Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 1
Quidway® S6500 Series High-end Multi-service
Switches Order Information
Table 1 Quidway® S6503 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6503-AC-XG-PO
E-OVS
S6503 Ethernet Switch Assembly Chassis (AC
110/220V) with fan,1 AC power and document,
support PoE and XGBUS 1 Mandatory
LS-6503-DC-XG-PO
E-OVS
S6503 Ethernet Switch Assembly Chassis (DC
48V) with fan, 1 DC power and document ,support
PoE and XGBUS 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE
Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1 110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1 Mandatory

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 2
Table 2 Quidway® S6506 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6506-AC-XG-PO
E-OVS
S6506 Ethernet Switch Assembly Chassis (AC
110/220V) with fan, 2 AC power and document,
support PoE and XGBUS, two power cord input 1 Mandatory
LS-6506-DC-XG-PO
E-OVS
S6506 Ethernet Switch Assembly Chassis (DC
48V) with fan, 2 DC power and document, support
PoE and XGBUS, two power cord input 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1 110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1 Mandatory
System Software
LIS-S6506 S6506 VRP Network Operating System (host
software) 1 Mandatory

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 3
Table 3 Quidway® S6506R Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6506R-AC-XG-P
OE-OVS
S6506R Ethernet Switch Assembly Chassis (AC
110/220V) with fan, 2 AC power and document,
support PoE and XGBUS, two power cord input 1 Mandatory
LS-6506R-DC-XG-P
OE-OVS
S6506R Ethernet Switch Assembly Chassis (DC
48V) with fan, 2 DC power and document,support
PoE and XGBUS, two power cord input 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M4220 S6500 AC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M448 S6500 DC Power Supply Module, for S6503,
S6506 and S6506R 0-1 Optional
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 220V:0-1 110V:0-2 Optional
Main Control Unit
LS8M4SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module,Salience III Edge-96GE with 4
1000BASE-X interface,SFP Req. 1-2 Mandatory
LS8M1SRPG S6503,S6506 and S6506R: Switch and Route Processing Module,Salience III, with 4
1000BASE-X interface,SFP Req. 1-2 Mandatory
LS8M2SRPG S6503,S6506 and S6506R: Switch and Route
Processing Module, Salience III Plus 1-2 Mandatory
System Software
LIS-S6506R S6506R VRP Network Operating System (host
software) 1 Mandatory

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 4
Table 4 Quidway® S6502 Host Configurations
Name Description Quantity Remark
Chassis configuration
LS-6502-XG-POE-O
VS
S6502 Ethernet Switch Chassis with fan and
documents, support PoE and XGBUS, 2 power
cord inputs, no power module, VRP incl. 1 Mandatory
Cabinet configuration
LS8M1B68 Assembly Cabinet for S6500 Ethernet Switch,
2.2M (optional) 0-1 Optional
Power Supply Configuration
LS8M7220PWR S6502 AC Power Supply Module, only for S6502 1-2 Mandatory
LS8M548PWR S6502 DC Power Supply Module, only for S6502 1-2 Mandatory
LS8M3POEPWR External PoE Power (220v-2500W, 110V-1250W)
Rack (with 1 PoE PSU) 0-1 PoE Mandatory
LS8M1POEPWR PoE Power Supply Unit (220v-2500W,
110V-1250W) module 0-1 Optional
Main Control Unit
LS8M1T12PE S6502 Switch and Route Processing Module with
12-port 10/100/1000BASE-T RJ-45 and 4-port
1000BASE-X SFP 1 Mandatory
LS8M1P12TE S6502 Switch and Route Processing Module with 12-port 1000BASE-X SFP and 4-port
10/100/1000BASE-T RJ-45 1 Mandatory
LS8M1GP48-XG S6500 48-port 1000BASE-X Ethernet Optical
Interface Module with XGBUS uplink, SFP Req. 1 Mandatory
LS8M1GT48B-XG S6500 48-port 10/100/1000BASE-T Ethernet
Interface Module with XGBUS uplink, RJ45 1 Mandatory
LS8M1T16P-XG S6500 16-port 10/100/1000BASE-T RJ45 and
8-port 1000BASE-X SFP with XGBUS uplink 1 Mandatory
LS8M1T32P-XG S6500 32-port 10/100/1000BASE-T RJ45 and
16-port 1000BASE-X SFP with XGBUS uplink 1 Mandatory
LS8M1TGX2-XG S6500 2-port 10GE Interface Module with XGBUS
uplink, XFP Req. 1 Mandatory
LS8M1TGX4-XG S6500 4-port 10GE Interface Module with XGBUS
uplink, XFP Req. 1 Mandatory

