Huawei eLTE2.2 eA660 Series User manual

eLTE2.2 eA660 Series CPE
User Guide
Issue 01
Date 2013-10-30
HUAWEI TECHNOLOGIES CO., LTD.

Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd. i
Copyright © Huawei Technologies Co., Ltd. 2013. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]

eLTE2.2 eA660 Series CPE
User Guide About This Document
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Overview
This document describes the hardware, functions, installation, configuration, operation and
maintenance (OM) of the eA660 series customer premises equipment (CPE).
Product Version
Product Name Product Version
eA660 Series CPE V100R001C01
Intended Audience
This document is intended for:
zSystem engineers
zProduct engineers
zTechnical support engineers
Change History
Issue 01 (2013-10-30)
This is the first commercial release.

eLTE2.2 eA660 Series CPE
User Guide Contents
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Contents
About This Document.................................................................................................................... ii
1 Overview.........................................................................................................................................1
1.1 Product Introduction ..................................................................................................................................................... 1
1.2 Application Scenarios ................................................................................................................................................... 2
1.3 Hardware Specifications............................................................................................................................................... 5
1.4 Antenna Specifications ................................................................................................................................................. 6
2 Hardware ........................................................................................................................................7
2.1 eA660 Hardware........................................................................................................................................................... 7
2.2 eA660 Cables.............................................................................................................................................................. 10
2.2.1 PoE Network Cable ................................................................................................................................................. 10
2.2.2 Ground Cable........................................................................................................................................................... 10
3 Installation....................................................................................................................................12
3.1 Installation Preparation............................................................................................................................................... 12
3.2 Installation Procedure ................................................................................................................................................. 13
3.2.1 Mounting on a Utility Pole (Without an Angle Adjusting Component)................................................................... 13
3.2.2 Mounting on a Utility Pole (with an Angle Adjusting Component) ........................................................................ 19
3.2.3 Mounting on the Wall (Without an Angle Adjusting Component)........................................................................... 26
3.2.4 Mounting on the Wall (with an Angle Adjusting Component)................................................................................. 32
3.2.5 Cable Connection..................................................................................................................................................... 38
3.3 Installation Check ....................................................................................................................................................... 42
4 Configuring the eA660 ...............................................................................................................45
5 Maintenance.................................................................................................................................46
5.1 Maintenance Preparation ............................................................................................................................................ 46
5.2 Fault Diagnosis ........................................................................................................................................................... 46

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Overview
1.1 Product Introduction
HUAWEI eA660 is a piece of customer premises equipment (CPE) that functions as the long
term evolution (LTE) wireless gateway. It implements the conversion between LTE wireless
data and wired Ethernet data and supports data backhaul. The eA660 series can be used
independently and deployed outdoors.
The eA660 supports the LTE R8 standards and provides the following services:
zData services
The eA660 series uses LTE broadband technologies to support high-speed broadband
network access, data backhaul, and video surveillance.
zSmall-scale local area network (LAN)
The eA660 series can connect to external concentrators and Ethernet switches or routers
to set up a LAN with multiple computers. When terminal devices on the LAN connect to
the eA660 using network cables, the terminal devices can provide data services.
zSecurity services
The eA660 series supports the firewall and PIN password, which protects your
computers when you access the Internet.
zFirewall services
The eA660 series supports the following firewall services:
−Firewall enabling or disabling: enables or disables firewalls.
−Media access control (MAC) address filtering: prevents certain MAC addresses from
accessing the computers on a LAN.
−IP address filtering: blocks certain IP addresses from accessing the local computers.
−URL filtering: prevents computers from accessing certain URLs.
zLocal and remote management and maintenance
The eA660 series can be locally configured in the local city to implement device
management and network configuration, thereby ensuring stable operation of the device.
Warning

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
zThis device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
zFCC Caution To assure continued compliance, any changes or modifications not
expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
zFCC Radiation Exposure Statement To comply with FCC RF exposure requirements in
section 1.1307, a minimum separation distance of 20cm is required between the antenna
and all public persons.
1.2 Application Scenarios
The eA660 provides wireless broadband and wired Ethernet data services.
The eA660 is deployed outdoors and provides wireless gateway services. The eA660 can be
deployed independently or used in conjunction with the eA100, which is deployed indoors
and connected to the eA660 using a network cable, enabling the eA660 to provide Wi-Fi and
other Internet services.
For details about the eA100, see the eLTE2.1 eA100 Series CPE Product Description.
Figure 1-1 shows an application scenario in which the eA660 is used with the eA100.

