery
pack is handled improperly. Do not attempt to open or service the battery pack.
Do not disassemble, crush, puncture, short external contacts or circuits, dispose of
in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).
WARNING: Danger of explosion if battery is incorrectly replaced. To
reduce risk of fire or burns, do not disassemble, crush, puncture, short
external contacts, expose to temperature above 60° C (140° F), or
dispose of in fire or water. Replace only with specified batteries. Recycle
or dispose of used batteries according to the local regulations or
reference guide supplied with your product.
• Take extra precautions
• Keep the battery or device dry and away from water or any liquid as it may
cause a short circuit.
• Keep metal objects away so they don’t come in contact with the battery or
its connectors as it may lead to short circuit during operation.
• Do not use a battery that appears damaged, deformed, or discolored, or the
one that has any rust on its casing, overheats, or emits a foul odor.
• Always keep the battery out of the reach of babies and small children, to
avoid swallowing of the battery. Consult the doctor immediately if the
battery is swallowed.
If the battery leaks:
• Do not allow the leaking fluid to come in contact with skin or clothing. If
already in contact, flush the affected area immediately with clean water and
seek medical advice.
• Do not allow the leaking fluid to come in contact with eyes. If already in
contact, DO NOT rub; rinse with clean water immediately and seek medical
advice.
• Take extra precautions to keep a leaking battery away from fire as there is a
danger of ignition or explosion.
• Communicate the appropriate steps immediately in case a hazard occurs.

6
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme temperatures. Do not
leave the product or its battery inside a vehicle or in places where the temperature
may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass
that is exposed to direct sunlight or strong ultraviolet light for extended periods of
time. This may damage the product, overheat the battery, or pose a risk to the vehicle.
PREVENTION OF HEARING LOSS
CAUTION: Permanent hearing loss may occur if earphones or headphones are used at
high volume for prolonged periods of time.
SAFETY IN AIRCRAFT
Due to the possible interference caused by this product to an aircraft’s navigation
system and its communications network, using this device’s phone function on board
an airplane is against the law in most countries. If you want to use this device when on
board an aircraft, remember to turn off the phone by switching to Flight Mode.
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical plants or where blasting
operations are in progress, or in potentially explosive atmospheres such as fuelling
areas, fuel storehouses, below deck on boats, fuel or chemical transfer or storage
facilities, and areas where the air contains chemicals or particles, such as grain, dust, or
metal powders. Please be aware that sparks in such areas could cause an explosion or
fire resulting in bodily injury or even death.
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere or where flammable
materials exist, the product should be turned off and the user should obey all signs
and instructions. Sparks in such areas could cause an explosion or fire resulting in
bodily injury or even death. Users are advised not to use the equipment at refueling
points such as service or gas stations, and are reminded of the need to observe
restrictions on the use of radio equipment in fuel depots, chemical plants, or where
blasting operations are in progress. Areas with a potentially explosive atmosphere
are often, but not always, clearly marked. These include fueling areas, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the air contains
chemicals or particles, such as grain, dust, or metal powders.
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony services with handheld
devices, except in the case of emergency. In some countries, using hands-free devices
as an alternative is allowed.

7
SAFETY PRECAUTIONS FOR RF EXPOSURE
• Avoid using your device near metal structures (for example, the steel frame of a
building).
• Avoid using your device near strong electromagnetic sources, such as microwave
ovens, sound speakers, TV and radio.
• Use only original manufacturer-approved accessories, or accessories that do not
contain any metal.
• Use of non-original manufacturer-approved accessories may violate your local RF
exposure guidelines and should be avoided.
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction. The use of this device is
forbidden in most hospitals and medical clinics.
If you use any other personal medical device, consult the manufacturer of your device
to determine if it is adequately shielded from external RF energy. Your physician may
be able to assist you in obtaining this information.
Turn the phone OFF in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may be using equipment that
could be sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of
such interference, you may want to consult your service provider, or call the customer
service line to discuss alternatives.
NONIONIZING RADIATION
Your device has an internal antenna. This product should be operated in its normal-use
position to ensure the radiative performance and safety of the interference. As with
other mobile radio transmitting equipment, users are advised that for satisfactory
operation of the equipment and for the safety of personnel, it is recommended that no
part of the human body be allowed to come too close to the antenna during operation
of the equipment.
Use only the supplied integral antenna. Use of unauthorized or modified antennas may
impair call quality and damage the phone, causing loss of performance and SAR levels
exceeding the recommended limits as well as result in non-compliance with local
regulatory requirements in your country.

