Component Parts
Page 2 of 4
A Fixture
B Mounting Bracket
C Anchors (4)
D #10 Screws (4)
E Cupped Washer
F Ground Screw
G Caulking Lip
H #8 Screws (4)
I Rubber Washers (2)
J Glass
K Glass Bracket
L Nylon Tip Set Screw

40148
Assembly & Installation Instructions B380
Edge Outdoor Sconces 302560 & 302563
MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM
Page 3 of 4
H
I
CAUTION: FAILURE TO INSTALL THIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH AND
PROPERTY DAMAGE. We recommend installation by a licensed electrician. This product must be installed in accordance with
applicable installation code(s), by a person familiar with the construction and operation of the product and the hazards involved.*
Caution: Do not exceed maximum wattage noted on xture. Use only recommended bulbs with xture.
Please Note: After installation extra hardware and accessories are possible; our kits are used on multiple products.
To Install Glass (Figures 1 & 2)
1. Carefully unpack the xture and glass from the carton.
2. Glass (J) should be installed in xture (A) prior to installing
xture to the wall.
3. Slide glass (J) into xture (A) on an angle as seen in Figure 1.
Align and insert glass (J) into glass bracket (K).
4. Center glass (J) in xture (A) (Figure 2) and secure with nylon
tip set screw (L). Tighten until snug against glass.
5. Follow steps on follow page to install xture (A) to wall.
J
K
A
L
(Figure 1)
(Figure 2)
J
A
L

40148
Assembly & Installation Instructions B380
Edge Outdoor Sconces 302560 & 302563
MODERN AMERICAN BLACKSMITHS | FINE, HAND CRAFTED LIGHTING
CASTLETON, VERMONT USA | HUBBARDTONFORGE.COM
If you need further assistance, or nd that you are missing any parts, please contact the dealer from which you purchased
this product. We hope you enjoy your xture!
* Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this
xture.
Page 4 of 4
To Install Fixture (Figures 3 & 4)
1. Place the mounting bracket (B) over the electrical box
being sure to hold it level. Line up holes in
mounting bracket with holes in electrical box. With a
pencil, mark the location of all mounting holes in the
mounting bracket on the wall behind. Set bracket aside.
2. Drill 1/4" holes in the locations marked on the wall.
Place the tapered end of the anchors (C) into the holes
and gently tap them ush to the wall using a light
weight hammer.
3. Thread the wires in the electrical box through the hole
in the mounting bracket (B) while moving the plate into
position. Using two machine screws (not provided)
fasten the mounting bracket to the electric box.
Note: A new electric box comes with screws. When
replacing an existing xture, retain screws for use with
the new xture.
4. Using #10 screws (D), screw the mounting bracket (B)
securely to the wall. Be careful not to over-tighten or
strip the anchors (C).
5. Attach a pigtail lead to the mounting bracket (B) using
the cupped washer (E) and ground screw (F) found in kit
bag. See location in Figure 3.
6. Hold xture (A) close to wall. Using suitable wire
connectors (not provided), connect xture wires to
supply wires (white to white and black to black).
Connect all ground wires (bare copper or green to bare
copper or green).
7. Apply a generous bead of a suitable caulking material
(not provided) to caulking lip (G) on the xture. Caulk
should be applied around the entire perimeter of the
backplate (Figure 4).
8. Place xture (A) over mounting bracket (B) and screw
with #8 screws (H) and rubber washers (I) on top and
#8 screws on bottom. Be sure no wires are pinched
between xture and the wall.
9. Restore electricity at main breaker.
CAUTION: MAKE SURE WIRE CONNECTORS ARE
TWISTED ON SECURELY, AND NO BARE WIRES ARE
EXPOSED.
B
C
D
A
MACHINE
SCREWS
E
I
F
H
(Figure 3)
(Figure 3)
G
A
G
G
G
(Figure 4)
