Huawei EchoLife HG8245 User manual

Quick Start
EchoLife HG8245 GPON Terminal

Huawei Proprietary and Condential
Copyright © Huawei Technologies Co., Ltd.
EchoLife HG8245 GPON Terminal
V100R002C06
Quick Start
Issue 01
Date 2011-06-30
BOM number 31505131

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support.
Please feel free to contact our local ofces or headquarters.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Web site: http://www.huawei.com
Tel: [phone] 4008302118
Fax: [phone]
Email: [email protected]
Huawei Proprietary and Condential
Copyright © Huawei Technologies Co., Ltd.
Copyright © Huawei Technologies Co., Ltd. 2011.All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without
prior written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their
respective holders.
Notice
The information in this document is subject to change without notice. Unless otherwise stated, this
guide serves only as a guide. All statements, information, and recommendations in this document
do not constitute a warranty of any kind, expressed or implied.
Changes or modications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.

Safety Precautions
Basic Requirements
�Keep the device dry when it is stored, transported, and used.
�Prevent any violent collision when the device is stored, transported, and
used.
�Install the device in strict compliance with the requirements of the supplier.
�Do not disassemble the device without permission. In the case of a
device fault, contact the authorized service center.
�Do not change the structure, safety design, or performance design of
the device without prior authorization.
�Observe relevant laws and regulations and respect legal rights of others
when using the device.
Environmental Requirements
�Install the device in a well-ventilated environment that is free from direct
sunlight.
�Keep the device clean and free from dust.
�Keep the device away from water sources or damp areas.
�Do not place any object on the device, so that the device will not be
damaged due to overheating or deformation.
�Reserve a space of at least 10 cm above and around the device for heat
dissipation.
�During the installation, keep the device away from heat sources or
exposed fire sources such as electric heaters and candles.
�During the installation, keep the device away from electric appliances
that generate strong magnetic or electric fields, such as microwave
ovens, refrigerators, and mobile phones.
Instructions for Cleaning
�Before cleaning the device, stop the device, switch off the power, and
disconnect all cables, including the power cable, optical fiber, and
network cable.
�Use a clean, soft, and dry cloth to clean the shell of the device. Do not
use any cleaning agent or spray to clean the shell of the device.
To use the device properly and safely, read the safety precautions carefully before using the
device and strictly observe these precautions when using the device.
1

Safety Precautions
Instructions for Use
�Use only the accessories delivered or recommended by the supplier, for
example, the power adapter and battery.
�The power supply voltage of the device must meet the requirements for
the input voltage of the device.
�Keep the power plug clean and dry to prevent electric shocks or any
other hazard.
�Dry your hands before connecting or disconnecting cables.
�Stop the device and switch off the power before connecting or
disconnecting cables.
�Switch off the power and disconnect all cables, including the power
cable, optical fiber, and network cable, during periods of lightning
activities.
�Switch off the power and then remove the power plug if the device is
to be unused for a long time.
�Prevent water or other liquid from entering the device. If any liquid
enters the device accidentally, immediately switch off the power and
disconnect all cables, including the power cable, optical fiber, and
network cable. In the case of a device fault, contact the authorized
service center.
�Do not crush, pull, drag, or excessively bend the cables as doing so may
damage the device and cause the device to malfunction.
�Do not use damaged or deteriorating cables.
�Do not look into the optical port without eye protection.
�If an abnormality occurs, for example, smoke, unusual sound, and smell,
stop the device immediately, switch off the power, disconnect all cables
(such as the power cable, optical cable, and network cable) to the
device, and contact the authorized service center.
�Prevent objects, such as metal, from entering the device through the
heat dissipation hole.
�Do not scratch or abrade the shell of the device. Otherwise, the fallen
coating may lead to device abnormalities (such as short-circuit) and
bodily allergy.
�Keep the device out of the reach of children as the components or
accessories may be swallowed.
�Keep the running device at least 20 cm away from the human body.
Environmental Protection
�Dispose of the device or batteries properly and hand them over to the
certied recycling station.
�Dispose of the packing materials, expired batteries, and old or
abandoned devices in accordance to local laws and regulations
(recycling them is strongly recommended).
2

3
After opening the product packaging, check each item against the following checklist.
Contact the supplier if there are any discrepancies.
GPON terminal Power adapter
Quick Start Network cable
Packing List
NOTE
The gures shown in this document may differ from the actual products, but the difference
does not affect the functions of the products.

