HTC TOUCH PRO 2 User manual

Quick Start Guide

Please Read Before Proceeding
THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU DISASSEMBLE OR ATTEMPT TO DISASSEMBLE
THE DEVICE.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and stipulate that you must
inform the person with whom you are speaking that the conversation is being recorded. Always obey the
relevant laws and regulations of your country when using the recording feature of your PDA Phone.
LIMITATION OF DAMAGES
To the maximum extent permitted by applicable law, in no event shall HTC or its providers be liable to user or
any third party for any indirect, special, consequential, incidental or punitive damages of any kind in contract
or tort, including, but not limited to, injury, loss of revenue, loss of goodwill, loss of business opportunity,
loss of date, and/or loss of profits arising out of, or related to, in any manner, or the delivery, performance
or nonperformance of obligations, or use of the weather information, stock data, data or documentation
hereunder regardless of the foreseeability thereof.
FOR MORE INFORMATION
For health, safety, and regulatory information, see “Appendix: Safety and Other Notices”.

Table of Contents
Contents
1. Welcome to the HTC Touch Pro2 Quick Start Guide .................................. 4
2. Inside the Box .......................................................................................................... 4
3. Get to Know Your HTC Touch Pro2 ................................................................... 5
4. Installing the SIM Card, Battery, and Storage Card..................................... 7
5. Get Started..............................................................................................................10
6. Personalise Your HTC Touch Pro2....................................................................14
7. Add Contacts..........................................................................................................17
8. Experience People-centric Communication...............................................19
9. Make Calls ...............................................................................................................21
10. Send Text and Multimedia Messages............................................................23
11. Set Up and Use E-mail.........................................................................................24
12. Keep Track of Your Appointments..................................................................25
13. Straight Talk™ .........................................................................................................26
14. Experience Internet Without the Wait...........................................................29
15. Use the Camera .....................................................................................................30
16. Manage Wi-Fi, Bluetooth and Other Connections....................................32
17. Synchronise Your HTC Touch Pro2 with Your Computer ........................34
18. Maintain the Performance of Your Device...................................................35
19. Troubleshooting Tips ..........................................................................................36
Appendix: Safety and Other Notices.....................................................................37

4 Quick Start Guide
1. Welcome to the HTC Touch Pro2 Quick Start Guide
Congratulations on your purchase of the HTC Touch Pro2.
This Quick Start Guide will help you get started with your HTC Touch Pro2. This
guide will walk you through the features we feel you will want to learn right
away when you use your HTC Touch Pro2.
For a more complete guide in using your HTC Touch Pro2, please refer to the
User Manual PDF that is on the accompanying disc.
2. Inside the Box
You should find the following items inside the box.
HTC Touch Pro2
Battery
AC adapter
Screen protector
Wired stereo headset
•
•
•
•
•
USB sync cable
Quick Start Guide
Extra stylus
Pouch
Getting Started disc
•
•
•
•
•

Quick Start Guide 5
3. Get to Know Your HTC Touch Pro2
Earpiece
Touch Screen
END
BACK
Second
Camera
Zoom
Bar
TALK/SEND
Hardware
Keyboard
START
Light
Sensor
Notification LED
Strap Holder
Back Cover
3.2 Megapixel
Camera
MUTE
Dual Speaker
VOLUME
UP
VOLUME
DOWN
Stylus
Microphone
POWER
Sync Connector/
Earphone Jack/TV Out
Microphone

6 Quick Start Guide
Opening the hardware keyboard
To use the hardware keyboard, slide the screen
panel to the right to reveal the keyboard.
The screen orientation automatically switches to
landscape mode when the keyboard is opened.
Adjusting the LCD screen angle
50° angle
The maximum tilting angle
is 50 degrees. Do not force
the screen to tilt further than
the maximum angle as it will
break the device.
Before you retract the screen,
be sure to adjust the screen
angle back to the original
horizontal position.

Quick Start Guide 7
4. Installing the SIM Card, Battery, and Storage Card
You need to remove the back cover before you can install the SIM card, battery
and storage card. Also, make sure to always turn off the power before installing
or replacing the SIM card and battery.
To remove the back cover
1. Make sure your device is turned off.
2. Remove the stylus.
Note You need to temporarily remove the
stylus to be able to remove or replace
the back cover.
3. Firmly hold the device with both hands
and the front panel facing down.
4. Push the back cover up with your thumbs
until it disengages from the device and
then slide it up to remove.
SIM card
To install the SIM card
Remove the battery if it is installed.
Locate the SIM card slot, then insert
the SIM card with its gold contacts
facing down and its cut-off corner
facing out the card slot.
Slide the SIM card completely into
the slot.
1.
2.
3.
Cut-off
corner

8 Quick Start Guide
To remove the SIM card
Insert the tip of the stylus into the small
hole above the SIM card slot, and then
push the SIM card out with the stylus.
Slide the SIM card out from the slot with
your other thumb or finger.
1.
2.
Battery
To install the battery
Align the battery’s exposed
copper contacts with the battery
connectors at the bottom part of
the battery compartment.
Insert the contacts side of the
battery first and then gently push
the battery into place.
Replace the back cover and insert
the stylus back into the stylus
compartment.
1.
2.
3.
Groove
To remove the battery
Lift out the battery from the groove at the upper right side of the battery
compartment.

Quick Start Guide 9
To charge the battery
Connect the USB connector of the AC adapter to the sync connector at the
bottom of your device.
Plug in the AC adapter to an electrical outlet to start charging the battery.
The battery will be fully charged after about 3 hours of charging.
Note Only the AC adapter and USB sync cable provided with your device must be used
to charge the battery.
Storage card
To install the microSD card
Remove the stylus and then
remove the back cover.
Locate the microSD card slot on
the upper part of the exposed right
panel.
Insert the microSD card into the
slot with its gold contacts facing
down until it clicks into place.
Note To remove the microSD card, press to
eject it from the slot.
1.
2.
3.
Storage
card slot
1.
2.

10 Quick Start Guide
5. Get Started
After installing and charging the battery, you can now power on and start using
your device.
Turning on the power
Press the POWER button on the top panel of your device.
On first time use, after customised settings are installed, if you have contact
information stored on your SIM card, the SIM Card Changed screen appears.
Follow the on-screen instructions to import the contacts.
Note If you skip SIM contact import, you can still import your SIM contacts manually at
any time, using SIM Manager to import SIM contacts to your device. To open SIM
Manager, tap Start > All Programs > SIM Manager.
Using the Start screen
Touch Start on the top-left corner of the screen
or press the START ( ) button to open the Start
screen. The Start screen gives you one-touch access
to the programs and settings of your device. You
can also add the shortcut icons of your favourite
programs in the Start screen so you can open them
quickly.
Using the TouchFLO™3D Home screen
Your device’s main screen is the TouchFLO™ 3D Home screen which allows
finger-touch access to the most important functions such as favourite contacts,
text messages, e-mail, calendar, Internet, and more.
