Huawei HG659 User manual

HG659 Home Gateway
User Guide
HUAWEI TECHNOLOGIES CO., LTD.

I
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Ports and Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Selecting an Installation Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the HG659 on a DSL Broadband Network. . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the HG659 on an Ethernet Broadband Network . . . . . . . . . . . . . . . . . . . 5
Powering On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setting Network Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting the Computer IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Logging In to the Web Management Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting Network Access Parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wireless Connection Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Enabling and Disabling the WLAN on the HG659. . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting Up a Wireless Connection Using the WPS Button . . . . . . . . . . . . . . . . . . . 8
Manually Setting Up a Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Changing Your WLAN Name and Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Parent Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Controlling Computer Internet Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Filtering Out Inappropriate Websites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
IP Telephony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Introduction to IP Telephony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Configuring VoIP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Placing a VoIP Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
USB Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
USB Storage Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Connecting a USB Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Setting the Samba Access Permission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Accessing Data Using Samba. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Sharing a USB Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

II
IPTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Introduction to IPTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Configure IPTV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Maintenance Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the Web Management Page User Name and Password . . . . . . . . . . . 17
Restoring Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Changing the Web Management Page IP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
What Can I Do If I Cannot Open the Web Management Page? . . . . . . . . . . . . . . 19
What Can I Do If the HG659 Cannot Access the Internet through a Wireless Network
Adapter Sometimes or If the WLAN Connection Is Unsteady?. . . . . . . . . . . . . . . 19
What can I do if I cannot access the Internet? . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
I Often Need to Restart the HG659 to Display Web Pages. What Can I Do?. . . . 21
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
For More Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

1
1 Product Overview
Ports and Buttons
No. Item Description
1WPS Starts Wi-Fi protected setup (WPS) negotiation.
2WLAN Enables or disables the WLAN function.
3On/Off Powers the HG659 on or off.
4Power Connects to a power adapter.
5Reset
Restores the HG659 to its default settings after you press and hold this
button for 6 seconds or more while the HG659 is powered on.
A reset will result in all custom data and settings being lost. Use
with caution.
6DSL Connects to a DSL filter or phone socket.
7PHONE Connects to a telephone.
8LAN1 ～LAN4 Connects to Ethernet devices, such as computers, set-top boxes (STBs),
and switches.
9WAN Connects to an Ethernet device that provides Internet access, such as a
modem or switch.

2
Indicators
10 USB
Connects to a USB device.
If you connect a USB device to the HG659, verify that the input
voltage and current of the USB device does not exceed 5 V/0.65 A.
Otherwise, the HG659 may malfunction.
Indicator Status Description
Power
Steady green The HG659 is powered on.
Off The HG659 is powered off.
WAN
Blinking green A DSL connection is being activated.
Steady green A DSL connection has been set up and activated.
A WAN connection has been set up.
Off The WAN or DSL port is not connected.
No. Item Description

3
Internet
Steady green The HG659 is connected to the Internet in router
mode, but no data is being transmitted.
Blinking green The HG659 is connected to the Internet in router
mode, and data is being transmitted.
Off
> The HG659 is in router mode, but not connected to
the Internet.
> The HG659 is in bridge mode.
WLAN
Steady green The HG659 has WLAN enabled, but is not transmitting
data.
Fast Blinking
(2Hz)
The HG659 has WLAN enabled, and data is being
transmitted.
Slow Flashing
(1Hz)
The HG659 is attempting to connect to a wireless
client over the WLAN using the WPS function.
This process lasts for no longer than 120 seconds.
Off WLAN is disabled.
VoIP
Steady green The HG659 is registered with a SIP server, but no
data is being transmitted.
Blinking green The HG659 is registered with a SIP server, and data is
being transmitted.
Off The HG659 is not registered with a SIP server.
LAN1 ～LAN4
Steady green
The LAN port is connected to an Ethernet device
(such as a computer) with a network cable, but no
data is being transmitted.
Blinking green The LAN port is connected to an Ethernet device with
a network cable, and data is being transmitted.
Off The LAN port is not connected to any Ethernet device.
USB
Steady green The USB port is connected to an USB device, but no
data is being transmitted.
Blinking green The USB port is connected to an USB device, and
data is being transmitted.
Off The HG659 is not connected to any USB device.
Indicator Status Description

