FusionModule2000 Smart Modular Data Center
Maintenance Guide
About This Document
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Overview
This document describes FusionModule5000 Smart Modular Data Center (Smart Module for
short) in terms of the routine maintenance, alarm references, troubleshooting, and parts
replacement, which helps maintenance personnel to inspect and maintain the Smart Module
and eliminate potential risks promptly.
Intended Audience
This document is intended for:
Sales engineers
Technical support engineers
System engineers
Hardware installation engineers
Commissioning engineers
Data configuration engineers
Maintenance engineers
Symbol Convention
The symbols that may be found in this document are defined as follows.
Symbol
Remarks
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
About This Document
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol
Remarks
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all
updates made in previous issues.
Issue 01 (2016-10-18)
This issue is the first official release.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
Contents
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 O&M Preparations........................................................................................................................1
1.1 O&M Personnel Skill Requirements ............................................................................................................................1
1.2 Tools .............................................................................................................................................................................1
2 Routine Maintenance ...................................................................................................................4
2.1 Routine Maintenance for the Power Supply and Distribution System..........................................................................4
2.2 Routine Maintenance for the Cooling System..............................................................................................................4
2.3 Intelligent Battery Monitoring System .........................................................................................................................5
2.4 Routine Maintenance for the Management System......................................................................................................6
2.4.1 Routine Maintenance for the Switch..........................................................................................................................6
2.4.2 Routine Maintenance for the ECC Collector.............................................................................................................8
2.4.3 Routine maintenance for the skylight controller........................................................................................................8
2.4.4 Routine Maintenance for the Smoke Detector and Camera.......................................................................................8
2.4.5 Routine Maintenance for the Water Sensor and Water Detection Cable....................................................................9
2.4.6 Routine Maintenance for the Lighting Controller....................................................................................................10
2.4.7 Routine Maintenance for the Access Control System..............................................................................................10
2.4.8 Routine Maintenance for the Emergency Door Release Button .............................................................................. 11
2.4.9 Routine Maintenance for the Double-Door or Four-Door Access Controller.......................................................... 11
2.4.10 Routine Maintenance for the Double-Door Magnetic Lock .................................................................................. 11
2.5 Routine Maintenance for the Fire Extinguishing System...........................................................................................12
2.5.1 Routine Maintenance for the Smoke Detector.........................................................................................................12
2.5.2 Routine Maintenance for the Alarm Beacon............................................................................................................13
2.6 Routine Maintenance for the Structural System .........................................................................................................14
3 Alarm Reference..........................................................................................................................15
3.1 Alarms for the Power Supply and Distribution System..............................................................................................15
3.2 Alarms for the Cooling System...................................................................................................................................15
3.3 Management System Alarm Reference.......................................................................................................................15
4 Troubleshooting..........................................................................................................................18
4.1 Troubleshooting Power Supply and Distribution equipments.....................................................................................18
4.2 Troubleshooting the Cooling System..........................................................................................................................18
4.2.1 Cabinet Overtemperature.........................................................................................................................................18

FusionModule2000 Smart Modular Data Center
Maintenance Guide
Contents
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v
4.2.2 Abnormal Humidity Inside the Equipment Room ...................................................................................................20
4.2.3 Water Accumulates Near Air Conditioners..............................................................................................................21
4.2.4 Loud Noise ..............................................................................................................................................................22
4.2.5 Air Conditioners Blowing MoistAir or Condensation ............................................................................................23
4.3 Troubleshooting the Management System..................................................................................................................23
4.3.1 Troubleshooting ECC Faults....................................................................................................................................23
4.3.2 Troubleshooting RS485 orAI/DI Expansion Card Faults........................................................................................24
4.3.3 Troubleshooting Skylight Controller Faults.............................................................................................................25
4.3.4 Troubleshooting Camera Faults...............................................................................................................................25
