Huawei HG630 Technical specifications

Part Number: 203197
HG630 Home Gateway Product
Description
Issue
01
Date
2012-05-20
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without
prior written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd. All other
trademarks and trad
e names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the commercial contract made
between Huawei and the customer. All or partial products, services and features described in this
document may not be within the purchased scope or the usage scope. Unless otherwise agreed by
the contract, all statements, information, and recommendations in this document are provided “AS
IS” without warranties, guarantees or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in
the preparation of this document to ensure accuracy of the contents, but all statements, information,
a
nd recommendations in this document do not constitute the warranty of any kind, express or
implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huaweidevice.com
Email: [e-mail]

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 3 of 16
Contents
1 Overview...............................................................................................................................4
1.1 Introduction to the HG630 ...................................................................................................................4
1.2 Hardware Features ............................................................................................................................... 5
1.3 Network Architecture ...........................................................................................................................8
2 Functional Features...........................................................................................................10
2.1 High- bandwidth VDSL2 and HSPA Upstream Link .........................................................................10
2.2 Support 802.11n .................................................................................................................................10
2.3 WPS Function .................................................................................................................................... 10
2.4 Routing Function................................................................................................................................ 10
2.5 IPv6 Function..................................................................................................................................... 10
2.6 Flexible QoS Policies ......................................................................................................................... 11
2.7 Standardized TR-069 Management.................................................................................................... 11
2.8 Convenient and Secure Management and Maintenance..................................................................... 11
3 Technical Specifications ..................................................................................................12
3.1 Interface Features ............................................................................................................................... 12
3.2 Security Features................................................................................................................................ 13
3.3 Routing & Bridged Features ..............................................................................................................13
3.4 QoS Features ......................................................................................................................................14
3.5 Network Management........................................................................................................................14
3.6 Power Supply Specifications..............................................................................................................14
3.7 Physical Specifications.......................................................................................................................14
3.8 Environmental Specifications ............................................................................................................14
4 Acronyms and Abbreviations.........................................................................................15

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 4 of 16
1 Overview
1.1 Introduction to the HG630
Figure 1-1 Appearance of the HG630
HG630 Home Gateway (hereinafter referred to as the HG630) is a type of Very High
Speed Digital Subscriber Line (VDSL) terminal. It's also compatible with Asymmetric
Digital Subscriber Line (ADSL), ADSL2, ADSL2+. On the network side, the HG630
provides a DSL interface.
For users, it provides an 2×2 MIMO 802.11b/g/n interface and four Ethernet interfaces.
After connecting to a PC, STB, video phone, or another terminal, users can enjoy data,
voice, and a range of other services.
The HG630 supports the triple play service completely and provides powerful routing
and bridging functions. It supports the IPv4 & IPv6 dual stack mode and the DS-Lite
mode, and various access modes such as PPPoE, IPoA and IPoE. Besides, it supports
DHCP, DNS, NAT, IGMP Proxy and Snooping, ACL, firewall, and ALG technologies.
With flexible configuration and QoS strategy, the HG630 ensures the quality of audio
service and video service that are respectively sensitive to time delay and packet loss.
Using the HG630, users can enjoy high-speed and high-quality broadband services at
home.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 5 of 16
As a broadband network terminal, the HG630 is an extension of an operator's
broadband network. HG630 provides powerful remote maintenance and administration
functions. It supports the latest TR-069 terminal management standards and remote
upgrades, thus facilitating large-scale deployment and maintenance.
1.2 Hardware Features
1.2.1 Interfaces and Buttons
Figure 1-2 Interfaces and buttons on the HG630
DSL
1
2
3
4 5 6 7 8 9 10 11
Table 1-1 Interfaces and buttons on the HG630
No. Description
1 WPS button, which is used to enable the WPS negotiation function.
2 WLAN button, which is used to enable or disable wireless network
function quickly.
3 Power button, which is used to power on or off the HG630.
4 DSL interface, which is used to connect HG630 to the MODEM interface
on the splitter or to the telephone jack on the wall.
5-8 LAN interfaces, which are used to connect the HG630 to the Ethernet
interface on the computer.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 6 of 16
No. Description
9
USB interface, which is used to connect a USB device, such as a Huawei
HSPA USB interface link device.
The maximum voltage/current output from the USB port is 5 V/0.8 A. That is, the
input voltage/current of the USB device connected to the USB port cannot exceed
5 V/0.8 A. Otherwise, the HG532s may not work correctly.
10
Power interface, which is used to connect the HG630 to the power
adapter.
11 Reset button, which is used to restore the factory settings of the HG630.
1.2.2 Indicators
Figure 1-3 Indicators on the HG630
Table 1-2 Indicators on the HG630
Indicator Description
Power Indicates the power condition of the HG630.
DSL Indicates the status of the DSL line.
Internet Indicates whether the WAN uplink service is available in routing
mode.
WLAN Indicates the status of the wireless network connection.
WPS Indicates the status of the wireless network connection through
the WPS protocol.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 7 of 16
Indicator Description
LAN1 ~ LAN4 Indicate the status of the Ethernet connection between the HG630
and the PC.
USB Indicates the status of the USB connection between the HG630
and the USB device.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 8 of 16
1.3 Network Architecture
Figure 1-4 shows the location of the HG630 in the network.
Figure 1-4 Networking diagram of the HG630
2
9
8
11 12
7
4
5
3
1
6
10

