Human Touch iJoy-100 Replacing the Power Panel
Initiator: MG Replaces: NA Revision date: 09/03/2003
Title: Replacement of the iJoy 100 Side Power Panel and AC Cord
Purpose: To provide end users with the procedure for replacement of the iJoy-100 Side Panel – this
replaces the AC Cord and On/Off Switch.
Tools/Parts Required: Phillips Screwdriver, diagonal cutters
Requires Side Panel Unit with ON/OFF power switch/ AC cord
Procedure:
1) Turn off and unplug your iJoy
2) As an option, you can carefully tip your unit onto its Right Side (the side opposite the
AC cord). This will make it easier to access the assembly and side cover.
3) Locate The Side Panel Assembly. This is the plate that both the AC cord and
remote cord enter. This assembly also incorporates the ON/OFF switch.
4) You will need to either remove the SN/Model information label from the Side Panel
Assembly, or locate the single screw hole covered by the label. You can find the
hole by feeling the sticker for a depression. Using the Phillips Screwdriver, gently
poke a hole to access the screw. See photo for screw location.
5) Remove all Three (3) screws securing the Side Panel Assembly to the chair frame.
6) Carefully lower the Side Panel Assembly. Caution: The Side Panel Assembly
remains connected via cables to the chair.
7) Locate the white 11-pin plug attaching the Remote Control to the Chair. Carefully
disconnect.
8) Disconnect the Red/Violet plug attaching the AC Power to the unit.
9) Remove the screw attaching the Green (Ground) wire to the frame.
10) Locate the four (4) screws securing the Remote Cable Clamp. Remove the four
screws, noting the position of the clamp and the Remote Cable Strain Relief.
11) Slide the Controller Cable out of its holder. Note orientation of holder and remote
cable.
12) Install NEW Side Panel
13) Slide the Remote Cable Clamp back into position. Ensure the tab on the cable
clamp aligns with the insert slot in the cable/cable strain relief.
14) Reinsert the four (4) screws removed in step 8.
15) Reconnect Remote Connector Plug
16) Reconnect AC Power Plug
17) Reattach Green Ground Wire
18) Reinstall the side panel assembly with the three screws removed in step 5.
19) Plug the iJoy back into the wall outlet, and turn the Main Power Switch on.
20) Test the chair for proper operation.

Human Touch Confidential Page 2
Title: Replacement of the iJoy 100 Remote with Cable
PCB
Module
Remote Cord
AC Cord
Access to Screws
* Screw on right may be under product information label
Side Panel Detail
Four screws securing
Cable Clamp to Cover
Remote Control
Cable Connecto
r
*
Slide out clamp to remove
Controller and Cable
AC Cable
Connecto
r
Ground
W
ire