4.3.5 Troubleshooting the Smoke Detector.......................................................................................................................26
4.3.6 Troubleshooting the Alarm Beacon .........................................................................................................................27
4.3.7 Lighting Controller Box ..........................................................................................................................................28
4.3.8 Troubleshooting the Water Sensor and Water Detection Cable ...............................................................................29
4.3.9 Troubleshooting Access Controller Faults...............................................................................................................29
4.3.10 Troubleshooting Double-Door or Four-DoorAccess Controller Faults.................................................................30
4.3.11 Troubleshooting Double Door Magnetic Lock Faults............................................................................................31
4.3.12 Troubleshooting Emergency Door Release Button Faults.....................................................................................32
5 Parts Replacement.......................................................................................................................33
5.1 Replacing the Aisle LED Light...................................................................................................................................33
5.2 Parts Replacement for the Power Supply and Distribution System............................................................................35
5.3 Replacing Cooling System Components ....................................................................................................................36
5.4 Parts Replacement for the Management System.........................................................................................................36
5.4.1 Replacing the ECC500.............................................................................................................................................36
5.4.2 Replacing the AI/DI Module....................................................................................................................................37
5.4.3 Replacing an RS485 orAI/DI Expansion Card .......................................................................................................38
5.4.4 Replacing the Hard Disk..........................................................................................................................................39
5.4.5 Replacing a Dome Camera......................................................................................................................................41
5.4.6 Replacing the Smoke Detector.................................................................................................................................42
5.4.7 Replacing the Alarm Beacon ...................................................................................................................................43
5.4.8 Replacing the Lighting or Skylight Controller ........................................................................................................45
5.4.9 Replacing a Skylight Magnetic Lock.......................................................................................................................46
5.4.10 Replacing the Water Sensor and Water Detection Cable .......................................................................................47
5.4.11 Replacing a Door Status Sensor.............................................................................................................................49
5.4.12 Replacing anAccess Controller.............................................................................................................................50
5.4.13 Replacing a Double-Door Magnetic Lock.............................................................................................................53
5.4.14 Replacing the Switch.............................................................................................................................................57
5.4.15 Replacing a Card Reader .......................................................................................................................................59
A Acronyms and Abbreviations..................................................................................................63

FusionModule2000 Smart Modular Data Center
Maintenance Guide
1 O&M Preparations
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 O&M Preparations
1.1 O&M Personnel Skill Requirements
Professional Quality and Skills
Maintenance personnel must be trained before performing maintenance tasks to master
necessary maintenance knowledge, basic operation skills, and emergency handling skills.
They should strictly follow the operation regulations and industry safety regulations to ensure
personal safety and equipment security.
Have the product knowledge.
Be clear of related device functions and basic protocols.
Understand device positions in the network as well the services and ports provided.
Have the basic computer network knowledge, such as the Ethernet, TCP/IP, and
Client/Server.
Skilful in routine device operations and basic computer operations, especially routine
maintenance such as device alarm management and performance management.
Device Operations
To improve the troubleshooting efficiency and avoid misoperations, maintenance personnel
must obtain the work permit and understand the related operation procedure. Critical
troubleshooting tasks should be performed by qualified personnel trained by Huawei.
Maintenance personnel should also be clear of the following during maintenance:
Operations that may lead to the failure of some or all the services
Operations that may damage devices
Operations that may lead to customer complaints
Emergency and backup measures
1.2 Tools
Table 1-1 lists the tools required for maintenance.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
1 O&M Preparations
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Table 1-1 Tools and instruments
Tool Name, Specifications, and Appearance
Protective gloves
Marker
Measuring tape (5
m)
Level
Step ladder (2 m)
Phillips screwdriver
M4/M6/M8
Phillips screwdriver
M3/M4 (length <
100 mm)
Flat-head
screwdriver (2–5
mm)
Adjustable wrench
(6")
Socket wrench
M6/M8/M12
Hex key
Box-end wrench
M6/M8/M12
Electric screwdriver
Hand drill
(Φ3/Φ3.7/Φ4/Φ4.5/
Φ5/Φ6/Φ10/Φ12 bit)
Hammer drill
(Φ6.0/Φ10 bit)
Heat gun
Pressure gauge
Electrician's knife
Impact tool
Insulation tape
Needle-nose pliers
Diagonal pliers
RJ45 crimping tool
Crimping tool

FusionModule2000 Smart Modular Data Center
Maintenance Guide
1 O&M Preparations
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
Tool Name, Specifications, and Appearance
Wire stripper
Hydraulic pliers
Wire clippers
Nylon cable tie
Multimeter
Electroprobe
Brush
Hammer
Vacuum cleaner
Hacksaw
Handsaw
Right angle

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
2 Routine Maintenance
2.1 Routine Maintenance for the Power Supply and
Distribution System
To perform routine maintenance for a single component in the power supply and distribution
system, see the documents delivered with the component. Table 2-1 lists the reference
documents.
