Huawei OceanStor CloudStor CSE User manual

1
Safety Information
OceanStor CloudStor CSE V100R001C01
Quick Installation Guide
Issue: 03
Date: 2012-10-17
Do not operate devices or handlecables on a stormy day.
To avoid personal injuries, take off your electrostatic discharge (ESD) wrist strap before insertinga power cable.
To avoid personal injuries, arrangeenough persons to carry the devices according to the suggestion on the package.
Before handling devices, wear an ESD suite, ESD gloves, or an ESD wrist strap and take off conductive objects such
as ornaments and watches.
To avoid device damage, ensure thatthe devices are grounded before powering them on.
Do not insert or remove disks or cables duringpower-on of the CSE. When data is being read or written on hard
disks, do not power off the device by cutting off power or holding down the power button for seconds. Otherwise, the
hard disks may have bad tracks and data may be damaged. To power off the device, stop reading and writing data on
the hard disks first and then send a shutdown command through the operating system (OS).
Copyright © Huawei Technologies Co., Ltd. 2012. All rights reserved.
Installation Process
The power distribution system (DC or AC power distribution box), auxiliary tools (guide rails and floating nuts) are
pre-installed and cables (includingpower cables and network cables) are laid out in the system cabinet of the CSE
before delivery.
确定T3200 G3在机柜中的位置
Prepare the materials and
installation tools.
Take antistatic measures.
Install hardware devices of
the CSE.
Connect cables.
Power on the devices and
check indicator status.
Install software.
Start
End
Page 2
Page 14
Page 12 to 13
Page 7 to 11
Page 4 to 7
Page 3
Determine positions of
devices in the cabinet.
Remove filler panels.
Install back-end storage
devices.
Install a KVM.
Install a switch.
Install a SD-Node.
Page 4
Page 5
Page 5
Page 5
Page 5
Page 6
Install a C-Node.
Install a SMS modem.
Page 6
Page 6
Connect the SD-Node.
Connect the C-Node.
Connect the switch.
Connect the KVM.
Connect the SMS modem.
Connect the remote modem.
Page 10
Page 10
Page 11
Page 11
Page 11
Page 11
Install a Remote modem.Page 7

2
List of Tools and Materials
PS/2 to USB converter KVM cables 100M/1000Mnetwork cable
Stack cables
SD-Node C-Node KVM
Switch SMS modem Remotemodem
AC power cable
ESD wrist strap with a crocodileclip
Floatingnut, M6 screw, and
M4 screw ESD suite
ESD wrist strap with a plug
ESD gloves
Phillipsscrewdriver Diagonal pliers
1E1 trunk cable PGND cable
Tie
The previous table lists part of the materials required for installation.For the complete list, refer to the
Packing List.

3
Wearing ESD Gloves
2
Wearing an ESD Wrist Strap
Taking Antistatic Measures
For an ESD wrist strap with a plug, insert the plug into the ESD jack on the cabinet (scenario 1). For an ESD
wrist strap with a crocodile clip, snap the clip onto the cabinet (scenario 2).
Scenario 1: Wearingan ESD wrist strap with a plug Scenario 2: Wearingan ESD wrist strap with a crocodile clip
1
Wearing an ESD Suite
3

4
Determining Positions of Devices in the Cabinet
1
Installing Hardware Devices of the CSE
Install the devices of the CSE according to the
specific installationenvironment. The following
describes the general installationplan:
Each cabinet requires two switches and one
KVM device.
You are advised to install the back-end
storage devices in the storage space of 3 U to 22
U.
You are advised to install devices except the
back-end storage devices in the storage space of
32 U to 41 U.
SD-Nodes must be installedbelow C-Nodes.
If the number of C-Nodes exceeds three or the
number of OSN nodes exceeds three, an
expansion cabinet is required.
If an expansion cabinet is used, installthe
back-end storage devices in the storage space of
1 U to 22 U, and C-Nodes in the positions of 32
U to 41 U. Devices in the expansion cabinets
must be parallel to the devices of the same type
in the system cabinet.
The CSE uses a cloud storage system (CSS) as the back-end storage. This section uses the CSS as an example to
explain how to install a CSE system.
Thissection uses the configuration of three C-Nodes in the CSE as an example. The CSE includes two SD-Nodes,
threeC-Nodes, two switches, one KVM device, and the back-end storage (CSS with two MDS nodes and two OSN
nodes).

