human care Diana II MLA User manual

Service manual / Servicemanual / Servicehandbuch /
Servicehandleiding
Diana II MLA 90555

2www.humancaregroup.com
Content Innehåll
InhoudInhalt
ENGLISH
DEUTSCH
SVENSKA
NEDERLANDS
Service Manual 3
Compliances and Standards 4
Useful informaon 4
Service manual descripon 5
Tools & Maintenance 5
Troubleshoong & Solving 7
Spare parts list 10
Servicemanual 11
Eerlevnad och standarder 12
Användbar informaon 12
Beskrivning av servicemanual 13
Verktyg och underhåll 13
Felsökning och lösning 15
Reservdelslista 18
Servicehandbuch 19
Konformität und Standards 20
Nützliche Informaonen 20
Beschreibung des Servicehandbuchs 21
Werkzeuge & Wartung 21
Fehlersuche und -behebung 23
Ersatzteilliste 27
Servicehandleiding 28
Nalevingen en normen 29
Nuge informae 29
Beschrijving van de service handleiding 30
Gereedschappen & Onderhoud 30
Probleemoplossing 32
Reserveonderdelenlijst 36

www.humancaregroup.com 3
ENGLISH
Symbols
WARNING symbol indicates a poten-
ally hazardous situaon which, if not
avoided, could result in serious injury
to the user or damage to property
and/or the device itself.
INFORMATION symbol indicates
recommendaons and informaon for
proper, trouble-free usage.
WEIGHT CAPACITY symbol indicates
maximum user weight for the product.
Do not exceed this weight in any
circumstance.
CE MARKING symbol indicates product
meets requirements of EU Direcve
93/42/EEC (MDD) and/or EU
Regulaon 2017/745 (MDR).
RECYCLE according to local regulaons.
MEDICAL DEVICE symbol indicates
that the product is a medical device
according to the denion of
medical device in EU Direcve 93/42/
EEC (MDD) and/or EU Regulaon
2017/745 (MDR).
READ INSTRUCTIONS and ensure you
fully understand them before using
this product.
Important!
You must read the user manual for your device prior to usage. Keep this
booklet and informaon handy for future use.
Product modicaon is not permied.
Before use, always check that the product
is not damaged or worn.
Human Care’s products are connuously
being developed and updated to provide our
customers with the highest quality. We reserve
the right to make design changes without prior
noce.
Always make sure that you have the most
recent version of the manual which is available
for downloading from our website at
www.humancaregroup.com.
Contact your local distributor if you have any
quesons about the product and its use.
Service Manual

4www.humancaregroup.com
Diana II MLA Service Manual
Human Care is an ISO 13485:2016 cered
Swedish medical device company. The Quality
Management System is in compliance with US
21 CFR part 820.
The product is CE marked in accordance with EU
Direcve 93/42/EEC (MDD) and/or EU Regula-
on 2017/745 (MDR), as class I medical device.
The CE mark is on the product.
This product has been tested in accordance
with ISO 10535.
Compliances and Standards
Useful informaon
a) Service manual
The service manual is created for technicians
involved in servicing of Diana II MLA mobile li.
Safe performance of mobile li service proce-
dures requires experience, technical skills and
general knowledge of safety rules.
This manual uses warnings and cauons to pay
special aenon to service procedures.
Warning – this informaon tells us about the
possibility of safety risk of technician
and user.
Cauon – this informaon tells us about acons
that can cause potenal damage of the
li.
b) Diana II MLA installaon and operang
For installaon and operaon of the li, see the
user manual.
c) Service of Diana II MLA mobile li
The service can be only made by Human Care’s
authorized service team or authorized units by
Human Care.
Human Care shall bear no responsibility for the
consequences of repairs or modicaons that
have been done by unauthorized personnel and
for the use of non-original replacement parts
dedicated by Human Care for mobile li.
d) Service documentaon
Service documentaon and service repair
document are available on a website accessible
for authorized service.
e) Safety precauons
Mobile li design provides maximum of safety
Safety of the device are ensured by safety stan-
dards IEC60601-1.
Read these cauons carefully before
start servicing!
Note - do not perform service repairs
and funconal tesng when the client is
on the device.
f) Addional informaon
In case of any problems with mobile li contact
the intermediary or manufacturer’s service.
Service contact details:
HUMAN CARE SWEDEN (HQ)
Årstaängsvägen 21B
117 43 Stockholm
Phone: [phone]
Fax: [phone]
Email: [e-mail]

www.humancaregroup.com 5
ENGLISH
Service manual descripon
Tools & Maintenance
Service manual contains informaon about
repairing, maintaining and idencaon of
Paent Li. The li can be idened by using
the idencaon code which is placed on the
name plate.
Note – if the plug from baery charger
does not match a socket in your country,
you can use an adapter.
3.1 Tools
Standard set of tools is required for servicing of
mobile li:
Allen key set Ordinary set of various keys
Flat screwdriver
Hammer Volt meter

