ASSEMBLY & INSTALLATION INSTRUCTIONS
Banded Outdoor Sconce w/ Top Plate 305996 ,305997, 305998
B419
(Shown in Illustrations)
305996
305997
305998

MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM 44196
ASSEMBLY & INSTALLATION INSTRUCTIONS
Banded Outdoor Sconce w/ Top Plate 305996 ,305997, 305998
B419
Component Parts
A Fixture
B Crossbar
C Stud (2)
D Ground Screw
E Knurled Ball (2)
F Caulking Lip
G O-ring (2)
H Inner Glass
I Outer Glass
J Top Plate
K Thumb Screw (2)
2 OF 3

MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM 44196
ASSEMBLY & INSTALLATION INSTRUCTIONS
Banded Outdoor Sconce w/ Top Plate 305996 ,305997, 305998
B419
1. Carefully unpack the xture (A) from the carton.
2. Using two machine screws (not provided) attach crossbar (B) to the electrical box
(Figure 1).
Note: A new electric box comes with screws. When replacing a fixture, retain the
existing screws for use with the new fixture.
3. Thread the two studs (C) into the appropriate holes in the crossbar (D) to align
with xture. Adjust the studs to proper length to ensure the xture will t snugly to
the wall.
4. Using ground screw (D), secure a pigtail lead to the crossbar (B).
5. Hold the xture (A) close to the crossbar (B), using suitable wire connectors (not
provided), connect xture wires to supply wire (white to white and black to black).
Connect all ground wires (bare copper or green to bare copper or green).
6. Apply a generous bead of a suitable caulking material (not
provided) to caulking lip (F) on the xture. Caulk should
be applied around the entire perimeter of the
backplate (Figure 2).
7. Carefully tuck all wires behind xture and inside
the crossbar (B). Place xture rmly onto
crossbar and fasten with two knurled balls (E).
Note: Be sure no wires are pinched between
the wall and fixture, and studs are fully seated
in knurled balls.
8. Install bulb (not provided) into socket.
9. Place two o-rings (G) (found in kit bag) around
inner glass (H) (Figure 1). Slide inner glass (H)
over bulb into cup.
10. Place outer glass (I) over inner glass (H) until it
rests on stem.
11. Secure top plate (J) on top of outer glass (I)
using thumb screws (K).
12. Restore electricity at main breaker
To Install Fixture (Figures 1, 2)
CAUTION: FAILURE TO INSTALL THIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH
AND PROPERTY DAMAGE. We recommend installation by a licensed electrician. This product must be installed in accordance
with applicable installation code(s), by a person familiar with the construction and operation of the product and the hazards involved.*
Caution: Do not exceed maximum wattage noted on xture. Use only recommended bulbs with xture.
Please Note: After installation extra hardware and accessories are possible; our kits are used on multiple products and options.
CAUTION: BE SURE POWER IS OFF AT THE MAIN BREAKER BOX PRIOR TO INSTALLATION.
CAUTION: MAKE SURE WIRE CONNECTORS ARE TWISTED ON
SECURELY AND NO BARE WIRES ARE EXPOSED.
3 OF 3
F
F
F
F
(Figure 2)
(Figure 1)
I
H
G
B
MACHINE
SREWS
E
A
C
D
STEM
CUP
J
K
