Huazheng HZJY-20K User manual

HZJY-20K
Insulation Resistance Tester
User Manual
Huazheng Electric Manufacturing (Baoding) Co., Ltd

Dear use r:
Thank you for cho os in g HZJY-20K Ins ul at ion Resistan ce Tester.
We hope that this instrum ent can mak e your wo rk easier an d mo re
enjoyable, so that yo u can get the feeling of offi ce aut om at ion in the test
and ana ly si s work.
Before using the instrument, please read thi s ma nu al, and opera te and
maintain th e instrum en t according to the manual to prolong its se rvice life.
"Just a lig ht press, the test will be completed au tomatically" is the
operating chara ct eristi cs of this instrum en t.
If you ar e sat isfied wi th th is instrum en t, please tell you r colleagues;
if you are not satisfie d with this instrum ent, please call (03 12 ) 6775656 to
tell you to serve you at all ti me s- Ba od in g Huazheng Electric Ma nu facturing
Co. , Ltd., our company will def in itely make you sati sf ied !

Contents
I. Warning...................................................................................................................................1
II. Feature.................................................................................................................................. 2
III. Specification Parameter.................................................................................................... 2
IV. Introduction of instrument..................................................................................................3
V. Instrument using.................................................................................................................. 6
VI. Packing List.......................................................................................................................7

1
I. Warning
Design and manufacture of the instrument and testing achieves IEC61010 safety
standards (electronic measuring product safety requirements), this manual including the
safety of the instrument use and ensure the safety of equipment state, users must follow
the warnings and safety regulations Please read the following instructions before use.
Warning
● Instrument output voltage, before use, read and understand the instructions of
operational guidelines.
● Please take manual save you to check at any time.
● Must be instructed to use the instrument.
● Understand and comply with the safety operating instructions.
Must strictly abide by the above instructions.
If you don't comply, measurement may cause personal injury and equipment damage.
Dangerous (for improper operation can lead to serious or fatal damage)
● Before use, please wear insulated gloves.
● Please do not over AC/DC600V measurement circuit.
● Please do not test in flammable places, spark could cause an explosion.
● please do not hand wet or damp operators in instrument surface operation.
● Please don't charged the connection test line low.
● Low in the measurement, or do not touch the circuit being measured immediately after
the test, may result in electric shock accidents.
● Low test line or port found easy to damage the insulation properties of dirt or carbon
please stop test.
Warning (for improper operation exists the possibility of a severe or fatal damage)
● If the instrument is abnormal, please stop using it. For example: instrument damage or
bare metal parts.
● Please do not install in the device replacement parts or any unauthorized modification,
maintenance, please contact with me.
● Make sure all wires and instrument testing port connection is firm.
Note (for improper operation may cause personal injury or equipment damage)
Squared before measurement, confirm the voltage selection in the appropriate value.
If long time not to use, the battery should be fully charge, and recharge in 3 months.
Squared do not in high temperature, damp, places and condensation may be placed
under direct sunlight for a long time.
Please use a damp cloth or cleaner to clean the equipment enclosure, do not use
abrasives or solvents.
Instrument wet, please dry storage first.

2
II. Feature
High-voltage insulation resistance tester, with 7 range: 500V, 1000V, 2500V, 5000V,
10000V, 15000V, 20000V,test up to 20TΩ, manual voltage regulation function.
● Strict accordance with the safety standards for design
●Insulation resistance range 20TΩ @ 20 kv
● Short circuit current can be adjusted, maximum 5mA (Can be ordered as high as 10mA,
short circuit current products).
● Automatic display polarization index (PI), induced electric absorption test values than
(DAR), and can test the leakage current and capacitance.
● Anti-jamming performance is superior, the interference current reaches 2 mA, still
ensure accuracy of test instruments.
●2 methods for power: use of lithium ion batteries, battery life can be up to 4 hours
(10000V @ 100MΩ).
●Insulation resistance simulation column.
●Digital filtering functions, external influence deviation display value causing mitigation
point using filter function.
●Perfect protection function, and the spare fuse prompt functions.
III. Specification Parameter
●Safety Standard
IEC 61010-1 CAT.IV 600V
IEC 61326 EMC specification: test, control and electrical equipment for testing
IEC60529 IP64 （Outer closed state）
● AC Power：220V±10%，50/60 HZ ，20 VA
● battery：16.8V Lithium ion rechargeable battery
● Battery Life：10000V@100M，4 hour
● size（L x W x H）：37cm x 27cm x 17cm
● weight：3.6kg
● Test voltage accuracy: the nominal value 100% to 110%
● Voltage measurement accuracy：5%+3V
● Current test range：10mA
● current measure precision：5%+0.2nA
● short-circuit current：5mA
● Capacitance test range：20uF
● Capacitance testing accuracy：15%+0.03uF

3
● Insulation resistance testing range and accuracy （T:23±5ºC ，RH :45 – 75%）
range
accuracy
500V
1000V
2500V
5000V
10000V
Unspecified
<1M
<1M
<1M
<1M
<1M
5%
1M -10G
1M -20G
1M -100G
1M -100G
1M -200G
20%
10G -100G
20G-200G
100G-1T
100G-1T
200G-2T
Unspecified
> 100G
> 200G
> 1T
> 1T
> 2T
range
accuracy
15000V
20000V
Unspecified
<1M
<1M
5%
1M -300G
1M -400G
20%
300G -3T
400G-4T
Unspecified
> 3T
> 4T
IV. Introduction of instrument
●The Front Panel Description
number
Description
number
Description
1
AC plug
2
AC ON
3
Test Port（E、G、L）
4
LCD display
5
Key
6
HV LED
●Key and function
Key numbered from left to right, the first for a total of five off down the power Key.
key number
Description
1
Press the switch on button startup, shutdown condition