Table 2-1 Reference documents for power supply and distribution devices
Category
Device Name
Reference Document
PDU8000
Integrated PDU8000
(with UPS inside)
PDU8000 user manual (available on
http://enterprise.huawei.com)
Integrated PDU8000
(with UPS outside)
UPS input and output
PDU8000
Precision PDU8000
Transformer cabinet
UPS
UPS2000 series
UPS2000 user manual (available on
http://enterprise.huawei.com)
UPS5000 series
User manual (delivered with the UPS)
2.2 Routine Maintenance for the Cooling System
To maintain a cooling system component, see the documents delivered with it. Table 2-2 lists
the reference documents.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Table 2-2 Reference documents for the cooling system
Device Name
Reference Document
NetCol5000-C 30
kW
Quick guide (delivered with the device)
NetCol8000-C 50
kW
User manual (delivered with the device)
NetCol8000-C 70
kW
For maintenance details for the NetCol500 outdoor unit, see the delivered documents.
2.3 Intelligent Battery Monitoring System
Only trained personnel are allowed to maintain the intelligent battery monitoring system of
the data center.
Table 2-3 Monthly battery maintenance
Item
Expected Result
Troubleshooting
Battery management alarm
No battery management
alarm is generated.
Identify the cause of an
alarm based on the alarm
information.
Cleanliness
Wipe the cabinet surface
using a white paper and the
paper does not turn black.
Clean the dust.
Battery connection
Battery terminals and cables
are in good contact.
Ensure that battery terminals
and cables are in good
contact.
Ambient temperature of the
intelligent battery
monitoring system
The ambient temperature of
the intelligent battery
monitoring system is lower
than 45ºC.
Find the cause of an
abnormal temperature.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
2.4 Routine Maintenance for the Management System
2.4.1 Routine Maintenance for the Switch
Table 2-4 Routine maintenance for the switch
Item
Maintenan
ce Interval
Method
Expected
Result
Exception Handling

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Item
Maintenan
ce Interval
Method
Expected
Result
Exception Handling
LAN switch
availability
Semi-annua
lly
Check the
power
indicator
(marked
PWR) of
the switch.
Check the
running
indicator
(marked
SYS) of the
switch.
The PWR
indicator is
steady
green.
The SYS
indicator is
blinking
green.
Take corrective measures
based on the PWR indicator
status:
Off: The power supply unit
(PSU) is not detected, or
the board power supply is
abnormal when the switch
is configured with one
PSU.
Steady red, The possible
causes are as follows:
Two PSUs configured on
the switch are detected, but
the circuit breaker is off.
The power supply is
disconnected.
Both the board and power
over Ethernet (PoE) power
supplies are faulty.
Steady orange: When the
switch is configured with
one PSU, the PoE power
supply is abnormal. When
the switch is configured
with two PSUs, the board
or PoE power supply is
abnormal.
Take corrective measures
based on the SYS indicator
status:
Off: The switch is not
running.
Steady green: The switch is
not running properly or is
starting.
Steady orange: The
indicator takes a self-test
during startup.
Steady red: The switch
does not run properly after
being registered, or alarms
indicating that the power
supply, fan, or temperature
is abnormal are generated.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
2.4.2 Routine Maintenance for the ECC Collector
For details about ECC collector routine maintenance, see the ECC500 V600R001C03 User
Manual (available on http://e.huawei.com).