4
2 Hardware Installation
Selecting an Installation Location
Place the HG659 on a well-ventilated even surface without exposure to direct sunlight. For the best
possible performance, take note of the following:
> Make sure there are no obstacles, such as concrete or wooden walls, between the computer
and HG659.
> Ensure that the computer and HG659 are far from electric appliances that generate strong
magnetic or electric fields, such as microwave ovens.
Installing the HG659 on a DSL Broadband Network
In some communities, Internet service providers use telephone lines to provide broadband access
services.
If you have subscribed to digital subscriber line (DSL) broadband, you can connect the HG659 to a
telephone port for Internet access.
Connect your devices in the sequence indicated in the following figure.
When configuring the HG659 for the first time, use an Ethernet cable to connect the HG659
to a computer.
1Telephone wall jack 2Power adapter 3Splitter
4Telephone 5Set-top Box 6Laptop computer
7Desktop computer 8Smart Phone 9Pad
aLINE port bMODEM port cPHONE port

5
Installing the HG659 on an Ethernet Broadband Network
In some communities, network service providers use Ethernet interfaces as Internet interfaces. On this
network, your PC is directly connected to the Internet through the Ethernet interface provided by the
network service provider.
If you have subscribed to digital Ethernet broadband, you can connect the HG659 to an Ethernet
interface for Internet access.
Connect your devices in the sequence indicated in the following figure.
Powering On
To power on the HG659, press its power button.
After the HG659 is powered on, the HG659 indicator turns on.If the indicators do not behave as
expected, ensure that everything is plugged in correctly.
1Power adapter 2Telephone 3Set-top Box
4Network interface on the
wall 5Desktop computer 6Pad
7Smart Phone 8Laptop computer
2
1
3
4
5
6
7
8

6
3 Setting Network Parameters
Setting the Computer IP Address
Before logging in to the HG659 web management page, set the IP address of the computer that will be
used for the login.
On Windows 7
1. Choose start > Control Panel > Network and Internet > Network and Sharing Center.
2. Choose Change adapter settings. Right-click Local Area Connection and choose
Properties.
3. Double-click Internet Protocol Version 4 (TCP/IPv4).
4. Select Obtain an IP address automatically and Obtain DNS server address
automatically. Click OK.
On Windows XP
1. Choose start > Control Panel > Network and Internet Connections.
2. Click Network Connections. Right-click Local Area Connection and choose Properties
from the shortcut menu.
3. Double-click Internet Protocol (TCP/IP).
4. Select Obtain an IP address automatically and Obtain DNS server address
automatically. Click OK.
Logging In to the Web Management Page
The HG659 provides an intuitive web management page where you can view or set the HG659
parameters.
Before you log in to the HG659 web management page, ensure that the computer used for
the login is connected to the HG659 and has been configured to automatically obtain an IP
address or assigned with a static IP address.
1. Open a browser. In the address box, enter 192.168.1.1. Press Enter.
2. Enter the login user name (user by default) and password (HuaweiUser by default). Click
Log in.
To protect against unauthorized access, change the user name and password after the first
login.

7
Setting Network Access Parameters
Configuring an Automatical Connection to Access the Internet
The HG659 supports you to choose the proper connection mode automatically to access the Internet,
meaning you do not need to install dial-up software or perform dial-up operations on your computer and
just following the wizard page.
To set up an automatical connection to access the Internet:
1. Log in to the web management page.
2. On the I want to... Connect to the Internet page, choose Connect automatically, and click
Next.
The HG659 supports ADSL/ETH compliance uplink mode, meaning you can use the HG659
with a telephone port, a network interface on the wall for Internet access.
After you complete the preceding settings, check the status of the Internet indicator light. When the
Internet indicator light turns steady green, you can start browsing the Internet.
You need to perform the preceding operations on a computer once only. The next time you power on
your computer, you can browse the Internet without performing the same configurations.
Configuring a Wireless Account
After you complete the preceding settings, click Try WLAN, you will see the I want to Set Up WLAN
page used to configure the wireless account.
The default SSID and WLAN Key printed on the HG659's rear panel are unique and secure.
If you do not want to change them, just turn the WLAN switch on.
For security reasons or to make the password easy to remember, you can change the wireless network
name and password as follows:
1. On the I want to Set Up WLAN page, choose the 2.4 GHz or the 5 GHz WLAN network.
2. Enter your desired SSID (WLAN name) and WLAN password.
3. Click Save.

