AP4050DN-HD
Product Description About This Document
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Intended Audience
This document describes the positioning, characteristics, hardware structure, product features,
and technical specifications of the AP.
This document helps you understand the characteristics and features of the AP.
This document is intended for:
Network planning engineers
Hardware installation engineers
Commissioning engineer
Data configuration engineers
On-site maintenance engineers
Network monitoring engineers
System maintenance engineers
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation
which, if not avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
Indicates a potentially hazardous situation
which, if not avoided, may result in minor
or moderate injury.
Indicates a potentially hazardous situation
which, if not avoided, could result in
equipment damage, data loss, performance
deterioration, or unanticipated results.
NOTICE is used to address practices not

AP4050DN-HD
Product Description About This Document
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol Description
related to personal injury.
Calls attention to important information,
best practices and tips.
NOTE is used to address information not
related to personal injury, equipment
damage, and environment deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in previous issues.
Changes in Issue 01 (2016-04-30)
This is the initial commercial release.

AP4050DN-HD
Product Description Contents
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document.................................................................................................................... ii
1 Product Positioning and Characteristics...................................................................................1
1.1 Product Positioning....................................................................................................................................................... 1
1.2 Product Characteristics ................................................................................................................................................. 4
2 Hardware Structure.......................................................................................................................7
2.1 AP4050DN-HD ............................................................................................................................................................ 7
3 Product Features ..........................................................................................................................10
3.1 WLAN Features.......................................................................................................................................................... 10
3.2 Network Features........................................................................................................................................................ 11
3.3 QoS Features............................................................................................................................................................... 11
3.4 Security Features ........................................................................................................................................................ 11
3.5 Maintenance Features ................................................................................................................................................. 12
3.6 BYOD......................................................................................................................................................................... 12
3.7 Locating Service......................................................................................................................................................... 13
3.8 Spectrum Analysis ...................................................................................................................................................... 13
4 Technical Specifications ............................................................................................................14
4.1 Basic Specifications.................................................................................................................................................... 14
4.2 Radio Specifications ................................................................................................................................................... 15
4.3 Standards Compliance ................................................................................................................................................ 18

AP4050DN-HD
Product Description 1 Product Positioning and Characteristics
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1
1 Product Positioning and Characteristics
1.1 Product Positioning
Table 1-1 Product positioning
Product
Model
Frequency
Band
IEEE
Standards
Compliance
Positioning Usage
Scenario
AP4050DN-HD Dual band:
2.4 GHz
5 GHz
The
AP4050DN-HD
can provide
services
simultaneously
on the 2.4 GHz
and 5 GHz
frequency
bands to
support more
access users.
IEEE
802.11a/b/g/n/a
c/ac wave2
The
cost-effective
AP4050DN-HD
supports 2 x 2
MIMO and
provides
comprehensive
service support
capabilities. It
is deployed
indoors and
features high
reliability, high
security, simple
network
deployment,
automatic AC
discovery and
configuration,
and real-time
management
and
maintenance.
Huawei
AP4050DN-HD
complies with
IEEE 802.11ac
and can provide
gigabit access
for wireless
The
AP4050DN-HD
provides basic
802.11n/ac
wireless
networks for
indoor
high-density
scenarios such
as stadiums. It
can be
distributed
flexibly based
on
environments,
such as
shopping and
supermarkets,
hospitals,
warehouses,
manufacturing,
and logistics.
The
AP4050DN-HD
can work in AP
and bridge
modes.

