Huawei TP48200A-HT15D3 User manual

TP48200A-HT15D3 Outdoor Power System
(Russia, Megafon)
User Manual
Issue
02
Date
2019-02-26
HUAWEI TECHNOLOGIES CO., LTD.

Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://e.huawei.com

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
About This Document
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Overview
This document describes the DC power system in terms of product introduction, component
introduction, and system maintenance.
The figures of this document are for reference only.
Intended Audience
This document is intended for:
Sales engineers
Technical support engineers
Maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Description
Indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided, could
result in equipment damage, data loss, performance deterioration, or
unanticipated results.
NOTICE is used to address practices not related to personal injury.
Calls attention to important information, best practices and tips.
NOTE is used to address information not related to personal injury,
equipment damage, and environment deterioration.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
About This Document
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
iii
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 02 (2019-02-26)
Optimized the content of the document.
Issue 01 (2014-08-20)
This issue is the first official release.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
Contents
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Safety Precautions.........................................................................................................................1
1.1 General Safety ..............................................................................................................................................................1
1.2 Electrical Safety............................................................................................................................................................2
1.3 Battery Safety ...............................................................................................................................................................3
1.4 Cable Layout.................................................................................................................................................................4
1.5 Mechanical Safety ........................................................................................................................................................4
2 Overview.........................................................................................................................................7
2.1 Overview ......................................................................................................................................................................7
2.2 Model Number Description ..........................................................................................................................................8
2.3 Features.........................................................................................................................................................................9
2.4 Working Principles........................................................................................................................................................9
2.5 Configurations ............................................................................................................................................................10
3 Components .................................................................................................................................12
3.1 Interior........................................................................................................................................................................12
3.2 PDU............................................................................................................................................................................14
3.2.1 Battery Switch .........................................................................................................................................................15
3.3 Rectifier ......................................................................................................................................................................15
3.4 SMU02B.....................................................................................................................................................................17
3.5 UIM02C......................................................................................................................................................................20
3.6 Heater..........................................................................................................................................................................24
3.7 TCU ............................................................................................................................................................................25
3.7.1 Heat Exchanger........................................................................................................................................................25
3.7.2 TEC..........................................................................................................................................................................26
3.8 (Optional) Intelligent Battery Detector.......................................................................................................................30
3.9 Sensor and Lamp ........................................................................................................................................................34
3.9.1 Smoke Sensor ..........................................................................................................................................................34
3.9.2 Temperature and Humidity Sensor ..........................................................................................................................34
3.9.3 Water Sensor............................................................................................................................................................35
3.9.4 Battery Temperature Sensor.....................................................................................................................................36
3.9.5 Temperature Sensor for the Equipment Compartment.............................................................................................36
3.9.6 Door Status Sensor...................................................................................................................................................36