6www.humancaregroup.com
Diana II MLA Service Manual
Device maintaining
All movable joints must be lubricated every six
months or when experiencing squeaks or other
noise. These nodes are:
• axle transport wheels,
• axle actuator mounng,
• jib arm bearing sleeve.
We recommend using any available penetrang
lubricants.
Report all loose connecons that are supposed
to be xed to the manufacturer’s authorized
service agent and stop using the product unl
the problem is resolved.
This device is equipped with electric actuator
which allows to adjust the height of the jib
arm. In order to ensure proper performance of
the actuators check the actuators for unusual
sounds every 3 months. These unusual sounds
contain rales, squeaks, creaks. Any perceived
performance deciency must be reported to
Human Care technical service immediately cea-
sing device operaon unl remove their causes.
Not less frequently than every 1 years and aer
each failure/repair of actuator technical service
must check the li for electric safety.
The minimal range of the review should include:
• check if there were no mechanical wiring
damages of the device,
• check if there were no mechanical damages
of the controller and the actuators.
See checklist in user manual.
Basic periodic review
One year aer producon date or every 8000
cycles of using the li, the indicator lamp light
up.
If this LED is on, operator must check condion
of the li (cables connecons, looseness on the
frame etc.).
Press and hold “up” and “down” buon for 5
sec., to turn o the light aer review.
Transport wheels
Actuator mounng
Jib arm bearing sleeve
LED indicator

www.humancaregroup.com 7
ENGLISH
Troubleshoong
Symptom Possible cause - soluon
Device doesn’t work properly. Diagnose the mobile li.
Height adjustment doesn’t work. Replace main actuator.
Spreading legs emits sounds. Lubricaon legs spread mechanism.
Problem with moving device. Check/replace castors.
Troubleshoong & Solving
Diagnose the mobile li
In case of problems with height adjustment
please complete the following steps:
Step 1:
• Check the baery level on the hand control.
If any led is lighng, please check the baery
with the voltmeter,
• If the baery is empty, please charge it,
• If aer a few hours the baery is sll empty,
please check if the charger is working cor-
rectly by using the voltmeter. If the charger
is ok, you have to replace the baery for a
new one.
Step 2:
If the baery level is correct, check that the
wires are connected properly to the control box
in the boom part of the device.
Step 3:
If everything looks good so far but device sll
doesn’t work, for further diagnose, spare parts
will be necessary (hand control, control box and
actuator).
• At rst, replace the hand control for new
one (or switch with another device if it’s
possible) and check.
• Next, prepare a new control box and connect
it with slots from device,
• Now test what is wrong, control box, hand
control or actuator.
Checking voltage on baery
Checking voltage on charger
Checking wires connecon

8www.humancaregroup.com
Diana II MLA Service Manual
Step 4:
To remove the control box, just loosen two
main screws and li up whole holder with the
control box.
Replace main actuator
Step 1:
Remove the coer from upper side and take
out the safety pin. Do the same operaon for
boom side of actuator.
Loosening two screws Removing main holder
1. Removing coer 2. Removing safety pin
3. View aer removal 4. Removing coer
5. Removing safety pin 6. View aer removal

www.humancaregroup.com 9
ENGLISH
Step 2:
Remove old and install the new actuator in the
reverse order to dismounng, carefully ghten
the gland.
Lubricaon of boom leg mechanism
Cauon - Following procedures require
turn down device on aside. To protect
it from any damage or scratches we
strongly recommend to prepare some
kind of protecon (card boards, spong-
es, etc.) on the oor.
Step 1:
Remove the boom metal cover. Use the pedals
for localize noises.
Step 2:
Lubricate with oil, or another lubricant moving
part.
Sponges under device
Removing the screws Internal view
Lubricang moving parts

10 www.humancaregroup.com
Diana II MLA Service Manual
Wheel replacement
To replace the rear wheels, use the allen and
17” key. To replace front wheels use 17” socked
wrench.
Rear wheels replacement Front wheels replacement
Spare parts list
INDEX Price list for DIANA II MLA
04-N0101-0012 LINAK Baery BAJ
04-N0107-0047 LINAK one funcon hand control HB3X
04-N0109-0040 LINAK CBJ-CARE control box
04-N0301-0072 LINAK main actuator LA34
04-N0901-0043 LINAK control box holder + screw M5x8
04-N0901-0094 LINAK safety ring for micro-t wire
04-N0901-0113 LINAK spiral cable 200mm LA34
04-N0901-0018 LINAK external charger
04-N30901-0123 EU LINAK power supply cord
04-M42010-0059 TENTE wheel set with brakes D100 gray
04-M2010-0047 TENTE wheel set D75 gray
04-E4027-0002 Velcro bandage 150x10mm
04-M0505-0077 Rectangular Cap 50x40 black
04-M0505-0113 Rectangular Sliding End Cap 40x20x6 Black
04-M3015-0014 Self-adhesive bumper D8 x1.5
04-M0501-0024 Round, at D10 PE white cap
04-M3001-0078 Tubular coer pin 10x60
04-M0507-0007 Gray cover for the foot lever
04-M1503-0124 Flanged plain bearing 8x10x6.5
04-M1503-0126 Plain bearing 8x10x6
02-SLU-1561 Safety locks hanger bar 2P