8
4 Wireless Connection Setup
Enabling and Disabling the WLAN on the HG659
Press the WLAN button in the HG659 to enable or disable the WLAN. To ascertain whether the WLAN
is enabled, view the WLAN indicator.
Setting Up a Wireless Connection Using the WPS Button
Push the WPS button once to quickly set up a wireless connection between the HG659 and any WPS-
capable device.
Before you set up a wireless connection using the WPS button, verify the following:
> The wireless network security mode of the HG659 is WPA2-PSK or WPA-PSK/WPA2–PSK.
> The wireless device (laptop, tablet, or mobile phone) to connect to the HG659 is WPS-
capable.
1. Press the WPS button on the wireless device to start WPS negotiation. For details, see the
user guide for the wireless device.
2. Within 2 minutes, press and hold the WPS button on the HG659 for 1 second or more. The
WPS button indicator blinks.
When the WPS button indicator on the HG659 is steady on, a connection between the HG659 and
wireless device is set up. The WPS button indicator is on for 300 seconds.
Manually Setting Up a Wireless Connection
The wireless configuration software provided by Windows is used as an example to describe how to
set up a wireless connection.
You can also use the tool built into the network adapter to set up a wireless connection. For
details, see the network adapter's user guide.
Before setting up a wireless connection, record the WLAN name and password of the HG659. The
default WLAN name and password are printed on the HG659 cover label.
On Windows 7
1. Choose start > Control Panel > Network and Internet > Network and Sharing Center >
Change adapter settings. Right-click Wireless Network Connection, and select
Connect/Disconnect.
2. From the wireless network list, select the WLAN provided by the HG659. Click Connect.
3. In the displayed dialog box, enter the WLAN password and click OK.
4. In the wireless network list, check the WLAN connection status. If the status is Connected,
the computer is wirelessly connected to the HG659.

9
On Windows XP
1. Choose start > Control Panel > Network and Internet Connections > Network
Connections. Right-click Wireless Network Connection and choose View Available
Wireless Networks from the shortcut menu.
2. From the wireless network list, select the WLAN provided by the HG659. Click Connect.
3. In the displayed dialog box, enter the WLAN password and click Connect.
4. In the wireless network list, check the WLAN connection status. If the status is Connected,
the computer is wirelessly connected to the HG659.
Changing Your WLAN Name and Password
WLAN access requires the WLAN name and password. To improve your WLAN security, regularly
change your WLAN name and password.
1. Log in to the web management page.
2. In the navigation tree, choose Home Network > WLAN Settings.
3. On the Basic Settings page, enable your WLAN, and click Save.
4. On the WLAN Encryption page, enter your desired WLAN SSID and Key, and click Save.

10
5 Parent Control
Controlling Computer Internet Access
Your HG659 provides time control function. With this function, you can set limits on the duration of
Internet usage. you can confine Internet access to specific computers or deprive specific computers of
Internet access.
1. Log in to the web management page.
2. In the navigation tree, choose Internet > Parental Control > Time Rules.
3. Click New time rule.
4. In Rule name, enter a new rule name you specified.
5. In Times allowed, set the time range that allowed to access the Internet.
6. Select the device you want to control.
7. Click Save.
Filtering Out Inappropriate Websites
Use URL filtering to prevent certain websites from being accessed.
1. Log in to the web management page.
2. In the navigation tree, choose Internet > Parental Control > URL Filter.
3. Click New URL filter.
4. In URL, enter the website address you specified.
5. Select Manage devices manually, and select the device you want to apply to.
6. Click Save.

11
6 IP Telephony
Introduction to IP Telephony
IP telephony, namely voice over Internet Protocol (VoIP), is also called broadband telephony or
Internet telephony. It utilizes Internet Protocol (IP) network technologies to implement voice
communication. During a VoIP call, voice signals are digitized, encoded, packetized, and transmitted
as packets over a network. On the receiving side, the packets are then decoded, and digital signals
are converted to reproduce the original voice streams, which can be heard by the called party. Different
from traditional PSTN calls, VoIP calls are transported over IP networks, meaning voice streams are
transmitted over users' existing broadband Internet. This makes full use of broadband resources.
Configuring VoIP
The HG659 supports VoIP. You can place VoIP calls after your phone is connected to the Phone port
on the HG659.
To use the HG659 to place VoIP calls, ask your network service provider to activate VoIP services for
you. By default, your network service provider will have all related parameters, such as the VoIP
account and address, set for you. You will not need to configure any settings to place VoIP calls.
To configure voice services, do as follows:
1. Configure a VoIP provider.
a) Choose Telephony > VoIP to display the VoIP provider page.
b) Click New VoIP provider.
c) Enter the VoIP provider name provided by the service provider.
d) Enter the IP address or name of the SIP registrar server provided by the service provider
in the Primary registrar text box.
e) Enter the port number of the SIP registrar server provided by the service provider in the
primary registrar Port text box. If the service provider does not provide the port number,
the default value should be used.
f) Enter the IP address or name of the SIP proxy server provided by the service provider in
the Primary proxy text box.
g) Enter the port number of the SIP proxy server provided by the service provider in the
primary proxy Port text box.
h) Enter the home domain name of the SIP user in the SIP domain box.
i) Click Save to save the settings.
2. Configure a VoIP number.
a) Choose Telephony > VoIP > VoIP Numbers to display the VoIP configuration page.
b) Select the VoIP provider name from the drop-down list box.
c) Click New number.
d) Enter the SIP phone number.
e) Enter the SIP user name and password.
f) Click Save to save the settings.