5
2 Removing Filler Panels
Remove only filler panels that cover the planned
installationpositions.
3 Installing Back-End Storage Devices
Install the back-end storage device by referring to the accompanying documents.
5
4 Installing a KVM
2
1Installthe KVM balancingpole to the
rear of the cabinet. 3
Slide the KVM along the guide rails.
5 Installing a Switch
2
3
1Fix the mountingears on each side of the
switch by using M4 panel screws.
Slide the switch along the guide
rails.
Fix the mountingears on the square hole bar
of the cabinet by using M6 panel screws.
Fix the mountingears on the square
hole bars of the cabinet by using M6
panel screws.

66
The SMS modem is equipped with the 220 V to 12 V transformer. When the equipment
room has only –48 V DC power supply, use the service provider (SP) short message method
instead.
The SMS modem is a small and lightpurchased component. Different types of SMS
modems may require different installationmethods. Use a tie to fix the SMS modem in a free
position near the SD-Node in the cabinet so that you can connect cables of the SD-Node
conveniently.
Tie the SMS modem securely to prevent it from falling off and ensure that the SMS modem
does not affect the wiring of other devices or opening/closing of the cabinet door.
8 Installing an SMS Modem
6
7 Installing a C-Node
The installation procedure of a C-Node is the same as that of an SD-Node. Install the C-Nodes by referring to the
installationprocedure of an SD-Node.
A C-Node weighs 29 kg in its full configuration, so at least two persons are required to mount the C-Node into the
cabinet.
After the previous devices have been installed,you are advised to install filler panels to cover empty positions to
ensure good ventilation. If an SMS modem or a remote modem is used, install the modem before installingfiller panels.
6 Installing an SD-Node
An SD-Node weighs 29 kg in its full configuration,
so at least two persons are required to mount the SD-
Node into the cabinet.
To avoid hard disk vibration, push the SD-Node into
the cabinet gently and secure it.
Slide the SD-Node into the cabinet
along the guide rails.
Fix the device in the cabinet using
two M6 screws.
To keep the gravity balance of the cabinet, you are advised to installdevices of the CSE from bottom to top.
2
1

1 Connecting Ground Cables of the CSE
7
Connecting Cables
The remote modem is equipped with a 220 V to 12 V transformer, which connects to an external power supply.
The remote modem is a small and light purchased component. Different types of remote modems may require
different installationmethods. Use a tie to fix the remote modem in a free position near the SD-Node in the cabinet
so that you can connect cables of the SD-Node conveniently.
The remote modem is connected to an external power supply instead of the cabinet power supply. Ensure that the
remote modem does not affect the cabling of other devices or opening/closing of the cabinet door.
Because the SD-Node provides only one serial port, you cannot connect an SMS modem and a remote modem at
thesame time.
9 Installing a Remote Modem
Before connecting cables of devices, make sure that the cabinet is securely grounded.
Before connecting other types of cable, ground the devices by referring to the following figure.

8
2 Connecting Network Cables of the CSE
Network cables are delivered with labels that describe the connections. Connect the network cables by referring
to the labels.
Before connecting the network cables, make sure that the devices have been grounded securely.
Thisfigure shows the network cable connections among devices of the CSE. Power cable connections and ground
cable connections are not illustrated.

9
a
3 Distribution of Switch Ports
Distributionof network ports on switch 1
On a switch, network ports are numbered from bottom to top and then from left to right.
Network cables are clearly labeled before delivery. The following tables describe distribution of network ports on
switches to help you quickly complete network cable connections.
Device Port Switch port Number Switch port Number Device Port
- 1 2 -
- 3 4 -
- 5 6 -
- 7 8 -
MDS1 NIC1 9 10 MDS1 NIC2
MDS2 NIC1 11 12 MDS2 NIC2
OSN1 NIC1 13 14 OSN1 NIC2
OSN2 NIC1 15 16 OSN2 NIC2
- 17 18 -
SD-Node-1 IPMI 19 20 C-Node1 IPMI
C-Node-3 IPMI 21 22 -
MDS-1 IPMI 23 24 OSN-1 IPMI
SD-Node-1 Slot0-B 25 26 SD-Node-2 Slot-0-B
C-Node-1 Slot2-B 27 28 C-Node-2 Slot-2-B
C-Node-3 Slot2-B 29 30 -
- 31 32 -
- 33 34 -
SD-Node-1 Slot0-A 35 36 SD-Node-2 Slot-0-A
C-Node-1 Slot2-A 37 38 C-Node-2 Slot-2-A
C-Node-3 Slot2-A 39 40 -
- 41 42 -
- 43 44 -
- 45 46 -
- 47 48 -
b Distributionof network ports on switch 2
Device Port Switch port Number Switch port Number Device Port
- 1 2 -
- 3 4 -
- 5 6 -
- 7 8 -
MDS1 Slot0-A 9 10 MDS1 Slot3-A
MDS2 Slot0-A 11 12 MDS2 Slot3-A
OSN1 Slot1-A 13 14 OSN1 Slot2-A
OSN2 Slot1-A 15 16 OSN2 Slot2-A
- 17 18 -
SD-Node-2 IPMI 19 20 C-Node2 IPMI
- 21 22 -
MDS-2 IPMI 23 24 OSN-2 IPMI
SD-Node-1 Slot-3-B 25 26 SD-Node-2 Slot3-B
C-Node-1 Slot3-B 27 28 C-Node-2 Slot-3-B
C-Node-3 Slot3-B 29 30 -
- 31 32 -
- 33 34 -
SD-Node-1 Slot3-A 35 36 SD-Node-2 Slot-3-A
C-Node-1 Slot3-A 37 38 C-Node-2 Slot-3-A
C-Node-3 Slot3-A 39 40 -
- 41 42 -
- 43 44 -
- 45 46 -
- 47 48 -