2.4.3 Routine maintenance for the skylight controller
Table 2-5 Routine maintenance for the skylight controller
Item
Maintenan
ce Interval
Method
Expected
Result
Exception Handling
Skylight
controller
function
Monthly
In working
mode, press
the
MANUAL
button and
check
whether the
skylight
opens.
The
skylight
opens
properly.
If the skylight does not open,
check whether it is stuck. If
yes, adjust the skylight
connective plate. If no, check
the magnetic lock cable
connection or replace the
skylight controller. For the
replacement procedure, see
5.4.8 Replacing the Lighting or
Skylight Controller.
2.4.4 Routine Maintenance for the Smoke Detector and Camera
Table 2-6 Routine maintenance for the smoke detector
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Functions of the
smoke detector
Monthly
In working
mode, press the
TEST button or
blow smoke to
the smoke
detector and
check whether
the sensor
works properly.
The
indicator is
ON, and the
relay is
closed. The
smoke
detector
generates an
alarm.
In alarm
mode, press
the RESET
button and
check
whether the
smoke
detector
restores to
the normal
state.
If the smoke
detector does
not generate an
alarm, check
whether cables
to the smoke
detector are
loose or
disconnected. If
cables to the
smoke detector
are securely
connected,
replace the
smoke detector
by referring to
5.4.6 Replacing
the Smoke
Detector.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Table 2-7 Routine maintenance for the camera
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Camera
availability
Semi-annually
On the NetEco,
click Camera >
Camera >
Camera
Management
to enter the
camera
management
page. Type the
camera name or
IP address to
find the camera,
and click the
camera name or
icon on the
left to view the
real-time
monitoring
page.
A monitoring
page is
displayed.
If the
monitoring
page is not
displayed,
check whether
the IP address is
correctly set
and the PoE
function is
enabled on the
LAN switch.
Then check the
cables or
replace the
camera. For
details about
how to replace
a camera, see
5.4.5 Replacing
a Dome
Camera.
2.4.5 Routine Maintenance for the Water Sensor and Water
Detection Cable
Table 2-8 Routine maintenance for the water sensor and water detection cable
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Functions of the
water sensor
and water
detection cable
Monthly
Place the water
detection cable
into water and
check whether a
water leakage
alarm is
generated by
the water
sensor.
A water leakage
alarm is
generated.
If no water
leakage alarm is
generated,
replace the
water detection
cable by
referring to
5.4.10
Replacing the
Water Sensor
and Water
Detection
Cable.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
2.4.6 Routine Maintenance for the Lighting Controller
Table 2-9 Routine maintenance for the lighting controller
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Functions of the
lighting
controller
Quarterly
Operate the
lighting
controller. For
details, see the
delivered ZYT-L
CON-24 Light
Controller User
Manual.
The actions of
the lighting
controller
conform to
those described
in the user
manual.
If the lighting
controller is not
responsive or
the actions do
not conform to
those described
in the user
manual, replace
the light
controller by
referring to
5.4.8 Replacing
the Lighting or
Skylight
Controller.
2.4.7 Routine Maintenance for the Access Control System
Table 2-10 Routine maintenance for the access control system
Item
Maintena
nce
Interval
Method
Expected
Result
Exception
Handling
Card reader
Monthly
Use a spare card
reader to check
whether the
access control
system works
properly.
The card reader
functions
properly.
If the access
controller fails to
operate properly,
replace the card
reader by
referring to
5.4.15 Replacing
a Card Reader.
Door status
sensor
Monthly
Power on the
door status
sensor and check
whether the door
has strong
attracting
capability.
The door status
sensor functions
properly.
If the door status
sensor fails to
attract properly,
replace the
sensor by
referring to
5.4.11 Replacing
a Door Status
Sensor.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
2.4.8 Routine Maintenance for the Emergency Door Release
Button
Table 2-11 Routine maintenance for the emergency door release button
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Emergency
door release
button function
Monthly
Check whether
the glass plate
for the
emergency door
release button is
intact.
