Huion KAMVAS 22 Plus User manual

2
25
45
65
85
105
User Manual
Benutzerhandbuch
Manuel d' utilisateur
ユーザーマニュアル
Manuale d' uso
Manual de Usuario
GS2202
KAMVAS 22 Plus

GS2202
2
EN
Contents
1 / Precautions...................................................................................................................................3
2 / Product Overview .......................................................................................................................4
2.1 Display Introduction.................................................................................................................................4
2.2 Product and Accessories........................................................................................................................4
2.3 Setting Up Display ....................................................................................................................................8
2.4 Install Driver ................................................................................................................................................8
3 / Pen Basic Operation ...................................................................................................................9
3.1 Hold the Pen................................................................................................................................................9
3.2 Position the Cursor....................................................................................................................................9
3.3 Click............................................................................................................................................................. 10
3.4 Move............................................................................................................................................................ 10
3.5 Use the Side Buttons ............................................................................................................................. 10
3.6 Pen Nib Replacement ........................................................................................................................... 11
4 / OSD Buttons...............................................................................................................................11
5 / Function Setting....................................................................................................................... 12
5.1 Working Area Setting ............................................................................................................................ 12
5.2 Display Setting......................................................................................................................................... 14
5.3 Pen Buttons Function Setting............................................................................................................ 16
5.4 Enable the Windows Ink Feature...................................................................................................... 16
5.5 Pressure Sensitivity Setting................................................................................................................. 17
5.6 Pen Pressure Testing............................................................................................................................. 18
5.7 Pen Nib Activity Setting........................................................................................................................ 18
5.8 Data Export and Import ........................................................................................................................ 19
6 / Specifications............................................................................................................................20
7 / Trouble Shooting......................................................................................................................21
8 / After-service Contact ..............................................................................................................24

GS2202
3
EN
【Please read this manual carefully before using, and keep it well for future reference.】
/ Precautions
1
--Before cleaning the display, please unplug the USB cable and wipe with a soft damp cloth, do
not use any kind of detergents.
--Please don't place the display near water sources such as bathtub, washbasin, sinks, washing
machine, damp basement, swimming pool, etc.
--Do not place the display on where is unstable or a height for children reaching easily in order to
avoid danger.
--Do not place the display and digital pen close to the magnetic field.
--The grooves and holes on the back case is designed for ventilation to prevent the monitor from
overheating. Please don't place the display on beds, sofas, carpets or in embedded device.
--Only power supplies shown on the nameplate can be used for the display. If you have questions
about the power supply which you are using, please consult the distributor of your display.
--To protect your display, please switch off the power when it is not in use. During blackouts or not
using for long time, please unplug the display from the socket.
--Make sure no foreign bodies get inside the monitor through grooves and prevent liquid from
splashing on the display as to prevent short-circuit or fire.
--If the display has a breakdown, do not open the main case and try to repair it by yourself. Please
ask for a service for proper repair and maintenance.
--When the following situations occur, please unplug the power adapter and you may need a
service for full repair and maintenance:
A. The power wire or plug is damaged or worn out;
B. There is liquid splashed inside of the display;
C. The display has fallen or the LCD is broken;
D. When obvious abnormalities occur to the display.
--While getting the components replaced, you are supposed to guarantee that the repairman
is using the substitute components specified by the manufacturer. Unauthorized component
replacement might cause fire, electric shocks or other dangers.

GS2202
4
EN
/ Product Overview
2
2.1 Display Introduction
Thanks for choosing HUION®KAMVAS®22 Plus creative display. This is a new generation
of desktop-level professional drawing display, which can greatly improve your work
efficiency of painting and creation, and full of fun. You can freely paint and write, depicting
different lines and colors, just as the pen writes on the paper, which brings you a real shock
experience.
To give you a better understanding and using of your display, please read this user manual
carefully. The user manual only shows the information under Windows, unless otherwise
specified, this information applies to both Windows and Macintosh systems.
2.2 Product and Accessories