indicates an actual network connection.

indicates a logical management channel.
Table 1-3 lists the network units in the networking diagram of the HG630.
Table 1-3 Network units in the networking diagram of the HG630
No. Item Full Name
1 NGN Next Generation Network
2 Internet -
3 IPTV Internet Protocol Television
4 BRAS Broadband Remote Access Server
5 DSLAM Digital Subscriber Line Access Multiplexer
6 OSS Operations Support System
7 ACS Auto-Configuration Server

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 9 of 16
No. Item Full Name
8 HG630 -
9 Telephone -
10 STB Set-Top Box
11 Desktop computer -
12 Notebook computer -

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 10 of 16
2 Functional Features
2.1 High- bandwidth VDSL2 and HSPA Upstream
Link
With an embedded high-performance VDSL2 network processor and High-Speed
Packet Access (HSPA) uplink through HSPA modem, the HG630 can bring more
abundant service experiences to users. It's also compatible with ADSL, ADSL2 and
ADSL2+.
2.2 Support 802.11n
The HG630 provides high-speed, secure, and convenient wireless network access, and
supports 802.11n (2.4 GHz ~ 2.4835 GHz), 802.11b, and 802.11g. It can implement
the network access at a high speed by using a powerful built-in antenna. The IEEE
802.11n supports the MIMO 2×2 technology and the access rate can reach 300Mbit/s.
2.3 WPS Function
The HG630 provides the WPS 2.0 function. A wireless connection can be set up
between the computer and the HG630 conveniently and securely.
2.4 Routing Function
The HG630 has an embedded PPP dialer. It supports the functions of a Dynamic Host
Configuration Protocol (DHCP) server and simultaneous access of multiple users and
devices.
2.5 IPv6 Function
The HG630 provides the IPv6 function. It supports the IPv4 & IPv6 dual stack mode
and the DS-Lite mode.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 11 of 16
2.6 Flexible QoS Policies
The HG630 supports multiple methods of traffic classification, thus ensuring that user
services at different levels of network applications are smoothly implemented and that
end users can enjoy quality video and audio services.
2.7 Standardized TR-069 Management
The HG630 is completely compatible with the TR-069 standard defined by the Digital
Subscriber Line (DSL) Forum. Providing complete remote management and
diagnostic functions, it can implement the zero configuration solution. In addition, the
HG630 can carry out customized service provisioning conveniently through automatic
upgrade based on the service provisioning process. Hence operation and maintenance
cost can be greatly reduced.
2.8 Convenient and Secure Management and
Maintenance
The HG630 supports the TR-069 remote management, provides a Web-based
configuration utility, and ensures secure use of the Web-based configuration utility
through password verification.

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 12 of 16
3 Technical Specifications
3.1 Interface Features
3.1.1 DSL Interface
Multiple DSL Standards
VDSL2
−Supports G.993.2 VDSL2
−Supports VDSL2 Profiles for 8a, 8b, 8c, 8d, 12a, 17a
−Supports VDSL Vectoring
ADSL2+
−Supports G.992.5 (G.dmt.bitplus)
ADSL2
−Supports G.992.3 (G.dmt.bis) Annex L
ADSL
−Supports G.992.1 (G.dmt)
−Supports G.992.2 (G.lite)
−Supports G.994.1 (G.hs)
−Supports ANSI T1.413 Issue 2
Other Features
Supports multiple permanent virtual channels (PVCs)
Supports manual configuration of PVC parameters
3.1.2 WLAN Interface
Supports 802.11n 2×2 antenna
Supports 802.11b, 802.11g, 802.11n (2.4 GHz ~ 2.4835GHz)
Supports WPS 2.0 (PBC mode and PIN mode)
Supports DQPSK, DBPSK, CCK, OFDM, BPSK, QPSK, 16-QAM and 64-QAM
wireless modulation method