12
3. Associate your telephone to the VoIP number.
a) Choose Telephony > Telephone to display the telephony page.
b) Associate your telephone to the VoIP number.
c) Click Save to save the settings.
Placing a VoIP Call
Once your network service provider has activated VoIP services for you, you will be assigned a VoIP
account, which is also your VoIP call number.
Before placing a VoIP call, ensure that the HG659 has connected to the network. When the call is
established, your VoIP call number is displayed on the called party's phone.
For VoIP call tariffs, contact your network service provider.

13
7 USB Device
USB Storage Device
USB storage devices use their USB ports to exchange data with other devices.
You can connect a USB storage device to your HG659 and access the USB device from your
computer.
Both the USB drive and removable hard disk can connect to your HG659.
Your HG659 supports the following file systems for reading and writing.
> FAT32/FAT
> NTFS
Connecting a USB Device
After you connect a USB device to your HG659, computers or other devices connected to the HG659
network can access and share the data in or applications provided by the USB device.
If you connect a USB device to the HG659, verify that the input voltage and current of the
USB device does not exceed 5 V/0.65 A. Otherwise, the HG659 may malfunction.
You can connect the following USB devices to your HG659:
> USB storage device
> USB printer
Setting the FTP Access Permission
To avoid unauthorized access to the USB storage device, you can set the FTP access permission on
your HG659. This allows only authorized users to access the USB storage device.
Accessing to FTP Server Through the User Name and Password
1. Connect the portable storage device to the HG659's USB port.
2. Enable the FTP server.
a) Log in to the web management page.
b) Choose Share > Storage Share.
c) In Service Settings, select Enable FTP for FTP server.
d) Click Save to save the settings.
3. Set the user name and password of the portable storage device.
a) In User Settings, click Add USB storage user.
b) In Username and Password, enter a user name and password for the FTP server, and
re-enter the password to confirm it.
c) In Directory mode, choose a file sharing path.
d) In Privilege, select the desired right.
e) Click Save to save the settings.

14
Accessing to FTP server Anonymously
1. Connect the portable storage device to the HG659's USB port.
2. Enable the FTP server.
a) Log in to the web management page.
b) Choose Share > Storage Share.
c) In Service Settings, select Enable FTP for FTP server.
d) Click Save to save the settings.
3. Enable anonymous users.
a) In FTP Anonymous Users, select Enable anonymous users.
b) In Directory mode, choose a file sharing path.
c) In Privilege, select the desired right.
d) Click Save to save the settings.
Accessing a USB Storage Device Using FTP
You can access a USB storage device through the FTP server.
To access a USB storage device using FTP, connect the USB storage device to your HG659 and set
the FTP login parameters.
1. Open a browser on your computer.
2. In the address box, enter ftp://192.168.1.1. Press Enter.
3. In the Login dialog box, enter the login user name and password your set in the HG659's
Storage Share page (Anonymous users select the anonymous directly). Click Login.
Once you pass the authentication, the directory of and files in the USB storage device will be displayed.
Setting the Samba Access Permission
To prevent unauthorized users from accessing data stored in USB devices, you can set the Samba
access permission for the HG659. After this permission is set, only authorized users can access data
stored in USB devices.
1. Connect the portable storage device to the HG659's USB port.
2. Enable the samba server.
a) Log in to the web management page.
b) Choose Share > Storage Share.
c) In Service Settings, select Enable SAMBA for samba server.
d) Click Save to save the settings.
3. Set the user name and password of the portable storage device.
a) In User Settings, click Add USB storage user.
b) In Username and Password, enter a user name and password for the samba server,
and re-enter the password to confirm it.
c) In Directory mode, choose a file sharing path.
d) In Privilege, select the desired right.
e) Click Save to save the settings.