GS2202
5
EN
2.2.1 Accessories
2.2.2 Adjustable Stand
We designed this ergonomic adjustable stand specially for your KAMVAS display, you can
adjust the angle of the display according to your usage habit, and make you feel more
comfortable when painting and creating.
By dragging this switch to adjust the
stand angle from 20°-80°
Battery-free pen Replacement Nibs
(inside the pen holder)
Pen Holder
Quick Start Guide
Warranty Card
Power Adapter
Cleaning Cloth
Pen Nib Clip
(inside the pen holder)
3-in-1 Cable Power Cable USB-C Cable

GS2202
6
EN
2.3 Setting Up Display
[1] Take out the pen display and stand from the package, then assemble the stand
to the back of the display with attached screwdriver according to the following
instruction.
[2] Connect the pen display to your computer with 3-in-1 Cable or USB-C to USB-C
Cable.
1) Connect the display to your computer with 3-in-1 cable;
Connect the power adapter to the power cable.
Adjust the stand angle
by dragging this switch
Power Cable
Power Adapter
USB Cable
HDMI Cable

GS2202
7
EN
2) Connect the display to your computer with USB-C to USB-C cable;
Connect the power adapter to the power cable.

GS2202
8
EN
2.4.3 Driver Page
After the download is successful, double-click to open the driver, connect the display to
your computer with attached cables.
When the connection is complete, watch for a prompt at the bottom left of the driver
page that display two states "Device disconnected" or "Device connected".
Notes:
[1] Before installing, you need to uninstall other driver of similar products, including the
old driver of this product.
[2] Before installing, please close all graphics software and anti-virus software to avoid
unnecessary mistake.
2.4 Install Driver
2.4.1 OS Support
Windows 7 or later, macOS 10.12 or later.
2.4.2 Install Driver
Please download the driver from our website: www.huion.com/download
After finishing installation, you can find the driver icon " " in the system tray area, which
means the driver was installed successfully; when you connect the display to computer,
the icon will change to color " ", which means the driver has already recognized the
display and you can start using it now.

GS2202
9
EN
3
3.1 Hold the pen
Hold the pen as you hold a normal pen or pencil. Adjust your grip so that you can toggle
the side switch easily with your thumb or forefinger. Be careful not to accidentally press
the switch while drawing or positioning with the pen.
Notice:
When not in use, place the pen in the pen case or on the desk. Do not place the pen
on the surface of screen, which may interfere with the use of other screen cursor
positioning equipment, may also cause your computer can not enter the sleep mode.
3.2 Position the cursor
Move the pen slightly above the active area without touching the screen surface, the
cursor will move to the new position accordingly.
Press the pen tip on the screen to make a selection. Tap the screen once with the pen
tip, or touch it to the screen with enough pressure to register a click.
/ Pen Basic Operation

GS2202
10
EN
3.3 Click
Use the pen tip to tap once on the screen to register a click. Tap to highlight or
select an item on the screen and double-click to open it.
3.4 Move
Select the object, then slide the pen tip across the screen to move it.
3.5 Use the side buttons
The buttons on the pen can be set to two different customizable functions.
You can use the buttons whenever the pen tip is within 10mm of the display active area.
You do not have to touch the pen tip to the display in order to use the switch.

GS2202
11
EN
3.6 Pen Nib Replacement
The nib will be worn off after using for a long time, then you need to replace a
new nib.
[1] Anticlockwise rotate the pen holder to open the cover, take a new nib out.
[2] Insert the pen nib into the pen nib clip and tilt the pen to pull out the old nib.
[3] Insert the new nib straight into the pen and push the nib slowly and firmly
until it stops.
4/ OSD Buttons
OSD Buttons
: Power on/off the display.
: Press to call up the menu, after entering menu, its function is "confirm".
: After entering menu, its function is "to up/right/increase".
: After entering menu, its function is "to down/left/decrease".
: Before entering menu, its function is "auto adjustment". After entering menu, its
function is "back to previous menu".