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 13 of 16
Supports SSID hiding
Supports WPA1.0 and WPA2.0 security
Supports 64/128 digits WEP encryption
Supports TKIP and AES encryption
Supports multiple SSIDs
Supports WMM
Supports enable or disable the WLAN function by press WLAN button or config
the web-based utility
WLAN Rates:
−802.11b: Up to 11 Mbit/s
−802.11g: Up to 54 Mbit/s
−802.11n(with a 2×2 antenna used):Up to 300.0 Mbit/s
3.1.3 USB Interface
Functions as a USB Host 2.0 interface
Supports mass storage device
Supports accessing a portable storage device through FTP server
Supports a printing function
Supports USB modem
Supports DLNA
3.2 Security Features
Supports powerful wireless network security
Supports IP/MAC filtering
Supports URL filtering
Supports ACL access control
Prevents DoS attacks such as LAND, SYN flooding, ICMP Smurf, Ping of Death,
Ping Sweep, Teardrop, Unreachable, TCP/UDP PortScan and ICMP Redirection.
3.3 Routing & Bridged Features
Supports IPv6
−Supports IPv4 and IPv6 dual-stack
−Supports DS-Lite Tunnel
−Supports SLAAC
Supports NAT and ALG expansion
Supports DHCP Server/Client
Supports DNS Relay/Client
Supports IGMP proxy and IGMP snooping
Supports DMZ

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 14 of 16
Supports UpnP
Supports SNTP
Supports port mapping
Supports RIP V1&V2
Bridging between the WAN port and the LAN port
3.4 QoS Features
Supports 802.1p and 802.1q
Agile QoS Strategy
Rich of stream classification strategy
3.5 Network Management
Supports TR-069
Supports Views system logs
Supports two levels of web access control
Prevents improper upgrades
Supports the upgrade through TR-069
Supports remote and local web configuration and management
Backing up and restoring the configuration
3.6 Power Supply Specifications
Entire-device power supply: 12 V DC, 2 A
Entire-device power consumption: < 24 W
3.7 Physical Specifications
Dimensions (L ×W × H): about 162 mm ×137 mm ×32 mm
(Including the base plate)
Weight: about 266 g (Not including the power adapter)
3.8 Environmental Specifications
Ambient temperature for operation: 0°C to 40°C (32°F to 104°F)
Relative humidity for operation: 5% to 95%, non-condensing

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 15 of 16
4 Acronyms and Abbreviations
ACS Auto-Configuration Server
ADSL Asymmetrical Digital Subscriber Line
ADSL2+ Asymmetrical Digital Subscriber Line 2 plus
AES Advanced Encryption Standard
ATM Asynchronous Transfer Mode
BRAS Broadband Remote Access Server
CBR Constant Bit Rate
DHCP Dynamic Host Configuration Protocol
DNS Domain Name System
DoS Denial of Service
DSCP Differentiated Services Code Point
DSL Digital Subscriber Line
DSLAM Digital Subscriber Line Access Multiplexer
HSPA High Speed Packet Access
HTTP Hyper Text Transport Protocol
IP Internet Protocol
IPTV Internet Protocol Television
LAN Local Area Network
MAC Media Access Control
MER MAC Encapsulation Routing
NAPT Network Address and Port Translation
NAT Network Address Translation
NGN Next Generation Network
nrt-VBR Non-real-time Variable Bit Rate
OSS Operations Support System
PC Personal Computer
PPPoA Point-to-Point Protocol over ATM

HG630 Home Gateway Product
Description
Issue: 01 (2012-05-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. Page 16 of 16
PPPoE Point-to-Point Protocol over Ethernet
PTM Packet Transfer Mode
PVC Permanent Virtual Channel
QoS Quality of Service
RIP Routing Information Protocol
rt-VBR Real-time Variable Bit Rate
SSID Service Set Identifier
STB Set-Top Box
TKIP Temporal Key Integrity Protocol
ToS Type of Service
UBR Unspecified Bit Rate
VDSL Very High Speed Digital Subscriber Line
VDSL2 Very High Speed Digital Subscriber Line 2 plus
WEP Wired Equivalent Privacy
WLAN Wireless Local Area Network
WPA Wi-Fi Protected Access
WPS Wi-Fi Protected Setup