The glass plate
for the
emergency door
release button is
intact.
If the
emergency door
release button is
broken, replace
the button by
referring to
5.4.14
Replacing the
Switch.
2.4.9 Routine Maintenance for the Double-Door or Four-Door
Access Controller
Table 2-12 Routine maintenance for the double-door or four-door access controller
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Access
controller
function
Quarterly
Check whether
the access
controller
works properly
by referring to
the installation
guide.
The access
controller
works properly.
If the access
controller fails
to operate
properly,
replace the
controller by
referring to
5.4.12
Replacing an
Access
Controller.
2.4.10 Routine Maintenance for the Double-Door Magnetic Lock
Table 2-13 Routine maintenance for the double-door magnetic lock
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
12
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Double door
magnetic lock
function
Monthly
Check whether
the magnetic
lock attracts
and separates
properly when
being powered
on and off
respectively.
The magnetic
lock attracts
and separates
properly.
If the magnetic
lock fails to
attract or
separate
properly,
replace the lock
by referring to
5.4.13
Replacing a
Double-Door
Magnetic Lock.
2.5 Routine Maintenance for the Fire Extinguishing
System
2.5.1 Routine Maintenance for the Smoke Detector
Table 2-14 Routine maintenance for the smoke detector
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Smoke detector
indicator
Quarterly
Observe and
check whether
the indicator on
the smoke
detector is
normal.
The indicator
blinks once
every 6
seconds. (The
interval varies
with sensors.
See the product
instructions.)
If the indicator
blinks twice
every 6 seconds
or does not
blink, the
smoke detector
is faulty or the
cables are not
properly
connected.
Check the
cables or
replace the
smoke detector.

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
13
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Smoke detector
availability
Semi-annually
Use a dedicated
test instrument
or a smoke
generator to test
the smoke
detector. Blow
smoke to the
smoke detector
probe and
observe the
indicator status.
If the smoke
density is
below the
alarm
threshold,
the alarm
indicator
blinks once
every 6
seconds.
If the smoke
density
exceeds the
alarm
threshold,
the alarm
indicator is
steady on.
If the smoke
density is
below the
alarm
threshold
but the
alarm
indicator
blinks twice
every 6
seconds, the
smoke
detector is
faulty.
Replace the
smoke
detector.
If the smoke
density
exceeds the
alarm
threshold
but the
alarm
indicator is
not steady
on, replace
the smoke
detector.
You are advised to clean the smoke detectors every two years.
2.5.2 Routine Maintenance for the Alarm Beacon
Table 2-15 Routine maintenance for the alarm beacon
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling

FusionModule2000 Smart Modular Data Center
Maintenance Guide
2 Routine Maintenance
Issue 01 (2016-10-18)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Functions of
the alarm
beacon
Quarterly
Trigger the
smoke detector
and
temperature
sensor
simultaneously,
and check
whether the
alarm beacon
generates an
alarm.
When the
alarm beacon
reports alarms,
it generates an
obvious flash
signal and a
shrill audible
signal.
If the alarm
beacon does not
generate a sound
or blink, it is
faulty or the
cables are not
well connected.
Check the cables
or replace the
alarm beacon.
2.6 Routine Maintenance for the Structural System
Table 2-16 Routine maintenance for the skylight
Maintenance
Item
Maintenance
Interval
Method
Expected
Result
Exception
Handling
Skylight
magnetic lock
operation
Quarterly
1. Open the
skylight
magnetic
lock and
check
whether the
skylight
opens
properly.
2. Reset the
skylight,
close the
skylight
magnetic
lock, and
check
whether the
skylight
closes
properly.
The skylight
opens and
closes properly.
If the skylight
fails to open or
close properly,
check or replace
the skylight
magnetic lock.
Skylight steel
glass cleaning
Semi-annually
Use a soft
cotton cloth to
clean the glass.
None
None