GS2202
12
EN
5/ Function Setting
5.1 Working Area Setting
5.1.1 Using Multiple Monitors
Select the Working Area tab to define the relationship between pen movement on the
display and cursor movement on the monitor screen.
By default the entire active area of display maps to the entire monitor. If more than one
monitor is in use and you are in extended mode, you need to choose the related monitor
on the driver interface which you are going to map to.
If your monitors are in mirror mode (All monitors display the same content), the display
maps to the entire space on each monitor and the screen cursor is displayed on each
monitor simultaneously.
5.1.2 Working Area Setting
Define the display area that will be mapped to the screen area.
[1] Full Area: the entire active area of the display. This is the default setting.
[2] Screen Ratio: As a general rule, be 16:9.
[3] Customized Area:
1> Enter coordinate values.
2> Drag the corners of the foreground graphic to select the screen area.

GS2202
13
EN
5.1.3 Rotate Working Area
By changing the direction of the display to adapt to the left and right hand operation. You
can rotate the display by 0°, 90°, 180° or 270°.
①
②
③

GS2202
14
EN
5.2 Display Setting
Click the " " in the upper right corner of the driver to set the Display, including General
settings, Hotkeys and Updates.
5.2.1 General settings
Add App: Shortcut key function can be set by adding different programs.
When opening different programs, the driver will automatically recognize that the shortcut
function is the corresponding function set.

GS2202
15
EN
5.2.2 Hotkeys settings
Set the shortcut key to quickly open the driver interface. The default value is Ctrl+Alt+H,
which can be set according to usage habits.
5.2.3 Updates
You can view the driver version number, click "Check for Update", view the latest
driver version, and update according to the system prompt.

GS2202
16
EN
5.3 Pen Buttons Function Setting
Select the function to be achieved on the pop-up dialog box, then click "Apply" or "OK" to
take effect.
5.4 Enable the Windows Ink Feature
Microsoft Windows provides extensive support for pen input. Pen features are supported
in such as Microsoft Office, Windows Journal, Adobe Photoshop CC, SketchBook 6 and so
on.

GS2202
17
EN
5.5 Pressure Sensitivity Setting
The pressure sensitivity will be changed by dragging the slider up and down, the smaller
the value, the more pressure sensitive.
Drag upward (left): the pressure change is more obvious, small pressure produces a great
pressure.
Drag down (right): pressure change is weak, a lot of pressure produces less pressure.
Click the button at the bottom right of the Settings box to reset the pressure
sensitivity to the default state.
For example: apply *N respectively the same pressure, under different pressure coefficient
produced different pressure effects. According to their habit of holding the pen posture
and the size of the hand for the appropriate pressure Settings.
Same press*N
Pressure 1
Same press*N
Pressure 2
*N *N
Press Sensitivity Adjustment Press Sensitivity Adjustment

GS2202
18
EN
5.6 Pen Pressure Testing
You can gradually apply pressure to the stylus on the screen to test the pressure level.
Click " " button to clear all the ink.
5.7 Pen Nib Activity Setting
The pen nibs can be set to be Active/Inactive as needed.Click the drop-down option to
select, and click OK again to save the Settings. In Active mode, the digital pen can be used
normally. In Inactive mode, the digital pen has cursor movement, but cannot complete the
specified action.

GS2202
19
EN
5.8 Data Export and Import
The driver supports exporting and importing your custom configuration data of the
product, which is convenient for you to use different software and avoid the trouble of
repeated settings.

GS2202
20
EN
/ Specifications
6
Model GS2202
Screen
Panel Size 21.5 inches
Resolution 1920 x 1080 (16:9)
LCD Type IPS
Active Area 476.64 x 268.11mm
Contrast Ratio 1200:1
Brightness 220cd/m2
Response Time 14ms
View Angle 89°/89° (H) /89°/89° (V) (Typ.) (CR ＞10)
Gamut 140% sRGB
Display Color 16.7M (8bit)
Touch
Touch Type Battery-Free Electromagnetic Resonance
Resolution 5080LPI
Pressure Level 8192
Accuracy ±0.5 mm (Center), ±3 mm (Corner)
Sensing Height 10mm
Pen
Model PW517
Dimension 163.7 x Φ14.3 mm
Buttons Two Customized Press Key
General
Output Voltage 12V 3A
Video Interface 3-in-1 USB-C and USB-C to USB-C
Dimension 546.06 x 323.07 x 19.1~26.7mm (Without Stand)
Net Weight 3.9kg (With stand)
OS Support Windows 7 or later, mac OS 10.12 or later
