ASSEMBLY & INSTALLATION INSTRUCTIONS
Loft Outdoor Sconce: 302570, 302573, 302575
B394
1 OF 4

MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM 42755
ASSEMBLY & INSTALLATION INSTRUCTIONS
Loft Outdoor Sconce: 302570, 302573, 302575
B394
Component Parts
2 OF 4
A Fixture
B Mounting Bracket
C Ground Screw
D Cupped Washer
E Caulking Lip
F #8 Screws (4)
G Rubber Washers (2)
H Socket
I Glass
J White Washer
K Retaining ring

MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM 42755
ASSEMBLY & INSTALLATION INSTRUCTIONS
Loft Outdoor Sconce: 302570, 302573, 302575
B394
1. Carefully unpack the xture (A) from the carton.
2. Using two machine screws (not provided) attach
mounting bracket (B) to the electrical box.
Note: A new electric box comes with screws. When
replacing a fixture, retain the existing screws for use with
the new fixture.
3. Using the green ground screw (C) and the cupped
washer (D) found in the kit bag, secure a pigtail lead to
the mounting bracket (B). Hold the xture close to the
mounting bracket and using suitable wire connectors (not
provided), connect xture wires to supply wire (white to
white and black to black). Connect all ground wires (bare
copper or green to bare copper or green).
4. Apply a generous bead of a suitable caulking material
(not provided) to caulking lip (E) on the xture. Caulk
should be applied around the entire perimeter of the
backplate (Figure 2).
5. Carefully tuck all wires behind xture and inside the
mounting bracket. Place xture rmly onto bracket and
fasten with two #8 screws (F) and rubber washers (G)
on top.
6. Install the two remaining #8 screws (F) in bottom of
xture (A).
7. Follow steps on next page to complete installation.
To Attach to Wall (Figure 1 & 2)
CAUTION:FAILURE TO INSTALLTHIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONALINJURY OR DEATHAND
PROPERTY DAMAGE. We recommend installation by a licensed electrician. This product must be installed in accordance with
applicable installation code(s), by a person familiar with the construction and operation of the product and the hazards involved.*
Caution: Do not exceed maximum wattage noted on xture. Use only recommended bulbs with xture.
Please Note: After installation extra hardware and accessories are possible; our kits are used on multiple products.
CAUTION: BE SURE POWER IS OFF AT THE MAIN BREAKER BOX PRIOR TO INSTALLATION.
CAUTION: MAKE SURE WIRE CONNECTORS ARE
TWISTED ON SECURELY, AND NO BARE WIRES ARE
EXPOSED.
3 OF 4
E
(Figure 2)
D
C
B
A
MACHINE
SCREWS
G
F
(Figure 1)
F

MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM 42755
ASSEMBLY & INSTALLATION INSTRUCTIONS
Loft Outdoor Sconce: 302570, 302573, 302575
B394
BULB
H
I
K
J
A
(Figure 3)
To Install Glass (Figure 3)
If you need further assistance, or nd that you are missing any parts, please contact the dealer from which you
purchased this product. We hope you enjoy your xture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use
of this xture.
4 OF 4
1. Unpack glass (I).
2. Retaining ring (K) is shipped installed on socket (H). Remove retaining ring (K) from socket and set aside.
3. Slide glass (I) over socket (H).
4. Slip white washer (J) over socket (H) up to glass (I).
5. Thread retaining ring (K) onto socket (H) to hold glass (I).
6. Install bulb (not included) into socket (H).
7. Restore electricity at main breaker.