4
2、3、4
functional key
5
The TEST key, press and hold 1 s TEST, then stop (enter the
Settings menu is invalid)
●Test setup interface
Set test voltage SetThe test time Battery Indicator
Set Short Current Set the filter
Button function tip
Soft key
Description
OFF
Power Off (No operation, 3 minutes automatic shutdown)
H.V
Set test voltage: Manual、500V、1000V、2500V、5000V、
10000V、15000V、20000V
TIME
SetThe test time: 01:00、10:00、30:00
Switching software keys to a new function, or from other
function to return
I
Set Short Current，1mA step selection Usually according to the
maximum, can also according to the regulations stipulated by
the short circuit current value choice.
Filter
Set the filter:
0：without filtering; (no interference case recommended)
1：hardware low-pass filter; (applicable to most situations)
2：software Low pass filter;High resistance (greater than 100G
recommended choose)
3：hardware + software low-pass filter;
(high resistance is greater than 1T recommend choose)
HELP
About Tester message
Battery Indicator： 、 、 、 、
When the battery voltage shows just one more case should be timely charge, when
the battery displaying flashing is automatically cut off the power at any time, should
be recharged.
charge：AC socket provided meet the requirements of the AC power supply for panel,
you can recharge equipment charging, the power indicator, display the battery label,
in turn, from (0) to (full) showed that when filled, displays (full)
Contrast Settings interface: LCD display gray level change due to temperature
changes, may affect the electronic contrast adjustment using the instrument Settings
Follow these steps to set up:
1. In shutdown state, hold key 2 (the 2 key).

5
2. Press the 1 key (the power button), until into the contrast adjustment menu.
3. Press 1 or 2 keys to adjust contrast, until the right .
4. Press the 4 key save and exit, if you don't need to adjust the press 3 key to exit.
Soft key
Description
Move the cursor, also used to increase or decrease in contrast
Move the cursor, also used to increase or decrease in contrast
Back
Return to the main menu
OK
Confirm to enter the current menu function or to determine the
current Settings and exit
Help menu system
HELP ：Record the serial number of product, production date, version information.
●Insulation testing interface
Digital Insulation value ( > greater than; < less than)Measured time
actual voltage
H.V warning Leakage current
1mA=1000uA
1uA =1000nA
DAR Capacitance
PI
Simulation column
When the test time or manual stopped, display shows as shown in the table of the soft
keys.
Soft key
Description
OFF
Power Off (No operation, 3 minutes automatic shutdown)
Back
Return to the main menu
H.V
Set test voltage: Manual 、500V、1000V、2500V、5000V、
10000V、15000V、20000V
Rt
Veiw 15S、30S、60S、600S Insulation value

6
●Manual voltage regulation function
Digital Insulation value ( > greater than; < less than)Measured time
actual voltage Battery Indicator
H.V warning Leakage current
1mA=1000uA
1uA =1000nA
Set Voltage
Regulating key
Soft key
Description
Regulating key +，By a voltage rise of 10V, long time boost up,
the fastest up to 600V per second.
Regulating key -，According to a voltage drop 10V, long time
step-down speed up, the fastest u
Stop
measuring
In manual voltage regulation, due to the use of 3 and 4 keys,
only 1, 2 keys and start stop keys can be used to stop the
measurement operation.
When the test time or manual stopped, display shows as shown in the table of the
soft keys.
Soft key
Description
OFF
Power Off (No operation, 3 minutes automatic shutdown)
Back
Return to the main menu
H.V
Set test voltage: Manual、500V、1000V、2500V、5000V、
10000V、15000V、20000V
Rt
Veiw 15S、30S、60S、600S Insulation value
V. Instrument using
measured DAR:
1. Select more than 1 minute length measurement.
2. Select the appropriate voltage and start.
3. The instrument automatically record 15 s and 60 s resistance, and calculate the
absorption than after 60 seconds.
Absorption ratio calculation method: DAR = R60 / R15;
measured PI :
1. Select more than 10 minute length measurement.
2. Select the appropriate voltage and start.
3. The instrument automatically record 15S, 60S and 600S resistance, and calculate the
polarization index after 600 seconds.
Set Voltage:

7
Polarization index calculation method : PI= R600/R60;
test connection points for attention
1. Tested to confirm product safety grounding, try not charged.
2. Confirm the instrument E end (ground) have been grounded.
3. The use of G terminal (protection ring) (this machine is of low voltage side of the
screen)
When measuring high insulation resistance, the sample should be in the position a
conductor surface protection between the two measuring end ring, and the conductor
protection ring is connected to the instrument with a test line G side, try to eliminate the
measuring error caused by the surface leakage current, security testing is accurate.
VI. Packing List
No.
Item
Qty
1
Main engine
1
2
Power line
1
3
Red test line
1
4
Black test line
1
5
Green test line
1
6
Red high voltage shielded wire
1