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
Contents
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
v
3.9.7 (Optional) Light.......................................................................................................................................................37
4 Maintenance.................................................................................................................................38
4.1 Routine Maintenance..................................................................................................................................................38
4.2 Rectifying Common Faults.........................................................................................................................................39
4.2.1 AC Failure................................................................................................................................................................39
4.2.2 AC Over Volt ...........................................................................................................................................................40
4.2.3 AC Under Volt .........................................................................................................................................................40
4.2.4 DC Over Volt ...........................................................................................................................................................40
4.2.5 DC Under Volt .........................................................................................................................................................41
4.2.6 Batt Chg. Overcur....................................................................................................................................................41
4.2.7 LLVD Disconnected ................................................................................................................................................41
4.2.8 BLVD Disconnected................................................................................................................................................42
4.2.9 Batt Loop Trip..........................................................................................................................................................42
4.2.10 High Amb. Temp....................................................................................................................................................42
4.2.11 Low Amb. Temp. ...................................................................................................................................................43
4.2.12 High Amb. Humi. ..................................................................................................................................................43
4.2.13 Low Ambient Humidity.........................................................................................................................................44
4.2.14 Batt. High Temp.....................................................................................................................................................44
4.2.15 Batt. Low Temp. ....................................................................................................................................................44
4.2.16 Door Alarm............................................................................................................................................................45
4.2.17 Water Alarm...........................................................................................................................................................45
4.2.18 Smoke Alarm .........................................................................................................................................................45
4.2.19 Rect Fault...............................................................................................................................................................46
4.2.20 Rect Protection.......................................................................................................................................................46
4.2.21 Rect Comm Fault...................................................................................................................................................46
4.2.22 AC SPD Fault ........................................................................................................................................................47
4.2.23 DC SPD Fault ........................................................................................................................................................47
4.3 Identifying Component Faults ....................................................................................................................................47
4.3.1 Identifying AC SPD Faults ......................................................................................................................................47
4.3.2 Identifying Circuit Breaker Faults ...........................................................................................................................47
4.3.3 Identifying Rectifier Faults......................................................................................................................................47
4.3.4 Identifying SMU Faults ...........................................................................................................................................48
4.4 Parts Replacement ......................................................................................................................................................48
4.4.1 Replacing a Rectifier ...............................................................................................................................................48
4.4.2 Replacing an AC SPD Module ................................................................................................................................50
4.4.3 Replacing a Circuit Breaker.....................................................................................................................................51
4.4.4 Replacing the PCB of UIM02C...............................................................................................................................52
4.4.5 Replacing an SMU...................................................................................................................................................54
4.4.6 Replacing the Internal Fan of the Heat Exchanger ..................................................................................................55
4.4.7 Replacing the External Fan for the Heat Exchanger................................................................................................57
4.4.8 Replacing the Heat Exchanger Core........................................................................................................................59

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
Contents
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
vi
4.4.9 Replacing the TCUA Control Board........................................................................................................................61
4.4.10 Replacing the TEC.................................................................................................................................................64
4.4.11 Replacing the Heater..............................................................................................................................................67
4.4.12 Replacing a Smoke Sensor ....................................................................................................................................68
4.4.13 Replacing a Door Status Sensor.............................................................................................................................69
A Technical Specifications...........................................................................................................71
A.1 Environment Specifications.......................................................................................................................................71
A.2 Electrical Specifications.............................................................................................................................................71
A.3 EMC Specifications...................................................................................................................................................73
A.4 Cabinet Specifications ...............................................................................................................................................73
A.5 Rectifier Specifications..............................................................................................................................................74
A.6 Heater Specifications .................................................................................................................................................74
A.7 Intelligent Battery Detector Specifications ................................................................................................................75
A.8 Lamp Specifications ..................................................................................................................................................75
B Electrical Conceptual Diagram ................................................................................................76
C Associations Between Alarms and Dry Contacts on the UIM...........................................77
D Cables Connection of TCUA Control Board ........................................................................78
E Acronyms and Abbreviations ..................................................................................................79