10
4 Connecting an SD-Node
5 Connecting a C-Node
Connectcables in the sequence of the ground cables, network cables, then power cables.
Thissection uses SD-Node-2 as an example to describe cable connections of an SD-Node. Connect cables of SD-
Node-1 in the same way.
The SMS modem connects only to SD-Node-2.
Connectcables in the sequence of the ground cables, network cables, then power cables.
Thissection uses C-Node-1 as an example to describe cable connections of a C-Node. Connect cables of
other C-Nodes in the same way.

11
7 Connecting the KVM
8 Connecting the SMS Modem
A KVM is a purchased device. For details on how to installa KVM, see documentsdelivered with the KVM.
9 Connecting the Remote Modem
6 Connecting the LAN Switch
Rear panels of the two switches in a cabinet are connected to each other throughtwo crossed stack cables.
If the CSE has an expansion cabinet, switches in the system cabinet are connected to those in the expansion cabinet
throughfour network cables.

12
a
3 Checking Status Indicators of an SD-Node
2 Pressing the Power Button on an SD-Node
Powering On the System and Checking Indicator Status
Status Indicatorsof an SD-Node (Front View)
Before power-on, switches of all devices must be in the off state. This section uses an SD-Node as an example to
explain how to power on a device. Power on other devices in the same way.
Power on the SMS modem by connecting it to an external power supply. Power on the other devices by pressing their
power buttons.
Mandatory Optional
Connect the
cabinet to the
external power
Power on the
LAN Switch Power on the
modem
Power on the
KVM
Power on the
back-end
storage devices
Power on the
SD-Node Power on the
C-Node
1 Device Power-On Sequence
No. Name Normal State
1 System power indicator Steady green
2 Disk online indicator Steady green
3 Systemalarm/locationindicator Off,The device runs normally.
An SD-Node and a C-Node have identical hardware devices. This section uses an SD-Node as an example to
describe indicator status.

13
b Status Indicatorsof an SD-Node(Rear View)
No. Name Normal State
1 Power runningindicator Steady green
2、3、4、5 LNK indicatorof the service
network port on the expansion
network adapter
Steady green: The data transfer rate between the SD-Node and
applicationserver (AS) is 100 Mbit/s.
6 Link indicator of the
managementnetwork port Steady green
7、8 LINK indicatorof the service
network port on the onboard
network adapter
Steady green: The data transfer rate between the SD-Node and
applicationserver (AS) is 1000 Mbit/s.

14
Installing Software
For details, refer to the OceanStor CloudStor CSE Software Installation Guide.
HUAWEI TECHNOLOGIES CO., LTD.
Huawei Industrial Base Bantian Longgang
Shenzhen 518129
People’s Republic of China
http://enterprise.huawei.com
Start
Initial Configuration of Devices
Deploy the CSE.
Configure the CSE
management environment.
End
Configure the C-node.
Configure the SD-node.
Configure switches.
Preconfiguration
Configure nodes.
Start deployment.
Verify the deployment result.
Start the ISM service.
Configure event notification.
Mandatory
parent item Mandatory child item
Set the client browser.
Optional
child item
Install the management system
of the CSE.
Log in to the ISM service.
Configure the system.
Install the back-end storage software.
Install the management environment.
Start ISM ServiceTool.
Discover the CSE.