15
Accessing Data Using Samba
Using Samba, you can securely and easily access data stored in USB devices by accessing shared
network directories.
You have connected a USB device to the HG659 and set its access permission.
1. On your computer, open a browser.
2. Enter \\192.168.1.1 in the address box, and then press Enter.
If the access permission of the USB device is set, your identity will be authenticated. During the
authentication, follow the onscreen instructions. When the authentication is successful, you will be able
to access data stored in the USB device.
Sharing a USB Printer
HG659 supports USB printers. After you connect a USB printer to your HG659 through the USB port,
you can access the printer from the Internet or internal network.
1. Connect the USB cable of the printer to the USB port on the HG659.
2. Add a Network Printer.
On Windows 7
1. Choose start > Devices and Printers.
2. Choose Add a printer.
3. Choose Add a network, wireless or Bluetooth printer.
4. Click The printer that I want isn't listed.
5. Choose Select a shared printer by name and enter the printer address http://
192.168.1.1:631/printers/myprinter in the text box. myprinter is the customized name of the
printer to add. Click Next.
6. Select the model of the printer you want or click Have Disk to manually install the printer
drive.
7. Click OK.
On Windows XP
1. Choose start > Printers and Faxes.
2. Choose Add a printer.
3. In the Add Printer Wizard dialog box, click Next.
4. Choose A network printer, or a printer attached to another computer and click Next.
5. Choose Connect to a printer on the Internet or on a home or office network and enter
the printer's address http://192.168.1.1:631/printers/myprinter in the URL text box.
myprinter is the customized name of the printer to add. Click Next.
6. Select the model of the printer you want or click Have Disk to manually install the printer
drive. Click Next.
7. Determine whether to set the printer as the default printer. Click Next.
8. Click Finish.
After you complete the preceding settings, open the files you want to print on your computer. Then you
can choose the printer just installed to print your files.

16
8 IPTV
Introduction to IPTV
Internet Protocol Television (IPTV) is digital television delivered on your television (and not PC)
through high speed internet (broadband) connection. In this service, channels are encoded in IP format
and delivered to the TV through a set top box.
Configure IPTV
The HG659 supports IPTV. You can watch IPTV from your network service provider after your STB is
conneced to the LAN port on the HG659.
To use the HG659 to watch IPTV, ask your network service provider to activate IPTV services for you.
By default, your network service provider will have all related parameters, such as the VLAN id, internet
account and password, set for you.
To configure IPTV services, do as follows:
1. Log in to the web management page.
2. Choose Internet > IPTV Service.
3. In IPTV Setup, select Enable IPTV.
4. In Access type, select your IPTV access type.
5. In LAN Interface, select a LAN port for IPTV service.
6. In Connection type, select your IPTV connection type.
7. In VPI/VCI, enter the VPI and VCI parameters provided by your network service provider.
8. Enable the VLAN and enter the VLAN id provided by your network service provider.
If your network service provider doesn't provide the VLAN, you don't need to enable the
VLAN.
9. Click Save.

17
9 Maintenance Guide
Changing the Web Management Page User Name and Password
The correct user name and password are required to log in to the web management page. Regular
changes to the web management page user name and password can effectively prevent unauthorized
users from logging in and modifying important parameters.
1. Log in to the web management page.
2. In the navigation tree, choose Maintain > Account Management.
3. Click Edit.
4. In New username, enter the new user name you specified.
5. In Current password, enter the currently used password.
6. In New password, enter the new password you specified. In Confirm password enter the
new password again.
7. Click Submit.
When modify password successfully, this page will jump to the login page, enter the new user
name and password to log in.
If you forget the password , you can press and hold the Reset button for 6 seconds or more,
then the user name and password of the Web management page will back to factory value.
This operation will make your own configuration data lost, please perform this operation with
caution.
Restoring Default Settings
Using the Configuration Tool
If the HG659 parameter settings were configured incorrectly, log in to the web management page to
reload the default configuration file and restore the HG659 to its default settings. Perform this operation
with caution. After the HG659 is restored to its default settings, all custom data and settings will be lost,
and the password will be restored to HuaweiUser.
1. Log in to the web management page.
2. In the navigation tree, choose Maintain > Device Management.
3. In Factory Restore, click Reset.
4. In the displayed dialog box, click OK.
Using the Reset Button
If you forget the login password to the web management page or could not access the web
management page, use the Reset button on the HG659 rear panel to restore the HG659 to its default
settings. Perform this operation with caution. After the HG659 is restored to its default settings, all
custom data and settings will be lost, and the password will be restored to HuaweiUser.