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety Precautions
1.1 General Safety
Ensure that the product is used in an environment that meets the product design
specifications such as the grid power, input voltage, temperature, and humidity. Using
the product in an incompatible environment may cause malfunctions, damage
components, or invalidate the warranty.
Follow the precautions and special safety instructions provided by Huawei when
operating this product. Personnel who plan to install or maintain Huawei equipment must
receive thorough product training, understand all necessary safety precautions, and be
able to correctly perform all operations. Huawei will not be liable for any consequences
that are caused by the violation of general safety regulations and equipment usage safety
standards.
The upstream power distribution box for the cabinet should be equipped with a
protection switch that has the same specifications as or higher specifications than the
input switch of the cabinet.
Comply with local laws and regulations. The safety instructions in this document are
only supplemental to local laws and regulations.
Do not operate the product or handle cables during thunderstorms.
Do not expose the equipment to flammable or explosive gas or smoke. Keep batteries
away from strong infrared radiation, organic solvents, and corrosive gas.
Do not use water to clean the product's internal or external electrical components.
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to
telecommunication network voltage (TNV) circuits.
Do not place any irrelevant objects on batteries.
Before using the product, remove any conductors such as jewelry or watches.
Use insulated tools for all operations that involve electrical connections.
Bolts should be tightened with a torque wrench and marked using red or blue color.
Installation personnel mark tightened bolts in blue. Quality inspection personnel confirm
if the bolts are tightened and then mark them in red.
Follow specified procedures during installation and maintenance. Do not attempt to alter
the product or deviate from the recommended installation procedures without prior
consent from the manufacturer.
Disconnect the AC power supply before maintaining AC power distribution.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
2
Measure contact point voltage with a multimeter before handling a conductor surface or
terminal. Ensure that the contact point has no voltage or the voltage is within the
specified range.
When installing or removing power cables, ensure that the corresponding circuits are
disconnected to prevent electric arcs or sparks.
IfAC input power cables need to be routed from the top, bend the cables in a U shape
outside the cabinet and then route them into the cabinet.
Performing maintenance or replacing components may interrupt power to the loads if
batteries are not connected or the battery reserve is insufficient. Ensure that the switches
for primary loads are in the ON position and do not turn off the battery switch and the
AC input switch at the same time.
Cables stored at subzero temperatures must be stored at room temperature for at least 24
hours before they are laid out.
Perform routine maintenance as described in this manual; replace faulty components at
the earliest.
After maintenance is completed, lock cabinet doors and seal cable holes to prevent
rodents from entering the cabinet.
1.2 Electrical Safety
Grounding
When installing a device, install the ground cable first. When uninstalling a device,
remove the ground cable last.
Before operating a device, ensure that the device is properly grounded. Ensure that the
ground cable is installed securely (the ground resistance should be less than 0.1 ohm).
Inappropriate grounding may cause device damage and personal injury.
AC and DC Power
The power system is powered by high-voltage power sources. Direct or indirect contact
(through damp objects) with high-voltage power sources may result in serious injury or
death.
Non-standard and improper operations may result in fire or electric shocks.
Before making electrical connections, turn off the protection switch on the upstream
device to cut the power supply.
Before connecting theAC power supply, ensure that electrical connections are complete.
Before connecting cables to loads or battery cables, check cable and terminal polarities
to prevent reverse connections.
ESD
To prevent electrostatic-sensitive components from being damaged by static from human
bodies, wear a grounded electrostatic discharge (ESD) wrist strap or ESD gloves when
touching circuit boards.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
3
When holding a board, hold its edge without touching any components, especially chips.
Package boards with ESD packaging materials before storing or transporting them.
Liquid Prevention
Do not place the product in areas prone to water leakage, such as near air conditioner
vents, ventilation vents, or feeder windows of the equipment room.
Ensure that there is no condensation inside the product or equipment room.
Ensure that no liquid enters the product. Otherwise, short circuits will occur and may
result in serious injury or death.
If any liquid is detected inside the product, immediately disconnect the power supply and
contact the administrator.
1.3 Battery Safety
Before installing, operating, or maintaining the batteries, read the battery manufacturer's
safety instructions. Observe the safety precautions provided in this section, which are
supplemental to the safety instructions provided by the battery manufacturer.
Basic Requirements
Avoid skin contact with battery electrolyte. Before handling batteries, wear goggles,
rubber gloves, and protective clothing.
When handling a battery, ensure that its electrodes always point upward. Do not tilt or
overturn batteries.
Before installing or maintaining batteries, switch off the battery circuit breaker or
remove the battery fuse.
Install batteries in a dry, clean, and ventilated environment that is free from sources of
ignition. Do not expose batteries to sunlight or water.
Ensure that the load-bearing capacity of the floor in the installation area is sufficient.
Install additional supports if required.
Secure battery cables to the torque specified in the battery documentation. Loose
connections will result in excessive voltage drop or cause batteries to burn out in the case
of excessive current.
Ensure that battery cables do not come in contact with water.
Battery Short Circuit
High short circuit currents or electric shocks can cause equipment damage, personal injury, or
death.
To prevent short circuit or electric shock, disconnect the batteries before performing any
operation or maintenance.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
4
Flammable Gas
Do not use unsealed lead-acid batteries.
Lead-acid batteries emit flammable gas. Therefore, place and secure lead-acid batteries
horizontally to prevent fire or corrosion.
Store lead-acid batteries in a place with good ventilation, and take fire safety precautions.
Battery Leakage
High temperatures may result in battery distortion, damage, and electrolyte overflow.
If the battery temperature is higher than 60°C, battery electrolyte may overflow. If the
electrolyte overflows, wear goggles, rubber gloves, and protective clothing and absorb the
leaking electrolyte using sodium bicarbonate (NaHCO3) or sodium carbonate (Na2CO3). Do
not transport or move batteries if there is an electrolyte leakage.
Battery Overdischarge
After connecting the batteries, remove the battery fuse or turn the battery circuit breaker OFF
and then power on the power system. This prevents battery overdischarge. After the power
system is on, replace the battery fuse or turn the battery circuit breaker ON.
1.4 Cable Layout
When routing cables, ensure that a sufficient distance exists between the cables and the
DC busbar, shunt, and fuse. This prevents damage to the insulation layer of the cables.
Route and bind signal cables and power cables separately.
Ensure that cables meet the VW-1 testing requirements.
Do not route cables behind the air exhaust vents of rectifiers in the cabinet.
Ensure that all cables are securely bound.
1.5 Mechanical Safety
Hoisting Devices