4
Product Overview
Appearance and ports of the HG8245
1Optical port 2Ethernet port 3POTS port
4Power switch 5Power port 6Indicator
7Backup battery monitoring port 8USB port 9WLAN switch
10 WPS switch 11 RESET

5
Installing the GPON Terminal
NOTE
1. HG8245 can be mounted onto a wall or be placed on a workbench.
2. Other installation modes are not allowed.
Perform the following operations to mount HG8245 onto the wall.
Step 1 Mark the positions of two holes, keeping the holes 72 mm from each other.
Step 2 Select a proper drill according to the outer diameter of the screws. Use a
hammer drill to drill the marked positions on the wall. Then clean the wall and
install two expansion bolts.
Step 3 Use a screwdriver to fasten the screws into the expansion bolts, leaving the
heads of the screws 3 mm over the wall. Then install the GPON terminal to the
screws.
Place the GPON terminal on the workbench.

6
Connecting Cables
Cable Connections Between the HG8245 and Other Devices
1Optical port in the wall 2PC 3IP STB
4TV set 5Phone 6Fax machine
7Power socket 8Backup battery unit 9USB storage device
10 Wi-Fi terminal

7
Step 1 Use an optical fiber to connect the OPTICAL port on the GPON terminal to
the optical port in the wall.
Step 2 Use a network cable to connect the LAN port to a PC or the Ethernet port on
the IP STB.
Step 3 Use a phone line to connect the TEL port to a phone or fax machine.
Step 4 Use a power adapter to connect the POWER port to the power socket.
Step 5 Use a USB data cable to connect the USB port to the USB storage device.
Step 6 Press the ON/OFF power switch.
Step 7 Press the WLAN switch to enable the Wi-Fi access function. By default, this
function is enabled.
Step 8 Press the WPS switch to enable the WPS encryption function.
NOTE
Connecting Cables
Refer to the preceding cable connections of each product and select the following
corresponding steps to connect the GPON terminal.
NOTE
The optical connector connected to the OPTICAL port on the HG8245 is an SC/APC
connector, and the type of the optical connector connected to the optical port in the
wall is determined by practical conditions.
The preceding figure connects the power adapter as an example. When the backup
battery unit is used, a power monitoring cable is used for connecting the BBU port
to the monitoring port of the backup battery unit. This allows the GPON terminal to
monitor the backup battery unit. For details on how to use the backup battery unit, see
the usage guide to the backup battery.
NOTE
Before enabling the WPS encryption function of a GPON terminal, ensure that the
function is set in the system software in advance. After successful setting, press the
WPS switch for the settings to take effect.
NOTE
The Ethernet port on the HG8245 is a 10/100/1000M Base-T Ethernet port.

8
Step 1 Set the IP address of the PC in the same subnet 192.168.1.64 – 192.168.1.253.
Example:
- IP address: 192.168.1.100
- Subnet mask: 255.255.255.0
Step 2 Enter the management IP address of the GPON terminal in the address box of
Internet Explorer and press Enter. The login window is displayed.
Step 3 In the login window, select your preferred language, enter the user name
and password (default user name is TELMEX and default password is
WEP Key), and click Login. After the password is authenticated, the Web
configuration window is displayed.
Logging in to the Web Conguration Window
Perform the following steps to log in to the Web configuration window of a GPON
terminal.
NOTE
The default management IP address and subnet mask of the GPON terminal are as
follows:
- IP address: 192.168.1.254
- Subnet mask: 255.255.255.0

Indicator Description
9
Indicator Status Description
WPS
Steady on The WPS function is enabled.
Blinking A Wi-Fi terminal is connecting to the system.
Off The WPS function is disabled.
WLAN
Steady on The WLAN function is enabled.
Blinking Data is being transmitted.
Off The WLAN function is disabled.
USB
Steady on The USB port is already connected but no data is transmitted.
Blinks twice a
second Data is being transmitted.
Off The system is not powered on or the USB port is not connected.
TEL1 – TEL2
Steady on The connection between the TEL port and the voice server has
been set up.
Blinks twice a
second
The connection between the TEL port and the voice server is
set up and the phone is in the off-hook or ringing state.
Blinks once
two seconds The TEL port is registering with the voice server.
Off The connection between the TEL port and the voice server is
not set up.
LAN1 – LAN4
Steady on The Ethernet connection is in the normal state.
Blinking Data is being transmitted on the Ethernet port.
Off The Ethernet connection is not set up.
INTERNET
Steady on The internet connection is in the normal state.
Blinks once
two seconds The terminal is connecting to the internet.
Off The internet connection is not set up.
PON See Table 2.
POWER
Steady green The terminal is powered on.
Steady yellow The backup battery is supplying power.
Off The power supply is cut off.
Table 1 Indicator status description 1
NOTE
In the preceding table, if the indicator status is blinking but the duration is not specied, the
blinking duration of the indicator is determined by the transmitted data trafc.