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 5
Table 5 Quidway® S6 500 Optional Interface Modules
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
Standard Module
LS8M1FT48E 48-port 10/100BASE-TX Ethernet Electrical
Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1FP48 48-port 100M Ethernet Optical Interface
Module,SFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT20A Enhanced 20-port 10/100/1000BASE-T
Ethernet Electrical Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1GT48 48-port 10/100/1000BASE-T Enhanced
Ethernet Electrical Interface Module,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1GP20A Enhanced 20-port 1000BASE-X Ethernet
Optical Interface enhansed Module,SFP
Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT8UE S6500 8-port 10/100/1000BASE-T Ethernet
Interface Module, RJ45 0-1 0-3 0-5 0-5 Optional
LS8M1GP8UB S6500 8-port 1000BASE-X Ethernet Optical
Interface Module, SFP Req. 0-1 0-3 0-5 0-5 Optional
LS8M1TGX1C Enhanced 1-port 10GBASE-R Ethernet
Interface Module,Xenpak Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT48A-Po
E 48-port 10/100/1000Bae-T Ethernet Electrical Interface Module,PoE,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1FT48F-Po
E 48-port 10/100BASE-TX Ethernet Electrical Interface Module,PoE,RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1T12P
12-port 10/100/1000BASE-T,RJ45, Gigabit
Ethernet Electrical Interface+4-port
1000BASE-X Gigabit Ethernet Optical
Interface Module,SFP Req.
0-1 0-3 0-6 0-6 Optional
LS8M1P12T
12-port 1000BASE-X Gigabit Ethernet
Optical Interface+4-port
10/100/1000BASE-T,RJ45 Gigabit Ethernet
Electrical Interface Module,SFP Req.
0-1 0-3 0-6 0-6 Optional
LS8M1GP48-XG S6500 48-port 1000BASE-X Ethernet
Optical Interface Module with XGBUS
uplink, SFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1GT48B-X
G
S6500 48-port 10/100/1000BASE-T
Ethernet Interface Module with XGBUS
uplink, RJ45 0-1 0-3 0-6 0-6 Optional
LS8M1T16P-XG S6500 16-port 10/100/1000BASE-T RJ45 and 8-port 1000BASE-X SFP with XGBUS
uplink 0-1 0-3 0-6 0-6 Optional

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 6
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
LS8M1T32P-XG S6500 32-port 10/100/1000BASE-T RJ45
and 16-port 1000BASE-X SFP with XGBUS
uplink 0-1 0-3 0-6 0-6 Optional
LS8M1TGX2-XG S6500 2-port 10GE Interface Module with
XGBUS uplink, XFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1TGX4-XG S6500 4-port 10GE Interface Module with
XGBUS uplink, XFP Req. 0-1 0-3 0-6 0-6 Optional
LS8M1VSNP S6500 Versatile Network Processing Service Module (PBR/NAT/NetStream) with
XGBUS uplink 0-1 0-2 0-5 0-5 Optional
EPON OLT module
LS8M1PT8GB0 8-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (20km, SFF) 0-1 0-3 0-5 0-5 Optional
LS8M1PT4GB0 4-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (20km, SFF) 0-1 0-3 0-6 0-6 Optional
LS8M1PT8GA 8-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (10km, SFF) 0-1 0-3 0-5 0-5 Optional
LS8M1PT4GA 4-Port 1000BASE-PX10 Gigabit Passive
Optical Line Interface Module (10km, SFF) 0-1 0-3 0-6 0-6 Optional
EPON upgrade package
LS8M1EPONSW
P
EPON Upgrade Package for Salience III
Series Switch and Route Processing
Module, with a 512M memory and
documents
0 1 1 1-2
EPON
mandatory
LS8M1EUP EPON Upgrade Package for S6502, with
Documents 1 0 0 0 EPON
mandatory
EPON splitter module
OC-1x32 Optical Splitter, 1x32, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is
1:32
OC-1x2-5:95 Optical Splitter, 1x2/5:95 (Splitting Ratio), Single Mode, 1310nm&1520nm±40nm,
SC/PC Splitter
ratio is
5:95
OC-1x2 Optical Splitter, 1x2, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:2
OC-1x4 Optical Splitter, 1x4, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:4
OC-1x16 Optical Splitter, 1x16, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is
1:16

Quidway® S6500 Series High-end Multi-service Switches Order Information
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/ 7
Quantity
Name Description S6502 S6503 S6506 S6506R Remark
OC-1x32-U Optical Splitter, 1x32, Single Mode,
1310nm&1520nm±40nm, SC/PC, 1U Splitter
ratio is
1:32
OC-1x8 Optical Splitter, 1x8, Single Mode,
1310nm&1520nm±40nm, SC/PC Splitter
ratio is 1:8