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
5
Do not walk under hoisted objects.
Only trained and qualified personnel should perform hoisting operations.
Check that all hoisting tools are available and in good condition.
Before hoisting objects, ensure that hoisting tools are firmly fixed onto a load-bearing
object or wall.
Ensure that the angle formed by each hoisting cable is less than 90 degrees.
If metal hoisting cables are used, place protective pads between the cables and the
cabinet to prevent scratches to the cabinet surface.
Figure 1-1 Hoisting heavy objects
Drilling Holes
Do not drill holes into a cabinet without permission. Incorrect drilling operations may affect
the electromagnetic shielding of the cabinet and damage cables inside. Metal shavings from
drilling may short-circuit boards inside the cabinet.
Before drilling holes into a cabinet, wear goggles and protective gloves. Remove cables
from inside the cabinet.
After drilling, clean up any metal shavings that have accumulated inside or outside the
cabinet.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
1 Safety Precautions
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
6
Moving Heavy Objects
Only trained personnel are allowed to move heavy objects.
Wear protective gloves and shoes before moving heavy objects.
Be cautious to prevent injury when moving heavy objects.
At least two people are required to move heavy objects.
When you transport cabinets, ensure that there is no excessive tilt and no sudden jolt.
The maximum allowed tilt angle when loading and unloading a cabinet is 15 degrees.
Secure the cabinet to a pallet truck before you transport it.
When you move a cabinet, ensure that it does not bump into other objects or fall down.
Figure 1-2 Transportation gradient