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Figure 1-1 The eA660 deployed with the eA100
The eA660 provides a variety of data services, such as LTE-TDD wireless routing and
converting LTE wireless data into wired Ethernet data, and vice versa. Figure 1-2 shows an
application scenario in which the eA660 is used in private industrial networks.
Figure 1-2 The eA660 deployed in industrial private networks
The following example describes how to use the eA660 for video monitoring.

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
1. Use a power adapter to supply power for the eA660 or video camera, as shown in Figure
1-3.
Figure 1-3 The eA660 connected to a video camera.
2. Use a network cable to connect the eA660 to an external device. If the eA660 connects
to a single device, connect the power adapter directly to the eA660. If the eA660
connects to multiple devices, connect the power adapter to a Hub or switch and then to
the eA660, as shown in Figure 1-4.

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Figure 1-4 The eA660 connected to multiple devices
1.3 Hardware Specifications
Table 1-1 describes the technical specifications of eA660.
Table 1-1 Technical specifications of eA660
Category eA660-160 eA660-135
Technical
standards
WAN: LTE R8
LAN: IEEE 802.3/802.3u
Working band LTE TDD (2300 MHz to 2400
MHz)
LTE TDD (2570 MHz to 2620
MHz)
LTE TDD (3650 MHz to 3675
MHz)
External ports 1 Ethernet interface (RJ45): 10/100Base-TX
1 USB interface
2 External antenna interface (N)
1 SIM card slot
Transmit power zLTE
23 dBm (±2)
Receiving
sensitivity
zLTE
Meets the 3GPP 36 101
standard
< -100 dBm/5 MHz
< -97 dBm/10 MHz
zLTE
Meets the 3GPP 36 101
standard
< -96 dBm/10 MHz
< -94.2dBm/20 MHz
110-240V AC

eLTE2.2 eA660 Series CPE
User Guide 1 Overview
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
Category eA660-160 eA660-135
< -94 dBm/20 MHz < -93 dBm/20 MHz
Power
consumption
< 25 W
Power supply Power over Ethernet (PoE) power supply
Dimensions (H x
W x D)
280 mm x 250 mm x 90 mm
Waterproof and
dustproof grade
IP67
Weight About 1500 g (without power adapter)
Working
temperature
-40°C to 65°C
Storage
temperature
-40°C to 70°C
Relative
humidity
5% RH to 95% RH
Installation
method
Mounted on utility poles or walls
1.4 Antenna Specifications
Table 1-2 and lists the eA660antenna's specifications.
Table 1-2 eA660 LTE antenna specifications
Item eA660-160 eA660-135
Band 2300 MHz to 2400 MHz
(LTE Band 40)
2570 MHz to 2620 MHz
(LTE Band 38)
3650 MHz to 3675 MHz
(LTE Band 43)
Input impedance 50 ohm 50 ohm
SWR < 2 < 2
Gain 13 dBi 16 dBi
Polarization Dual polarization Dual polarization
Radiation pattern Directional antenna Directional antenna

eLTE2.2 eA660 Series CPE
User Guide 2 Hardware
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
2 Hardware
2.1 eA660 Hardware
This section describes the appearance, ports, and indicators of the eA660.
Appearance
Figure 2-1 shows the appearance of the eA660.
Figure 2-1 eA660 appearance
Panel
The panel of the eA660 provides the Power over Ethernet (PoE) port, SIM card maintenance
window, and indicator.
Figure 2-2 shows the panel of the eA660.

eLTE2.2 eA660 Series CPE
User Guide 2 Hardware
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Figure 2-2 Panel of the eA660
Table 2-1 lists the ports of the eA660.
Table 2-1 Ports on the eA660
Name Description
PoE PoE port
LED Indicators
SIM card maintenance window Consists of the SIM card slot and USB port.
zA SIM card is inserted into the SIM card
slot.
zThe USB port is used for internal
commissioning.
Grounding end Connects a ground cable
Nameplate Displays the identifier information of a
vendor
Anti-scalding label Anti-scalding sign
External antenna interface NOTE
Only supports dual-polarized antenna or dual

eLTE2.2 eA660 Series CPE
User Guide 2 Hardware
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Name Description
antenna installation。
Indicators of the eA660 are below the SIM card maintenance window and are used to indicate
the running status of the eA660.
The four indicators from top to bottom are POWER, WLINK, RSSI, and HEAT, as shown
in Figure 2-3.
Figure 2-3 Indicators of the eA660
Table 2-2 describes the indicators of the eA660.
Table 2-2 Indicators of the eA660
Identifier Status Description
POWER On The power supply is normal.
Off No power is supplied.
WLINK Steady on The eA660 is successfully registered
to the network.
Blink per 1000 ms The product fails to register to the
network.
RSSI
NOTE
The blink frequency
Steady on The signal strength ranges from –40
dBm to –60 dBm.
Blink per 500 ms The signal strength ranges from –60