8
2
.
0
M
E
G
A
P
I
X
E
L
S
C
A
M
E
R
A
Internal
antenna
location
To assure optimal phone performance
and ensure human exposure to RF energy
is within the guidelines set forth in the
relevant standards, always use your device
only in its normal-use position. Do not touch
or hold the antenna area unnecessarily
when placing or receiving a phone call.
Contact with the antenna area may impair
call quality and cause your device to operate
at a higher power level than needed.
Avoiding contact with the antenna area
when the phone is IN USE optimizes the
antenna performance and the battery life.
General Precautions
• Avoid applying excessive pressure to the device
Do not put heavy objects or apply excessive pressure on the device to prevent
damaging the device or distorting the touch screen display. Also avoid carrying the
device inside your pocket for extensive lengths of time.
• Heed service markings
Except as explained elsewhere in the Operating or Service documentation, do
not service any product yourself. Service needed on components inside these
compartments should be done by an authorized service technician or provider.
• Damage requiring service
Unplug the product from the electrical outlet and refer servicing to an authorized
service technician or provider under the following conditions:
• Liquid has been spilled or an object has fallen into the product.
• The product has been exposed to rain or water.
• The product has been dropped or damaged.
• There are noticeable signs of overheating.
• The product does not operate normally when you follow the operating
instructions.
• Avoid hot areas
The product should be placed away from heat sources such as radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.

9
• Avoid wet areas
Never use the product in a wet location.
• Avoid using your device after a dramatic change in temperature
When you move your device between environments with very different temperature
and/or humidity ranges, condensation may form on or within the device. To avoid
damaging the device, allow sufficient time for the moisture to evaporate before
using the device.
NOTE: When taking the device from low-temperature conditions into a
warmer environment or from high-temperature conditions into a cooler
environment, allow the device to acclimate to room temperature before
turning on power.
• Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other openings in the product.
Slots and openings are provided for ventilation. These openings must not be blocked
or covered.
• Mounting accessories
Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any
mounting of the product should follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the manufacturer.
• Avoid unstable mounting
Do not place the product with an unstable base.
• Use product with approved equipment
This product should be used only with personal computers and options identified as
suitable for use with your equipment.
• Adjust the volume
Turn down the volume before using headphones or other audio devices.
• Cleaning
Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the
LCD screen.

10
Contents
Chapter 1 Getting Started 15
1.1 Getting to Know Your Device and Accessories ..................................16
1.2 Installing the SIM Card, Battery, and Storage Card ..........................20
1.3 Starting Up ..........................................................................................23
1.4 The Today Screen .................................................................................25
1.5 The Start Menu ....................................................................................26
1.6 Quick Menu ..........................................................................................26
1.7 HTC Home ............................................................................................27
1.8 TouchFLO™ ............................................................................................32
1.9 Programs ..............................................................................................38
1.10 Settings ...............................................................................................41
1.11 Status Icons ........................................................................................45
Chapter 2 Entering and Searching Information 47
2.1 Entering Information ...........................................................................48
2.2 Using the On-screen Keyboard ...........................................................49
2.3 Using the Touch Keyboard ..................................................................49
2.4 Using the Touch Keypad ......................................................................52
2.5 Using the Symbol Pad ..........................................................................53
2.6 Using Letter Recognizer ......................................................................54
2.7 Using Block Recognizer .......................................................................54
2.8 Using Transcriber .................................................................................55
2.9 Searching Information ........................................................................56
Chapter 3 Using Phone Features 57
3.1 Using the Phone ...................................................................................58
3.2 Making a Call ........................................................................................60
3.3 Receiving a Call ....................................................................................63
3.4 Smart Dialing .......................................................................................64