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
2 Overview
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
7
2 Overview
2.1 Overview
The TP48200A-HT15D3 is an integrated communications power system that supplies power
to and backs up power for –48 V DC outdoor communications equipment. Figure 2-1 shows
the TP48200A-HT15D3.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
2 Overview
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
8
Figure 2-1 TP48200A-HT15D3
2.2 Model Number Description
Figure 2-2 describes the TP48200A-HT15D3 model number.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
2 Overview
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
9
Figure 2-2 TP48200A-HT15D3 model number description
2.3 Features
Wide voltage range of 85 V AC to 300 VAC.
Comprehensive battery management.
ComprehensiveAC and DC surge protection design.
Network application over a fast Ethernet (FE) port and an RS485/RS232 port.
Communication with Huawei NetEco or third-party network management systems (NMS)
over protocols such as the Simple Network Management Protocol (SNMP) and
Hypertext Transfer Protocol (HTTPS) to enable remote management and unattended
working. NetEco is Huawei iManager NetEco data center infrastructure management
system.
Liquid crystal display (LCD) for display and operations.
Web user interface (WebUI) for display and operations.
Access through the mobile app for easy deployment.
Multiple display languages, such as English, Chinese, French, Spanish, Portuguese,
Italian, and Russian.
Hot swapping of Rectifiers and site monitoring units (SMUs).
Rectifier power factor up to 0.99.
Rectifier efficiency up to 96%.
2.4 Working Principles
Figure 2-3 shows the conceptual diagram.AC power enters rectifiers through theAC power
distribution unit (PDU). The rectifiers convert the AC power input into -48 V DC power
output, which is directed by the DC PDU to DC loads along different routes.
When theAC power is normal, rectifiers power DC loads and charge batteries. When the AC
power is absent, rectifiers stop working and batteries start to power loads. After theAC power
resumes, rectifiers power DC loads and charge batteries again.
The SMU monitors the operating status of each component in the power system in real time
and performs appropriate intelligent control. When detecting a fault, the SMU generates an
alarm. The SMU monitors and regulates the temperature control unit based on the temperature

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
2 Overview
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
10
measured by the temperature sensor to ensure the normal operating temperature for the
cabinet.
Figure 2-3 Conceptual diagram
2.5 Configurations
Table 2-1 describes the TP48200A-HT15D3 configurations.
Table 2-1 Configurations
Item
Configuration
Application
environment
Class C
Heater
HAU03A-01
Rectifier
A maximum of four R4850G2s or R4850N2s
Maximum output
current
200 A
Temperature
control capacity
Equipment compartment: heat exchanger ≥ 85 W/k
Battery compartment: TEC (200 W cooling capacity and 400 W
heating capacity), 500 W heater
Heat dissipation
Equipment compartment: heat exchanger

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
2 Overview
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
11
Item
Configuration
Battery compartment: TEC
SMU
SMU02B
UIM
UIM02C
Sensors
Mandatory: battery temperature sensor, door status sensor, smoke
sensor, and equipment compartment temperature sensor
Optional: temperature and humidity sensor and water sensor
Lamp
Mandatory
Battery
One string of 12 V, 150 Ah batteries
Class A environments refer to indoor environments where temperature and humidity is controllable,
including rooms where human beings live.
Class B environments refer to indoor environments in which the ambient temperature and humidity
are not controlled and outdoor environments (with simple shielding measures) where humidity can
reach 100%.
Class C environments refer to sea environments or outdoor land environments (with simple
shielding measures) near pollution sources. If a site is near a pollution source, it is at most 3.7 km
away from salt water, such as the sea and salt lakes, 3 km away from heavy pollution sources, such
as smelteries, coal mines, and thermal power plants, 2 km away from medium pollution sources,
such as chemical, rubber, and galvanization industries, and 1 km away from light pollution sources,
such as packing houses, tanneries, and boiler rooms.
Class D environments refer to areas about 500 m away from the seashore. Class D environments are
special Class C environments.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
3 Components
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
12
3 Components
3.1 Interior
Figure 3-1 shows the TP48200A-HT15D3 interior.

TP48200A-HT15D3 Outdoor Power System (Russia,
Megafon)
User Manual
3 Components
Issue 02 (2019-02-26)
Copyright © Huawei Technologies Co., Ltd.
13
Figure 3-1 Interior
(1) DC PDU
(2) AC surge protective
device (SPD)
(3) AC input circuit breaker
and terminal
(4) AC PDU
(5) Battery switch (behind
the cover)
(6) Space for installing
rectifiers
(7) Cabinet ground bar
(8) Space for installing
customer equipment
(9) Cable holes
(10) Space for installing
batteries
(11) Heater
(12) Internal circulation fan
(13) Site monitoring unit
02B (SMU02B)
(14) User interface module
02C (UIM02C)
(15) RTN+ busbar
(16) Heat exchanger core
(17) External circulation fan
(18) Space for installing an
intelligent battery detector
(19) TEC control box
(20) Thermoelectric cooler
(TEC)