eLTE2.2 eA660 Series CPE
User Guide 2 Hardware
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
Identifier Status Description
of the RSSI indicator
on the panel is
determined by the
valve of the reference
signal received power
(RSRP).
dBm to –80 dBm.
Blink per 1000 ms The signal strength ranges from –80
dBm to –105 dBm.
Blink per 2000 ms The signal strength ranges from -105
dBm to -120 dBm.
Off The signal strength is equal to or
smaller than –120 dBm.
HEAT Controlled by the
hardware temperature.
When the hardware temperature is
lower than 0°C, the hardware is heated
and the indicator is on.
When the hardware temperature is
higher than 0°C, the indicator is off.
2.2 eA660 Cables
2.2.1 PoE Network Cable
The power over ethernet (PoE) network cable is a shielded network cable that is used to
connect the PoE port of the eA660. The PoE network cable connects to an RJ45 connector at
both ends.
Background Information
The PoE network cable transmits data signals to the eA660 and provides DC power for the
equipment.
Technical Specifications
Table 2-3 lists the technical specifications of the PoE network cable.
Table 2-3 Technical specifications of the PoE network cable
Name Description
Color Black
Outer diameter 6.8 mm
Working temperature range –40°C to 75°C
2.2.2 Ground Cable
The ground cable ensures the proper grounding of the eA660.

eLTE2.2 eA660 Series CPE
User Guide 2 Hardware
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Appearance
The ground cable provides a 6 mm² cross-section, is yellow-green, and has OT terminals at
both ends. Figure 2-4 shows the appearance of the ground cable.
Figure 2-4 Ground cable
Technical Specifications
Table 2-4 lists the technical specifications of the ground cable.
Table 2-4 Technical specifications of the ground cable
Name Description
Color Yellow-green
Cross-section 6 mm²
Outer diameter 5.1 mm
Working temperature range –10°C to 70°C

eLTE2.2 eA660 Series CPE
User Guide 3 Installation
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
3 Installation
3.1 Installation Preparation
Before you install the eA660, unpack and inspect the equipment delivered to the site and
prepare the related tools.
Prerequisites
Perform the following operations to inspect the goods delivered to the site:
1. Unpack the equipment, count the total number of items based on the packing list
attached to each packing case, and check whether each packing case is intact.
2. Check whether the models and quantities are consistent with those specified on the
Packing List.
3. Record the serial number of the CPE.
Installation Tools
Table 3-1 lists the tools used for installing the eA660.
Table 3-1 Installation tools
Hammer drill
ESD gloves
Vacuum cleaner
Heat gun
Phillips screwdriver
(M3–M6)
Flat-head screwdriver
(M3–M6)

eLTE2.2 eA660 Series CPE
User Guide 3 Installation
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
Claw hammer
Utility knife
Wire stripper
Power cable crimping tool
Cable cutter
Adjustable wrench (open end
≥32 mm)
Vise
Hex key (M5,M6)
Phillips torque screwdriver
Measuring tape
Multimeter
Marker (diameter ≤10 mm)
3.2 Installation Procedure
3.2.1 Mounting on a Utility Pole (Without an Angle Adjusting
Component)
Prerequisites
The eA660 and mounting components are ready, as shown in Figure 3-1 and Table 3-2.

eLTE2.2 eA660 Series CPE
User Guide 3 Installation
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
Figure 3-1 eA660 and mounting components
Table 3-2 Mounting components
No. Name
1 Mounting frame
2 Hose clamp
3 CPE
Context
Figure 3-2 shows the flowchart for mounting the eA660 on a utility pole without an angle
adjusting component.

eLTE2.2 eA660 Series CPE
User Guide 3 Installation
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Figure 3-2 Flowchart for mounting the eA660 on a utility pole without an angle adjusting
component
Procedure
Step 1 Open the SIM card maintenance window of the eA660 and insert the SIM card, as shown in
Figure 3-3.
Figure 3-3 Installing the SIM card
Figure 3-4 shows the correct installation method.

eLTE2.2 eA660 Series CPE
User Guide 3 Installation
Issue 01 (2013-10-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
16
Figure 3-4 Installation method of the SIM card maintenance window
When you install the SIM card maintenance window, insert the protrusion into the caging slot
to ensure that the SIM card maintenance window is waterproof. Do not fasten the screws until
the SIM card maintenance window has been correctly installed.
Step 2 Insert the hose clamp to the wall-mounting frame, as shown in Figure 3-5.