11
3.5 Additional Dialing Information ..........................................................67
3.6 Setting Up Bluetooth SIM Access for Car Kit Phones ........................67
Chapter 4 Setting Up Your Device 69
4.1 Basic Settings .......................................................................................70
4.2 Personalizing the Today Screen ..........................................................73
4.3 Protecting Your Device ........................................................................76
Chapter 5 Synchronizing Information With Your Computer 79
5.1 About Synchronization .......................................................................80
5.2 Setting Up Windows Mobile® Device Center on Windows Vista™ ....81
5.3 Setting Up ActiveSync® on Windows XP® ..........................................83
5.4 Synchronizing With Your Computer ...................................................84
5.5 Synchronizing via Bluetooth ..............................................................85
5.6 Synchronizing Music and Video .........................................................86
Chapter 6 Organizing Contacts, Appointments, Tasks, and Other
Information 87
6.1 Contacts ................................................................................................88
6.2 SIM Manager ........................................................................................92
6.3 Calendar ...............................................................................................94
6.4 Tasks ......................................................................................................97
6.5 Notes .....................................................................................................99
6.6 Voice Recorder ....................................................................................101
Chapter 7 Exchanging Messages 103
7.1 Messaging ..........................................................................................104
7.2 Text Messages ....................................................................................106
7.3 MMS ....................................................................................................109
7.4 Types of E-mail Accounts ...................................................................113
7.5 E-mail Setup Wizard ...........................................................................113
7.6 Using E-mail ........................................................................................116

12
Chapter 8 Working With Company E-mails and Meeting
Appointments 123
8.1 Synchronizing Your Device with the Exchange Server ...................124
8.2 Working With Company E-mails .......................................................125
8.3 Managing Meeting Requests ...........................................................129
8.4 Finding Contacts in the Company Directory ...................................131
Chapter 9 Working With Documents and Files 133
9.1 Microsoft® Office Mobile ...................................................................134
9.2 Adobe® Reader® LE ............................................................................135
9.3 Copying and Managing Files .............................................................136
9.4 ZIP .......................................................................................................137
9.5 Backing Up Data ................................................................................138
Chapter 10 Getting Connected 141
10.1 Comm Manager ................................................................................142
10.2 Ways of Connecting to the Internet ................................................143
10.3 Wi-Fi ..................................................................................................143
10.4 GPRS ..................................................................................................146
10.5 Dial-up ..............................................................................................147
10.6 Starting a Data Connection .............................................................147
10.7 Internet Explorer® Mobile ...............................................................148
10.8 Windows Live™ .................................................................................150
10.9 Using Your Device as a Modem (Internet Sharing) .........................154
10.10 Bluetooth .......................................................................................156
Chapter 11 Experiencing Multimedia 163
11.1 Camera ..............................................................................................164
11.2 Camera Album .................................................................................174
11.3 Pictures & Videos .............................................................................178
11.4 Windows Media® Player Mobile ......................................................180
11.5 Streaming Media .............................................................................185
11.6 Audio Manager ................................................................................187

13
Chapter 12 Managing Your Device 191
12.1 Adding and Removing Programs ...................................................192
12.2 Using Task Manager .........................................................................192
12.3 Resetting Your Device ......................................................................194
12.4 Managing Memory ..........................................................................196
12.5 Windows Update ..............................................................................197
12.6 Battery Saving Tips ..........................................................................198
Chapter 13 Using Other Applications 199
13.1 Voice Speed Dial ..............................................................................200
13.2 Java ...................................................................................................202
Appendix 205
A.1 Specifications .....................................................................................206
A.2 Regulatory Notices ............................................................................209
Index 213