10
Table 2 Indicator status description 2
Indicator Description
Indicator Status Description
PON
Green steady on The fiber connection between the terminal and the uplink
device is set up.
Green blinking The terminal attempts to set up a connection with its upper-
layer device.
Red steady on The fiber connection between the terminal and the uplink
device is interrupted.
Red blinking The terminal is a rogue terminal.
PON is GPON indicator. The status of PON reflects the connection between GPON
terminal and its upper-layer device. The following table describes the status of the PON
indicator.
NOTE
If the indicator is in the state described in No. 4, that is, the terminal is a rogue terminal, contact
the service provider immediately.

11
FAQs
The POWER indicator Is off.
�Check whether the ON/OFF button on the rear plane is depressed.
�Ensure that the power adapter matches the GPON terminal.
�Check whether the power supply is connected properly.
The LAN indicator is off.
�Ensure that the network cable matches the GPON terminal.
�Check whether the network cable is properly connected.
�Check whether the network adapter works in the normal state.
The TEL indicator is off.
�Check whether a voice service user is configured and enabled.
The WPS indicator is off.
�Check whether the WPS function is enabled.
The WLAN indicator is off.
�Check whether the WLAN function is enabled.
The USB indicator is off.
�Check whether the USB device is properly connected.
The phone does not ring upon an incoming call but communication
is in normal state when the phone is in the off-hook state.
�The GPON terminal provides a maximum of 60 V AC ringing current voltage. Check
whether the ringing current voltage of the phone is higher than 60 V AC. If it is
higher than 60 V AC, replace it with another phone.
How can I reset the GPON terminal?
�Press RESET by using a needle-type object to reset the GPON terminal.
How can I restore factory defaults?
�Press RESET by using a needle-type object for longer than 10s to restore factory
defaults and reset the GPON terminal. If the indicator is off and then is lit, the
system is reset successfully.

12
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
&$87,21
Item HG8245
Dimensions(H x W x D) 195mm×174mm×34mm
Weight (including the power adapter) About 550g
System power supply 11V – 14V DC, 2A
Power adapter input 100V – 240V AC 50Hz – 60Hz
Maximum system power consumption 14W
Ambient temperature 0oC – +40oC
Ambient humidity 5% – 95%(non-condensing)
Technical Specications
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.

User Information
Personal or company's full name: __________________________________________________
Address/Postal Code: ____________________________________________________________
Telephone: ____________________________________________________________________
Email: ________________________________________________________________________
Product Type: __________________________________________________________________
Product Serial Number: __________________________________________________________
Purchase Date: _________________________________________________________________
Invoice Number: ________________________________________________________________
Dealer's Name: _________________________________________________________________
Dealer's Address: _______________________________________________________________
Dealer's Telephone: _____________________________________________________________
Warranty Card
Thank you for choosing Huawei Technologies Co., Ltd.To get better services, please
read this warranty card carefully, ll in the required information, and preserve this
card in good condition.
Preserve well. No reissue.
Dealer's Seal

Limited Warranty
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Code: 518129
Web site: http://www.huawei.com
Subject to the exclusions contained below, Huawei Technologies Co., Ltd. (Huawei
for short) warrants its access terminals ("Products") to be free from defects in
materials and workmanship under normal consumer usage for one year from
the date of purchase of the product ("Warranty period"). During the warranty
period, a Huawei authorized service partner shall remedy defects in materials and
workmanship free of charge.
Special Notice:
1. The warranty card shall be applicable only after being stamped by the dealer.
2. The warranty card must be preserved in good condition and free of any scratch
or alteration.
3. To claim such service for defects that are not included in the following exclusion
terms, the warranty card and the invoice that records that product serial number
shall be presented to a Huawei authorized service partner.
Exclusions:
In any of the following cases, the warranty card becomes unenforceable or
inapplicable without prior notice:
1. The defects are caused by improper handling in transportation and assembly.
2. The defects are caused by the fact that the product is dismantled or altered by
anyone that is not from a Huawei authorized service partner.
3. The defects are caused by the fact that the product is used in a harsh
environment that is not suitable for the operation of the product.
4. The defects are caused by any force majeure including but not limited to re,
earthquake, lightning, and tsunami.
5. The defects are caused by the fact that the product is used or handled
incorrectly, roughly or not as instructed in the applicable User Guide.
6. The normal wear and tear, including but not limited to the normal wear and tear
of the shell and the power module, shall not be covered by the limited warranty.
7. The warranty card is altered or illegible, or the product serial number recorded
on the warranty card is inconsistent with the actual one imprinted or labeled on
the product.
In any case that is not covered by this limited warranty or should the warranty
expire, Huawei shall charge for the service(s) claimed for the products if the product
is still remediable. Huawei reserves all rights to interpret this limited warranty.

Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Web site: http://www.huawei.com
Qualification Card
PASS