AP4050DN-HD
Product Description 1 Product Positioning and Characteristics
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Product
Model
Frequency
Band
IEEE
Standards
Compliance
Positioning Usage
Scenario
users. This high
capacity greatly
improves user
experience on
wireless
networks.
Typical networking modes are as follows:
Figure 1-1 Fit AP networking (AP mode)

AP4050DN-HD
Product Description 1 Product Positioning and Characteristics
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
In this networking, the AP functions as a fit AP. The AC is responsible for user access, AP
go-online, AP management, authentication, routing, security, and QoS.Huawei AC products
include the AC6605, AC6005, ACU2 (with S7700, S9700, or S12700), S5720HI, S7700 (with
X1E board), S9700 (with X1E board), and S12700 (with X1E board).
Figure 1-2 Fit AP networking (WDS mode: point-to-point)
Figure 1-3 Fit AP networking (WDS mode: point-to-multipoint)
In this networking, the AP connects two or more independently wired or wireless LANs
through wireless links to construct a network on which users can exchange data. In Wireless
Distribution System (WDS) mode, the AP supports point-to-point (P2P) and
point-to-multipoint (P2MP) networking modes. With 5 GHz and 2.4 GHz frequency bands,
the AP can implement wireless bridging and access functions.

AP4050DN-HD
Product Description 1 Product Positioning and Characteristics
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Figure 1-4 Fit AP mesh networking
In this networking, APs function as mesh points (MPs) and are fully-meshed to establish an
auto-configured and self-healing wireless mesh network (WMN). APs with the gateway
function can work as the mesh portal points (MPPs) through which the WMN can provide
access to the Internet. Terminals connect to APs to access the WMN. The WMN uses
dedicated mesh routing protocols to guarantee high transmission quality and is more
applicable to scenarios that require high bandwidth and highly stable Internet connections.
1.2 Product Characteristics
The AP4050DN-HD has the following advantages on a WLAN.
Product
Characteristics
Description
High-speed and
reliable wireless
access
Compatibility with IEEE 802.11a/b/g/n/ac/ac wave2
2 x 2 MIMO and a maximum rate of 1.167 Gbit/s
Supports Wi-Fi Multimedia (WMM) and priority mapping on the
air interface and wired interface.
Supports wired link integrity check.
Supports load balancing.
Supports roaming without service interruptions.

AP4050DN-HD
Product Description 1 Product Positioning and Characteristics
Issue 01 (2016-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
Product
Characteristics
Description
Supports dual-AC backup.
Latest 802.11ac wave2 chip with higher performance and wider
coverage
Supports airtime scheduling which ensures fairness in channel
occupation time for all users
Comprehensive
user access control
capability
Supports access control lists (ACLs) and implements user access
control based on the user group policy.
Provides fine-grained bandwidth management for each user.
Supports user isolation policies.
Supports uniform authentication on an AC.
Identifies the device type according to the organizationally unique
identifier (OUI) in the MAC address, user agent (UA) information
in an HTTP packet, and DHCP options in Fit AP mode.
The RADIUS server delivers packet forwarding, security, and
QoS policies according to the device type carried in the RADIUS
authentication and accounting packets in Fit AP mode.
High network
security
Open system authentication
WEP authentication/encryption
WPA/WPA2-PSK authentication and encryption
WPA/WPA2-802.1x authentication and encryption
WAPI authentication and encryption
Supports wireless intrusion detection system (WIDS) and wireless
intrusion prevention system (WIPS), including rogue device
detection and countermeasure, attack detection and dynamic
blacklist, STA/AP blacklist and whitelist.
Flexible
networking and
environment
adaptability
Provides flexible networking capabilities and applies to various
application scenarios. Mesh and WDS scenarios are supported
only in Fit AP mode.
Has strong environment adaptability. The AP can automatically
select the transmission rates, channels, and transmit power to
adapt to various radio environments and avoid interference in real
time.
Adjusts bandwidth allocation based on the user quantity and
environment to improve user experience.
Identifies interference sources such as baby monitors, Bluetooth
devices, digital cordless phones (at 2.4 GHz frequency band only),
wireless audio transmitters (at both the 2.4 GHz and 5 GHz
frequency bands), wireless game controllers, and microwaves in
Fit AP mode and works with eSight to locate interference sources
and display spectrums.
Easy device
management and
maintenance
Automatically goes online and loads the configuration, and
supports plug-and-play (PnP) in Fit AP mode.
Supports batch upgrade.
Allows real-time monitoring on the network management system