14

Chapter 1
Getting Started
1.1 Getting to Know Your Device
and Accessories
1.2 Installing the SIM Card, Battery,
and Storage Card
1.3 Starting Up
1.4 The Today Screen
1.5 The Start Menu
1.6 Quick Menu
1.7 HTC Home
1.8 TouchFLO™
1.9 Programs
1.10 Settings
1.11 Status Icons

16 Getting Started
1.1 Getting to Know Your Device and Accessories
Top panel
POWER
Press to turn off the display temporarily. To turn off the power, press and hold for
about 5 seconds. For more information, see “Starting Up” in this chapter.
Left panel
Volume Slider
• Slide up or down
to adjust the
speaker volume.
• During a call, slide
up or down to
adjust the earpiece
volume.
Lanyard/
Strap holder
Right panel
CAMERA
Press to launch the
Camera. See Chapter
11 for details.
Stylus

Getting Started 17
Front panel
Notification LEDs
* See description below.
Earpiece
Listen to a phone
call from here.
Touch Screen
TALK
Press to answer
an incoming call
or dial a number.
NAVIGATION Control/ENTER
Press this multi-directional control up, down,
left, or right to move through menus and
program instructions; carry out the selection
by pressing the center button.
END
Press to end a call
or to return to the
Today screen.
* Right LED: Shows Green and Amber lights for GSM/GPRS/EDGE standby, message,
and network status as well as for notification and battery charging status.
Left LED: Shows a flashing Blue light when the Bluetooth system is powered up
and ready to transmit Bluetooth radio signal, or a flashing Green light for
Wi-Fi status. When both Bluetooth and Wi-Fi are enabled, their lights flash
alternately.

18 Getting Started
Back panel
2
.
0
M
E
G
A
P
I
X
E
L
S
C
A
M
E
R
A
Speaker
2 Megapixel
Camera
See Chapter 11
for details.
Back Cover
Slide the back cover
upward to remove it.
Self-portrait Mirror
• Use it when taking self-
portrait shots.
Bottom panel
Sync Connector/Earphone Jack
Connect the supplied USB cable to
synchronize information or plug in the
AC adapter to recharge the battery. You
can also connect the supplied USB stereo
headset for hands-free conversation or
for listening to audio media.
Microphone
RESET
With the stylus, press
the RESET button to
soft-reset your device.

Getting Started 19
Accessories
2
13
4
No. Accessory Function
1 AC adapter Recharges the battery.
2 USB Sync cable Connects your device to a PC and synchronizes data.
3 Stereo headset Provides a volume control slider and a Send/End
button. Press the Send/End button to pick up a call or
put a call on hold; press and hold the button to end
the call.
4 Pouch Acts as a protective carrying case for your device.

20 Getting Started
1.2 Installing the SIM Card, Battery, and
Storage Card
Always turn off your device before installing or removing the SIM card or
battery.
The SIM card contains your phone number, service details, and phonebook/
message memory. Your device supports both 1.8V and 3V SIM cards. Some
legacy SIM cards will not function with your device. You should consult with
your service provider for a replacement SIM card. There may be fees for this
service.
Your device contains a rechargeable Li-ion battery. It is designed to use
only manufacturer-specified original batteries and accessories. Battery
performance depends on many factors, including network configuration,
signal strength, the temperature of the environment in which you operate
your device, the features and/or settings you select and use, items attached
to connecting ports, and your voice, data, and other program usage
patterns.
Battery life estimates (approximations):
• Standby time: Up to 200 hours for GSM.
• Talk time: Up to 5 hours for GSM.
• Media playback time: Up to 8 hours for WMV;
Up to 12 hours for WMA.
Warning! To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire
or water.
• Do not expose to temperatures above 60oC (140oF).
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulation.
